Roland CY-6 User manual

Edge Portion
Pad Face
Output Jack
Bow Portion
Contents of the Package
❑PD-6 (pad unit)
❑Connection Cable (monaural)
■Owner's Manual (this manual)
Stand Fixing Screw
Stand Fixing Screw
Head
Output Jack
Holder
Holder
Contents of the Package
❑CY-6 (cymbal pad unit)
❑Connection Cable (stereo)
❑Wing Nut
❑Felt Washer
❑Stopper
■Owner's Manual (this manual)
Before using CY-6/PD-6, you need to make the settings for
the percussion sound module (p. 7).
Owner's Manual
Thank you and congratulations on your choice of the Roland Cymbal Pad CY-6/Pad PD-6.
02564567 ’01-6-F3-21N
Copyright © 2001 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any
form without the written permission of ROLAND CORPORATION.
Before using this unit,
carefully read the
sections entitled:
“USING THE UNIT
SAFELY” (p. 2–3) and
“IMPORTANT NOTES”
(p. 3). These sections
provide important
information concerning
the proper operation of
the unit. Additionally, in
order to feel assured
that you have gained a
good grasp of every
feature provided by
your new unit, Owner’s
manual should be read
in its entirety. The
manual should be
saved and kept on
hand as a convenient
reference.

2
USING THE UNIT SAFELY
001
• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.
................................................................................................
002a
• Do not open or perform any internal
modifications on the unit.
................................................................................................
003
• Do not attempt to repair the unit, or replace
parts within it (except when this manual
provides specific instructions directing you
to do so). Refer all servicing to your retailer,
the nearest Roland Service Center, or an
authorized Roland distributor, as listed on
the “Information” page.
................................................................................................
004
• Never use or store the unit in places that are:
• Subject to temperature extremes (e.g.,
direct sunlight in an enclosed vehicle, near
a heating duct, on top of heat-generating
equipment); or are
• Damp (e.g., baths, washrooms, on wet
floors); or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
................................................................................................
005
• This unit should be used only with a rack or
stand that is recommended by Roland.
................................................................................................
006
• When using the unit with a rack or stand
recommended by Roland, the rack or stand
must be carefully placed so it is level and
sure to remain stable. If not using a rack or
stand, you still need to make sure that any
location you choose for placing the unit
provides a level surface that will properly
support the unit, and keep it from wobbling.
................................................................................................
011
• Do not allow any objects (e.g., flammable
material, coins, pins); or liquids of any kind
(water, soft drinks, etc.) to penetrate the unit.
................................................................................................
013
• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for
the safe operation of the unit.
................................................................................................
014
• Protect the unit from strong impact.
(Do not drop it!)
................................................................................................
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ●symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.

3
IMPORTANT NOTES
291a
In addition to the items listed under “USING THE UNIT SAFELY” on page 2–3, please read and observe the
following:
Placement
354a
•Do not expose the unit to direct sunlight, place it
near devices that radiate heat, leave it inside an
enclosed vehicle, or otherwise subject it to
temperature extremes. Excessive heat can deform or
discolor the unit.
355
•To avoid possible breakdown, do not use the unit in
a wet area, such as an area exposed to rain or other
moisture.
356
•Do not allow rubber, vinyl, or similar materials to
remain on the piano for long periods of time. Such
objects can discolor or otherwise harmfully affect
the finish.
357
•Do not put anything that contains water (e.g.,
flower vases) on the piano. Also, avoid the use of
insecticides, perfumes, alcohol, nail polish, spray
cans, etc., near the unit. Swiftly wipe away any
liquid that spills on the unit using a dry, soft cloth.
Maintenance
401a
•For everyday cleaning wipe the unit with a soft, dry
cloth or one that has been slightly dampened with
water. To remove stubborn dirt, use a cloth
impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly
with a soft, dry cloth.
402
•Never use benzine, thinners, alcohol or solvents of
any kind, to avoid the possibility of discoloration
and/or deformation.
Additional Precautions
553
•Use a reasonable amount of care when using the
unit’s buttons, sliders, or other controls; and when
using its jacks and connectors. Rough handling can
lead to malfunctions.
558d
•This instrument is designed to minimize the
extraneous sounds produced when it’s played.
However, since sound vibrations can be transmitted
through floors and walls to a greater degree than
expected, take care not to allow these sounds to
become a nuisance to neighbors, especially when
performing at night and when using headphones.
104
•Try to prevent cords and cables from
becoming entangled. Also, all cords and
cables should be placed so they are out of the
reach of children.
................................................................................................
106
•Never climb on top of, nor place heavy
objects on the unit.
................................................................................................
118
•Should you remove wing nut (for CY-6),
washers (for CY-6), or stand fixing screw (for
PD-6) make sure to put them in a safe place
out of children's reach, so there is no chance
of them being swallowed accidentally.
................................................................................................

4
CY-6
Features
• Velocity sensitive cymbal pad provides rich
expression.
• Designed specially for cymbals, the pad offers
superior playing feel. Even the movement caused by
playing is simulated.
• You can use bow shots, edge shots, and choking
techniques.
• Compatible with all Roland percussion sound
modules (p. 7).
Making the Settings
Attaching the Cymbal Pad to a Stand
Attach the CY-6 to a separately sold cymbal mount (MDY
series).
1. Use a commercially available tuning key to
tighten the stopper bolt.
The stopper keeps the cymbal pad from turning, and
preventsthecablesfromcatchingorgettingtangledonthe
stand.
2. Attach the CY-6 so the unit is oriented as
shown in the diagram.
3. Tighten the wing nut to obtain the desired
movement.
Use the included felt washer and the wing nut.
Connecting to a Percussion Sound
Module (TD-6, TD-8, TD-10, etc.)
To prevent malfunction and/or damage to speakers or other
devices, always turn down the volume, and turn off the power
on all devices before making any connections.
1. Use the included connection cable and connect
the output jack of the CY-6 to the trigger input
jack of the percussion sound module.
Connect the L-shaped plug of the included cable to the
CY-6. This will prevent strain from being applied to the
CY-6.
To make use of edge shot and choking play techniques,
you'll need to connect to a trigger input jack on the
percussion sound module that accommodates rim shots.
2. Make the trigger settings for the percussion
sound module. For the recommended values,
refer to p. 7.
Should you neglect to make the appropriate settings for
the percussion sound module, you could likely experience
the following problems:
•Sometimes it does not sound (uneven volume)
•The volume is too low (reduced sensitivity)
For information on how to change the parameters for a
percussion sound module, refer to the documentation for
the percussion sound module you're using.
Stopper
(Be sure to
orient it correctly)
Tighten the bolt with
the included tuning key.
Wing Nut
Felt Washer

5
CY-6
Playing the CY-6
Bow Shot
This is the most common playing method, playing the pad face
of the cymbal. It corresponds to the sound of the “head-side”of
the connected trigger input.
Edge Shot
This playing method involves striking the edge with the
shoulder of the stick. It corresponds to the sound of the “rim-
side”of the connected trigger input.
To make use of edge shot, you'll need to connect to a trigger
input jack on the percussion sound module that
accommodates rim shots.
Choking
Choking (pinching) the cymbal's edge with the hand
immediately after hitting the cymbal makes the sound stop.
To make use of choking play techniques, you'll need to
connect to a trigger input jack on the percussion sound
module that accommodates rim shots.
Specifications
CY-6: Cymbal Pad
Pad Size: 12 inches
Triggers: 2 (Bow, Edge)
Dimensions: 290 (W) x 295 (D) x 45 (H) mm
11-7/16 (W) x 11-5/8 (D) x 1-13/16 (H) inches
Weight: 0.6 kg / 1 lb 6 oz
Accessories: Owner's Manual, Connection Cable, Wing Nut,
Felt Washer, Stopper
Options: Cymbal Mounts (MDY-10U)
Drum Stands (MDS-6, MDS-7U, MDS-8, MDS-10)
In the interest of product improvement, the specifications
and/or appearance of this unit are subject to change without
prior notice.
Bow
Edge

6
PD-6
Features
•Velocity sensitive pad provides rich expression.
•Compact, 8.5-inch pad allows for greater versatility
when setting up.
•Compatible with all Roland percussion sound
modules (p. 7).
•When used with a percussion sound module capable
of positional sensing, you can obtain tonal changes
by varying the location at which the pad is struck.
For details on positional sensing, refer to the documentation
for the percussion sound module you’re using.
Making the Settings
Attaching the Cymbal Pad to a Stand
Attach the PD-6 to a separately sold drum stand (MDS-6, MDS-
7U, MDS-8, or MDS-10).
When attaching the PD-6 to the pad mount, be sure to tighten
the stand fixing screw securely. If any of them remain loose,
the pad could fall off.
When attaching the PD-6 to a commercially available tom
stand, check the dimensions of the rod. Depending on the
dimensions of the rod, it may not be possible to attach the pad
to the stand.
Acceptable rod diameters: 8.5–11.5 (3/8 to 1/2 inch)
Connecting to a Percussion Sound
Module (TD-6, TD-8, TD-10, etc.)
To prevent malfunction and/or damage to speakers or other
devices, always turn down the volume, and turn off the power
on all devices before making any connections.
1. Use the included connection cable and connect
the output jack of the PD-6 to the trigger input
jack of the percussion sound module.
Connect the L-shaped plug of the included cable to the
PD-6. This will prevent strain from being applied to the
PD-6.
2. Make the trigger settings for the percussion
sound module. For the recommended values,
refer to p. 7.
Should you neglect to make the appropriate settings for
the percussion sound module, you could likely experience
the following problems:
•Sometimes it does not sound (uneven volume)
•The volume is too low (reduced sensitivity)
For information on how to change the parameters for a
percussion sound module, refer to the documentation for
the percussion sound module you're using.
Specifications
PD-6: Pad
Pad Size: 8.5 inches
Trigger: 1 (Head)
Dimensions: 221 (W) x 274 (D) x 64 (H) mm
8-3/4 (W) x 10-13/16 x 2-9/16 (H) inches
Weight: 1.2 kg / 2 lbs 11 oz
Accessories: Owner's Manual, Connection Cable
Options: Pad Mounts (MDH-10U)
Drum Stands (MDS-6, MDS-7U, MDS-8, MDS-10)
In the interest of product improvement, the specifications
and/or appearance of this unit are subject to change without
prior notice.
Tighten
Loosen
Rod
Pass the rod through the pipe that is inside the holder.
