Rohnson RS-1060 User manual

EU Declaration of Conformity
Manufacturer:
Name: Shenzhen hutianmei technology co.,ltd
Address: 32 building, The third industrial park, houting, shajing, Baoan district ,
shenzhen city,
China
Model No.: RS-1030, RS-1040, RS-1060
Description: Speaker
Radio-related Software Version: BT5.0
We, Shenzhen hutianmei technology co.,ltd., declare under our sole responsibility
that the
product described above is in conformity with the relevant Union Harmonization
Legislations:
RE Directive (2014/53/EU), RoHS Directive (EU) 2015/863
The following harmonized standards and/or other relevant standards have been
applied:
1. Health and Safety (Article 3.1(a) of the RE Directive)
■EN62479:2010
■EN62638-1:2014+A11:2017
2. Electromagnetic compatibility (Article 3.1(b) of the RE Directive 2014/53EU
(EMCD))
■EN301 489-1 V2.1.1(2017-02)
■EN301 489-17 V3.1.1(2017-02)
3. Radio frequency spectrum usage (Article 3.2 of the RE Directive)
■EN300 328 V2.2.2(2019-07)
4. RoHS Directive (EU) 2015/863
■IEC 62321-3-1:2013
■IEC62321-4:2013+A1:2017
■IEC62321-5:2013
■IEC63321-6:2015
■IEC62321-7-1:2015
■IEC62321-7-2:2017

■IEC62321-8:2017
The object of the declaration described above is in conformity with the following
relevant
Union harmonization legislation(s):
Radio Equipment Directive (RED)2014/53/EU
Low Voltage Directive (LVD) 2014/53/EU
Electromagnetic Compatibility (EMC) 2014/53/EU
Restriction of the use of certain hazardous substances (Rohs)2015/863/EU
The notified body (Name: SHENZHEN YARUI TESTING CO.,LTD) performed the
conformity
assessment according to Annex II of the RE Directive and issued the EU-type
examination
certificate (Ref. No.: YRT202010261C)
Signed for and on behalf of Shenzhen hutianmei technology co.,ltd
Name: Ivy zhan
Position: Sales Manager
Date:30/11/2020
Place: Shenzen, China
Signature:

RS-1060
60WHigh Power Subwoofer
Parameter
Model RS-1060 F.R 80Hz~18KHz
BT version 5.0 Distortion ≤1%
BT range ≥18 M（Open field）Speaker unit φ66MM
Speaker power 60W Play time ≥10-12 H
Battery 3.7V/6600mAh Charging time ≤3.5H
Input power Type-C 5V/2.1A Product Size 220*95*72MM
Accessories
A U X c able Type-C cable
Key Function
1.Status Indicator
2.Sound effect indicator
3.Play / Pause / Answer / Hang up
4.Volume down / Previous track
5.Volume up / Next track Phone 6.Phone assistant wake up
7.Power on / off
8.Sound effect/mode switching
9.Microphone
10.Type-C charging / Audio port
11.TF card
12.AUX in

BUTTON
OPERATING
FUNCTION DESCRIPTION
Short press
1. In the off state, short press to turn on
2. In the on state, short press to turn off
Double click
In the state of Bluetooth to be connected, Double-click to
enter TWS pairing mode.
Short press
Play mode switching: Bluetooth, AUX/Type-C cable, TF
card
Long press
Sound switching: pop, vocal, heavy bass
Short press
1. Musicplaybackstatus:play,pausefunction
2. Callstatus:shortpresstoconnect
3. When thecallisanswered,shortpresstohangup
4. When thephone'sBluetoothisconnected:
Double-click quicklytocallbackthelastcall made by
thephone
Long press
1.Bluetooth connection status: Long press for 2S to
disconnect
2. When there is an incoming call: Long press for 2S to
reject
Short press
Volume down, total 16 levels
Long press
Previous track
Short press
Volume up, total 16 levels
Long press
next track
Short press
Bluetooth connection status: short press to wake up
phone voice assistant
Long
press
1. Bluetooth connection status: long press for 2s to
disconnect and forget the bluetooth device
2. Press and hold for 5s to reset the device

LED indicatorndicatorsTAATUS
LED Indicator
Status Indicator
(Above the “ ”key)
a. The blue light flashes qucikly when bluetooth
is ready to pair; the blue light is always on when
bluetooth is connected
b. When the AUX/TF card is playing, the blue
light flashes slowly; When the Type-C cable is
playing, the red and purple lights flash
alternately
Sound effect Indicator
(Above the “ ”key)
a. Press and hold for 2s to switch sound effects;
b. A white light is on: pop
Two white lights: Vocal
Three white lights on: Heavy bass
TF / Cable playback
1. Bluetooth speaker supports reading up to 64GB TF card
Supports music format:APE/FLAC/WAV/MP3
2. Insert the TF card into the card slot and automatically play the audio file after recognition
3. AUX, Type-C cable can be inserted into the device to play; If it is connected with bluetooth, press the “M”key to switch to the
audio cable playback mode.
TWS pairing
1. Power on the two speakers (if a bluetooth device is connected, you must first disconnect the Bluetooth connection)
2. Double click one of the “” keys to enter TWS pairing mode.
3. After the TWS is successfully paired, there will be a beep. At this time, the yellow indicators of the two speakers are on.
4. Turn on the Bluetooth function of the mobile phone or other bluetooth device, find and connect the bluetooth named “X8”
5. TWS paired successfully, the machine will automatically perform TWS pairing each time after turning on the machine, no need to
repeat the operation.
6. If the machine has been paired with TWS, please press and hold 5s “” key to reset; After the reset is successful, restart the
machine, and then refre to 1~4 above to complete the TWS pairing.
7. In TWS mode, only the main speaker has hands-free function, and the sub speaker is silent during a call.
8. In TWS mode, you can still switch sound effects

Radio equipment
The frequency bands on which the radio is operating are 2.4 GHz and the maximum
radiotelephone power is 5 dBm Max.
EN : SIMPLIFIED EU DECLARATION OF CONFORMITY Hereby, Shenzhen
Hutianmei Technology Co LTD declares that the radio equipment type RS-1060 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of
conformity is available at the following internet address: www.vassilias.gr
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE PRODUCT IN
ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban waste.
It must be taken to a special local authority differentiated waste collection centre or to
a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health, deriving form inappropriate disposal
and enables the constituent materials to be recovered to obtain significant savings in
energy and resources. As a reminder of the need to dispose of household appliances
separately, the product is marked with a crossed-out wheeled dustbin.
