Roline 14.01.3586-5 User manual

HDMI UHD Splitter 1x4
HDMI UHD Splitter1x4
14.01.3586
User Manual

HDMI UHD Splitter 1x4
1
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
This is a high-performance and small-sized HDMI 2.0 UHD Splittter with
hot plug and iron shell. It distributes the input of the HDMI signal into
four identical outputs at the same time. It provides high performance
audio and video output through HDMI cables up to 4k*2k@60HZ
resolution and is capable of receiving and transmitting up to
6Gbps/600MHz bandwidth.
2.0 FEATURES
 One HDMI Input, four HDMI outputs
 12-bit Deep Full HD, Full 3D, HDR and 4K2K 60Hz video
 Supports HDMI wide frequency max up to 600MHZ
 Supports compressed audio
 Supports HDCP 2.2
3.0 SPECIFICATIONS
Input/Output Connector
Input
HDMI X1
Output
HDMI X
4
Operating Frequency
Vertical Frequency Range 24/30/50/60Hz
Video Amplifier
Bandwidth
6Gbps/600MHz
Resolutions (HDTV)
Interlaced (50&60Hz) 480i,576i,1080i
Progressiv
e
(50&60Hz)
Max up to 4kx2k@60Hz
Physical
Size(L-W-H) 123x51x20mm
Weight
(Net)
156g
Power Requirement
External Power Supply
5V/2A
Power
C
onsumption (Max)
4.2
W
Note: Specifications are subject to change without notice.

HDMI UHD Splitter1×4
2
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
 Main unit
 User manual
 5V DC power supply
5.0 CONNECTION
1) Connect the HDMI video source to the HDMI input of the Splitter with
one HDMI cable (HDMI cables are optional).
*Please refer to connection diagram section
2) Connect the four outputs of the Splitter to four displays.
3) Turn on the power.
6.0 DIAGRAM
