Rolls MS112 User manual
SPECIFICATIONS:
IN Connectors: XLR
OUT Connectors: XLR
Size: 3.75"w x 5"d x 1.5"h
Thick powder coated steel chassis..
100% Handcrafted in Salt Lake City, UT.
Rolls Corporation
Salt Lake City, UT
9/19
Made in USA ww.rolls.com
Made in USA ww.rolls.com
MS112
Push to talk
XLR A-B switch
All this and it is 100% Handcrafted in Salt Lake City, UT.
What's in the box?
1 - Made in USA MS112
1 - This owners manual
1 - Rolls PS27s Power supply
Thank you for purchasing the MS112. We sincerely appreci-
ate the opportunity to build a product for you and participate
in your love of quality music and sound. We love what we do
and we’re happy to help. Rolls products are hand built in Salt
Lake City, Utah by people who care about high quality audio.
MS112 XLR A-B switch
- XLR female input and XLR male output jacks
- Selectable Momentary or latching
- Status indicator to let you see what output is active
- Bottom panel screw holes for convenient mounting
This device momentarily mutes (or talks) a microphone
or XLR signal between the A or B XLR outputs. This
function is very handy in the event of a sneeze, cough,
or other possible distracting noise. Or when you need to
control when a mic is active for announcing or paging.
Or when switching between two dierent outputs.
OPERATION: To mute or send a microphone signal, connect the balanced XLR cable to the female input jack on the MS112. Connect
the male XLR output jacks to your next devices. Press and hold the switch for the amount of time you want the signal sent to the A out-
put. To hear the mic signal again on the B output, release the switch. The MS112 can be congured to “push for momentary” or “Push
for latching” by selecting the internal switch. The switch can be accessed from the side of the MS112.
Switch for changing the
orientation of the MS112
from a latching switch to
momentary. Momentary or latching
switch.
XLR jacks: Female input, Male outputs.
9-15
VDC
B
OUT
MS112
XLR A/B SWITCH
gnd
lift
INPUT
A
OUT
MOMENTARY
LATCHING
PUSH TO TALK
Ground - lift switch for A out XLR.
9-15 VDC: Connects to the included
Rolls PS27s power adapter.
Status led to indicate when signal is
present on A output. When light is o
signal is sent to B output.
In momentary mode
signal is sent to the B
output when powered on.
