Roland JP-8080 Operating and maintenance manual

July, 1998
JP-8080
TABLE OF CONTENTS Page
SPECIFICATIONS•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••1
LOCATION OF CONTROLS ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••3
EXPLODED VIEW•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••4
PARTS LIST•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••5~6
IDENTIFYING THE VERSION NUMBER•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••7
SAVING AND LOADING USER DATA ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••7
FACTORY RESET•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••8
HOW TO UPDATE THE SOFTWARE•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••8
TEST MODE•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••9~12
ERROR MESSAGE FOR MEMORY TEST•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••12
BLOCK DIAGRAM•••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••13
CIRCUIT BOARD •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••14~16
CIRCUIT DIAGRAM••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••17~27
Printed in Japan (ACE0) (CR) 1
17059936
Issued by RJA
Copyright c1998 by ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
SPECIFICATIONS
JP-8080
SYnthesizer module
Synthesizer Section
●Parts
2 (Upper, Lower)
●Key Mode
Single, Dual, Split
●Maximum Polyphony
10 Voices (Voice Modulator OFF)
8 Voices (Voice Modulator ON)
●Waveform
OSC 1
SUPER SAW TRIANGLE MOD
NOISE FEEDBACK OSC
SQUARE (PWM) SAW
TRIANGLE
OSC 2
SQUARE (PWM) SAW
TRIANGLE NOISE
●Effects
Tone Control
Multi-FX (13 types)
SUPER CHORUS SLW, SUPER CHORUS MID, SUPER CHORUS FST, SUPER
CHORUS CLR, FLANGER SLOW, FLANGER DEEP, FLANGER FAST, DEEP
PHASING SLW, JET PHASING, TWISTING, FREEZE PHASE 1, FREEZE PHASE 2,
DISTORTION
Delay (5 types)
PANNING L->R, PANNING R->L, PANNING SHORT, MONO SHORT, MONO LONG
●Internal Memory
Performances User : 64
Preset : 192
Patches User : 128
Preset : 384
●Voice Modulator
Two 12-band band-pass filters
Noise
Robot Oscillator
Dedicated effect unit for Voice Modulator
(Ensemble, Delay)
Arpeggiator/RPS Section
●Arpeggio Mode
UP
DOWN
UP&DOWN
RANDOM
●Arpeggio Beat Patterns
1/4, 1/6, 1/8, 1/12, 1/16, 1/32, PORTA-A1--A11, PORTA-B1--B15, SEQUENCE-A1--
A7, SEQUENCE-B1--B5, SEQUENCE-C1--C2, SEQUENCE-D1--D8, ECHO1--3,
MUTE1--16, STRUMMING1--8, REFRAIN1--2, PERCUSSION1--4,
WALKING BASS, HARP, RANDOM (total 90 types)
●Arpeggio Range
1 - 4 octave
●Hold
ON/OFF
●RPS Pattern Data (Internal Memory)
Patterns: 48
Maximum Loop Length (Measures): 4
●Resolution
24 ticks per quarter note
●Gate Time
REAL, STACCATO, 33%, 50%, 66%, 100%
●Input Quantize
OFF, TRIPLET1/16, 1/16, TRIPLET1/8, 1/8, TRIPLET1/4, 1/4
●Recording Method
Realtime (Loop Recording)
●Tempo
20 to 250

2
Motion Control Section
●Motion Data (Internal Memory)
Motions : 2 x 2 sets (SET A, B)
Maximum Loop Length (Measures) : 8
Maximum Recording Length (Measures): 99
●Recording Method
Realtime (Loop Recording and One Shot Recording)
●Tempo
20 to 250
Others
●External Storage Device (SmartMedia)
Storage:
S2M-5 (2M bytes)
Performances :64 x 32
Patches :128 x 32
RPS Patterns :48
Motion Controls :2 x 4
System Settings :1
S4M-5 (4M bytes)
Performances :64 x 64
Patches :128 x 64
RPS Patterns :48
Motion Controls :2 x 4
System Settings :1
●Display
16 characters, 2 lines (backlit LCD)
●Connectors
MIDI connectors (REMOTE KBD IN, IN, OUT)
Output jacksL(MONO) : 1/4 inch phone type
R : 1/4 inch phone type
External Input jacks
INST/LOWER(MONO) : 1/4 inch phone type
VOCAL/UPPER : 1/4 inch phone type
MIC jack : 1/4 inch phone type
Headphone jack : Stereo 1/4 inch phone type
●Input Level
External Input jacks
INST/LOWER(MONO) : -30dBm -- +4dBm
VOCAL/UPPER : -30dBm -- +4dBm
MIC jack : -60dBm -- -20dBm
●Input Impedance
External Input jacks
INST/LOWER(MONO) : 24kΩ
VOCAL/UPPER : 24kΩ
MIC jack : 5kΩ
●Output Impedance
Output jacks
L(MONO) :2.2kΩ
R :2.2kΩ
Headphone jack :100Ω
●Power Supply
AC117V, AC230V, AC240V
●Power Consumption
17W(AC117V), 17W(AC230V), 17W(AC240V)
●Dimensions
482(W) x 88(D) x 264(H) mm
19(W) x 3-1/2(D) x 10-7/16(H) inches
●Weight
4.5 Kg/9 lbs 15 oz (except Power cord)
●Accessories
Owner's ManualEnglish :#71122323
Japanese :#71017512
Power Cord 117V :#00894378
230V :#00894389
240VE :#00907001
240VA :#23495124
●Options
SmartMedia : S2M-5 (2M bytes)
S4M-5 (4M bytes)
* In the interest of product development, the specifications for this product are subject
to change without prior notice.
JP-8080
Jul, 1998

Jul, 1998
JP-8080
3
LOCATION OF CONTROLS
[PARTS]
No. PART No. PART NAME Qty.
q32490595 P S-KEY MX BLK 1
01453245 PUSH SWITCH SDDLB1-B2-D-2 TV-5 1
w01343101 D C-ESCT BX1H BLK 1
01458756 D C-ESCT HOLDER 1
01341178 CARD CONECTR CN015S-3013-0 1
e00231401 U R-KNOB MF270 BLK/LCG 10
01560601 9M/M ROTARY POT. EVU JFY FL1 B24 10
(Serial No. earlier than Z**3399)
01672945 9M/M ROTARY POT. EVU JDE FL1 B24 10
(Serial No. Z**3400 or later)
r00231401 U R-KNOB MF270 BLK/LCG 17
01560590 9M/M ROTARY POT. EVU JFU FL1 B24 17
t00231401 U R-KNOB MF270 BLK/LCG 2
01561045 9M/M ROTARY POT. EVU F2K FL1 A53 2
y00231401 U R-KNOB MF270 BLK/LCG 1
01674867 12M/M ROTARY POT. EVJ Y15 F02 A24 1
u01561578 J S-KNOB S BLK/LCG 2
01567056 30M/M SLIDE POT. RS30111Z9 CLICK 2
i01561578 J S-KNOB S BLK/LCG 12
01567078 30M/M SLIDE POT. RS30111Z9 NON-CLICK 12
o00900189 D S-KEYTOP SX1H BLK 10
01340290 PTR TACT SWITCH EVQ11A H=5.0 10
!0 01129767 D S-KEYTOP SX1H DRD 1
01340290 PTR TACT SWITCH EVQ11A H=5.0 1
!1 00900190 D S-KEYTOP SX2H BLK 3
01340290 PTR TACT SWITCH EVQ11A H=5.0 6
!2 00900145 D S-KEYTOP SD1H BLK 8
01340290 PTR TACT SWITCH EVQ11A H=5.0 8
00348490 PTR LED SLR-325VCT31 8
!3 00900145 D S-KEYTOP SD1H BLK
01340290 PTR TACT SWITCH EVQ11A H=5.0 1
15029342 LED GL3ED8 1
!4 01013023 D S-KEYTOP SD1H DRD 1
01340290 PTR TACT SWITCH EVQ11A H=5.0 1
00348490 PTR LED SLR-325VCT31 1
!501016867 D S-KEYTOP SD1H LCG 1
01340290 PTR TACT SWITCH EVQ11A H=5.0 1
00348490 PTR LED SLR-325VCT31 1
!6 01016867 D S-KEYTOP SD1H LCG 1
01340290 PTR TACT SWITCH EVQ11A H=5.0 1
15029342 LED GL3ED8 1
!7 01125890 D S-KEYTOP SD1H-A CLR 4
01232201 TACT SWITCH SKHJGS WITH LED 4
!8 00900156 D S-KEYTOP SD2H BLK 4
01340290 PTR TACT SWITCH EVQ11A H=5.0 8
00348490 PTR LED SLR-325VCT31 8
!9 00900156 D S-KEYTOP SD2H BLK 1
01340290 PTR TACT SWITCH EVQ11A H=5.0 2
15029342 LED GL3ED8 2
@0 01568356 D S-KEYTOP MD4H LCG 4
01340290 PTR TACT SWITCH EVQ11A H=5.0 16
00348490 PTR LED SLR-325VCT31 16
@1 00899023 PTR LED LNJ282RKRXE 37
@2 01343090 LED SPACER 11
@3 15029342 LED GL3ED8 2
01455901 LED SPACER LH-36-9 2
@4 01230678 VK-7 DISPLAY COVER 1
00127378 LCD RCM7044U-1A 1
@5 22150756 JACK NUT 2 1
01561034 6.5MM JACK YKB21-5277 1
@6 22150756 JACK NUT 2 1
01129145 6.5MM JACK YKB21-5268 1
@7 13449283 6.5MM JACK HLJ7101-01-3010 4
@8 13429274 DIN YKF51-5041 1
@9 01347623 AC INLET NC-176-1.0 1

4
EXPLODED VIEW
Jul, 1998
[PARTS]
No. PART No. PART NAME
q01458778 RACK ANGLE
w01458712 BOTTOM COVER
e12359139 FOOT FF-018 BLK
r01458723 JACK HOLDER
t01458701 TOP PANEL
y01458734 PWR SPLY HOLDER
u01561056 INSULATING SHEET
i40016589 NYLON RIVET NRP-335
o01458745 PWB HOLDER
!0 32490595 P S-KEY MX BLK
!1 00127378 LCD RCM7044U-1A
!2 01451678 SWTNG REG KW1AA265
!3 01347623 AC INLET NC-176-1.0
!4 71017534 MAIN BOARD ASSY
!571017556 PANEL BOARD ASSY
!6 71017578 SW BOARD ASSY
!7 71017589 MIC BOARD ASSY
!8 71017590 PHONES BOARD ASSY
!9 71017567 CARD BOARD ASSY
NOTE:Replacement CARD BOARD ASSY does not include Escutcheon and Holder.
@0 01232978 WIRING GND
@1 01568190 WIRING W1
@2 01568201 WIRING W2
@3 01568212 WIRING W3
@4 01452890 FUJI CARD 14X150-A6.0BBR-P1.25-HBL10
@5 01568256 FUJI CARD 25X240-A6.0BBR-P1.25-HBL10
@6 01568267 FUJI CARD 35X220-A6.0BBR-P1.25-HBL10
@7 01568512 RIBON CABL 3X70-P2.0
@8 01568534 RIBON CABL 4X90-P2.0
@9 00789856 RIBON CABL 5X200-P2.0
#0 01568245 RIBON CABL 7X120-P2.0
#1 40016512 INSULOK TIE 80M/M T-18S
[SCREW]
å40011056 BINDING TAPTIGHT B 3*6 ZC (x19)
∫40011067 BINDING TAPTIGHT B 3*8 ZC (x12)
ç40011090 BINDING TAPTIGHT B 3*6 BZC (x16)
∂40011123 BINDING TAPTIGHT B 4*8 BZC (x6)
¤
e40011278 BINDING TAPTIGHT P 3*8 ZC (x2)
ƒ40011312 BINDING TAPTIGHT P 3*8 BZC (x4)
©40011501 SEMS 3*8 BZC (x2)
˙40013056 DOUBLE SEMS(SMALL WASHER) 3*6 ZC (x4)
¤i40011745 NUT WITH SPRING WASHER M4 ZC (x1)
∆22150756 JACK NUT 2 (x2)
JP-8080
CAUTIONS IN REPAIRING
As shown in the diagram, the shape of the two connecters of WIRING 1(#01568190)
No.@1 are same. When you repairing, be careful of the combinations of connection.(refer to
the following)
Connecter with WHITE/BROWN wirings--> SWITCHING REGULATOR KW1AA265
Connecter with BLACK/BROWN wirings--> SWITCH BOARD
This is a ncessity for safety standard.

PARTS LIST 00231878 TC74VHC00F QUAD NAND GATE IC30 on MB
00567534 TC74VHC138F 3-TO-8 LINE DECODER IC16 on MB
00670290 TC74VHC139F DUAL 2-TO-4 LINE DECODER IC5 on MB
15289106 M5238AFP-600C OpAmp IC14 on MB
15189261 M5218AFP-600E OpAmp IC54,56 on MB
15289105 UPC4570G2-T2 OpAmp IC37,43,44,46,50,51,53,55 on MB
15219157 M5241L-600Y VCA IC48 on MB
00344390 TA7805F +5V Regulator IC35 on MB
15289123 M51953AFP-600C Reset IC IC2,52,67 on MB
15289125 PC-410T Photo Coupler IC45,47 on MB
15169596 TC74HC4051AP 8CH ANALOG MULTIPLEXER IC2,4,6,8,10 on PB
15169542 TC74HC273AP OCTAL D FLIP-FLOP IC7 on PB
15169550T0 TC74HC138AP 3-TO-8 LINE DECODER IC3,13 on PB
15189189 UPC4570HA OpAmp IC1,5,9 on PB
15189186 UPC4570C OpAmp IC601 on VB
TRANSISTOR
01121278 2SA1576A Q3,5,11,14-16 on MB
15319105 2SC3326A Q26-31 on MB
01121289 2SC4081 Q1,6,8,10,12,13 on MB
15329104 2SK368GR FET Q7,9 on MB
15329507 DTA114EK Q2 on MB
15329533 RN2307 Q17,23 on MB
15329516 DTC114EK Q4 on MB
15329521 RN1307 Q18 on MB
15129151 2SC1815-GR Q7-14 on PB
15119170 RN2226 Q1-6,15-22 on PB
DIODE
15339105 DAN202K DA13,14,20,22-37 on MB
01121323 DA204U DA1-8,11,12,21 on MB
15019126 1SS133 D1-59,64-69,71,86-89,147-152,155-161 on PB
LED
00348490 SLR-325VCT31 D80-83,90,113,117,126,127,146,153,154 on PB
00899023 LNJ282RKRXE D72-79,114-116,118-125,128-145 on PB
15029342 LED GL3ED8 D60-63,84,85 on PB
RESISTOR
15399952 MCR50JZH470 1/2W R221,222,228,229 on MB
# 01561412 MCR50-J222 1/2W R166 on MB
RESISTOR ARRAY
15399965 RCE9A103JAG7A RA11,15,27 on MB
00126112 EXBV8V101JV RA1-3,8,10,12-14,16 on MB
00909801 EXBV8V220JV RA4-7,9,18,20,21,23,25,26 on MB
13919140 RGLD8X103J RA1 on PB
POTENTIOMETER
# 01560590 EVU JFU FL1 B24 9mm Rotary VR VR1-6,9,10,12-15,20,21,25,35,41 on PB
# 01560601 EVU JFY FL1 B24 9mm Rotary VR with click VR7,8,11,16,17,22-24,26,40 on PB
(Serial No. earlier than Z**3399)
# 01672945 EVU JDE FL1 B24 9mm Rotary VR with click VR7,8,11,16,17,22-24,26,40 on PB
(Serial No. Z**3400 or later)
# 01561045 EVU F2K FL1 A53 9mm Rotary VR VR43,44 on PB
# 01567056 RS30111Z9 WITH CLICK 30mm Slide VR with click VR32,33 on PB
# 01567078 RS30111Z9 NON-CLICK 30mm Slide VR VR18,19,27-31,34,36-39 on PB
# 01674867 EVJ Y15 F02 A24 12mm Rotary VR.Dual VR601 on VB
CAPACITOR
15369151S0 16CV100BS C47 on MB
# 01455845 16CV22NP C259,C269,C276 on MB
15369145S0 16CV47BS C57,C283,C309,C323 on MB
15369163S0 25CV10BS C293 on MB
01340267 25CV100BS C278-282 on MB
15169210S0 50CV1BS C267,C272 on MB
15369212S0 50CV2R2BS C252,C325 on MB
# 15169214S0 50CV4R7BS C284 on MB
15369105S0 6.3CV100BS C265 on MB
15369152 ECEV1CA100SR C3,18,23,49,51,70,176,207,210-214,218,242,245,247-
249,251,258,260,268,270,274,286,287,295,296,336 on MB
# 13529509 DD106-999F103Z50 C4,13,24,36,50,52 on PB
13529132 RPE132-901F104Z50 C1-3,5-12,14-23,25-30,32-35,38,40,46-49,51,53-62,65-69 on PB
# 13639674S0 6.3MV100SWB+T 7mm Height C39 on PB
# 13649158 ECEA1HKA100B 7mm Height C31,37,41-45,71,74 on PB,C601-604 on VB
# 13519634M0 ECKR1H102KB5 C501,502 on PHB
INDUCTOR,COIL,FILTER
01455623 N2012Z102T01 L3-10,12,14,15,17 on MB
00903167 N2012Z601T02 L1 on MB
12449355 FBR07HA850TB00 Ferrite Bead L1-4 on PB,L401 on MIB,L501,502 on PHB
CRYSTAL
00894034 MA-406 16.000MHz for CPU X1 on MB
# 01453167 SG-8002DC 67.7376MHz for ESP X2 on MB
CONNECTOR
13379151 FFC Connector IL-FPC-14ST-N CN1 on MB
13369934 53253-1210 CN10 on MB
13369592 B7B-XH-A CN4 on MB
00453467 IL-FPC-25ST-N CN5 on MB,CN201 on CB
00780990 52045-3510 CN11 on MB
13369600 52147-0510 CN3 on MB
13369602 52147-0710 CN6 on MB
13429292 51048-0300 CN4 on PB
13429294 51048-0500 CN2 on PB
13429296 51048-0700 CN3 on PB
01341178 Card Connector CN015S-3013-0 CN202 on CB
13369898 B2P3-VH 7A/250V CN301 on SB
13369598 52147-0310 CN401 on MIB
13429293 51048-0400 CN501 on PHB,CN602 on VB
WIRING,CABLE
01232978 WIRING GND
# 01568190 WIRING W1 SB CN301-SW REG CN1-AC INLET
# 01568201 WIRING W2 MB CN4-SW REG CN2
# 01452890 FUJI CARD 14X150-A6.0BBR-P1.25-HBL10 MB CN1-LCD unit
# 01568256 FUJI CARD 25X240-A6.0BBR-P1.25-HBL10 MB CN5-CB CN201
# 01568267 FUJI CARD 35X220-A6.0BBR-P1.25-HBL10 MB CN11-PB CN1
# 00789856 RIBON CABLE 5X200-P2.0 PB CN2-MB CN3 5
NOTE:The parts marked # are new (initial parts)
CASING
# 01458701 TOP PANEL
# 01458712 BOTTOM COVER
01230678 DISPLAY COVER
# 01458723 JACK HOLDER
12359139 FOOT FF-018 BLK
# 01458778 RACK ANGLE
CHASSIS
# 01458734 POWER SUPPLY HOLDER
# 01561056 INSULATING SHEET
40016589 NYLON RIVET NRP-335
# 01458745 PWB HOLDER
# 01458756 D C-ESCT HOLDER
KNOB,BUTTON
32490595 P S-KEY MX BLK for Power Switch
00231401 U R-KNOB MF270 BLK/LCG for Rotary VR
# 01561578 J S-KNOB S BLK/LCG for Slide VR
01013023 D S-KEYTOP SD1H DRD Small,with Lens
01125890 D S-KEYTOP SD1H-A CLR Small,with Lens.Clear
# 01568356 D S-KEYTOP MD4H LCG Medium,with Lens.quadruple
01016867 D S-KEYTOP SD1H LCG Small,with Lens
00900190 D S-KEYTOP SX2H BLK Small,Double
01129767 D S-KEYTOP SX1H DRD Small
00900189 D S-KEYTOP SX1H BLK Small
00900156 D S-KEYTOP SD2H BLK Small,with Lens.Double
00900145 D S-KEYTOP SD1H BLK Small,with Lens
SWITCH
01340290 TACT SW EVQ11A H=5.0 SW1-3,6-32,35-59 on PB
01232201 TACT SW with Orange LED SKHJGS SW4,5,33,34 on PB
01453245 Power SW SDDLB1-B2-D-2 TV-5 SW301 on SB
JACK,SOCKET
13429274 YKF51-5041 MIDI JACK JK1 on MB(MIDI)
13449283 HLJ7101-01-3010 1/4 inch Phone Type Jack JK2,3,5,6 on MB(INPUT,OUTPUT)
# 01561034 YKB21-5277 1/4 inch Phone Type Jack JK401 on MIB(MIC)
01129145 YKB21-5268 Stereo 1/4 inch Phone Type Jack JK501 on PHB(PHONES)
DISPLAY UNIT
00127378 LCD UNIT RCM7044U-1A
POWER SUPPLY UNIT
01451678 Switching Regulator KW1AA265
PCB ASSY
#‰71017534 MAIN BOARD ASSY
# 71017556 PANEL BOARD ASSY
# 71017578 SW BOARD ASSY
# 71017589 MIC BOARD ASSY
# 71017590 PHONES BOARD ASSY
# 71017567 CARD BOARD ASSY
IC
01016123 HD6413002FP16 CPU IC7 on MB
00892556 TC170C140AF-003(ESP2) Custom IC17-21 on MB
01122412 TC551001CFL-70L SRAM IC11,13 on MB
01120523 HM514800DJ6Z DRAM IC23-25,63,64 on MB
00899812 LH28F800SUT-70 Flash Memory IC62 on MB
15289714 UPD63200GS-E2 DAC IC36 on MB
# 01453256 PCM3001E/T2 AD/DA IC32 on MB
15269219H0 HD74LS05FPEL TTL IC65 on MB
00127490 TC7W08F DUAL AND GATE IC27,38,66 on MB
00232634 TC7W74F D FLIP-FLOP IC31 on MB
15259758T0 TC74HC175AF QUAD D FLIP-FLOP IC42 on MB
15259716T0 TC74HC32AF QUAD OR GATE IC9,41 on MB
15259797T0 TC74HC365AF HEX BUS BUFFER IC12 on MB
01341567 TC74VHC163F SYNCHRONOUS 4-BIT COUNTER IC59,60,61 on MB
15249119 TC74HCT245AF OCTAL BUS TRANSCEIVER IC40 on MB
15259823T0 TC74HC574AF OCTAL D FLIP-FLOP IC4 on MB
15259720T0 TC74HC74AF DUAL D FLIP-FLOP IC3,10,34 on MB
15259883 TC7S00F NAND GATE IC15 on MB
15249104 TC7S04F INVERTER IC58 on MB
15249121 TC7W04F TRIPLE INVERTER IC8,33 on MB
MAIN BOARD ASSY=MB MIC BOARD ASSY=MIB
PANEL BOARD ASSY=PB PHONES BOARD ASSY=PHB
SW BOARD ASSY=SB CARD BOARD ASSY=CB
!
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics.
Use only listed parts for
replacement.
!
CONSIDERATIONS ON PARTS ORDERING
When ordering any parts listed in the parts list, please specify the following items in the order sheet.
QTY PART NUMBER DESCRIPTION MODEL NUMBER
Ex. 10 22575241 Sharp Key C-20/50
15 2247017300 Knob (orange) DAC-15D
Failure to completely fill the above items with correct number and description will result in delayed or
even undelivered replacement.
Jul, 1998
!
!
JP-8080

# 01568245 RIBON CABLE 7X120-P2.0 PB CN3-MB CN6
# 01568512 RIBON CABLE 3X70-P2.0 PB CN4-MIB CN401
# 01568212 WIRING W3 VB CN601-MB CN10
# 01568534 RIBON CABLE 4X90-P2.0 PHB CN501-VB CN602
AC INLET
# 01347623 AC INLET NC-176-1.0
BATTERY
00238990 CR2032 220MAH/3V
SCREW
40011056 BINDING TAPTIGHT B 3*6 ZC
40011067 BINDING TAPTIGHT B 3*8 ZC
40011090 BINDING TAPTIGHT B 3*6 BZC
40011123 BINDING TAPTIGHT B 4*8 BZC
40011278 BINDING TAPTIGHT P 3*8 ZC
40011312 BINDING TAPTIGHT P 3*8 BZC
40011501 SEMS 3*8 BZC
40013056 DOUBLE SEMS(SMALL WASHER) 3*6 ZC
40011745 NUT WITH SPRING WASHER M4 ZC
22150756 JACK NUT 2
PACKING
# 01458790 PACKING CASE
# 01568689 ACCESSORY BOX
# 01568690 FRONT PAD
# 01568701 REAR PAD
# 01670378 MANUAL PAD
40236612 VINYL BAG MIRROR MAT 0.5*600*460
MISCELLANEOUS
01346312 CARD PROTECTOR
40126812 CAUTION LABEL BARRIER
40016512 INSULOK TIE 80M/M T-18S
00238956 Battery Holder CR2032BH BT1 on MB
# 01567045 LEAF SPRING on MB
12199584 GROUNDING TERMINAL M1698 on MB
# 01458767 POT DUST COVER
# 01455901 LED SPACER LH-36-9 for GL3ED8
01343090 LED SPACER for LNJ282RKRXE
01343101 Card Escutcheon D C-ESCT BX1H BLK
40017412 CORD BINDER NO.11 BLACK for AC Cord Set 240VE Only
40014589 WARNING TACK SEAL 102-103 for AC Cord Set 240VE Only
ACCESSORIES(Standard)
# 71122323 OWNER'S MANUAL SET English
# 71017512 OWNER'S MANUAL SET Japanese
00894367 AC Cord Set 100V SP18A+IS14VCTF2X0.75
00894378 AC Cord Set 120V SP301+IS14 SJT18/3
00894389 AC Cord Set 230V SP22+IS14H05VV-F3G1.0
00907001 AC Cord Set 240VE KP-610 GTBS-3 KS-31A
23495124 AC Cord Set 240VA SC-114-J01ES303-10HMA
!
!
!
!
!
!
6
Jul, 1998
JP-8080

7
(1)Turn the power on while holding down
[LFO1 WAVEFORM], [NUMBER 1] and [NUMBER 3].
(2)The version number appears on the display.
(3)After checking the number, turn the power off.
You can save the user data to a memory card (SmartMedia).
Before perform the data saving, you must format a SmartMedia
by using the following procedure.
◆ Format a SmartMedia
(1)Insert a 2M or 4M SmartMedia (5V type) into the card slot
in state of power off.
(2)Turn the power on.
(3)Press [EDIT].
(4)Press [INIT/UTIL]([BANK 7]) several times to select the
display of Card.
(5)Press [DEC] or [INC] several times to select "FORMAT".
(6)Press [WRITE]. The following display of confirmation
appears on the LCD.
(7)Press [WRITE]. The format operation will be carried out.
(8)When formatting ends, "Completed" appears on the LCD.
◆ Saving the user data
(1)Insert a formatted SmartMedia (5V type) into the card slot
in state of power off.
(2)Turn the power on.
(3)Press [EDIT].
(4)Press [INIT/UTIL]([BANK 7]) several times to select the
display of Card.
(5)Press [DEC] or [INC] several times to select "USER-
>CARD"
(6)Press [WRITE].
(7)Press [DEC] or [INC] several times to select "ALL".
(8)Press [WRITE]. The following display of confirmation
appears on the LCD.
(9)Press [WRITE]. The saving the user data operation will be
carried out.
(10)When saving all user data ends, "Completed" appears on
the LCD.
◆ Loading the user data
(1)Insert the SmartMedia which is the data backed up in the
"Saving the user data" procedure into the card slot in state
of power off.
(2)Turn the power on.
(3)Press [EDIT].
(4)Press [INIT/UTIL]([BANK 7]) several times to select the
display of Card.
(5)Press [DEC] or [INC] several times to select "CARD-
>USER"
(6)Press [WRITE].
(7)Press [DEC] or [INC] several times to select "ALL".
(8)Press [WRITE]. The following display of confirmation
appears on the LCD.
(9)Press [WRITE]. The loading the user data operation will be
carried out.
(10)When loading all user data ends, "Completed" appears
on the LCD.
Jul, 1998
SAVING AND LOADING THE USER DATA
Card [WRITE]
Menu: FORMAT
Format CARD
OK? [WRITE/EXIT]
Formatting
65% oooooo... .
Card [WRITE]
Menu: USER->CARD
Type: [WRITE]
ALL
Overwrite CARD
OK? [WRITE/EXIT]
Card [WRITE]
Menu: CARD->USER
Type: [WRITE]
ALL
Overwrite USER
OK? [WRITE/EXIT ]
IDENTIFYING THE VERSION NUMBER
JP-8080

8
Jul, 1998
(1)Turn the power on.
(2)Press [EDIT].
(3)Press [INIT/UTIL]([BANK 7]) several times to select the
display of Factory Reset.
(4)Press [REC]. The message of confirmation appears on the
LCD.
(5)Press [WRITE] to load the factory setting data.
The JP-8080 is equipped with a flash memory allowing updates
of the program version from MIDI.
Update disk : 17048696 JP-8080 Ver.UP DISK
◆ WARNING!!
READ THIS BEFORE STARTING THE VERSION UPGRADE:
(1)The JP-8080 might not start up if mistakes are made in the
version upgrade procedure or the power is cut during
operation. Always comply with the procedure listed below
and PLEASE! never turn off the power during operation.
(2)The user data area is used as the job memory during the
version upgrade. This means that user data will be
deleted. Be sure to make a backup copy of the user data
before attempting the version upgrade.
◆ NOTICE:
(1)The software update disk(17048696 JP-8080 Ver.UP
DISK) consists of a floppy disk(3.5inch) and a list of Check-
sum. Obtain the latest version from the service center.
(2)The program is converted and saved as Standard MIDI
Files(SMF). A sequencer that can play SMF data is
required.(e.g. SB-55, XP-50/60/80)
(3)The file names are as follows.
"vvv" indicates the version number.
For example "102" signifies Version 1.02.
◆ Update procedure
(1)Connect the sequencer MIDI-OUT and the JP-8080 MIDI-
IN terminals with the MIDI cable.
(2)Turn on the power while holding down the two [WRITE]
and [PORTAMENTO ON] buttons.
(3)Press [REC] when the display in Fig.1 appears. You can
quit the version upgrade at this point, by pressing [EXIT].
Check that the display in Fig.2 appears.
(4)Load the file into sequencer. Load in sequence from
vvv_01.MID.
(5)Play the song. Fig.3 appears on the JP-8080 display.
(6)The check sum appears at the end of the song. Check that
it matches the value on the list.
If the value is different, press [EXIT] and repeat steps 5 and
6. (Inquire at your Roland Service center if the value is still
wrong after repeating steps 5 and 6 several times.)
(7)If the value is correct press the [REC] button. Be sure never
to cut off the power while the display in Fig.5 appears.
When loading one file ends, the display in Fig.6 appears.
(8)Load the files one at a time, in sequence from
vvv_02.MIDto vvv_14.MID and repeat steps (5) through
(7) from the procedure.
(9)Once all files have been loaded, the display in Fig.6
appears.
Turn the power off and then to make the factory resetting.
Reload the user data from backup copy.
Error1)If an error message appears during play of SMF, turn
off the power and redo from the beginning.
Error2)In step (7) of this procedure, if "Completed" does not
appear within 40 seconds after pressing [REC] or if
the message "Can't update!" appears, then the
version upgrade is a failure. When this occurs you
must replace the main board.
FACTORY RESET
vvv_01.MID vvv_02.MID vvv_03.MID vvv_04.MID
vvv_05.MID vvv_06.MID vvv_07.MID vvv_08.MID
vvv_09.MID vvv_10.MID vvv_11.MID vvv_12.MID
vvv_13.MID vvv_14.MID
HOW TO UPDATE THE SOFTWARE
Factory Reset
ALL [REC]
Erase your data
OK? [WRITE/EXIT]
Erase USER data!
Sure? [REC/EXIT] Ready to update [Play SMF]
fig 1. fig 2.
Check Sum: ****
>>>x [REC/EXIT] fig3.
Check Sum: ????
(^_^) [REC/EXIT] fig 4.Check this value
Now updating..
[Keep power on] Completed [Play next SMF]
fig. 5 fig. 6
JP-8080

9
◆ Tools required
• MIDI cable
• SmartMedia x2 (Formatted / Protected)
• Oscillator (SINE WAVE of 1kHz, 800Hz)
• Oscilloscope
• Headphones
• Monitor Speaker (MA-12 etc.)
◆ Entering the TEST MODE
(1)Insert a card without write protected to card slot previously.
(2)Turn the power on while holding down [FILTER -12dB/-24dB],
[FILTER TYPE], [MODULATION(LFO 2) DEPTH SELECT].
(3)Test mode is now set and the memory test starts.
◆ TEST Items
The following 8 tests are available and each test is detailed below.
Some test items will start automatically when the previous test item
was a pass.
Next test can be selected from pressing [INC].
Previous test can be selected from pressing [DEC].
The tests can be separately selected from the number keys or
[SHIFT].
[NUMBER 1] MEMORY Test
[NUMBER 2] MIDI Test
[NUMBER 3] Card Test
[NUMBER 4] Sw&LED Test
[NUMBER 5] A/D Test
[NUMBER 6] LCD Test
[NUMBER 7] Sound Test
[NUMBER 8] Input Test
[SHIFT] FACTORY RESET
◆ Exiting the TEST MODE
(When the test is SW/LED, exit it.)
Press [SHIFT], then "Are You Sure?" is displayed.
Press [WRITE], then display of Factory Reset appears.
Press [WRITE] again to exit the test mode, then factory data will be
loaded.
◆ Details of the each test
1. MEMORY Test
(1) When the unit enters the test mode, Memory test starts
automatically and checks CPU, DSP, SRAM, and Battery. Is
[fig.1] shown on the LCD?
(2) If test results are OK.Memory test ended correctly.
And, MIDI Test program runs automatically.
* When there is something wrong, error message appears on
the LCD.
Check each point according to the error message.
2. MIDI Test
(1) [fig.2] is shown on the LCD.
(2) Connect MIDI-IN and MIDI-OUT with a MIDI cable
Is "OK" shown on the LCD.
* If "OK" does not indicated, there in some error in MIDI circuit.
Check IC47 and IC65 on the MAIN BOARD.
(3) Disconnect MIDI cable connected to MIDI-IN.
[fig.3] is shown on the LCD
(4) Connect REMOTE KBD IN and MIDI-OUT with a MIDI cable.
Is program version number shown on the LCD?
* If version number does not indicated, there is error in MIDI
circuit.
(5) MIDI Test ended correctly.
Disconnect MIDI cable, then Card Test program runs automatically.
3. Card Test:
(1) Is [fig.4] shown on the LCD?
* If [fig4] does not appear on the LCD:
[fig.7] shown on the LCD.
· Check IC41(3pin:XCWR, 6pin:XCRE) on the MAIN BOARD.
Is the level of XCWR and XCRE change during the test?
· Check IC40, RA27 on the MAIN BOARD.
Is there something wrong with card bus?
· Check IC41(8pin), IC42 on the MAIN BOARD.
Is there something wrong with decoder ?
· Check IC38(7pin) on the MAIN BOARD.
Is the voltage high level?
(2) Remove the card from card slot.
[fig.5] is shown on the LCD.
(3) Insert a card with write protected to card slot.
Is [fig.6] shown on the LCD?
TEST MODE
CPU DSP SRAM BAT
OK OK OK OK
[fig.1]
MESSAGE
CPU NG
DSP mn
SRAM NG
BAT NG
CHECK POINT
IC7 is defective.Replace IC7.
IC17, IC18, IC19, IC20, IC21, IC23, IC24, IC25, IC63,
IC64
(Refer to "Error Message in Memory Test" on another
page about "mn".)
IC11, IC13
Replace the battery.(BT1:CR2032)
[2] MIDI Test
MIDI IN WAITING
[fig.2]
[2] MIDI Test
REMOTE WAITING
[fig.3]
[3] Card Test
non-protected ok
[fig.4]
[3] Card Test
non-protected NG
[fig.7]
[3] Card Test
protected
[fig.5]
[3] Card Test
protected ok
[fig.6]
JP-8080
Jul, 1998

10
* If [fig6] does not appar on the LCD:
[fig.8] is shown on the LCD.
·Check R99 and IC12(14pin:CWPSNS) on the MAIN BOARD.
Is there voltage of CWPSNS low level?
(4) Sw&LED Test runs automatically.
4. Sw&LED Test
(1) [fig.9] is shown on the LCD.
(2) Do all LEDs (except two SIG/LIMITER LEDs) light up ?
* If error:
·Check LEDs and Transistors on the PANEL BOARD.
· Check IC3, IC7 and IC13 on the PANEL BOARD.
(3) Press the buttons on the panel one by one.
The count displayed on the LCD decreases as each button is
pressed.
· In case of buttons with single color LED : Press the button,
then LED turn off.
· In case of buttons with double color LED:
At first, LED lights up orange.
Press the button once, then LED lights up green.
Press the button again, then LED lights up dark green.
Press the button once more, then LED is turned off.
· In case of self-lighting buttons(PANEL SELECT and MOTION
CONTROL)
At first, LED lights up red.
Press the button once, then LED's red dims a little.
Press the button again, then LED's red dims ******.
Press the button once more, then LED is turned off.
· In case of buttons without LED:
In case of being no LED nearby:
Press the button, then "o" is turned off on the LCD.
· In case of being some LED nearby (Example:three LEDs):
Press the button, 1st LED is turned off.
Press the button again, 2nd LED is turned off.
Press the button once more, 3rd LED is turned off.
(4) Are all buttons and LEDs working as above?
After pressing all buttons, Is number shown on the LCD now at
(0)?
* If error:
· Check switches, LEDs and Transistors on the PANEL
BOARD.
·Check IC3, IC7 and IC13 on the PANEL BOARD.
(5) If all switches and LEDs are working correctly, A/D Test program
runs automatically.
5. A/D Test
(1) [fig.10] is shown on the LCD.
(2) Move all the rotary volumes (except LEVEL at VOLUME section,
INST/LOWER and VOCAL/UPPER at EXTERNAL INPUT
section) fully right and fully left.
Move all the sliders fully up and fully down.
The values displayed at the lower right of the LCD change within
the ranges listed below as each volume or
slider is moved.
Volumes and sliders without center click :0~127
OSC2 RANGE :-WIDE~+WIDE
OSC2 FINE/WIDE :-50~+50
TEMPO :20~250
Other volumes and sliders with center click :-64~+63
The count displayed at the lower left of the LCD decreases as
each volume or slider is moved.
(3) Do the values displayed at the lower right of the LCD change
within the ranges listed above?
Finally, do the count displayed at the lower left of the LCD
decrease from (41) to (0)?
* If error
Check IC1, IC2, IC4, IC5, IC6, IC8, IC9, IC10 and IC11 on the
PANEL BOARD.
(4) A/D Test ended correctly.
LCD Test program runs automatically.
6. LCD Test
(1) [fig.11] is shown on the LCD.
Press [WRITE], then all dots of LCD are turned off.
Press [WRITE] again, then all dots of LCD are turned on.
(2) Are all dots of LCD turned off correctly?
Are all dots of LCD turned on correctly?
* If error:
· Check the LCD unit.
(3) Move the slider of FILTER ENVELOPE R from the minimum to
the maximum, then LED of number buttons light up in order
from [NUMBER 1] to [NUMBER 8], and also the contrast of LCD
changes gradually.
(4) Do LEDs of number buttons light up in order from [NUMBER 1]
to [NUMBER 8]?
Does the contrast of LCD change gradually?
* If error:
· Check Q1, IC7(1pin:PWM) on the MAIN BOARD.
(5) Press [NUMBER 7] or [INC], then Sound Test program runs.
7. Sound Test
(1) [fig.12] is shown on the LCD.
Connect the monitor speaker to the OUTPUT jack.
Connect the headphones to PHONES jack.
Raise the volume as needed.
(2) Press [WRITE], then "L: Saw" is displayed on the LCD.
Check the signal at the OUTPUT L with an oscilloscope.
Check that a sound can be heard from left channels of the
monitor speaker and the headphones.
(3) Do triangular waveforms appear on both channels on an
oscilloscope?
Can sound from the triangular waveforms be heard on both
channels of the monitor speaker and the headphones?
* If error:
·Check IC31, IC35, IC36(DAC), IC37, IC55 and IC56 on the
MAIN BOARD.
· Check IC601 on the VOLUME BOARD.
[3] Card Test
protected NG
[fig.8]
[4] Sw&LED Test
(58) oo oo ooo
[fig.9]
[5] A/D Test
(41)
[fig.10]
[6] LCD Test
[fig.11]
[7] Sound Test
[fig.12]
JP-8080
Jul, 1998

11
(4) Press [WRITE], then " L:Saw is displayed on the LCD.
Check the signal at the OUTPUT L with an oscilloscope.
Check that a sound can be heard from left channels of the
monitor speaker and the headphones.
(5) Do sawtooth waveforms appear on left channels on an
oscilloscope?
Can sound from the sawtooth waveforms be heard on left
channels of the monitor speaker and the headphones?
* If error:
·Check IC31, IC35, IC36(DAC), IC37, IC55 and IC56 on the
MAIN BOARD.
· Check IC601 on the VOLUME BOARD.
(6) Press [WRITE], then "R: Square" is displayed on the LCD.
Check the signal at the OUTPUT R with an oscilloscope.
Check that a sound can be heard from right channels of the
monitor speaker and the headphones.
(7) Do Square waveforms appear on right channels on an
oscilloscope?
Can sound from the Square waveforms be heard on right
channels of the monitor speaker and the headphones?
* If error:
·Check IC31, IC35, IC36(DAC), IC37, IC55 and IC56 on the
MAIN BOARD.
· Check IC601 on the VOLUME BOARD.
(8) Press [WRITE], then "Effect" is displayed on the LCD.
A delay will be applied in order on the center, left and right so
check the sound on the left and right channels of the monitor
speaker and the headphones.
(9) Can sounds with a delay be heard from the center, left and right
in order?
* If error:
·Check IC21(DSP), IC64(DRAM) and their connections on the
MAIN BOARD.
(10) Press [WRITE], then "10 Voice" is displayed on the LCD.
10 tones corresponding to the white keys from C4 to E5 will be
issued so check the sound on the left and right channels of the
monitor speaker and the headphones.
(11) Can 10 tones corresponding to the white keys from C4 to E5 be
heard on the monitor speaker and the headphones?
*If error:
·Check IC31, IC35, IC36(DAC), IC37, IC55 and IC56 on the
MAIN BOARD.
· Check IC601 on the VOLUME BOARD.
(12) Press [WRITE], then "DRAM1" is displayed on the LCD.
Do(C4), Fa(F4) and Sol(G4) are issued in order. After they are
formed a chord, Fa(F4) and So(G4) are stopped.
(13) Does the output waveform contain noise?
*If error:
·Check IC18(DSP), IC23(DRAM) and their connections on
the MAIN BOARD.
(14) Press [WRITE], then "DRAM2" is displayed on the LCD.
Do(C5), Fa(F5) and Sol(G5) are issued in order. After they are
formed a chord, Fa(F5) and So(G5) are stopped.
(15) Does the output waveform contain noise?
*If error:
·Check IC19(DSP), IC24(DRAM) and their connections on
the MAIN BOARD.
(16) Press [WRITE], then "DRAM3" is displayed on the LCD.
Do(C6), Fa(F6) and Sol(G6) are issued in order. After they are
formed a chord, Fa(F6) and So(G6) are stopped.
(17) Does the output waveform contain noise?
*If error:
·Check IC20(DSP), IC25(DRAM) and their connections on
the MAIN BOARD.
(18) Press [WRITE], then "DRAM0" is displayed on the LCD.
Delay tones are issued in sequence?
(19) Does the output waveform contain noise?
*If error:
·Check IC17(DSP), IC63(DRAM) and their connections on
the MAIN BOARD.
(20) Press [WRITE], then "DRAM4" is displayed on the LCD.
Delay tones are issued in sequence?
(21) Does the output waveform contain noise?
*If error:
·Check IC21(DSP), IC64(DRAM) and their connections on
the MAIN BOARD.
8. Input Test
Raise the VOLUME LEVEL, the INST/LOWER INPUT LEVEL and
the VOCAL/UPPER INPUT LEVEL to the maximum.
Connect the OUTPUT L and R of JP-8080 to the oscilloscope.
Set the input range of the oscilloscope for 200mV/div.
NOTE:SINE WAVE (i),(ii),(iii) as in the following explanations are as
follows.
Depending on the program version, the value of the SINE WAVE
are different.
Versions earlier than 1.03
SINE WAVE (i) :f=1kHz, LEVEL=100mVpp
SINE WAVE (ii) :f=1kHz, LEVEL=500mVpp
SINE WAVE (iii) :f=1kHz, LEVEL=16mVpp
Version 1.04 or later
SINE WAVE (i) :f=800Hz, LEVEL=75mVpp
SINE WAVE (ii) :f=800Hz, LEVEL=500mVpp
SINE WAVE (iii) :f=1kHz, LEVEL=16mVpp
(1) [fig.13] is shown on the LCD.
Press [WRITE].
[fig.14] is shown on the LCD.
(2) Input the SINE WAVE (i) to the INST/LOWER jack and the
VOCAL/UPPER jack in rear panel.
Two SIG/LIMITER LEDs of INST/LOWER and VOCAL/UPPER
light up green.
The SINE WAVE, the level of which go in two divisions
(400mVpp) of the oscilloscope, is displayed on a screen of the
oscilloscope.
According as you move the rotary volumes of INST/LOWER and
VOCAL/UPPER from the maximum to the minimum, the level of
the sine wave on a screen changes by degrees.
(3) Do Two SIG/LIMITER LEDs of INST/LOWER and
VOCAL/UPPER light up green?
* If error:
·Check IC43, IC44, IC53, IC54, CN3 and CN6 on the MAIN
BOARD.
· Check D84(LED), D85(LED), CN2 and CN3 on the PANEL
BOARD.
[8] Input Test
[fig.13]
[8] Input Test
REAR:
[fig.14]
JP-8080
Jul, 1998

(4) Is the sine wave which is proper level displayed on a screen of
the oscilloscope?
According to movement of the rotary volumes of INST/LOWER
and VOCAL/UPPER, does the level of the sine wave on a screen
change by degrees?
* If error:
·Check IC17(DSP), IC32(AD/DA), IC43, IC44, IC46, IC51 and
CN6 on the MAIN BOARD.
· Check CN3 on the PANEL BOARD.
(5) Press [WRITE].
[fig.15] is shown on the LCD.
(6) Input the SINE WAVE (ii) to the INST/LOWER jack and the
VOCAL/UPPER jack in rear panel.
Two SIG/LIMITER LEDs of INST/LOWER and VOCAL/UPPER
light up red.
According as you move the rotary volumes of VOCAL/UPPER
INPUT LEVEL with range from the maximum to the minimum,
the value of "vocal" displayed on the LCD changes with range
from 0 to 127.
(7) Do Two SIG/LIMITER LEDs of INST/LOWER and
VOCAL/UPPER light up red?
* If error:
·Check IC43, IC44, IC53, IC54, Q7, Q9, Q15, Q16, Q17, Q18,
Q23, CN3 and CN6 on the MAIN BOARD.
· Check D84(LED), D85(LED), CN2 and CN3 on the PANEL
BOARD.
(8) According to movement of the rotary volumes of
VOCAL/UPPER, does the value of "vocal" displayed on the LCD
change with range from 0 to 127?
* If error:
·Check IC7(80pin:ESPDAC L), IC17(DSP), IC32(AD/DA),
IC43, IC44, IC46, IC48(VCA), IC51 and CN6 on the MAIN
BOARD.
· Check CN3 on the PANEL BOARD.
(9) Press [WRITE].
[fig.16] is shown on the LCD.
(10) Input the SINE WAVE (iii) to the MIC jack in front panel.
The SIG/LIMITER LED of VOCAL/UPPER lights up red.
The sine wave is displayed on a screen of the oscilloscope.
(11) Does the SIG/LIMITER LED of VOCAL/UPPER light up red?
*If error:
·Check IC44, IC50, IC53, IC54, Q7, Q9, Q15, Q16, Q17,
Q18, Q23, CN3 and CN6 on the MAIN BOARD.
· Check D85(LED), CN2 and CN3 on the PANEL BOARD.
(12) Is the sine wave displayed on a screen of the oscilloscope?
*If error:
·Check IC17(DSP), IC32(AD/DA), IC48(VCA), IC50, IC51
and CN6 on the MAIN BOARD.
· Check CN3 on the PANEL BOARD.
(13) Input Test ended correctly.
Press [SHIFT] or [INC], then Initialize program runs
9. Initialize
(1) [fig.17] is shown on the LCD.
(2) Press [WRITE].
(3) [fig.18] is shown on the LCD.
(4) Press [WRITE] again to exit the test mode, then factory data will
be loaded.
· Under normal conditions ‘OK’ displayed on the LCD.
◆ TABLE 1:ERROR MESSAGE of 01 to 0F
* Error in inter-DSP communications.
'x' means wrong inter-DSP communications.
◆ TABLE 2:ERROR MESSAGE of 11 to 4F
* Defect in DSP. Replace it.
'x' means wrong DSP.
◆ TABLE 3:ERROR MESSEGE of 31 to 3F
* Defect in DRAM. Check the DRAM and its bus.
'x' means wrong DRAM.
ERROR MESSAGE FOR MEMORY TEST
TABLE 1
Msg.
01
02
03
04
05
06
07
08
09
0A
0B
0C
0D
0E
0F
IC17-IC18
x
x
x
x
x
x
x
x
IC18-IC19
x
x
x
x
x
x
x
x
IC19-IC20
x
x
x
x
x
x
x
x
IC20-IC21
x
x
x
x
x
x
x
x
TABLE 2 * is 1,2,3 or 4.
Msg.
*1
*2
*3
*4
*5
*6
*7
*8
*9
*A
*B
*C
*D
*E
*F
IC17
x
x
x
x
x
x
x
(x)
IC18
x
x
x
x
x
x
x
(x)
IC19
x
x
x
x
x
x
x
(x)
IC20
x
x
x
x
x
x
x
(x)
IC21
x (all or IC21)
TABLE 3
Msg.
31
32
33
34
35
36
37
38
39
3A
3B
3C
3D
3E
3F
IC63
x
x
x
x
x
x
x
(x)
IC23
x
x
x
x
x
x
x
(x)
IC24
x
x
x
x
x
x
x
(x)
IC25
x
x
x
x
x
x
x
(x)
IC64
x (all or IC64)
[8] Input Test
REAR: Vocal=
[fig.15]
[8] Input Test
FRONT:
[fig.16]
Are You Sure?
[EXIT/WRITE]
[fig.17]
JP-8080
Jul, 1998
12
Factory Reset
[WRITE]
[fig.18]

1 2 3 4 5 6 7 8 9 10111213141516171819202122232425262728
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U13
LINE OUT
[L(MONO), R]
MIDI OUT MIDI IN
+5V
-15V
VOLUME BOARD
REMOTE KBD IN
EXT. IN
INST / LOWER
(MONO)
EXT. IN
VOCAL / UPPER
MIC. IN
VOCAL / UPPER
To IC32 BCKIN IN
To IC32 XT1 IN
64Fs
256Fs
LCD UNIT [16X2]
RCM7044U-1A
Card Control
7W08, HC32, HC175
(IC38, IC41, IC42)
Bus Buffer
HCT245 (IC40)
LCD I/F
HC74 & HC574
(IC3, IC4)
8M bit FLASH ROM [70ns]
LH28F800SUT
(IC62)
1M bit SRAM [70ns]
TC551001CFL
(IC11, IC13)
CPU
HD6413002FP
(IC7)
4M bit DRAM [60ns]
HM514800DJ6Z
(IC63)
4M bit DRAM [60ns]
HM514800DJ6Z
(IC23)
4M bit DRAM [60ns]
HM514800DJ6Z
(IC24)
4M bit DRAM [60ns]
HM514800DJ6Z
(IC25)
4M bit DRAM [60ns]
HM514800DJ6Z
(IC64)
DAC
uPD63200GS
(IC36)
LPF & Buffer
OP.AMP 4570
(IC55)
Voltage
Follower
Gain 0dB
OP.AMP 4570
(IC43A)
Mic Jack
(JK401)
Sig / Limiter
Indicator
(Lower = D84)
(Upper = D85)
X' TAL 67.7376MHz
SG-8002DC
(X2)
Divider (1/768)
VHC163
(IC59, IC60, IC61)
To IC17 - 21
OSC IN
[67.7376MHz]
To IC17 - 21
SYNC IN
[2Fs=88.2kHz]
SW & LED Matrix
VR Matrix
Decoder & Driver
HC4051
(IC2, IC4, IC6, IC8,
IC10,IC11)
HC138
(IC3, IC13)
HC273
(IC7)
OP.AMP 4570
(IC1, IC5, IC9)
2SC1815
(Q7-Q14)
RN2226
(Q1-Q6, Q15-Q22)
AC IN
~
Lower
Upper
Voltage
Follower
Gain 0dB
OP.AMP 4570
(IC43B)
Mic AMP
Gain +30dB
OP.AMP 4570
(IC50)
PHONES
OUT
Headphone AMP
OP.AMP 5218
(IC56)
AMP
Gain +24.6dB
OP.AMP 4570
(IC44B)
AMP
Gain +24.6dB
OP.AMP 4570
(IC44A)
Input Volume
(Lower = VR43)
(Upper = VR44)
Lower
Upper
Lower
Upper
(Q7, Q9,
Q17, Q18, Q23)
Switching
AD Section DA Section
AD/DA PCM3001 (IC32)
ESP2 CHIP
TC170C140
(IC18)
ESP2 CHIP
TC170C140
(IC19)
ESP2 CHIP
TC170C140
(IC20)
ESP2 CHIP
TC170C140
(IC21)
X' TAL 16MHz
MA-406
(X1)
REMOTE KBD IN
Receiver
PC410
(IC45)
SWITCHING REGULATOR
KW1AA265
Card Connector
CN015S-3013-0
(CN202)
for 5V SmartMedia [2M or 4M]
Phones
Jack
(JK501)
Buffer
OP.AMP 4570
(IC37) Master
Volume
(VR601)
MIDI IN
Receiver
PC410
(IC47)
MIDI OUT
Transmitter
HD74LS05
(IC65)
Limiter
VCA M5241L
OP.AMP 4570
(IC48, IC46, IC51)
Vocal Morph Sig.
ESP2 CHIP
TC170C140
(IC17)
PANEL BOARD
ASSY
[71017556]
MIC BOARD
ASSY
[71017589] MAIN BOARD ASSY
[71017534]
PHONES BOARD
PHONES BOARD
ASSY
[71017590]
SW BOARD ASSY
[71017578]
CARD BOARD ASSY
[71017567]
Memory Backup
CR2032 [3V]
(BT1)
Reset
M51953
(IC2)
+15V
For Digital Reset
Reset
M51953
(IC52)
For Analog Reset
Reset
M51953
(IC67)
For IC32 Reset
BLOCK DIAGRAM
Jul, 1998
JP-8080

1 2 3 4 5 6 7 8 9 10111213141516171819202122232425262728
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
14
PANEL BOARD ASSY (71017556)/CARD BOARD ASSY (71017567)/
MIC BOARD ASSY (71017589)/SW BOARD ASSY (71017578)/
PHONES BOARD ASSY (71017590)
View from component side
Jul, 1998
PANEL BOARD ASSY
(71017556)
CARD BOARD ASSY
(71017567)
SW BOARD ASSY
(71017578)
MIC BOARD ASSY
(71017589) PHONES BOARD ASSY (71017590)
JP-8080

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U15
View from foil side
PANEL BOARD ASSY (71017556)/CARD BOARD ASSY (71017567)/
MIC BOARD ASSY (71017589)/SW BOARD ASSY (71017578)/
PHONES BOARD ASSY (71017590)
PANEL BOARD ASSY
(71017556) CARD BOARD ASSY
(71017567)
SW BOARD ASSY
(71017578) MIC BOARD ASSY (71017589)
PHONES BOARD ASSY
(71017590)
JP-8080
Jul, 1998

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
16
View from component side
MAIN BOARD ASSY (71017534)
View from foil side
JP-8080
Jul, 1998

12345678910111213141516 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U17
RXD1
Flash ROM
0.1*3
TXD0
RXD0
SRAM * 2
(22*4)*5
E-CLK
A19
D12
D9
D15
AN7
XCS1
XCS1
XRD
A15
XCS1
XLWR
WP-CNT
D8
D10
D15
D13
AN2
AN5
LSC-EN0
D6
XHWR
PWM LCD1
LCD3
SC2
SD1
SD3
D13
D11
VR24-17
SLD6
SLD4
XLWR
A16
A19
LCD_CNT
SC0
D15
D14
AN4
VR48-41
XEJECT
SLD2
XLWR
XLCD
A19
D10
D8
D15
D10 XCS0
VR16- 9
XHWR
ADC0
D7
D7
XECS2
SC3
D13
LSC2
ADC1
LSC-EN0
XCS0
XCARD
SC6
D15
D13
D11
AN3
INV16
SLD7
INV16
VPP-CNT
SC4
D10
D14
D9
D8
D8
D15
D14
BATSENS
VR40-33
XLWR
LSC1
XRD
ADC0
XCCTL
LCD5
LCD4
SD6
D14
D12
D12
TXD0
SLD0
ESPINT1
LCD0
SD0
D11
XEJECT
MIC_SELECT
XHWR
ADC1
XECS1
SC5
SC1
SD2
D14
D14
D11
SLD5
LSC0
D6
XHWR
SD7
SD5
XRD
D9
D8
D11
D6
LSC1
LEN0
LSC-EN1 PWM
XECS0
D12
VR32-25
VR 8- 1
ADC2
D7
LSC-EN1
ESPDAC_L
XRD
A14
XCS2
A19
LCD2
SD4
D8
D9
D13
AN6
XCS0
XCS_S
LSC0
LSC2
SLD3
XLCD
A2
XECS4
LCD10
LCD6
SC7
D10
D9
XCS2
XRES
XCS_S
ADC2
XECS3
LCD9
WP-CNT
D12
D9
D11
SLD1
XRD
A1
LCD8
LCD7
LE0
XHWR
D10
D13
D12
XCS1
MIC_SELECT
ESPINT1
XCS_S
RXD0
RXD1
SD[0..7]
AN[2..7]
SC[0..7]
D[8..15]
D[8..15]
LCD[0..10]
XRES
XRES Vbat
Vbat
D7
D6
XCS2
XCBSY
XCBSY
BATSENS
XCS2
D0
D0
A14
A13
A5
A0
E4_INT0
A1
A17
A17
A16
D3
D3
D3
A5
D4
A1
A11
A6
D0
A14
D0
A8
D1
D4
A7
A18
A14
A[0..18]
A12
D4
A17
A18
D3
A2
A10
A4
A9
A2
A12
A3
D2
D4
A7
D0
A3
A16
D3
D5
A10
A4
A13
A13
E2_INT0
A8
A15
A9
A9
D2
A17
A4
A13
E1_INT0
A8
A3
A16
D5
A4
D0
A14
D5
A15
A15
A11
D1
A8
A15
A9
A2
A2
A12
A3
A1
D5
A10
A7 E3_INT0
D1
D2
D4
A1
A16
A5
A5
D1
D1
A11
A12
A6
A6
D2
A10
A18
CWPSNS
D1
A6
D2
A1
D5
A7
A0
E0_INT0
A11
XRD
D
D
+5D
+5D
+5D
D
D
+5D
+5D
D
D
+5D
D
+5D
D
+5D
D
D
+5D
D
+5D
-15
+
5D
D
-15
D
+
5D
D
+
5D
D
D
+
5D
+
5D
D
+
5D
D
+
5D
D
+
5D
D
D
+
5D
+
15
D-15
D
D
+
5D +
5D
D
+
5D
D D
+
5D
D
D D
+
5D
+
5D + 5D +
5D
D
D
D
D
D
D
+
5D
D
+
5D
D
D
D
D
R15
10k
R29
100
RA4 1 8 2 7
3 6
4 5
IC4
TC74HC574AF
D7
9
D6
8
D5
7
D4
6
D3
5
D2
4
D1
3
D0
2
OE
1
CK
11
Q7 12
Q6 13
Q5 14
Q4 15
Q3 16
Q2 17
Q1 18
Q0 19
VCC 20
GND
10
IC5A
TC74VHC139F
B
3
A
2
G
1
Y3 7
Y2 6
Y1 5
Y0 4
R250
47k
C71
0.1
C73
15P
R17 100
IC3A
TC74HC74F
D
2
CK
3Q5
Q6
PR 4
CR
1
IC10B
TC74HC74F
D
12
CK
11 Q9
Q8
PR 10
CR
13
R30
100
C78
1000P
X1 16M
14
RA8
100
18 27 36 45
RA16
100
18 27 36 45
C79
100P
C66
0.1
IC10A
TC74HC74F
D
2
CK
3Q5
Q6
PR 4
CR
1
C61
0.1
C62
1000P
IC16
TC74VHC138F
C
3
B
2
A
1
G2B
5
G2A
4
G1
6
Y7 7
Y6 9
Y5 10
Y4 11
Y3 12
Y2 13
Y1 14
Y0 15
VCC 16
GND
8
R247 47k
C7 1000P
R1 100
DA1
DA204U
21
3
RA10
100
18 27 36 45
RA5 1 8 2 7
3 6
4 5
RA6 1 8 2 7
3 6
4 5
Q2
DTA114EK 1
3 2
RA15
RCE9A@JA
10k
12
3
4
5
6
7
8
9
IC7
HD6413002FP
A19 58
A18 57
A17 56
A16 55
A15 54
A14 53
A13 52
A12 51
A11 50
A10 49
A9 48
A8 47
A7 45
A6 44
A5 43
A4 42
A3 41
A2 40
A1 39
A0 38
D15 36
D14 35
D13 34
D12 33
D11 32
D10 31
D9 30
D8 29
D7/P4-7 28
D6/P4-6 27
D5/P4-5 26
D4/P4-4 25
D3/P4-3 23
D2/P4-2 22
D1/P4-1 21
D0/P4-0 20
LWR 74
HWR 73
RD 72
AS 71
PHAI 63
BACK/P6-2 62
BREQ/P6-1 61
WAIT/P6-0 60
CS0/P8-4 93
CS1/IRQ3/P8-3 92
CS2/IRQ2/P8-2 91
CS3/IRQ1/P8-1 90
RFS/IRQ0/P8-0 89
RES
65 RESO 12
MD2
77
MD1
76
MD0
75
STBY
64 NMI
66
P9-5/SCK1/IRQ5
19
P9-4/SCK0/IRQ4
18
P9-3/RXD1
17
P9-2/RXD0
16
P9-1/TXD1
15
P9-0/TXD0
14
PB-7/TP15/DREQ1
11
PB-6/TP14/DREQ0
10
PB-5/TP13
9
PB-4/TP12
8
PB-3/TP11
7
PB-2/TP10
6
PB-1/TP9
5
PB-0/TP8
4
AN7/P7-7
87
AN6/P7-6
86
AN5/P7-5
85
AN4/P7-4
84
AN3/P7-3
83
AN2/P7-2
82
AN1/P7-1
81
AN0/P7-0
80
VREF
79
AVCC
78
AVSS
88
PA7/TP7/A20
2
PA6/TP6/A21
1
PA5/TP5/A22
100
PA4/TP4/A23
99
PA3/TP3/TCLKD
98
PA2/TP2/TCLKC
97
PA1/TP1/TCLKB
96
PA0/TP0/TCLKA
95
EXTAL
68
XTAL
69
VCC 3 VCC 37 VCC 70
VSS
13
VSS
24
VSS
46
VSS
59
VSS
67
VSS
94
IC9A
TC74HC32AF
1
23
R22
10
C75
15P
R10
10k
R8
NIU
R24
1k
R9
0R0
R248 47k
IC58
TC7S04F
2 4
53
RA14
100
18 27 36 45
IC9B
TC74HC32AF
4
56
R12
10k R13
100k
R243 47k
R242 47k
R27
100
RA11
RCE9A@JA
10k
12
3
4
5
6
7
8
9
C60
0.1
IC62
LH28F800SUT-70@
A19
5
A18
6
A17
7
A16
8
A15
10
A14
11
A13
12
A12
13
A11
17
A10
18
A9
19
A8
20
A7
22
A6
23
A5
24
A4
25
A3
26
A2
27
A1
28
A0
32
RY/BY
53
CE1
2
CE0
14
WE
55
OE
54
WP
56 BYTE
31
RP
16
3/5
1
DQ15 52
DQ14 50
DQ13 47
DQ12 45
DQ11 41
DQ10 39
DQ9 36
DQ8 34
DQ7 51
DQ6 49
DQ5 46
DQ4 44
DQ3 40
DQ2 38
DQ1 35
DQ0 33
NC 3
NC 4
NC 29
NC 30
VPP 15
VCC 9
VCC 37
VCC 43
VSS 21
VSS 42
VSS 48
Q1
2SC4081
1
2 3
R240 47k
RA9 1 8 2 7
3 6
4 5
RA12
100
18 27 36 45
R14
10k
R241 47k
RA7 1 8 2 7
3 6
4 5
IC5B TC74VHC139F
B
13
A
14
G
15
Y3 9
Y2 10
Y1 11
Y0 12
R249 47k
C67
0.1
R18 100
C87
0.1
C5
1000P
R2 100
RA13
100
18 27 36 45
C6 1000P
R3 100
IC9D
TC74HC32AF
12
13 11
C80
NIU
C86
0.1
IC14B
M5238AFP
+
-
6
57
IC14C
M5238AFP
+
-
84
C81
0.1
C84
0.1 C85
0.1
C82
0.1
C83
0.1
IC9E
TC74HC32AF
147
C57
47/16
IC13
TC551001BFL-70L
A16
2
A15
31
A14
3
A13
28
A12
4
A11
25
A10
23
A9
26
A8
27
A7
5
A6
6
A5
7
A4
8
A3
9
A2
10
A1
11
A0
12
CE2
30
CE1
22
R/W
29
OE
24
I/O8 21
I/O7 20
I/O6 19
I/O5 18
I/O4 17
I/O3 15
I/O2 14
I/O1 13
NC 1
VDD 32
VSS 16
IC11
TC551001BFL-70L
A16
2
A15
31
A14
3
A13
28
A12
4
A11
25
A10
23
A9
26
A8
27
A7
5
A6
6
A5
7
A4
8
A3
9
A2
10
A1
11
A0
12
CE2
30
CE1
22
R/W
29
OE
24
I/O8 21
I/O7 20
I/O6 19
I/O5 18
I/O4 17
I/O3 15
I/O2 14
I/O1 13
NC 1
VDD 32
VSS 16
IC14A
M5238AFP
+
-
2
31
C77
0.1
DA20
DAN202K
1 2
3
R20
10k
C74
100P
R11
10k
R19
10k
R25
100
R21
100
C69
0.1
BT1
CR2032BH
21
R23
10k
Q4
DTC114EK
1
2 3
R26
100k
Q3
2SA1576A
1
3 2
DA3
DA204U
21
3
DA5
DA204U
21
3
C68
0.1
C64
DA2
DA204U
21
3
IC5C
TC74VHC139F
VCC 16
GND
8
DA8
DA204U
21
3
DA7
DA204U
21
3
IC10C
TC74HC74F
VCC 14
GND
7
C76
0.1
IC3B
TC74HC74F
D
12
CK
11 Q9
Q8
PR 10
CR
13
C63
DA4
DA204U
21
3
R16
10k
C72
0.1
C70
10/16
21
C65
DA6
DA204U
21
3
IC3C
TC74HC74F
VCC 14
GND
7
IC12
TC74HC365F
6A
14
5A
12
4A
10
3A
6
2A
4
1A
2
G2
15
G1
1
6Y 13
5Y 11
4Y 9
3Y 7
2Y 5
1Y 3
VCC 16
GND
8
IC9C
TC74HC32AF
9
10 8
IC15
TC7S00F 1
2
4
53
CIRCUIT DIAGRAM
CPU BLOCK
JP-8080
Jul, 1998

22*7
(1/3)
(SYNC = 2F s = 88.2kHz)
4M D RAM (512k * 8)
4M D RAM (512k * 8)
(67.7376MHz)
0.1*13
0.1*13
(1/16)
(1/16)
4M D RAM (512k * 8) 4M D R AM (512k * 8)
0.1*130.1*13
22*7
4M D RAM (512k * 8)
A 5
A 6
A12
A13
A 0
A10
A 8
A 0
A 9
A13
A10
A 7
D15
XRST 2
EAC3
EAC9
EAC2
EDB9
64Fs
EDC6
EDC4
EC_CAS
EDC9
EAE2
EE_RAS
EAB4
X R S T0
EDA6
EDD6
SYNC
X H W R
TR01
TR01
A 0
A 3
D12
D15
D 9
D 8
X H W R
EAC7
E4_INT0
EAB0
EAB2
EAD6
EAD2
EDD9
EDD5
EAE7
EAA7
TR23
TCK2
XRD
EDA8
EAA0
EAA1
EAA6
TR10
A 5
A 7
A 0
A 3
A 8
D 8
EDB6
EE_RAS
EAA5
XRST 3
TCK3
TR34
TR15
TR41
TR00
TR03
A 9
A 6 A 5
A13
A 0
A 6
A 8
D13
D11
XRD
X H W R XRD
EAC1
EAC4
EAC6
EAC9
EDB5
E3_INT0
EC_RAS
EAE6
EE_WE
EAE2
EAB8
EAB7
EAB3
EAA2
EDA10
EDA9
EDA5
ED_CAS
EAD2
TR24
EAD7
EAD8
TR33
ESPCLK
TR11
XRST 1
A 3
D11
D10 D 9
D10
D 8
D13
TR44
EB_CAS
EDB8
EAB3
EAB7
EA_CAS
EAD9
EAD5
EAD1
XECS3
TR42
EDA4
EDA9
XRST 0
A 2
A 6
SYNC
EB_WE
EDB10
EC_RAS
EAE3
EAE7
ED_RAS
W C L K
BCLK
EAB8
EA_WE
EDD5
EAD0
EDD9
TR30
TR14
TR40
EAA7
A 3
A 6
A 1
A13
D 9 D 8
D14
EDC7
EDC9
EDC11
EE_CAS
EDD8
EDD4
EAE6
EAE5
EAE1
XRST 1
EAA6
EAA5
EAA1
EDD8
EAD3
TCK3
TR31
XECS4
EAA2
TR00
TR04
A 2
D 9
D12
XRD
EAC8
EDB7
EDB8
ESP_IN_R
EAB1
EAB4
EA_RAS
EAB2
TR31
TR35
TCK4
TR43
EDA5
EAA8
TCK1
TR12
A12
A13
A 2
E0_INT0
XECS0
EDC8
EDC8
EDC4
EAE0
EDD11
TR20
TR14
TR45
SYNC
EA_RAS
SYNC
A 5
A10
A 4 A 4
A 7
A11
A 1
EB_WE
EAC5
EAC3
EAC1
EAC7
EC_CAS
EDC11
ED_WE
EAD8
EAD4
EAD0
EDD7
EAE9
EAB6
EAA9
EDA8
EDA4
TCK2
TR23
TR21
EDA6
EDA10
EAA3
TR10
A 9
D11
D10
D14
D 9
D15
D14
XRST 3
EB_CAS
X H W R
EAC0
EAC6
EDB11
EDB9
EC_WE EE_WE
EDD4
EAB0
EAD4
ED_RAS
EDD10
TR32
TR43
TCK4
TR04
A 5
A 8
A12
A 9
A 4
A 7
D13
D10
D15
EAC8
EAC0
EAC2
EDB4
EDB10
EDC5
EC_WE
EAE1
EAE4
EAE8
ED_CAS
EAB9
XRD
TR24
TR22
TR13
TR02
TCK1
A11
A10
A 1
A 8 A 9
D11
EB_RAS
XECS2
X R S T4
ESP_IN_L
256Fs
EDC10
RDATA
EAD7
EAD3
EDD11
EAE4
EAE0
EAB5
EAA4
EAA0
EDA7
EAD6
EDD7
TR20 TR30
TR34
XRST 4
EDA7
EDA11
SYNC
TR02
A 2
A 4
D12
D14
EB_RAS
E1_INT0
EDB5
E2_INT0
EE_CAS
EAB5
TR25
TR40
TR45
TR15
TR42
EA_CAS
TR03
TR11
TR05
A10
A 4
A11
A 1
A 3
A12
A 1
A12
EDB6
EDB11
EDC6
EDC7
EDC5
EDC10
EAE5
EAE9
EAA9
TR22
TR21
TR12
TR05
A11
A 2
D13
D14
D10
TR44
ESPINT1
XECS1
EDATA_L
LDATA
EAB6
EDD10
EDD6
EAE8
EAE3
EAB9
EAA8
EAA3
EDA11
EAD9
TR25
EAD1
TR32
TR35
EA_WE
EAA4
TCK0
XRST 2
T C K 0 A 7
A11
D12
D11 D12
D 8
D15
D13
EAC5
EAC4
EDB7
EDB4
ED_WE
EAB1
X H W R
EAD5
TR33
TR41
TR13
SYNC
EAC[0..9]
D[8..15]
A[0..18]
EAD[0..9]
ED C [4. . 11 ]ED A [4 . .1 1 ]
EAB[0..9]
EAA[0..9]
ED B [4 . .1 1 ] EDD [ 4. . 1 1]
EAE[0..9]
EDE8
EDE10
EDE6
EDE9
EDE4
EDE10
EDE9
EDE11
EDE6
EDE5
EDE4
EDE7
EDE7
EDE11
EDE5
EDE8
EDE[4..11]
ESPRES
ESPRES
XRES
ESPRES ESPRES
ESPRESESPRES
D
D
D
D
+5D
+5D
D
D
D
+5D
D
D
+5D
D
D
D
D
+5D
D
+5D
D
D D
D
D
D
+5D
+5D
D
D
D
DD
D
+5D
+5D
+5D
+5D
D
+5D
D
D
D
+5D
D
D
D
D
D
D
D
D
D
D
DD
D
D
D
+5D
D
+5D
D
+5D
D
+5D
+5D
D
D
D
+5D
+5D
+5D
D
+5D
D
+5D
+5D
D
+5D
DD
DD D
+5D
D
+5D
D
D
+5D +5D
+5D
+5D +5D
C122
C105 C91
R236
R50
100
C149
R95
C96
C102
C147
C110
C101
C187
0.1
R46
100
C138C137
C115C112
R54
1 0
R91
IC18
TC170C140
7 4
7 5
7 6
7 7
7 8
7 9
8 1
8 2
8 3
8 4
8 5
8 6
8 7
8 8
9 2
9 3
9 4
9 5
9 6
9 7
9 8
9 9
6 6
6 7
6 8
6 9
7 0
6 2
6 1
6 0
5 9
5 8
5 7
5 6
5 1
5 2
5 3
101
102
103
104
105
106
107
6 4
6 5
132
133
136
137
138
139
140
141
142
2 7
2 6
2 5
2 4
2 3
2 2
2 1
2 0
1 7
1 6
4 9
4 8
4 7
4 6
4 5
4 4
4 3
4 2
3 9
3 8
3 7
3 6
3 5
3 4
3 3
3 2
1 0
9
8
7
6
5
4
3
1 3
1 4
1 5
2 9
111
112
113
114
115
116
117
118
120
121
122
123
124
125
128
129
130
131
1
1 2 1 8 3 0 4 1 5 4 7 2 9 0
108 109 126 134 144
2
1 1
1 9
2 8
3 1
4 0
5 0
5 5 6 3 7 1 7 3 8 0 8 9 9 1
100 110 119 127 135 143
C175
NIU
R38
1 0
R37
1 0
C151
C134
C125
C150
C98
C148
X 2
67MHz
O E 1
GND
2OUT 3
VDD
4
R237
R39
1 0 R41
1 0
C124
C130
C107
IC60
TC74VHC163F
D
6C
5B
4A
3
ENT
1 0 ENP
7
L O A D
9
CLR
1
C K
2
Q D 1 1
Q C 1 2
Q B 1 3
Q A 1 4
RCO 1 5
VDD 1 6
VSS
8
IC17
TC170C140
7 4
7 5
7 6
7 7
7 8
7 9
8 1
8 2
8 3
8 4
8 5
8 6
8 7
8 8
9 2
9 3
9 4
9 5
9 6
9 7
9 8
9 9
6 6
6 7
6 8
6 9
7 0
6 2
6 1
6 0
5 9
5 8
5 7
5 6
5 1
5 2
5 3
101
102
103
104
105
106
107
6 4
6 5
132
133
136
137
138
139
140
141
142
2 7
2 6
2 5
2 4
2 3
2 2
2 1
2 0
1 7
1 6
4 9
4 8
4 7
4 6
4 5
4 4
4 3
4 2
3 9
3 8
3 7
3 6
3 5
3 4
3 3
3 2
1 0
9
8
7
6
5
4
3
1 3
1 4
1 5
2 9
111
112
113
114
115
116
117
118
120
121
122
123
124
125
128
129
130
131
1
1 2 1 8 3 0 4 1 5 4 7 2 9 0
108 109 126 134 144
2
1 1
1 9
2 8
3 1
4 0
5 0
5 5 6 3 7 1 7 3 8 0 8 9 9 1
100 110 119 127 135 143
R36
1 0
R35
1 0
C159
1000P
R44
100
C173
NIU
R40
1 0
RA20
2 2 1 8
2 7
3 6
4 5
C108
C132
C109
C140
C162
1000P
R238
C174
NIU
C95
C100 C92
C136
IC59
TC74VHC163F
D
6C
5B
4A
3
ENT
1 0 ENP
7
L O A D
9
CLR
1
C K
2
Q D 1 1
Q C 1 2
Q B 1 3
Q A 1 4
RCO 1 5
VDD 1 6
VSS
8
R52
10k
C189
0.1
R96
R90
R48
1 0
RA21
2 2 1 8
2 7
3 6
4 5
C123
C131
C99
C127
C157
NIU
R235
R234
C153
1000P C154
1000P
C106
RA18
2 2 1 8
2 7
3 6
4 5
C152
C128
C142
C118
C121
C155
NIU
C179
NIU
R94
IC21
TC170C140
7 4
7 5
7 6
7 7
7 8
7 9
8 1
8 2
8 3
8 4
8 5
8 6
8 7
8 8
9 2
9 3
9 4
9 5
9 6
9 7
9 8
9 9
6 6
6 7
6 8
6 9
7 0
6 2
6 1
6 0
5 9
5 8
5 7
5 6
5 1
5 2
5 3
101
102
103
104
105
106
107
6 4
6 5
132
133
136
137
138
139
140
141
142
2 7
2 6
2 5
2 4
2 3
2 2
2 1
2 0
1 7
1 6
4 9
4 8
4 7
4 6
4 5
4 4
4 3
4 2
3 9
3 8
3 7
3 6
3 5
3 4
3 3
3 2
1 0
9
8
7
6
5
4
3
1 3
1 4
1 5
2 9
111
112
113
114
115
116
117
118
120
121
122
123
124
125
128
129
130
131
1
1 2 1 8 3 0 4 1 5 4 7 2 9 0
108 109 126 134 144
2
1 1
1 9
2 8
3 1
4 0
5 0
5 5 6 3 7 1 7 3 8 0 8 9 9 1
100 110 119 127 135 143
IC8A
TC7W04F
17
R53
100
RA25
2 2
1 8
2 7
3 6
4 5
C90
R42
1 0
C104
C176
10/16
21
RA23
2 2
1 8
2 7
3 6
4 5
L 1
N2012Z601
C120
C129
C139
C133
C111
C103
R92
C146
R93
R32
100 R34
100
RA26
2 2
1 8
2 7
3 6
4 5
C88
C126
IC61
TC74VHC163F
D
6C
5B
4A
3
ENT
1 0 ENP
7
LOAD
9
CLR
1
C K
2
Q D 1 1
Q C 1 2
Q B 1 3
Q A 1 4
RCO 1 5
VDD 1 6
VSS
8
C161
NIU
R47
1 0
C94
C143
C117
C135
C113
C119
C178
NIU
C177
1.0
C93
IC30A TC74VHC00F
1
23
C116
C89
C188
0.1
R45
10k
C141
C97
C145
R239
R233
IC19
TC170C140
7 4
7 5
7 6
7 7
7 8
7 9
8 1
8 2
8 3
8 4
8 5
8 6
8 7
8 8
9 2
9 3
9 4
9 5
9 6
9 7
9 8
9 9
6 6
6 7
6 8
6 9
7 0
6 2
6 1
6 0
5 9
5 8
5 7
5 6
5 1
5 2
5 3
101
102
103
104
105
106
107
6 4
6 5
132
133
136
137
138
139
140
141
142
2 7
2 6
2 5
2 4
2 3
2 2
2 1
2 0
1 7
1 6
4 9
4 8
4 7
4 6
4 5
4 4
4 3
4 2
3 9
3 8
3 7
3 6
3 5
3 4
3 3
3 2
1 0
9
8
7
6
5
4
3
1 3
1 4
1 5
2 9
111
112
113
114
115
116
117
118
120
121
122
123
124
125
128
129
130
131
1
1 2 1 8 3 0 4 1 5 4 7 2 9 0
108 109 126 134 144
2
1 1
1 9
2 8
3 1
4 0
5 0
5 5 6 3 7 1 7 3 8 0 8 9 9 1
100 110 119 127 135 143
IC20
TC170C140
7 4
7 5
7 6
7 7
7 8
7 9
8 1
8 2
8 3
8 4
8 5
8 6
8 7
8 8
9 2
9 3
9 4
9 5
9 6
9 7
9 8
9 9
6 6
6 7
6 8
6 9
7 0
6 2
6 1
6 0
5 9
5 8
5 7
5 6
5 1
5 2
5 3
101
102
103
104
105
106
107
6 4
6 5
132
133
136
137
138
139
140
141
142
2 7
2 6
2 5
2 4
2 3
2 2
2 1
2 0
1 7
1 6
4 9
4 8
4 7
4 6
4 5
4 4
4 3
4 2
3 9
3 8
3 7
3 6
3 5
3 4
3 3
3 2
1 0
9
8
7
6
5
4
3
1 3
1 4
1 5
2 9
111
112
113
114
115
116
117
118
120
121
122
123
124
125
128
129
130
131
1
1 2 1 8 3 0 4 1 5 4 7 2 9 0
108 109 126 134 144
2
1 1
1 9
2 8
3 1
4 0
5 0
5 5 6 3 7 1 7 3 8 0 8 9 9 1
100 110 119 127 135 143
C160
1000P
R49
100
R55
1 0
C144
C114
C158
NIU
C156
NIU
R51
100
R31
10k
C181
0.1
IC8D
TC7W04F
84
C182
0.1
IC8C
TC7W04F
6 2
IC30D
TC74VHC00F
1 2
1 3 1 1
IC30C
TC74VHC00F
9
1 0 8
IC30B
TC74VHC00F
4
56
IC30E
TC74VHC00F
1 47
C190
0.1
IC8B
TC7W04F
3 5
IC66C
TC7W08F
84
C332
0.1
IC66B
TC7W08F
5
63
IC63
HM514800CJ6Z
A 9
9
A 8
2 0 A 7
1 9 A 6
1 8 A 5
1 7 A 4
1 6
A 3
1 3 A 2
1 2 A 1
1 1 A 0
1 0 N C 6
N C 2 1
RAS
8CAS
2 3 W E
7
O E
2 2
I/O7 2 7
I/O6 2 6
I/O5 2 5
I/O4 2 4
I/O3 5
I/O2 4
I/O1 3
I/O0 2
VCC 1
VCC 1 4
VSS 1 5
VSS 2 8
IC23
HM514800CJ6Z
A 9
9
A 8
2 0 A 7
1 9 A 6
1 8 A 5
1 7 A 4
1 6
A 3
1 3 A 2
1 2 A 1
1 1 A 0
1 0 N C 6
N C 2 1
RAS
8
CAS
2 3
W E
7
O E
2 2
I/O7 2 7
I/O6 2 6
I/O5 2 5
I/O4 2 4
I/O3 5
I/O2 4
I/O1 3
I/O0 2
VCC 1
VCC 1 4
VSS 1 5
VSS 2 8
IC24
HM514800CJ6Z
A 9
9A 8
2 0
A 7
1 9 A 6
1 8 A 5
1 7 A 4
1 6 A 3
1 3
A 2
1 2 A 1
1 1 A 0
1 0 N C 6
N C 2 1
RAS
8
CAS
2 3
W E
7
O E
2 2
I/ O 7 2 7
I/ O 6 2 6
I/ O 5 2 5
I/ O 4 2 4
I/ O 3 5
I/ O 2 4
I/ O 1 3
I/ O 0 2
VCC 1
VCC 1 4
VSS 1 5
VSS 2 8
IC25
HM514800CJ6Z
A 9
9A 8
2 0 A 7
1 9 A 6
1 8 A 5
1 7 A 4
1 6 A 3
1 3 A 2
1 2 A 1
1 1 A 0
1 0 N C 6
N C 2 1
RAS
8
CAS
2 3
W E
7
O E
2 2
I/O7 2 7
I/O6 2 6
I/O5 2 5
I/O4 2 4
I/O3 5
I/O2 4
I/O1 3
I/O0 2
VCC 1
VCC 1 4
VSS 1 5
VSS 2 8
IC64
HM514800CJ6Z
A 9
9A 8
2 0 A 7
1 9 A 6
1 8 A 5
1 7 A 4
1 6 A 3
1 3 A 2
1 2 A 1
1 1 A 0
1 0 N C 6
N C 2 1
RAS
8
CAS
2 3
W E
7
O E
2 2
I/O7 2 7
I/O6 2 6
I/O5 2 5
I/O4 2 4
I/O3 5
I/O2 4
I/O1 3
I/O0 2
VCC 1
VCC 1 4
VSS 1 5
VSS 2 8
C167
1.0
C164
1.0
C166
1.0
C 1 6 9
1.0
IC31A
TC7W74F
D
2
C K
1Q5
Q3
P R 7
C R
6
C170
1.0
C172
1.0 C165
1.0
IC31B
TC7W74F
VCC 8
GND
4
C163
1 . 0C 1 7 1
1.0
C168
1.0
R33
10k
R43
10k
IC66A
TC7W08F
1
27
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
18
ESP BLOCK
JP-8080
Jul, 1998

(44.1kHz)
B
yp
ass
Condenser
for 23-24
p
in
(SYNC = 2Fs = 88.2kHz)
B
yp
ass
Condenser
for 2-3
p
in
DATA FORMAT 0
ADC : 16-bit, Left-justified
DAC : 16-bit, Right-justified
B
yp
ass
Condenser
for 13-14
p
in
(BCLK = 64Fs)
(WCLK = 2Fs = 88.2kHz)
ESPDAC_L
SYNC
ESP_IN_L
256Fs
Input_R ESP_IN_R
Input_L
64Fs
R-OUT
RDATA
WCLK
LDATA
DAC_OUT_L
BCLK
DAC_OUT_R
L-OUT
EDATA_L
RSTB
RSTB
FER +5
+5D
A
+5D
A
A
A
A
A
A
D
A
+5D
A
+15
D
A
A
FER +5
A
+15
- 15D
+5D
+5D
D DD
+5D
D
+5D
D
+5D
C247
10/16
IC32
PCM3001
VINL
1
VCC1 2
AGND1
3
VREFL
4
VREFR
5
VINR
6
CINPR
7CINNR
8
CINNL
9CINPL
1 0
VCOM 1 1
VOUTR 1 2
AGND2
1 3 VCC2 1 4
VOUTL 1 5
LRCIN 1 6
BCKIN 1 7
DIN 1 8
DOUT 1 9
XTI
2 0
XTO
2 1
CLKIO
2 2
VDD 2 3
DGND
2 4
FMT2
2 5 FMT1
2 6 FMT0
2 7
RSTB
2 8
C243 470P
C250
0.1
C252
2.2/50
C244
0.1
IC27A
TC7W08F
1
27
C248
10/16
IC33A
TC7W04F
1 7
IC27B
TC7W08F
5
63
IC34B
TC74HC74F
D
1 2
C K
1 1 Q9
Q8
P R 1 0
C R
1 3
C253
0.1
C249
10/16
C245 10/16
IC34A
TC74HC74F
D
2
C K
3Q5
Q6
P R 4
C R
1
C246 470P
R67
1 0
C251
10/16
C325
2.2/50
IC33B
TC7W04F
3 5
C242 10/16
IC36
UPD63200GS
DVDD 4
AVDD 7 AVDD 8
LRCK
1 3
CLK
1 6
SI/LSI
1 5
18/16SEL
3
4/8FS
1
LR/RSI
1 4
L.OUT 1 1
R.OUT 6
R.REF 9
L.REF 1 0
DGND
2
AGND
5
AGND
1 2
C215
150P
R80
100k
C214
10/16
21
R77
10k
R69
22k
C218
10/16
2 1
C212
10/16
2 1 IC37A
UPC4570G
+
-
2
31
R73
100k R74
100k
C209
150P
R78
22k
C208
0.1
C211
10/16
2 1
C210
10/16
2 1
IC37B
UPC4570G
+
-
6
57
R68
10k
R70
100k
C213
10/16
21
C205
0.1
C207
10/16
21
C206
0.1
C216
0.1 C217
0.1
C204
0.1
IC35
TA7805F
IN 1 OUT
3
COM
2
R103
100
C235
0.1
C233
0.1
IC37C
UPC4570G
+
-
84
C185
0.1
IC27C
TC7W08F
84
C193
0.1
IC33D
TC7W04F
84
IC33C
TC7W04F
6 2
C202
0.1
IC34C
TC74HC74F
VCC 1 4
GND
7
IC67
M51953AFP
RST 6
DLY 5
VCC
7
GND
4
N C 1
N C 2
N C 3
N C 8
C335
0.1 C336
10/16
R254
10k
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U19
AD/DA BLOCK
JP-8080
Jul, 1998

to PANEL
to PANEL
EXT IN L
(MONO)
EXT IN U
MUTE
LED_U_G
MIC_SELECT
MIC_IN
INPUT REAR
IN-U-RTN
PEAK LOWER
INPUT FRONT
LED_U_R
MIC_IN
IN-L-RTN
PEAK LOWER
INPUT REAR
PEAK UPPER
INPUT FRONT
LED_L_R
IN-L-SEND
IN-U-SEND
MUTE
LED_L_G
PEAK UPPER
Input_L
Input_R
AGND
AGND
A
A
A
A
A+15
+15
A
+15
+15
A
A
A
A
A
A
A
A
A
+15
A
- 15
AA
A
A
A
A
A
A
A
- 15A
A
A
A
A
- 15
A
A
A
- 15
- 15
A
A
A
A
A
+5D
A
A
A
A
- 15
A
A
A
+15
- 15
+15
- 15
+15
A
- 15- 15- 15
+15
A
A
A A
+15
- 15A - 15
A
+15 +15
- 15
+15
- 15
A
+15
A
R246
10k
C260
10/16
21
C258
10/16
2 1
IC43A
UPC4570G
+
-
2
31
R198
680
C272
1/50
R108
100k
R150
3.3k
R117
47k
JK3
HLJ7101-01-3010
2
4
1
C329
150P
Q 8
2SC4081
1
2 3
IC43B
UPC4570G
+
-
6
57
R183
33k
R187
100
R185
100
R119
33k
C326 150P
R188
5.6k
Q18
RN1307
1
2 3
R191
100k
R160
100k
C267
1/50
R156
220
R151
100k
R143
47k
R107
47k
IC44A
UPC4570G
+
-
2
31
C273
10P
C269
22/16
Q 6
2SC4081
1
2 3
IC51A
UPC4570G
+
-
2
31
IC46B
UPC4570G
+
-
6
57
C330
3300P
CN3
52147-0510
1
1
2
2
3
3
4
4
5
5
R177
47k
R154 100
C266 150P
R142
47k
R178
100k
R161 33k
R135
1M
C263
150P
R245
10k
R136
56k
R193
47k
Q17
RN2307
1
3 2
R153
12k
R162
10k
C328
150P
R110
3.3k
R179
47k
C293
10/25
R126
1.8k
R163
10k
JK2
HLJ7101-01-3010
2
4
1
R180
100k
R207
12k
R120
220
R118
100k
R244
47k
C259
22/16
IC54A
M5218AFP
+
-
2
31
R189
2.7k
R209
2 2
R164
33k
R114
33k
R144
100k
Q16
2SA1576A
1
32
IC50A
UPC4570G
+
-
2
31
R134
22k
C271
47P
Q15
2SA1576A
1
32
IC53A
UPC4570G
+
-
2
31
IC54B
M5218AFP
+
-
6
57
R184
33k
R113
33k
R138
150k
C277
47P
C327 150P
C276
22/16
IC51B
UPC4570G
+
-
6
57
R190
2.7k
R152
150k
R149
1M
C256 150P
Q23
RN2307
1
3 2
R159
47k
R141
33k
IC46A
UPC4570G
+
-
2
31
C275 150P
R197
680
R139
12k
C261
47P
C270
10/16
21
R140
3.3k
IC48
M5241L
1 2
3 4 5
6
7
89
1 0
C331
3300P
C268
10/16
2 1
R106
56k
Q 7
2SK368GR
3
1 2
R137
1k
IC53B
UPC4570G
+
-
6
57
IC44B
UPC4570G
+
-
6
57
R186
5.6k
R167
100k
R112
1k
R116
47k
R251
100k
R148
22k
Q26
2SC3326A
1
2 3
Q27
2SC3326A
1
2 3
CN6
52147-0710
11
22
33
44
55
66
77
R155
1.8k
L16
N2012Z102T01
L18
N2012Z102T01
L15
N2012Z102T01
L17
N2012Z102T01
DA11
DA204U
21
3
DA12
DA204U
21
3
R252
100
R253
180 DA13
DAN202K
1 2
3
DA14
DAN202K
1 2
3
C274
10/16
2 1
Q 9
2SK368GR
3
12
R147
100k
DA28
DAN202K
12
3
DA29
DAN202K 12
3
DA22
DAN202K
1 2
3
DA23
DAN202K
12
3
DA24
DAN202K
1 2
3
DA25
DAN202K
1 2
3
DA26
DAN202K
1 2
3
DA27
DAN202K
12
3
DA32
DAN202K
12
3
DA33
DAN202K
1 2
3
DA30
DAN202K
12
3
DA31
DAN202K
1 2
3
IC44C
UPC4570G
+
-
84
IC46C
UPC4570G
+
-
84
IC54C
M5218AFP
+
-
84
C308
0.1
C320
0.1
C304
0.1
C301
0.1
R192
100k
IC50C
UPC4570G
+
-
84
IC51C
UPC4570G
+
-
84
C317
0.1
C305
0.1
C316
0.1
C315
0.1
IC43C
UPC4570G
+
-
84
C319
0.1 C322
0.1
C302
0.1
IC50B
UPC4570G
+
-
6
57
IC53C
UPC4570G
+
-
84
C318
0.1
C303
0.1
C306
0.1
GAIN 0dB(*1.0)
GAIN 30dB(*31.3)
GAIN 0dB(*1.0)
GAIN 24.6dB
(*17.0)
GAIN 24.6dB
(*17.0)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
20
INPUT BLOCK
JP-8080
Jul, 1998
