Roland MVS-12 User manual

Multi-Viewer with Simple Matrix Switcher
for Convenient Video Monitoring

PC
LAN
Multi-Viewer Display
PGM OUT
Monitor 1 to 8
Multi-Viewer Display
PGM, PVW
MIDI
IN
MIDI
OUT
LVS-800
Camera 1 IN 1
Camera 2 IN 2
Camera 3 IN 3
Camera 4 IN 4
Camera 5 IN 5
Camera 6 IN 6
PC 1
PC 1
PC 2
PC 2
IN 1 IN 3 IN 4
IN 5
PVW
(IN 2)
PGM OUT
(PC2)
IN 6 PC1
MVS-12
Video Mix/Live Switcher
MULTI OUT
RGB/HDMI
IN 2
PC2
MULTI OUT
RGB/HDMI
IN 1 IN 2 IN 3
IN 4 IN 5 IN 6
Camera DVD
Player
Camera (Stage) IN 1
Camera (Stage) IN 2
Camera (Stage) IN 3
Camera IN 7
DVD Player IN 8
Video Player IN 9
Projector
Confidence Monitor
Video Recording
Back Stage
1234
MATRIX OUT
OUT 1
OUT 3
OUT 2
OUT 4
MVS-12
Matrix Output
Display
Multi-Viewer Display
PREVIEW
MULTI OUT
RGB/HDMI
Video
Player
Inputs
MATRIX OUT1 PGM
OUT
V-1600HD
SD
push
select
Multi-format Video Switcher
SD IN
MIDI OUT
Multi-Viewer Display
MIDI IN
MULTI OUT
RGB/HDMI
MVS-12
SD IN 1
12
Monitoring for Switcher Monitoring for Video Installation Expansion of SD Inputs
MULTI -
SOLUTIONS
The MVS-12 is a perfect companion for the LVS-800 allowing you to preview
all monitor outputs. Using a MIDI connection the PGM/PVM video source is
displayed and indicated by a red frame and green frame (tally).
Multi-viewer and Matrix
switcher function enables
system expansion.
Quick setup and operation with a mouse. Rearrange screen structure
with simple drag and drop motion. Select video source with a click of the
mouse.
Video sources can be distributed to up to four different locations. The Matrix Switcher function enables the V-1600HD mixer to access
additional SD inputs. By connecting a MIDI cable and using the
V-LINK function, the V-1600HD can directly select any video source
from the MVS-12.
Easily monitor and distribute input sources.
View all sources on a single HD display.
■10 Screen Layout ■9 Screen Layout ■4 Screen Layout
■12 Screen Layout
●Setup MENU also supports mouse operation.
INTUITIVE OPERATION MATRIX SWITCHER
Using the built-in Matrix Switcher function, 12 video sources are
assignable to 4 different outputs. Use as a simple switcher.
MULTI-VIEW
There are four layout patterns to choose from. Aspect ratios,
background color and source names can be selected from
the MENU.
MEMORY & CONTROL
Four display setups can be saved and recalled
from the 4 front panel memory buttons.
In addition, the MVS-12 can be controlled from
a PC via LAN or RS-232C.

Printed in U.S.. JUN. 2010
Copyright 2010 Roland Corporation. All right reserved.
All trademarks and logos are the property of their respective companies.
All specification and appearances are subject to change without notice.
www.rolandsystemsgroup.com/mvs12
Ensuring high quality while protecting the environment: Roland is ISO9001 and ISO14001 certified
At Roland, several group companies have obtained ISO9001 certification. In addition, in January 1999, Roland also received ISO14001 international environmental management system certification.
We’re actively seeking ways to maintain harmony with the environment. (ISO=International Standardization Organization: an organization for the promotion of standardization of international units and
terms. They provide different categories of certification: ISO9001 Series certification is a product quality certification for products that undergo a certain level of quality control from the design stage to
the after service stage; ISO14001 Series certification is for environment-related standards. Each member of the Roland Group is striving to obtain certification.)
Roland Systems Group, a member of the worldwide group of Roland companies, is dedicated to the support of audio and video professionals demanding excellence in both
performance and system design. Through the development and support of video and audio products, we endeavor to improve workflow and maximize creative possibilities.
Output
Connectors
Output
Connectors
Video Format
PC-RGB: 0.7 Vp-p, 75 ohms (H, V : 5V TTL)
Input / Output Level
and Impedance Current Draw 2 A
Composite: 1.0 Vp-p, 75 ohms
Other Connectors
Weight 3.0 kg, 6 lbs 10 oz (without AC Adaptor)
HDMI, PC-RGB: 1920 x 1080 (60 / 50 Hz), 1680 x 1050 (60 / 75 Hz),
1600 x 900 (60 / 75 Hz), 1440 x 900 (60 / 75 Hz),
1280 x 1024 (60 / 75 Hz), 1280 x 720 (60 / 50 Hz),
1024 x 768 (60 / 75 Hz) (Progressive Scan)
Power Supply
Video Input
Connectors
Connectors
Composite: NTSC or PAL
Dimensions 481 (430 without rack mount bracket) (W) x 320 (D) x 44 (H) mm,
19 (16-15/16 without rack mount bracket) (W) x 12-5/8 (D) x 1-3/4 (H) inches
Composite (for MATRIX OUT Preview): BNC type x 1 jack
HDMI (for MULTI-OUT, MENU) x 1 jack
Composite (for MATRIX OUT): BNC type x 4 jacks
PC-RGB (for MULTI-OUT, MENU): D-Sub 15pin type x 1 jack
Composite: BNC type x 12 jacks
Ethernet 10 / 100Base-Tx RJ45 type x 1 jack
RS-232C DB-9 type x 1 jack
MIDI IN 5-pin DIN type x 1 jack
MIDI OUT / THRU 5-pin DIN type x 1 jack
Mouse PS/2 type *Not bundled.
AC Adaptor (Accessory)
Sampling Rate 4:2:2 (Y:B-Y:R-Y), 8-bit,
13.5 MHz (ITU-R BT.601)
[MONITOR] XGA (1024x768 pixels) or greater, HDMI or Analog RGB input is required.
[HDMI OUTPUT Connection] Audio is not supported. HDMI version is 1.2. Supports EDID when the setup is AUTO.
[RGB OUTPUT Connection] Manual pixel rate setup is needed.
[Aspect Ratio] In MULTI-OUT, display aspect and each input aspects can be adjusted individually. MATRIX OUTPUT has no aspect adjustment function.
[Switching] An mixed image before and after switching may appear on MATRIX Output at switching.
■Specifications
■Dimensions ■Video Mixers/Switchers
12
430
304.8
481
43.6
LVS-800
Video Mix/Live Switcher
Innovative 8-channel Video Mixer with DSK
●8 video inputs including 2 separate PC/RGB inputs
●Simple panel layout
●Downstream Keyer for seamless mixing under
title/graphics
V-8
8-Channel Video Mixer
Powerful Eight Input Video Mixer
●8 video inputs including built-in scan converter for
RGB input
●Various video effects and transitions
●DV quality full digital processing
V-1600HD
Multi-Format Video Switcher
An All-in-One Multi-Format Live Video Switcher
●Built-in monitor, scalers and Multi-format inputs and outputs
●DSK, Key Composition and PinP are controlled using simple operation.
●Various video equipments can be connected.
Unit: mm
