Roper RUD6050R User instructions

Undercounter Dishwasher
PRODUCT MODEL NUMBERS OVERALL DIMENSIONS
CABINET OPENING DIMENSIONS
CUSTOM FRONT PANEL DIMENSIONS (Framed)
RUD6050R
Electrical: 120-volt, 60 Hz, AC-only, 15 or
20 amp. electrical supply. Use copper wire only. A
time-delay fuse or circuit breaker and separate
circuit is recommended.
Water: A hot water line with 20-120 psi
(138-862 kPa) water pressure. Water temperature
must be 120°F (49°C) at dishwasher. Use 3/8" O.D.
copper tubing with compression fitting (1/2"
minimum plastic tubing is optional but not
recommended). Use a 90° elbow with 3/8" N.P.T.
external pipe threads on one end to connect to
water inlet valve. Do not solder within 6" (15.2 cm)
from water inlet valve.
Drain: Use the new drain hose supplied with your
dishwasher. If this is not suitable, use a new drain
hose with a maximum length of 12 feet (3.7 m)
that meets all current AHAM/IAPMO test
standards, is resistant to heat and detergent, and
fits the drain connector of the dishwasher. Must
have a high drain loop 20 inches (50.8 cm) above
the subfloor or floor. Connect drain hose to waste
tee or disposer inlet above drain trap in house
plumbing and 20 inches (50.8 cm) minimum
above the floor. An air gap must be used if the
drain hose is connected to house plumbing lower
than 20 inches (50.8 cm) above subfloor or floor.
Use 1/2" minimum I.D. drain line fittings.
Corner location: Requires a 2" (5.1 cm)
minimum clearance between the side of the
dishwasher door and wall or cabinet.
A side panel kit is available from your dealer for
installing your dishwasher at end of cabinet.
Do not install dishwasher over carpeted floor.
Because Whirlpool Corporation policy includes a continuous commitment to improve
our products, we reserve the right to change materials and specifications without notice.
Dimensions are for planning purposes only. For complete details, see Installation
Instructions packed with product. Specifications subject to change without notice.
Ref. 8535436
02-02-06
Drain hose and power supply line entering through the right
side of opening in shaded areas makes connection easier.
Drain hose size: 1-1/2" (3.8 cm)
Power supply line hole-direct wired: 3/4" (1.9 cm)
Power supply line hole-with plug: 1-1/2" (3.8 cm)
Water line entering through the
left side of opening in shaded
areas makes connection easier.
Minimum 1/2" (12,7 mm) hole.
24" (61 cm)*
20-3/4"
(52.7 cm)
23-7/8" (60.6 cm)
33-7/8"
(86 cm) min.
*to front of
door frame
2-1/2"
(6.4 cm)
2-1/2"
(6.4 cm)
10"
(25.4 cm)
4" (10.2 cm)
4"
(10.2 cm)
4"
(10.2 cm)
5" (12.7 cm) 5" (12.7 cm)
2"
(5.1 cm)
2"
(5.1 cm)
34" (86.4 cm) min.*
6"(15.2 cm)
6"(15.2 cm)
24" (61 cm)
24" (61 cm)**
door panel
(side view)
door panel (front view)
access panel
(front view)
22 31/32"
(58.3 cm)
All edges routed to 7/32" (5.6 mm) thickness.
23 5/16" (59.2 cm)
7/32"
(5.6 mm)
7/32"
(5.6 mm)
3/8"
(9.5 mm)
1"
(25.4 mm)
These panels fit only models with frames around the door and access panels.
18 21/32"
(47.4 cm) 4 7/16"
(11.3 cm)
NOTE: Access panel is wider than door panel.
*Measured from the lowest point on the
underside of countertop. May be reduced
to 33-7/8" (86 cm) by removing wheels
from dishwasher.
**Minimum, measured from narrowest point
of opening.
top view
7/32" (5.6 mm) thick
access panel frame
1/4"
(6.4 mm) min.
side view
door closed
door pivot
door opened
access panel
Cut door panel to clear access panel when
door is in open position .

