Owner’s Manual
Connecting to or Disconnecting from the Recording Devices
You can connect the SSD-128G to the Roland R-1000 for use as recording storage.
For connection and disconnection steps, refer to the owner’s manuals for the R-1000.
NOTE
To avoid the risk of damage to internal components that can be caused by static electricity, please
carefully observe the following whenever you handle this drive.
• Before you touch the drive, always rst grasp a metal object (such as a water pipe), so you are sure
that any static electricity you might have been carrying has been discharged.
• When handling this drive, grasp it only by the case. Avoid touching any of the electronic
components or connectors.
• Before you connect any cables, make sure they do not carry a static electricity charge. Such
charges can be transmitted, for example, if the other end of the cable has been in contact with a
carpet (or other object) where there is a static electricity buildup.
NOTE
Before the rst recording to the SSD-128G, use the recording device (R-1000) to format this drive.
Without formatting process, this drive cannot carry out proper recording. For steps of formatting the
recording drive, refer to owner’s manuals for the R-1000.
Connecting to a Computer
You can copy the recorded data to your computer when the SSD-128G is connected.
* Use the included USB cable for connection.
USB Ports Accessory USB cable
USB Port
NOTE
When you connect the SSD-128G to your computer, note the following points.
• The USB cable has 2 plugs on one end. Be sure to connect both plugs to the USB ports on your
computer. If you connect one plug only, it may cause the SSD-128G to malfunction because of
limited power (depending on the model of your computer.
• If connecting 2 plugs is dicult because of limited USB ports or space, you can connect via USB
hub. In this case, use a self-powered type (a hub that receives power from an external AC adaptor).
Do not use a bus-powered USB hub. Note too that the SSD-128G may not work properly if it
connected via a bus-powered USB hub - again due to the limited power.
• Do not extend the USB cable. If the SSD-128G is connected to a computer via an extension cable, it
may not work properly.
Operating Systems
SSD-128G supports the Operating Systems as below.
• WindowsXP/Vista/7/8
The drive is displayed as [Roland]. You can nd it under My Computer or using Explorer.
• MacOSX
The drive is displayed as [Roland] on the desktop.
Disconnecting from a Computer
When you disconnect the SSD-128G from a computer, follow these steps before
unplugging of the USB cable.
NOTE
Do not disconnect the USB cable before executing these steps. It may cause damage to the recorded
data.
For Windows XP/Vista/7/8
1. Quit Application
Quit all the applications referencing recorded data on the SSD-128G and close all the
windows.
2. Select the Safe Disconnection Icon
In the task tray, select the icon representing safe disconnection.
* Icon design diers depending on the operating system.
3. Select SSD-128G
Select the SSD-128G from the displayed USB devices and wait for the safe disconnection message.
4. Disconnect USB cable
Disconnect the USB cable that is connecting the SSD-128G with the computer.
For Mac OS X
1. Trash SSD-128G icon
Drag and drop the SSD-128G icon to the trash located on the right end of the Dock. The trash icon
changes to the image below. Wait a while and conrm that the SSD-128G icon has disappeared from the
desktop.
2. Disconnect USB cable
Disconnect the USB cable that is connecting the SSD-128G with the computer.
Copyright © 2013 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND
CORPORATION.
* 5 1 0 0 0 3 9 0 6 0 - 0 1 *
Before using this unit, carefully read the sections entitled “USING THE UNIT SAFELY” and “IMPORTANT
NOTES” on back side. These sections provide important information concerning the proper operation
of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature of
your new unit, read Owner’s Manual in its entirety. This manual should be saved and kept on hand as a
convenient reference.

WARNING
Do not disassemble or modify by yourself
Do not carry out anything unless you are
instructed to do so in the owner’s manual.
Otherwise, you risk causing malfunction.
Do not repair or replace parts by yourself
Refer all servicing to your retailer, the nearest
Roland Service Center, or an authorized Roland
distributor, as listed on the “Information.”
Do not use or store in the following types of locations
• Subject to temperature extremes (e.g.,
direct sunlight in an enclosed vehicle, near
a heating duct, on top of heat-generating
equipment); or are
• Damp (e.g., baths, washrooms, on wet
oors); or are
• Exposed to steam or smoke; or are
• Subject to salt exposure; or are
• Exposed to rain; or are
• Dusty or sandy; or are
• Subject to high levels of vibration and shakiness.
Do not allow foreign objects or liquids to enter unit;
never place containers with liquid on unit
Do not place containers containing liquid (e.g.,
ower vases) on this product. Never allow
foreign objects (e.g., ammable objects, coins,
wires) or liquids (e.g., water or juice) to enter
this product. Doing so may cause short circuits,
faulty operation, or other malfunctions.
WARNING
Turn o the unit if an abnormality or malfunction occurs
Immediately turn the unit o, and request
servicing by your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the “Information” when:
• Objects have fallen into, or liquid has been spilled onto
the unit; or
• If smoke or unusual odor occurs; or
• The unit has been exposed to rain (or otherwise has
become wet); or
• The unit does not appear to operate normally or
exhibits a marked change in performance.
Be cautious to protect children from injury
Always make sure that an adult is on hand to
provide supervision and guidance when using
the unit in places where children are present,
or when a child will be using the unit.
Do not drop or subject to strong impact
Otherwise, you risk causing damage or
malfunction.
CAUTION
Avoid climbing on top of the unit, or placing heavy
objects on it
Otherwise, you risk injury as the result of the
unit toppling over or dropping down.
Keep small items out of the reach of children
To prevent accidental ingestion of the parts
listed below, always keep them out of the
reach of small children.
• Included Parts: Ferrite cores
USING THE UNIT SAFELY
IMPORTANT NOTES
Placement
• This unit may interfere with radio and television
reception. Do not use this unit in the vicinity of such
receivers.
• Do not expose the unit to direct sunlight, place it near
devices that radiate heat, leave it inside an enclosed
vehicle, or otherwise subject it to temperature
extremes. Excessive heat can deform or discolor the
unit.
• When moved from one location to another where the
temperature and/or humidity is very dierent, water
droplets (condensation) may form inside the unit.
Damage or malfunction may result if you attempt to
use the unit in this condition. Therefore, before using
the unit, you must allow it to stand for several hours,
until the condensation has completely evaporated.
• Do not place containers or anything else containing
liquid on top of this unit. Also, whenever any liquid
has been spilled on the surface of this unit, be sure to
promptly wipe it away using a soft, dry cloth.
Maintenance
• For everyday cleaning wipe the unit with a soft,
dry cloth or one that has been slightly dampened
with water. To remove stubborn dirt, use a cloth
impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly with a
soft, dry cloth.
• Never use benzine, thinners, alcohol or solvents of any
kind, to avoid the possibility of discoloration and/or
deformation.
Memory Backup
• Use a reasonable amount of care when using the unit’s
hundle or connectors. Rough handling can lead to
malfunctions.
• When disconnecting all cables, grasp the connector
itself—never pull on the cable. This way you will avoid
causing shorts, or damage to the cable’s internal
elements.
• When you need to transport the unit, pack it in shock-
absorbent material. Transporting the unit without
doing so can cause it to become scratched or damaged,
and could lead to malfunction.
Handling SSD
Important Performance and Image Data
• Once a SSD fails to function normally, all data that
has been stored on it could be destroyed. AllSSD
eventuallywearout. We recommend that you
consider the SSD not as a permanent storage site,
but as a place to store data temporarily. We also
recommend that you back up important performance
and image data that cannot be recorded again onto the
external media that is supported by your device. For
instructions on how to make such backups, refer to the
owner’s manual for your device.
Note that Roland assumes no liability whatsoever,
including monetary compensation, for the loss of any
recorded content in the event of the malfunction of,
or physical damage to the SSD, or for any direct or
incidental damages resulting from the loss of such data.
Precautions Regarding Setup and Use
• Certain SSD setup procedures and usage conditions
may result in the corruption of recorded data,
malfunctioning, or physical damage to the disk, so be
sure to observe the following precautions.
• If the device includes a cooling fan, ensure that
the fan and the side panel air vents remain
unobstructed.
• Do not detach the unit or disconnect the USB cable
while a read or write operation is in progress.
Emergency Procedures
* The following procedures are to be used as emergency
measures only, and are not recommended for normal
operation.
• If the unit does not turn o following normal
shutdown procedures, disconnect the USB plug.
If the unit does not operate normally when it is
turned on again, it may mean that the SSD has been
damaged. In such instances, consult your dealer or
the nearest Roland Service Center. Note, however,
that it may not be possible to recover any data from
the SSD once it has been lost. If your device features
drive check capabilities, use the drive check function
to regularly conrm that there are no problems, even
when the device is operating normally. For more
detailed information on the shutdown and drive
check procedures, refer to the Owner’s Manual.
* Roland is either registered trademark or trademark of Roland Corporation in the United States and/or other countries.
* Company names and product names appearing in this document are registered trademarks or trademarks of their
respective owners.
Specications
Capacity 128 GB
Connectors USB connector (For Computer : mini-B type), Connector for Recording Device
Dimensions 85 (W) x 20 (D) x 136 (H) mm,
3-3/8 (W) x 13/16 (D) x 5-3/8 (H) inches
Weight 200 g
8 oz
Accessories USB Cable , Ferrite cores, Owner’s Manual
* In the interest of product improvement, the specications and/or appearance of this unit are subject to change
without prior notice.
Used for instructions intended to alert the
user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic animals
or pets.
Used for instructions intended to alert the
user to the risk of death or severe injury
should the unit be used improperly.
The symbol alerts the user to things that must be
carried out.The specific thing that must be done is
indicated by the design contained within the circle. In the
case of the symbol at left, it means that the power-cord
plug must be unplugged from the outlet.
The symbol alerts the user to important instructions or
warnings.The specific meaning of the symbol is
determined by the design contained within the triangle.In
the case of the symbol at left, it is used for general
cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never be
carried out (are forbidden).The specific thing that must
not be done is indicated by the design contained within
the circle. In the case of the symbol at left, it means that
the unit must never be disassembled.
About WARNING and CAUTION Notices About the Symbols
ALWAYS OBSERVE THE FOLLOWING
For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Ð Reorient or relocate the receiving antenna.
Ð Increase the separation between the equipment and receiver.
Ð Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Ð Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operation.
This equipment requires shielded interface cables in order to meet FCC class B limit.
Any unauthorized changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
WARNING
This product contains chemicals known to cause cancer, birth defects and other reproductive harm, including lead.
For C.A. US (Proposition 65)
For Canada
CAN ICES-3 (B)/NMB-3 (B)
For Korea
For the USA
DECLARATION OF CONFORMITY
Compliance Information Statement
Model Name :
Type of Equipment :
Responsible Party :
Address :
Telephone :
SSD-128G
Solid State Drive Unit
Roland Systems Group U.S.
5100 S.Eastern Avenue, Los Angeles, CA 90040-2938, U.S.A.
[phone]
For EU Countries
For China
