Roland V-Drums KD-120 User manual

Before using this unit, carefully read the sections entitled: “USING THE
UNIT SAFELY” (p. 2–3) and “IMPORTANT NOTES” (p. 3). These sections
provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every
feature provided by your new unit, Owner‘s manual should be read in its
entirety. The manual should be saved and kept on hand as a convenient
reference.
CONTENTS
Features.....................................................................................................................4
Contents of the Package.........................................................................................4
Names of the KD-120 Components .....................................................................4
Setup.........................................................................................................................5
Connecting to the Sound Module ........................................................................7
Head Adjustment....................................................................................................8
Head Replacement..................................................................................................9
Specifications.........................................................................................................10
Copyright © 1998 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form
without the written permission of ROLAND CORPORATION.
®
OWNER’S MANUAL
We’d like to take a moment to thank you for purchasing the Roland KD-120.
* 5 1 0 0 0 4 3 0 0 8 - 0 6 *

2
001
• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.
..........................................................................................................
002b
• Do not open or perform any internal modifica-
tions on the unit. (The only exception would be
where this manual provides specific instructions
which should be followed in order to put in place
user-installable options; see p. 5.)
..........................................................................................................
003
• Do not attempt to repair the unit, or replace parts
within it (except when this manual provides
specific instructions directing you to do so). Refer
all servicing to your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the “Information” page.
..........................................................................................................
004
• Never use or store the unit in places that are:
• Subject to temperature extremes (e.g., direct
sunlight in an enclosed vehicle, near a
heating duct, on top of heat-generating
equipment); or are
• Damp (e.g., baths, washrooms, on wet
floors); or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
..........................................................................................................
007
• Make sure you always have the unit placed so it is
level and sure to remain stable. Never place it on
stands that could wobble, or on inclined surfaces.
..........................................................................................................
011
• Do not allow any objects (e.g., flammable material,
coins, pins); or liquids of any kind (water, soft
drinks, etc.) to penetrate the unit.
..........................................................................................................
013
• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for the
safe operation of the unit.
..........................................................................................................
014
• Protect the unit from strong impact.
(Do not drop it!)
..........................................................................................................
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
The ●symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power-
cord plug must be unplugged from the outlet.
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.
KD-120_e.book 2 ページ ２００７年８月１日 水曜日 午前９時４９分

3
104
• Try to prevent cords and cables from becoming
entangled. Also, all cords and cables should be
placed so they are out of the reach of children.
..........................................................................................................
106
• Never climb on top of, nor place heavy objects on
the unit.
..........................................................................................................
IMPORTANT NOTES
In addition to the items listed under “USING THE UNIT SAFELY” on page 2–3, please read and
observe the following:
Placement
•Do not expose the unit to direct sunlight, place it near devices that radiate heat, leave it inside an
enclosed vehicle, or otherwise subject it to temperature extremes. Excessive heat can deform or
discolor the unit.
Maintenance
•For everyday cleaning wipe the unit with a soft, dry cloth or one that has been slightly dampened
with water. To remove stubborn dirt, use a cloth impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly with a soft, dry cloth.
•Never use benzine, thinners, alcohol or solvents of any kind, to avoid the possibility of discoloration
and/or deformation.
Additional Precautions
•Use a reasonable amount of care when using the unit’s buttons, sliders, or other controls; and when
using its jacks and connectors. Rough handling can lead to malfunctions.
•When connecting / disconnecting all cables, grasp the connector itself—never pull on the cable.
This way you will avoid causing shorts, or damage to the cable’s internal elements.
558a
•To avoid disturbing your neighbors, try to keep the unit's volume at reasonable levels. You may
prefer to use headphones, so you do not need to be concerned about those around you (especially
when it is late at night).
558d
•This instrument is designed to minimize the extraneous sounds produced when it's played.
However, since sound vibrations can be transmitted through floors and walls to a greater degree
than expected, take care not to allow these sounds to become a nuisance to neighbors, especially
when performing at night and when using headphones.
KD-120_e.book 3 ページ ２００７年８月１日 水曜日 午前９時４９分

4
Features
•Kick trigger pad with net material on head for superior playing feel, and quiet response.
•The four-leg stand assures outstanding stability.
•You can also play using a double kick pedal.
Contents of the Package
This package does not include a kick pedal. Use with a commercially available kick pedal installed
on the KD-120.
Names of the KD-120 Components
KD-120 Pad
Stand
Leg x 2
Beater
Connection Cable
Owner’s Manual (this manual)
Due to the nature of the materials used in the sensor, changes in room temperature and humid
may affect the sensitivity of the sensor.
KD-120_e.book 4 ページ ２００７年８月１日 水曜日 午前９時４９分
Drum key
Lug
Bracket
Plate
Leg
T-bolt
Hoop Sensor
Cushion
Tuningbolt
Head
Outputjack
Shell
Rubberfoot

5
Setup
Assembling the KD-120
1.
Place the KD-120 pad, with the head surface facing downward, on a flat surface such as the
floor.
2.
Use the included drum key to loosen and remove the bolts for the brackets on the back of
the KD-120 pad.
3.
Mount the stand on the brackets so that the output jack for the KD-120 pad faces up.
Use the bolts you removed earlier to secure the KD-120 pad to the stand, tightening the
bolts with the included drum key.
* Take care not to pinch your fingers between the KD-120 pad and the stand plate.
4. Adjust the ends of the legs to match the location where you’re installing the KD-120.
Adjust to use the spike legs when installing on carpeting or other soft surfaces, or the
rubber legs when installing on flooring or other hard surfaces.
When shipped from the factory, the stand is adjusted for using the rubber legs. If you’re
using the rubber legs, proceed to step 5 on the next page.
Switching to the spike leg
1. Slightly loosen the foot bolt.
2. Move the rubber foot all the way upward, and then tighten
the bolt.
The spike will protrude from the rubber foot.
* The tip of the spike is sharp. Handle it with care.
Change to the rubber foot.
* When using on flooring, the spike may damage the floor.
Switching to the rubber leg
1. Slightly loosen the foot bolt.
2. Move the rubber foot all the way downward, and then tighten
the bolt.
KD-120_e.book 5 ページ ２００７年８月１日 水曜日 午前９時４９分
Output jack
Bracket
Rubber foot
Bolt
Bolt
Spike
Rubber foot

6
5.
Loosen the T-bolts for the stand and mount the legs on the stand.
Install the legs as shown in the figure so that the ends of the legs protrude by about 2 cm.
6.
Tighten the T-bolts to secure the legs to the stand.
7.
Lift the KD-120 and place the stand and the four legs upright.
8.
Adjust the angle of the head surface so that it’s at a right angle to the floor.
Use the included drum key to loosen the bracket bolts you tightened in step 3, and adjust
the angle of the KD-120 pad so that the head surface is at a right angle to the floor.
9.
Install the included beater on your kick pedal.
* Using a beater made of felt may result in wear to the felt. Use the special included beater or a plastic beater
as the beater for the kick pedal.
10.
Mount the kick pedal on the KD-120.
* With certain kick pedals, the chain (or belt) may come into contact with the hoop surrounding the KD-120’s
pad. If this occurs, adjust the angle of the KD-120’s pad to prevent such contact. Keep the adjustment within
a range that does not allow the KD-120’s pad hoop to touch the plate of the stand.
11.
Make any fine adjustments necessary and tighten the stand brackets to make sure the KD-
120 is secure on the stand.
Make sure the KD-120’s four legs and heel portion of the kick pedal is securely on the floor
by loosening the stand’s T-bolts and adjusting the length of the legs.
* If the kick pedal has no under-plate, then arrange the stand’s plate section at a right angle to the floor.
12.
Adjust the striking point for the beater.
Normally the beater’s striking point is adjusted to fall at the center of the head.
Adjust the striking point so that it doesn’t extend beyond the cushion on the back of the
head. Moving the striking point closer to the sensor increases the sensitivity, so carry out
fine adjustment to suit your preferences.
Allow sufficient
clearance
here.
Prevent contact
between the
hoop and plate.
If the kick pedal has no under-plate, then arrange
the stand’s plate section at a right angle to the floor.
90˚
KD-120_e.book 6 ページ ２００７年８月１日 水曜日 午前９時４９分
Extend the leg by about 2 cm.
T-bolt

7
When Using a Double Kick Pedal
With the KD-120, you can also play using a double kick pedal.
Set this up so that the striking points of the two beaters fall at equal distances to the left
and right of the center of the head.
fig.13.e
* When using a double kick pedal, as with a regular pedal, use the included beater
or a plastic beater as the beater for the kick pedal.
Connecting to the Sound Module
Connecting the KD-120 to a sound module.
To prevent malfunction and/or damage to speakers or other devices, always turn down the
volume, and turn off the power on all devices before making any connections.
•Make sure that KD-120 does not touch the drum stand or the other pads.
•The appropriate Trigger Type settings need to be made for the percussion sound
module.
For instructions on making the settings, read the Owner’s Manual for the relevant
sound module.
KD-120_e.book 7 ページ ２００７年８月１日 水曜日 午前９時４９分

8
Head Adjustment
The head tension of the KD-120 can be adjusted.
Adjusting the Head Tension
When adjusting, use the included drum key or the drum key for your acoustic drums.
In general, a tension that produces a strike response approximately the same as an
acoustic bass drum will be appropriate.
* Head tension that is too loose may not only cause incorrect operation, but may even damage the
sensor.
fig.14.e
1.
Check the current tension of the head.
2.
Remove the kick pedal from the KD-120.
3. Adjust bolt ‘a’ in the above diagram. Rotate it clockwise to tighten the head tension, or
slightly counterclockwise to loosen the tension.
* Fully tightening a tuning bolt at only a single location produces uneven tensioning, which may
make it impossible to obtain the proper strike sensitivity and may even result in incorrect
operation. Be sure to tighten each tuning bolt a little at a time, as described in the above
explanation.
4.
Adjust bolt ‘b’ so that the tension is the same as the tension of ‘a’.
5. Next adjust ‘c’ and ‘d’, and ‘e’ and ‘f’ in the same way.
6.
Make sure that the head tension is even, and repeat steps 5 and 6 if you wish to make
further adjustments.
* On the KD-120, adjusting the head tension affects only the head response, and does not change
the pitch of the sound as it would on an acoustic drum. To adjust the pitch, edit the sound
parameters of the TD-20 or TD-12. For details refer to the respective owner’s manual.
* The head tension will change as the instrument is used, so you should readjust when necessary.
7.
Mount the kick pedal on the KD-120.
ac
db
ef
HEAD MADE BY REMO U.S.A.
KD-120_e.book 8 ページ ２００７年８月１日 水曜日 午前９時４９分

9
Head Replacement
When the head should be replaced
The head is an expendable item that eventually will wear out and need to be replaced.
Replace the head when the following occurs:
To replace a head, contact your dealer or Roland service center.
•The head surface is torn
•Slack portions remain in the head even when the head tension is properly adjusted.
Replacing the Head
When replacing the head, use the included drum key or the drum key for your acoustic drums.
* Do not apply excessive force to the sensor and cushion located under the head. Doing so can
interfere with accurate detection, and may damage it.
fig.14.e
1. Remove all tuning bolts from the KD-120. Go around and gradually loosen each one in
order (by turning it counterclockwise).
2.
Remove the hoop.
3.
Remove the old head.
4. Place the new head on the shell.
5.
Place the hoop onto the head.
6.
First lightly tighten bolt ‘a’ in the above diagram by rotating it clockwise. Then tighten bolt ‘b’
to about the same force.
7. Now lightly tighten ‘c’, and then ‘d’. Tighten ‘e’ and ‘f’ in the same way.
8.
Next adjust the tension of the head. Refer to “Adjusting the Head Tension” above.
* Fully tightening a tuning bolt at only a single location produces uneven tensioning, which may make
it impossible to obtain the proper strike sensitivity and may even result in incorrect operation. Be sure
to tighten each tuning bolt a little at a time, as described in the above explanation.
Specifications
Pad Size: 12 inches
Dimensions: 490 (W) x 400 (D) x 500 (H) mm
19-5/16 (W) x 15-3/4 (D) x 19-11/16 (H) inches
Weight: 6.8 kg / 15 lbs
Accessories: Owner’s Manual, Connection Cable, Beater, Drum Key
* In the interest of product improvement, the specifications and/or appearance of this unit are
subject to change without prior notice.
a c
d b
ef
HEAD MADE BY REMO U.S.A.
KD-120_e.book 9 ページ ２００７年８月１日 水曜日 午前９時４９分

10
KD-120_e.book 10 ページ ２００７年８月１日 水曜日 午前９時４９分
Information When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your
country as shown below.
AFRICA
REUNION
MARCEL FO-YAM Sarl
25 Rue Jules Hermann,
Chaudron - BP79 97 491
Ste Clotilde Cedex,
REUNION ISLAND
TEL: [phone]
SOUTH AFRICA
Paul Bothner(PTY)Ltd.
Royal Cape Park, Unit 24
Londonderry Road, Ottery 7800
Cape Town, SOUTH AFRICA
TEL: [phone]
ASIA
CHINA
Roland Shanghai Electronics
Co.,Ltd.
5F. No.1500 Pingliang Road,
Yangpu Shanghai 200090, CHINA
TEL: [phone]
Toll Free: 4007-888-010
Roland Shanghai Electronics
Co.,Ltd. (BEIJING OFFICE)
3F, Soluxe Fortune Building
63 West Dawang Road,
Chaoyang Beijing, CHINA
TEL: [phone]
Toll Free: 4007-888-010
HONG KONG
Tom Lee Music
11/F Silvercord Tower 1
30 Canton Rd
Tsimshatsui, Kowloon,
HONG KONG
TEL: [phone]
Parsons Music Ltd.
8th Floor, Railway Plaza, 39
Chatham Road South, T.S.T,
Kowloon, HONG KONG
TEL: [phone]
INDIA
Rivera Digitec (India) Pvt. Ltd.
411, Nirman Kendra Mahalaxmi
Moses Road, Mumbai-400011,
INDIA
TEL: [phone]
INDONESIA
PT. Citra Intirama
Ruko Garden Shopping Arcade
Unit 8 CR, Podomoro City
Jl.Letjend. S.Parman Kav.28
Jakarta Barat 11470, INDONESIA
TEL: [phone]
KAZAKHSTAN
Alatau Dybystary
050000 Almaty, KAZAKHSTAN
TEL: [phone]
FAX: [phone]
KOREA
Cosmos Corporation
27, Banpo-daero, Seocho-gu,
Seoul, KOREA
TEL: [phone]
MALAYSIA/SINGAPORE
45-1, Block C2, Jalan PJU 1/39,
Dataran Prima, 47301 Petaling
Jaya, Selangor, MALAYSIA
TEL: [phone]
PHILIPPINES
G.A. Yupangco & Co. Inc.
339 Gil J. Puyat Avenue
Makati, Metro Manila 1200,
PHILIPPINES
TEL: [phone]
TAIWAN
ROLAND TAIWAN ENTERPRISE
CO., LTD.
9F-5, No. 112 Chung Shan
North Road Sec. 2 Taipei 104,
TAIWAN R.O.C.
TEL: [phone]
THAILAND
Theera Music Co. , Ltd.
100-108 Soi Verng
Nakornkasem, New Road,
Sumpantawong, Bangkok
10100, THAILAND
TEL: [phone]
VIET NAM
VIET THUONG CORPORATION
386 CACH MANG THANG TAM ST.
DIST.3, HO CHI MINH CITY,
VIET NAM
TEL: [phone]
OCEANIA
AUSTRALIA/
NEW ZEALAND
Roland Corporation
Australia Pty.,Ltd.
38 Campbell Avenue, Dee Why
West. NSW 2099, AUSTRALIA
For Australia
TEL: [phone]
For New Zealand
TEL: [phone]
CENTRAL/LATIN
AMERICA
ARGENTINA
Instrumentos Musicales S.A.
Av.Santa Fe 2055
(1123) Buenos Aires, ARGENTINA
TEL: [phone]
BARBADOS
A&B Music Supplies LTD
12 Webster Industrial Park
Wildey, St.Michael, BARBADOS
TEL: [phone]
BRAZIL
Roland Brasil Ltda.
Rua San Jose, 211
Parque Industrial San Jose
Cotia - Sao Paulo - SP, BRAZIL
TEL: [phone]
CHILE
Comercial Fancy II S.A.
Rut.: 96.919.420-1
Nataniel Cox #739, 4th Floor
Santiago - Centro, CHILE
TEL: [phone]
COLOMBIA
CENTRO MUSICAL S.A.S.
Parque Industrial del Norte
Bodega 130
GIRARDOTA - ANTIOQUIA,
COLOMBIA
TEL: [phone] EXT 115
COSTA RICA
JUAN Bansbach Instrumentos
Musicales
Ave.1. Calle 11, Apartado 10237,
San Jose, COSTA RICA
TEL: [phone]
CURACAO
Zeelandia Music Center Inc.
Orionweg 30
Curacao, Netherland Antilles
TEL: [phone]
DOMINICAN REPUBLIC
Instrumentos Fernando Giraldez
Calle Roberto Pastoriza #325
Sanchez Naco Santo Domingo,
DOMINICAN REPUBLIC
TEL: [phone]
ECUADOR
Mas Musika
Rumichaca 822 y Zaruma
Guayaquil - ECUADOR
TEL: [phone]
EL SALVADOR
OMNI MUSIC
75 Avenida Norte y Final Alameda
San Salvador, EL SALVADOR
TEL: [phone]
GUATEMALA
Casa Instrumental
Calzada Roosevelt 34-01,zona
11 Ciudad de Guatemala,
GUATEMALA
TEL: [phone]
HONDURAS
Almacen Pajaro Azul S.A. de C.V.
BO.Paz Barahona
3 Ave.11 Calle S.O
San Pedro Sula, HONDURAS
TEL: [phone]
MARTINIQUE
Musique & Son
Z.I.Les Mangle
97232 Le Lamentin,
MARTINIQUE F.W.I.
TEL: [phone]
MEXICO
Casa Veerkamp, s.a. de c.v.
Av. Toluca No. 323, Col. Olivar
de los Padres 01780 Mexico D.F.,
MEXICO
TEL: [phone]
Faly Music
Sucursal Capu Blvd. Norte N.3213
Col. Nueva Aurora Cp.72070
Puebla, Puebla, MEXICO
TEL: [phone] o 97
FAX: [phone]
Gama Music S.A. de C.V.
Madero Pte. 810 Colonia Centro
C.P. 64000 Monterrey, Nuevo
León, MEXICO
TEL: [phone] o 8372-4097
www.gamamusic.com
Proscenia
Morelos No. 2273
Col. Arcos Sur
C.P. 44120 Guadalajara, Jalisco,
MEXICO
TEL: [phone]
NICARAGUA
Bansbach Instrumentos
Musicales Nicaragua
Altamira D'Este Calle Principal
de la Farmacia 5ta.Avenida
1 Cuadra al Lago.#503
Managua, NICARAGUA
TEL: [phone]
PANAMA
SUPRO MUNDIAL, S.A.
Boulevard Andrews, Albrook,
Panama City, REP. DE PANAMA
TEL: [phone]
PARAGUAY
WORLD MUSIC
Jebai Center 2018, Centro
CIUDAD DE ESTE, PARAGUAY
TEL: [phone]
PERU
AUDIONET DISTRIBUCIONES
MUSICALES SAC
Jr. Ramon Dagnino N°201- Jesús
María
DISTRITO DE JESUS MARIA
LIMA, PERU
TEL: [phone]
TRINIDAD
AMR Ltd
Ground Floor
Maritime Plaza
Barataria TRINIDAD W.I.
TEL: [phone]
URUGUAY
Todo Musica S.A.
Francisco Acuna de Figueroa
1771
C.P.: 11.800
Montevideo, URUGUAY
TEL: [phone]
VENEZUELA
Instrumentos Musicales
Allegro,C.A.
Av.las industrias edf.Guitar
import
#7 zona Industrial de
Turumo Caracas, VENEZUELA
TEL: [phone]
EUROPE
BELGIUM/FRANCE/
HOLLAND/
LUXEMBOURG
Roland Central Europe N.V.
Houtstraat 3, B-2260, Oevel
(Westerlo) BELGIUM
TEL: [phone]
BOSNIA AND
HERZEGOVINA
Mix-AP Music
78000 Banja Luka, Veselina
Maslese 3,
BOSNIA AND HERZEGOVINA
TEL: [phone]
CROATIA
ART-CENTAR
Degenova 3.
HR - 10000 Zagreb, CROATIA
TEL: [phone]
EUROMUSIC AGENCY
K. Racina 1/15
HR - 40000 CAKOVEC, CROATIA
Tel: [phone]
CZECH REPUBLIC
CZECH REPUBLIC
DISTRIBUTOR s.r.o
Pod Bání 8
180 00 Praha 8, CZECH REP.
TEL: [phone]
DENMARK/ESTONIA/
LATVIA/LITHUANIA
Roland Scandinavia A/S
Skagerrakvej 7, DK-2150
Nordhavn,DENMARK
TEL: [phone]
FINLAND
Roland Scandinavia As, Filial
Finland
Vanha Nurmijarventie 62
01670 Vantaa, FINLAND
TEL: [phone]
GERMANY/AUSTRIA
ROLAND Germany GmbH.
Adam-Opel-Strasse 4, 64569
Nauheim, GERMANY
TEL: [phone]
GREECE/CYPRUS
STOLLAS S.A.
Music Sound Light
155, New National Road
Patras 26442, GREECE
TEL: [phone]
HUNGARY
Roland East Europe Ltd.
2045.Törökbálint, FSD Park 3. ép.,
HUNGARY
TEL: [phone]
IRELAND
Roland Ireland
E2 Calmount Park, Calmount
Avenue, Dublin 12,
Republic of IRELAND
TEL: [phone]
ITALY
Roland Italy S. p. A.
Viale delle Industrie 8,
20020 Arese, Milano, ITALY
TEL: [phone]
MACEDONIA
MK MJUZIK
Bratstvo Edinstvo 9
2208 Lozovo, MACEDONIA
TEL: [phone]
MONTENEGRO
MAX-AP
P. Fah 92
Przno, Kamenovo bb
86000 Budva, MONTENEGRO
TEL: [phone]
NORWAY
Roland Scandinavia Avd.
Kontor Norge
Lilleakerveien 2 Postboks 95
Lilleaker N-0216 Oslo,
NORWAY
TEL: [phone]
POLAND
ROLAND POLSKA SP. Z O.O.
ul. Katy Grodziskie 16B
03-289 Warszawa, POLAND
TEL: [phone]
PORTUGAL
Roland Iberia SL.
Edifício Tower Plaza
Rotunda Eng. Edgar Cardoso 23,
4-B
4400-676 Vila Nova de Gaia,
PORTUGAL
TEL: [phone]
ROMANIA
Pro Music Concept SRL
440221 Satu Mare
B-dul Independentei nr. 14/a.,
ROMANIA
TEL: [phone]
RUSSIA
Roland Music LLC
Dorozhnaya ul.3,korp.6
117 545 Moscow, RUSSIA
TEL: [phone]
SERBIA
Music AP
Sutjeska br. 5 XS - 24413 PALIC,
SERBIA
TEL: [phone]
SLOVAKIA
DAN Distribution, s.r.o.
Povazská 18.
SK - 940 01 Nové Zámky,
SLOVAKIA
TEL: [phone]
SPAIN
Roland Systems Group EMEA, S.L.
Paseo García Faria, 33-35
08005 Barcelona, SPAIN
TEL: [phone]
SWEDEN
Roland Scandinavia A/S
SWEDISH SALES OFFICE
Mårbackagatan 31, 4 tr.
SE-123 43 Farsta, SWEDEN
TEL: [phone]
SWITZERLAND
Roland (Switzerland) AG
Landstrasse 5, Postfach,
CH-4452 Itingen, SWITZERLAND
TEL: [phone]
TURKEY
ZUHAL DIS TICARET A.S.
Galip Dede Cad. No.33
Beyoglu, Istanbul, TURKEY
TEL: [phone]
UKRAINE
EURHYTHMICS Ltd.
P.O.Box: 37-a.
Nedecey Str. 30
UA - 89600 Mukachevo,
UKRAINE
TEL: [phone]
UNITED KINGDOM
Roland (U.K.) Ltd.
Atlantic Close, SWANSEA SA7
9FJ, UNITED KINGDOM
TEL: [phone]
MIDDLE EAST
BAHRAIN
Moon Stores
No.1231&1249 Rumaytha
Building Road 3931,
Manama 339, BAHRAIN
TEL: [phone]
EGYPT
9, EBN Hagar Al Askalany Street,
ARD E1 Golf, Heliopolis,
Cairo 11341, EGYPT
TEL: [phone]
IRAN
MOCO INC.
Jadeh Makhsous Karaj (K-9),
Nakhe Zarin Ave.
Jalal Street, Reza Alley No.4
Tehran 1389716791, IRAN
TEL: [phone]
ISRAEL
Halilit P. Greenspoon &
Sons Ltd.
8 Retzif Ha'alia Hashnia St.
Tel-Aviv-Yafo ISRAEL
TEL: [phone]
JORDAN
MUSIC HOUSE CO. LTD.
FREDDY FOR MUSIC
P. O. Box 922846
Amman 11192, JORDAN
TEL: [phone]
KUWAIT
EASA HUSAIN AL-YOUSIFI &
SONS CO.
P.O.Box 126 (Safat) 13002,
KUWAIT
TEL: [phone]
LEBANON
Chahine S.A.L.
George Zeidan St., Chahine Bldg.,
Beirut, LEBANON
TEL: [phone]
OMAN
TALENTZ CENTRE L.L.C.
Malatan House No.1
Al Noor Street, Ruwi
SULTANATE OF OMAN
TEL: [phone]
QATAR
AL-EMADI TRADING &
CONTRACTING CO.
P.O. Box 62, Doha, QATAR
TEL: [phone]
SAUDI ARABIA
Adawliah Universal
Electronics APL
Behind Pizza Inn
Prince Turkey Street
Adawliah Building,
PO BOX 2154,
Al Khobar 31952,
SAUDI ARABIA
TEL: [phone]
SYRIA
Technical Light & Sound Center
PO Box 13520 Bldg No.49
Khaled Abn Alwalid St.
Damascus, SYRIA
TEL: [phone]
U.A.E.
Adawliah Universal
Electronics APL
round about, nayef area, deira,
Dubai, U.A.E.
TEL: [phone]
NORTH AMERICA
CANADA
Roland Canada Ltd.
5480 Parkwood Way Richmond
B. C., V6V 2M4, CANADA
TEL: [phone]
Roland Canada Ltd.
170 Admiral Boulevard
Mississauga On L5T 2N6,
CANADA
TEL: [phone]
U. S. A.
Roland Corporation U.S.
5100 S. Eastern Avenue
Los Angeles, CA 90040-2938,
U. S. A.
TEL: [phone]
As of Nov. 1, 2013 (ROLAND)
