Rompa 20192 User manual

1. Product Name
Musical Water Bed by ROMPA®
2. Product Code
20192 - Double
20193 - Queen
3. Colour
Available in a range of colours. The colour of the foam wall may vary (it is likely to be
grey or white)
4. Brief Description
Fine vibrations of rhythm, tone and beat can be produced through your music system,
which connects to the bed. These are picked up through the skin as tactile stimulations.
The bed adapts to the body shape giving warmth, comfort and muffled noise.

5. Contents
1x Left Hand Base complete with Speaker Grills
1 x Right Hand Base complete with Speaker Grills
1 x Amplifier
1 x Speaker to amplifier lead
1 x Radio Lead (a single plug on one end and split at the other so there are two plugs)
1 x Mains Lead
1 x Microphone
1 x Water Mattress comprising:
1 x PVC Outer Cover
1 x Heater Pad with controller attached
4 x Shaped foam walls (2 longer, 2 shorter walls)
Screws
1 x Waterbed Safety Liner
1 x Waterbed Bag
Fill Kit –Hose Pipe, Air Extractor, Conditioner (1 large or 2 small bottles), Tap
Connector, Puncture Repair Kit
6. Snoezelen® Stimulations
Sound
Touch
Vibration

7. Best Use
Play music with high bass sounds through the Musical Water Bed for maximum
vibrations. Adjust the volume as required.
8. Compatible ROMPA® Products
21986 - Hi-Fi Audio System
21850 - Portable CD player with USB Port and Audio input
12413 - Water Mattress Conditioner (4 fluid oz.)
9. Starting Up
It is advisable for two people to assemble the Water Mattress together.
Clear and clean a suitable space so the base pieces can be positioned near to a
double electrical socket.
The assembled Musical Water Bed will be heavy so it should not be moved far once
ready to be filled.
If placing the Musical Water Bed next to a wall, allow a small gap between the assembled
Musical Water Bed and the wall to allow the zip of the PVC Cover to be opened as required.
A working area should also be cleared near to its final position
10. Detailed Description
Fine vibrations of rhythm, tone and beat can be produced through your music system,
which connects to the bed. These are picked up through the skin as tactile stimulations.
The bed adapts to the body shape giving warmth, comfort and muffled noise, possibly
similar to foetal experiences in the womb. The bed has a wooden base and is mounted
on a giant loud speaker cabinet. The bed can also be used for interactive stimulation by
means of the included microphone to create your own sounds.
NOTE: THE WATER MATTRESS SHOULD BE KEPT SWITCHED ON ALL THE TIME
11. Safety
Always supervise the use of this product
Mattress requires 8 fluid ounces of conditioner a year (annually or 4 fluid ounces
every 6 months)
Do not exceed 30° on the controller. Above this will encourage sweating and below
may lead to condensation on your mattress.
Avoid contact with sharp or pointed objects e.g. shoe buckles.
Do not mix and match components from other water beds with these components

12. Technical Specification
Double :
Dimensions: 140 x 200 x 45cm Capacity: holds 450 litres
Queen :
Dimensions: 160 x 200 x 45cm Capacity: holds 500 litres
13. Installation
Assembly –Musical components
Fit the left hand base into the right hand base. Place the ‘hooks’ over the ‘cut-
outs’. The two jack socket plates B in the bases should be positioned side by
side and on the same side of the two bases.
hooks
cut-outs
(speakers are usually
covered by a box)

Place the bases in the required position.
Fit the two Speaker to Amplifier Leads by fitting the plugs (A) to the two jack
socket plates (B) in the bases of the Water Mattress.
Position the amplifier adjacent to the side of the bases
Connect the straight plug of the “Speaker to Amplifier” lead to the LS B and LS A
sockets in the Amplifier.
It does not really matter which end of the “Speaker to Amplifier” lead fits into the jack
socket place, however, we recommend that the shorter, black angle jack plugs (A) are
connected to the base of the Water Mattress to enable it to fit flush against a wall.

The connection will look like this:
Connect the Radio Lead (the connection cable with one jack plug at one end and two
smaller phono plugs at the other, red and white). Insert the large jack plug into your
music system headphone socket (shown in a music system below)
Connect the smaller white and red phono plugs into the AUX 1 sockets on the
Amplifier:

Please note: your music system must have a minimum capacity of 100W between
both speakers in order to obtain vibration. This is a typical capacity of many music
systems.
Plug in the amplifier and switch on. A red LED at the front will illuminate.
When connecting the Amplifier, ensure that the Master volume control dial has
been turned right down and then adjust as required.
Once the Musical Water Bed base has been constructed successfully and the music
system connected, then the Water Mattress needs to be assembled on the top of the
base. This operation is described below and in the separate Water Mattress
instructions.

Assembly - Water Mattress Components
Place the PVC cover C on the floor with the reinforced sections underneath and
the ROMPA® logo on top.
Unzip the cover, pull back the top section and leave open. If the bed is
positioned next to a wall attach a cord (e.g. coloured ribbon) to the zip to
facilitate opening and closing when filled.
When the cover is unzipped, you will see:
a) A coloured section in the middle –this is to give you an approximate
indication where to place the heater pad later. Take a mental note where
this is before the Base Boards are positioned as you will not see this through
the Base Boards. The heater pad needs to be roughly in the centre.
b) Two reinforced sections
At the edge of the cover nearest to your electrical socket find the reinforced
section in the base of the cover. Make a cut in the middle of this reinforced section
using a pair of scissors or a sharp Stanley knife. You will only need to cut/use one
C

reinforced section but one is provided near to each side to give you plenty of
options when deciding where to place your Water Mattress.
Place the base boards into the bottom of the cover C with the cable slots to the
centre and the speaker grills to the top. Centre the boards within the cover,
leaving a 20mm channel between them.
Feed the controller F and plug of the heater pad through the slit in the cover
mentioned earlier. Make sure the lead runs through the 20mm channel between
the boards.
Place the foam walls on top of the boards.
Make sure the longer walls are against the length
of the base boards.
Please note: The short foam walls may be slightly shorter than the width of the
boards. For example, with the Queen Mattress, the foam is likely to be 153cmW
and the boards are 160cmW. This small gap can help when closing the cover,
especially when the Mattress is against a wall.
With the metal face of the heater pad J facing upwards, place the pad flat on the
base, on top of the sheets.

Please note:The heater pad must lie within the marked area on the base of the cover. The
heater pad gets very hot and nothing more than the liner must come into contact with it.
Make sure the lead is not pulled
over/under the pad. Test the heater pad
now by plugging it in and allowing a
couple of moments. Carefully check that
the heater pad does indeed start to warm
up.
On the previous model the foam was
screwed in place. The attached sheets
remove the need for the screws now.
Once filled, the water will help keep the
foam in place.
You may need to cut a slit in the sheets to
pass the heater pad through so it is on
top of the sheets OR if the distance to
your plug socket is minimal, pass the
cable of the heater pad through one of
the corners to position the heater pad on
the top.
Consider distance to a wall electrical socket (before filling) when deciding which
corner to use i.e. choose corner nearest to your socket. The length of the cable from
the controller to the plug is 1.5m. Please note: the foam walls may be shorter in length
than the base board position the foam walls evenly around the board. If cutting a slit,
make sure the slit is in the middle in a direct line with the groove in the board.
Place the liner on top of the sheets that are already attached to the foam walls so that
it fits over the side of the shaped foam walls and extends over the top. Ensure that the
liner fits evenly around the foam walls. The liner can be used either way up. The liner
is an essential component since in the unlikely event of a puncture, the liner prevents
possible water damage to the base of the bed floor. The heater pad is low voltage as a
further safety measure. Either tuck any excess liner under the foam walls, or back over
around the bag when that is placed on top and filled. Make sure that the excess liner
will not become trapped in the zip of the PVC cover.
