Rohm Shield-EVK-001 User manual

1/2
© 2018 ROHM Co., Ltd.
No. 60UG058E Rev001
Apr.2018
User’s Guide
Sensor Evaluation Board
Shield-EVK-001 Manual
Shield-EVK-001 is a Shield, which connects Arduino and ROHM Sensor Boards. Shield-EVK-001 will be refered to as “SensorShield” on this manual.
This User’s Guide is about how to use SensorShield.
Board Information
Connection Board between Arduino and ROHM Sensor
Board (Figure 1, 2)
Size: 88mm x 63mm
Five I2C Sensors, One I/O Sensor and Two Analog
Sensors can be controlled
5V-3.0/1.8V Level Shifter
GPIO : FAIRCHILD FXMA108
I2C : NXP PCA9306
I2C pull-up register is implemented
Figure 1. SensorShield (Top)
Figure 2. SensorShield (Bottom)
Preparation
Arduino Uno 1pc
Personal Computer installed Arduino IDE 1pc
Requirement : Arduino 1.6.7 or higher
Please use Arduino IDE which can be
downloaded from the link below:
http://www.arduino.cc/
USB cable for connecting Arduino and PC 1pc
SensorShield 1pc
ROHM Sensor Board, which is not attached 1pc
Setting
1. Connect the SensorShield to the Arduino (Figure 3)
Figure 3. Connection between the Arduino and the
SensorShield
2. Check the connection type of ROHM Sensor Board and
connect it to the corresponding type on the SensorShield
(Figure 4)
USB connecter
SensorShield

2/2
User’s Guide
Shield-EVK-001 Manual
© 2018 ROHM Co., Ltd.
No. 60UG058E Rev001
Apr.2018
3. Set voltage of the SensorShield to the corresponding
supply voltage range of each ROHM Sensor Board. (Figure
4)
Figure 4. Voltage settings and Connection of the Sensors
4. Connect the Arduino to the PC using a USB cable
Software Setting and Measurement
1. Download the program of ROHM Sensor Board from the
link below:
http://www.rohm.com/web/global/sensor-shield-support
2. In regards to the measurement procedure of each sensor
board, refer to the manual of ROHM Sensor Board.
