thomann Millenium MPS-750X User manual

MPS-750X
e-drum set
assembly instructions

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
17.01.2020, ID: 454015

Table of contents
1 Safety instructions.......................................................................................................................................................................................................... 4
2 Scope of delivery.............................................................................................................................................................................................................. 5
3 Assembly.............................................................................................................................................................................................................................. 7
4 Protecting the environment.................................................................................................................................................................................... 18
Table of contents
MPS-750X
3

1 Safety instructions
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children.
Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke!
Never let children unattended use electrical devices.
NOTICE!
Possible staining
The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum,
laminate or PVC oor and after some time cause permanent dark stains.
In case of doubt, do not put the rubber feet directly on the oor, but use felt-pad oor protectors or a carpet.
Safety instructions
e-drum set
4

2 Scope of delivery
Before you assemble your drum set, make sure the contents of package is complete according to the following list and gure.
Item Qty.
1 2 Lateral support tube left and right
2 2 Support tube for left and right crossbeams
3 1 Lower horizontal connection tube
4 1 Crossbeam for the Snare
5 2 Crossbeams left and right
6 1 Upper horizontal connection tube
7 2 Cymbal bracket (Crash and Ride)
8 2 Connection for the cymbal holder (Crash and Ride)
9 4 Sleeve for mounting bracket / mounting rod for the pads
10 1 Mounting bracket for the pads
11 3 Mounting rod for the pads
12 1 Hi-hat pad (10 inch)
13 1 Crash (12", two zones, with stop function)
14 1 Ride (14", three zones, with stop function)
15 3 Tom pad (10", two zones, mesh head)
16 1 Snare pad (10", two zones, mesh head)
17 1 Bass drum pad (8" mesh head)
18 1 Bass drum pad pedal
19 1 Hi-hat tripod with pedal
20 1 Hi-hat bracket
21 1 e-drum module Millenium MPS-750X
22 1 Multiple cable for connecting the pads, cymbals and pedals to the e-drum module
23 1 Drum key
24 1 Set of drum sticks
25 1 User manual e-drum module
Scope of delivery
MPS-750X
5

Item Qty.
26 1 Assembly instructions e-drum set
27 1 Plug-in power supply
Scope of delivery
e-drum set
6

3 Assembly
Overview
Loosen the screws of the clamps before sticking the tubes together. Mount the various elements in the specied sequence. The
nal positions of the components are shown in the illustration below.
12 Hi-hat pad (10 inch)
13 Crash (12", two zones, with stop function)
14 Ride (14", three zones, with stop function)
15 Tom pad (10", two zones, mesh head)
16 Snare pad (10", two zones, mesh head)
17 Bass drum pad (8" mesh head)
18 Bass drum pad pedal
19 Hi-hat tripod with pedal
Assembly
MPS-750X
7

Assembling the rack
CAUTION!
Danger of cuts on hands and ngers
When connecting the parts, take care for sharp edges on the metal tubes, screws etc.
1. Attach the clamp (4a) of the snare crossbeam (4) to one of the two lateral support tubes (1).
2. Then tighten the wing nut of the clamp (4a).
Assembly
e-drum set
8

1. Fasten the two lateral support tubes (1) in the fastening clamps of the horizontal connecting tube (3).
2. Then tighten the wing nuts of the fastening clamps.
1. Attach the crossbeam for the snare (4) to the left support tube (1).
2. Then tighten the wing nut of the fastening clamps.
Assembly
MPS-750X
9

1. Attach the two crossbeams (5) to the two lateral support tubes (1).
2. Then tighten the wing nuts of the fastening clamps.
1. Fasten the two support tubes for the crossbeams (2) in the fastening clamps of the crossbeams (5).
2. Then tighten the wing nuts of the fastening clamps.
Assembly
e-drum set
10

1. Fasten the two lateral support tubes (1) in the fastening clamps of the horizontal connecting tube (6).
2. Then tighten the wing nuts of the fastening clamps.
Assembly
MPS-750X
11

1. Attach the two connections for the cymbal holder (8) and the cymbal holder (7) to the two lateral support tubes (1).
2. Then tighten the wing nuts of the fastening clamps.
Assembly
e-drum set
12

1. Attach the sleeve for the mounting bracket (9) and the mounting bracket (10) in the bracket for the snare on the crossbeam
(4).
2. Then attach the sleeves for the mounting rods (9) and the mounting rods (11) in the holders for the tom pads on the right
crossbeam (5) and on the horizontal connecting tube (6).
3. Then tighten the wing nuts of the brackets.
Assembly
MPS-750X
13

Mounting tom pads on the rack
1. Attach the tom pads (15) to the mounting rods (9) and tighten the wing nuts of the tom pads hand-tight.
2. Align the pads on the rack to meet your needs, then tighten the wing nuts of the brackets and the wing nuts of the tom
pads evenly.
Mounting cymbals on the rack
1. Unscrew the wing nuts from the cymbal holders (7) and take the felt washers o the holders.
2. Place the cymbals (13, 14) as shown in the gure on the holders. Be sure to attach the crash pad (12") to the left holder and
the ride pad (14") to the right cymbal holder.
3. Place the felt washers on the cymbals (13, 14) and x the cymbals with the associated wing nuts on the holders.
Assembly
e-drum set
14

Mounting the Hi-hat on the rack
1. Screw on the wing nuts of the hi-hat tripod with pedal (19) and open the feet. Then tighten the wing nuts of the brackets.
2. Insert the hi-hat holder (20) into the hi-hat tripod with pedal (19) and tighten the holder clockwise.
3. Unscrew the wing nuts from the Hi-hat holder (20) and take the felt washers o the holders.
4. Place the Hi-hat (12) as shown in the gure on the holder.
5. Place the felt washers on the cymbals and x the Hi-hat (12) with the associated wing nut on the holder.
Assembly
MPS-750X
15

Setting up the bass drum pedal
1. Screw the bass drum pad and the associated foot (17) with the supplied screws using the drum key (23).
2. Engage the bolt of the foot machine (18) into the provided recess on the bass drum pad (17).
Mounting the drum module on the rack
1. Put the drum module (21) up to the stop into the free bracket of the left crossbeam (5). Insert the D-sub plug of the multiple
cable (22) into the provided socket on the bottom side of the drum module.
2. Tighten the D-sub plug with the hand screws.
3. Align the module and tighten the wing nut of the bracket.
Bass Drum positioning
Place the pedal with the bass drum pad centred under the rack. Position the bass drum pedal centred in front of the pad.
Assembly
e-drum set
16

Set-up and cabling
Set up the rack, the pads and the cymbals according to your needs. Finally, position the pedal with the bass drum pad in front of
the rack and connect all trigger cables to the e-drum module.
The skin tension of the mesh heads is relatively low in the delivery state in order to avoid damage during transport. For good playa‐
bility and better trigger behaviour, adjust the skin tension to your playing habits.
Assembly
MPS-750X
17

4 Protecting the environment
Disposal of the packaging material
For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal
recycling.
Ensure that plastic bags, packaging, etc. are properly disposed of.
Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling.
Please follow the notes and markings on the packaging.
Disposal of your old device
This product is subject to the European Waste Electrical and Electronic Equipment Directive (WEEE) in its currently valid version.
Do not dispose with your normal household waste.
Dispose of this device through an approved waste disposal rm or through your local waste facility. When discarding the device,
comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility.
Protecting the environment
e-drum set
18

Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de
