Romantis Satellite Communications UHP-8000 Operating and installation instructions

DUAL SATELLITE ROUTER
UHP-8000
GENERAL DESCRIPTION AND INSTALLATION GUIDE
DOCUMENT RELEASE 3.2
[UHP.8R32.EN]
JANUARY 2015

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 2 www.uhp.net
CONTENT
Acronyms and Abbreviations ..........................................................................................................4
Introduction.....................................................................................................................................6
Required level of qualification ..................................................................................................................6
Document version and applicability..........................................................................................................6
Copyright...................................................................................................................................................6
1. General description ..............................................................................................................7
1.1 System overview.......................................................................................................................7
1.1.1 Purpose.....................................................................................................................................7
1.2 Router composition ..................................................................................................................7
1.3 Measurement equipment, tools and accessories ....................................................................7
1.4 Labeling and sealing..................................................................................................................8
1.5 Packaging and content..............................................................................................................8
1.6 Description and principles of operation ...................................................................................8
1.6.1 Overview...................................................................................................................................8
1.6.2 Power connector (Power input A/B) ........................................................................................9
1.6.3 USB CONSOLE (USB A/B) ..........................................................................................................9
1.6.4 IF input (RX) ..............................................................................................................................9
1.6.5 LAN interface connector (LAN A/B) ........................................................................................10
1.6.6 Modulator output (TX)............................................................................................................10
1.6.7 “ERROR” Indicator ..................................................................................................................11
1.6.8 “STATUS” Indicator.................................................................................................................11
1.6.9 “LOCK” Indicator.....................................................................................................................11
1.6.10 “TDMA” Indicator ..............................................................................................................11
1.6.11 “SCPC” Indicator ................................................................................................................12
1.6.12 “TX” Indicator ....................................................................................................................12
2. Operations ..........................................................................................................................13
2.1 Operational limits ...................................................................................................................13
2.2 Preparation for use.................................................................................................................13
2.2.1 Unpacking ...............................................................................................................................13
2.2.2 Installation ..............................................................................................................................13
2.2.3 Connecting to external devices ..............................................................................................13
2.2.4 Powering on............................................................................................................................14
2.2.5 Local access to router via HTTP interface...............................................................................15
2.2.6 Local access via USB................................................................................................................15
2.2.7 Remote Telnet access .............................................................................................................15
2.2.8 Command Interface ................................................................................................................15
3. Operations ..........................................................................................................................16

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 3 www.uhp.net
3.1 Software updates....................................................................................................................16
3.2 Powering off ...........................................................................................................................16
3.3 Safety instructions for operations ..........................................................................................16
3.4 Actions in case of fire..............................................................................................................16
4. Troubleshooting .................................................................................................................17
4.1 Replacement of modules........................................................................................................18
4.1.1 Common recommendations...................................................................................................18
4.1.2 Safety instructions ..................................................................................................................18
5. STORAGE, TRANSPORTATION AND DISPOSAL....................................................................19
FIGURES
Figure 1 Structure of UHP Manuals...............................................................................................................6
Figure 2: Standard labeling of satellite router ..............................................................................................7
Figure 3: UHP-8000 satellite router –rear view ...........................................................................................8
Figure 4 Standard internal configuration of UHP-8000 router .....................................................................8
Figure 5 Internal configuration of UHP-8000 in Hub (HBIC) mode ...............................................................9
Figure 6 Internal configuration of UHP-8000 in dual Inroute (ICIC) mode .................................................10
Figure 7 Satellite Router UHP-8000 series front view.................................................................................11
Figure 8 Example of router’s connection in a basic mode of operation.....................................................14
Figure 9 Example of router's connection in Hub mode (with 3 Inroutes)...................................................14
TABLES
Table 1 Operational limits ...........................................................................................................................13
Table 2 Troubleshooting guide....................................................................................................................17

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 4 www.uhp.net
ACRONYMS AND ABBREVIATIONS
16APSK
16 Amplitude and Phase-shift keying or Asymmetric Phase-shift keying, (APSK), is a digital modulation scheme that
conveys data by changing or modulating both the amplitude and the phase of a reference signal (the carrier wave).
32APSK
32 Amplitude and Phase-shift keying or Asymmetric Phase-shift keying, (APSK), is a digital modulation scheme that
conveys data by changing, or modulating, both the amplitude and the phase of a reference signal (the carrier wave).
8PSK
Phase-shift keying (PSK) is a digital modulation scheme that conveys data by changing or modulating the phase of a
reference signal (the carrier wave).
AGC
Automatic Gain Control
BCH
BCH code is a multilevel cyclic variable-length digital error-correcting code used for correcting multiple random error
patterns. BCH codes may also be used with multilevel phase-shift keying whenever the number of levels is a prime
number or a power of a prime number.
BUC
Block Up-Converter (BUC) is used in the transmission (uplink) of satellite signals. It converts a band (or "block") of
frequencies from a lower frequency to a higher frequency.
C/N
Carrier-to-noise ratio, often written as CNR or C/N, is the signal-to-noise ratio (SNR) of a modulated signal.
CRTP
Compressing IP/UDP/RTP Headers for Low-Speed Serial Links
DAMA
Demand Assigned Multiple Access. Channel establishment on demand.
DSCP
Differentiated Services Code Point (DSCP) is a 6-bit field in the header of IP packets for packet classification purposes.
DSCP replaces the outdated IP precedence, a 3-bit field in the Type of Service byte of the IP header originally used to
classify and prioritize types of traffic
DVB
Digital Video Broadcasting (DVB) is a suite of internationally accepted open standards for digital television.
Eb/No
Eb/N0 (the energy per bit to noise power spectral density ratio) is an important parameter in digital communication or
data transmission. It is a normalized signal-to-noise ratio (SNR) measure, also known as the "SNR per bit". It is especially
useful when comparing the bit error rate (BER) performance of different digital modulation schemes without taking
bandwidth into account.
EIRP
Effective Isotropically Radiated Power
ETSI
The European Telecommunications Standards Institute (ETSI) is an independent, non-profit, standardization
organization in the telecommunications industry (equipment makers and network operators) in Europe, with worldwide
projection.
FEC
In telecommunication and information theory, forward error correction (FEC) is a system of error control for data
transmission, whereby the sender adds redundant data to its messages, also known as an error-correction code.
Frame
TDMA service packet describing which station should transmit in which time slot . Generated ~10 times per second.
Hard priority
Method of transmission queues handling when packets from lower priority queue are not transmitted until all packets
from higher priority queue are transmitted.
HTTP
Hypertext Transfer Protocol (HTTP) is an application-level protocol for distributed, collaborative, hypermedia
information systems.
HUB
Central Station of satellite network that is managing all the terminals and resources
Hubless
Special mode of operation when all stations are transmitting to one TDMA carrier and all receiving this carrier.
HW
Hardware
ICMP
The Internet Control Message Protocol (ICMP) is used by networked devices to send error messages—indicating, for
instance, that a requested service is not available or that a host or router could not be reached.
IESS
Intelsat Earth Station Standards
IFL
Connection from the indoor equipment (modem/router) to the outdoor equipment at the antenna normally involves
two inter-facility (IFL) cables.
IGMP
The Internet Group Management Protocol (IGMP) is a communications protocol used by hosts and adjacent routers on
IP networks to establish multicast group memberships.
Inroute
Channel from stations to hub.
IP
IP is the usual abbreviation for Internet Protocol.
LDPC
Low-density parity-check (LDPC) code is a linear error correcting code, a method of transmitting a message over a noisy
transmission channel, and is constructed using a sparse bipartite graph.
LNB
Low-noise block converter is the receiving converter installed at satellite antenna.
Local oscillator
Oscillator built into RF block converter ( BUC or LNB ). Value of LO is usually written on block enclosure or in datasheet.
Long frames
DVB-S2 frames 64800 bits long (including FEC). Require slightly lower C/N than short frames.
Master
Main station of Hubless network. Master allocates bandwidth and performs stations acquisition.
MCPC
Multiple channels per carrier. All TDM carriers generated by UHP can be treated as MCPC. Even if they are called SCPC.
Mesh
Capability of station allowing to receive other stations via TDMA link.
MF-TDMA
TDMA working on several RF channels simultaneously. All MF channels work as one aggregate TDMA channel.
MODCOD
Modulation and coding mode.
NMS
Network Management System
Node Station
Terminal of satellite network which is able to receive information directly from other network terminals
ODU
Out-Door Unit
Outroute
Forward TDM channel (MCPC) from HUB to stations.
QPSK
Phase-shift keying (PSK) is a digital modulation scheme that conveys data by changing, or modulating, the phase of a
reference signal (the carrier wave).
RF level
Absolute RF level of entire signal (carrier + adjacent carriers) expressed in dBm.
RSV
Reed–Solomon error correction is an error-correcting code that works by oversampling a polynomial constructed from
the data.

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 5 www.uhp.net
SCPC
Single Channel Per Carrier
Short frames
DVB-S2 frames 16200 bits long (including FEC). Advisable to use at lower symbol rates. Produce less delay than Long
frames.
SNMP
Simple Network Management Protocol
SNTP
Simple Network Time Protocol (SNTP) is a protocol and software implementation for synchronizing the clocks of
computer systems over packet-switched, variable-latency data networks.
SNR
Signal-to-noise ratio is an electrical engineering measurement defined as the ratio of a signal power to the noise power
corrupting the signal.
SR
Symbol Rate
Star
Type of network with one central station (hub) and several peripheral stations.
SW
Software
TDM
Time Division Multiplexing
TDMA
Time Division Multiple Access
Telnet
Telecommunication Network (Telnet) is a network protocol used on the Internet or local area networks to provide a
bidirectional interactive communications facility. Typically, telnet provides access to a command-line interface on a
remote host via a virtual terminal connection.
Terminal
Earth Stations (usually VSAT) operated under management of network HUB
TFTP
Trivial File Transfer Protocol (TFTP) is a file transfer protocol, with the functionality of a very basic form of File Transfer
Protocol (FTP).
Timestamp
Time format used by UHP. Plus sign at the beginning (+HH:MM:SS or +NN d HH:MM:SS)denotes relative time from some
event or UHP start-up. If UHP has time synchronized to hub or SNTP absolute time can be displayed. Time zone affects
absolute time.
Time-slot
Time interval for station transmission.
UDP
The User Datagram Protocol (UDP) is the set of network protocols used for the Internet. With UDP, computer
applications can send messages, in this case referred to as datagram, to other hosts on an Internet Protocol (IP) network
without requiring prior communications to set up special transmission channels or data paths.
USB
USB (Universal Serial Bus) is a specification to establish communication between devices and a host controller (usually
personal computers).
VLAN
A virtual LAN, commonly known as a VLAN, is a group of hosts with a common set of requirements that communicate as
if they were attached to the same broadcast domain, regardless of their physical location.
VoIP
Voice over Internet Protocol (VoIP) is a general term for a family of transmission technologies for delivery of voice
communications over IP networks such as the Internet or other packet-switched networks.
VSAT
Very Small Aperture Terminal –satellite earth station with small-size antenna
WFQ
Weighted fair queuing. Method of proportional division of bandwidth between transmission queues.
X-modem
Simple file-transfer protocol

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 6 www.uhp.net
INTRODUCTION
This document presents a general description of the UHP-8000 series satellite routers and is intended for
familiarization with the system capabilities and specifications. This manual describes all the key modes of the
router operations.
Required level of qualification
This manual is intended for engineering personnel operating VSAT networks. Such specialists should have
adequate educational credentials in the field of electronics and sufficient experience and skills in data networks
administration and satellite systems.
Document version and applicability
UHP VSAT platform is based on the universal satellite router UHP, which is available in different fully-compatible
hardware modifications. UHP satellite router is a basic element of any network architecture and can be used in any
combinations and at any hierarchy level. Router functional capabilities and its operating modes are determined by
the installed software and its configuration.
This manual is applicable to all UHP-8000 series satellite routers with software release 3.2 or higher. When
ordering this document, please specify its ID: [UHP.8R32.EN].
Figure 1 Structure of UHP Manuals
Copyright
The content of this document is the intellectual property of Romantis Inc. (referred to below as Romantis). Copying
or quoting this description as a whole or of any part of it without a written permission from Romantis is prohibited.
Network
Engineering
TDM/TDMA
Terminal
SCPC
Modem
Hubless
TDMA
Station
UHP-1000
UHP-8000
UHP-200
UHP-IFS
NMS
System Level
(Network engineering guide)
Hardware Level
(Installation guide and
specifications)
Service Level
(User manual)

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 7 www.uhp.net
1. GENERAL DESCRIPTION
1.1 System overview
1.1.1 Purpose
UHP satellite routers are essentially a universal solution for geographically distributed VSAT-class satellite
communication networks. UHP routers can be used to organize simple point-to-point channels, “star”- and
“mesh”-topology networks with several hierarchy levels and bandwidth-on-demand capabilities.
UHP-8000 dual satellite router is an integrated chassis with two UHP-1000 routers and IF subsystem that can be
used as two independent routers or as elements of some complex system (e.g. Hub, redundant modules, etc.).
1.2 Router composition
UHP-8000 router consists of:
1. Integrated UHP-1000 satellite router “A”;
2. Integrated UHP-1000 satellite router “B”;
3. IF subsystem with combiner and divider;
4. Integrated power supplies (individual for each router);
5. 1U rack-mountable chassis
1.3 Measurement equipment, tools and accessories
Standard computer (notebook) is required to configure and monitor status of UHP-8000 satellite router. The
computer must be equipped with a LAN interface and USB, and also have the following software installed:
Internet browser (WEB browser)
Telnet Client
The Terminal (e.g.: Hyperterminal, included in the OS Windows) (optional)
The router can be accessed via LAN or USB ports. Standard USB AM/BM cable (not supplied) is required for
connection to USB “Console” port of the satellite router.
Connection of a computer to the router via LAN interface is implemented through the Ethernet switch or hub via a
standard network cable with RJ-45 connectors (not supplied).
Figure 2: Standard labeling of satellite router

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 8 www.uhp.net
1.4 Labeling and sealing
The product is marked with the unique Serial Number on the bottom of the router’s case.
The warranty seals are located on the bottom of the product, at the junction of the two parts of the case.
Product’s warranty will automatically void if such labels have been removed, modified or damaged.
1.5 Packaging and content
Satellite router comes as an integrated chassis. It is recommended to keep original packaging throughout the
entire lifetime. Conservation, storage and transportation of the terminal must be in original packaging.
Standard package includes:
1. UHP-8000 dual satellite router
2. Power cables
1.6 Description and principles of operation
Figure 3: UHP-8000 satellite router –rear view
1.6.1 Overview
Figure 4 Standard internal configuration of UHP-8000 router
All the interfaces are located on the rear panel of the device. The indicators are located on the front panel.
Indication of each integrated router is located on the front panel of the chassis and similar to the standard display
of UHP- 1000 router. Indications on the left side of the front panel are related to the router "A", the indications on
the right side correspond to the router «B». The LAN and USB interfaces of each router are located on the rear
panel of UHP-8000 chassis and marked with «A» and «B», respectively.
UHP-1000
“A”
Tx
TDMA Rx
MCPC Rx
LAN
IF divider
TAP
Tx
IF combiner
LAN “A”
LAN “B”
Rx
USB “A”
USB “B”
DC
USB
UHP-1000
“B”
Tx
TDMA Rx
MCPC Rx
LAN
DC
USB
Power supply “B”
Power supply “A”
Power input “B”
Power input “A”
UHP-8000

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 9 www.uhp.net
USB PORTS MAY NOT BE AVAILABLE ON SOME VERSIONS OF UHP-8000 ROUTERS.
Depending on the ordered product’s configuration (mode of operation), interconnectivity of internal modules can
be configured with a different scheme. It applies only to connection of modulators and demodulators to interface
module (IF divider and combiner).
In the basic configuration (Figure 4) outputs of the modulators are summarized on the IF combiner ("Tx" output).
The IF combiner provides the transmission of IF signals, and can also transmit DC supply voltage and/or 10MHz
frequency reference for a BUC. Input signal from the "Rx" input is divided and fed to the inputs of all the
demodulators. The divider also provides a pass of DC and/or 10MHz reference frequency for LNB.
In HUB configuration (HBIC) (Figure 5) a high-speed demodulator of the satellite router “B” (acting as IC) is
connected to a «TAP» output of the IF combiner (“Tx” output) that allows synchronizing the router "B" with the
router “A” (acting as HB).
In dual Inroute configuration (ICIC) the “Tx” interface is used to input an Outroute signal from an external HB
module. This signal is divided and distributed to each of the high-speed demodulators for synchronization (see
Figure 6).
Figure 5 Internal configuration of UHP-8000 in Hub (HBIC) mode
1.6.2 Power connector (Power input A/B)
UHP-8000 router is powered with 100-240 VAC. UHP-8000 chassis has two independent power supplies (with
individual AC inputs) for each of the router respectively.
1.6.3 USB CONSOLE (USB A/B)
USB console ports provide local control of each of the integrated routers.
1.6.4 IF input (RX)
The RX interface is an input of the divider that distributes signals to the demodulators (see also 0). The router may
feed this input with 18 VDC power supply. Whether power source is on or off, the input can withstand external
UHP-1000
“A”
Tx
TDMA Rx
MCPC Rx
LAN
IF divider
TAP
Tx
IF combiner
LAN “A”
LAN “B”
Rx
USB “A”
USB “B”
DC
USB
UHP-1000
“B”
Tx
TDMA Rx
MCPC Rx
LAN
DC
USB
Power Supply “B”
Power Supply “A”
UHP-8000
Power input “B”
Power input “A”

UHP-8000 DUAL SATELLITE ROUTER
GENERAL DESCRIPTION AND INSTALLATION GUIDE, v3.2
© ROMANTIS 2015 10 www.uhp.net
voltage up to 50 VDC (power supply circuit is provided with a diode). Power supply circuit is protected with a
thermal fuse operating in case of short circuiting. After short circuiting is removed it may be required to disconnect
load from the Rx input for several seconds so as to allow the fuse to return to its initial state. Cable length and
cable quality (losses level) can affect the quality and possibility of receiving signals.
THE TOTAL CURRENT CONSUMED BY EXTERNAL EQUIPMENT SHOULD NOT BE IN EXCESS OF 750 MA. NORMALLY,
CURRENT CONSUMPTION BY DRO LNB -<150 MА, PLL LNB -<500 MА.
Figure 6 Internal configuration of UHP-8000 in dual Inroute (ICIC) mode
1.6.5 LAN interface connector (LAN A/B)
LAN connectors are purposed for connecting to Ethernet switch using a straight cable. These connectors are
connected directly with respective LAN outputs of the integrated routers. Bit rate 10 or 100 and duplex mode are
software selectable.
1.6.6 Modulator output (TX)
TX OUT OUTPUT CAN FEATURE 24 VDC WITH A HIGH SHORT-CIRCUIT CURRENT.SHORT CIRCUITING CAN CAUSE
SPARKLE SPREAD AND BURNS.THIS VOLTAGE CAN DAMAGE MEASUREMENT EQUIPMENT IF IT IS NOT PROTECTED AT ITS
INPUTS.SUPPLYING EXTERNAL VOLTAGE TO THIS CONNECTOR IS OBJECTIONABLE .SUPPLYING MORE THAN 24 VIS
PROHIBITED.
The purpose of “Tx” interface depends on the factory-selected mode of operation (see 0). The interface provides
transmission of IF signals, 10 MHz reference and 24 VDC power supply (if activated on the router).
WARNING! THE SUPPLY VOLTAGE AND THE REFERENCE SIGNAL SHOULD BE ACTIVATED ONLY ON THE ONE OF THE
ROUTERS!
UHP-8000 modulators are compatible with most satellite transmitters/converters (BUC), except that require to
explicit “TX On” FSK command.
UHP-1000
“A”
Tx
TDMA Rx
MCPC Rx
LAN
IF divider
TAP
Tx
IF divider
LAN “A”
LAN “B”
Rx
USB “A”
USB “B”
DC
USB
UHP-1000
“B”
Tx
TDMA Rx
MCPC Rx
LAN
DC
USB
Power Supply “B”
Power Supply “A”
UHP-8000
Power input “B”
Power input “A”
