Rosco 1900 User manual

MODEL 1900
FOG MACHINE
Operating Instructions
April, 2007
Rosco Laboratories, Inc.
52 Harbor View Avenue, Stamford, CT 06902, USA
(800) ROSCONY, [phone], Fax: [phone]
email: [email protected]

ROSCO MODEL 1900 Page 1 03/07
www.rosco.com
ROSCO MODEL 1900
Operations Manual
TABLE OF CONTENTS
INTRODUCTION...........................................................................................................…1
IMPORTANT SAFEGUARDS...........................................................................................2
HOW THE MACHINE WORKS........................................................................................3
OPERATING INSTRUCTIONS.........................................................................................4
DO'S AND DON'TS............................................................................................................7
MAINTENANCE................................................................................................................8
FOG DISTRIBUTION........................................................................................................8
ROSCO OFFICES...............................................................................................................9
LIMITED WARRANTY...................................................................................................10
STORAGE AND SHIPMENT..........................................................................................10
TECHNICAL SPECIFICATIONS....................................................................................11
OPTIONAL ACCESSORIES............................................................................................11
PARTS IDENTIFICATION GUIDE ................................................................................12
TROUBLESHOOTING GUIDE.......................................................................................22
PARTS LIST .....................................................................................................................23
INTRODUCTION
This manual offers a detailed explanation of the operation of the ROSCO MODEL 1900
smoke machine. To assure efficient and safe operation, please take a few minutes to read this
material.
The ROSCO MODEL 1900 smoke machine is a thermal aerosol generator designed for very
high variable fog output. It is part of a system, the other basic component being the full line of
Rosco fog fluids, and they should always be used together. These unique fluid formulations
are safe when used according to instructions. They are water-based and contain no petroleum
distillate. The operating temperature, pump pressure, and output nozzle orifice of the machine
have beeen specifically set to maximize aerosolization of the Rosco fluid. When used
properly, the system should operate for many years.

ROSCO MODEL 1900 Page 2 03/07
www.rosco.com
IMPORTANT SAFEGUARDS
READ AND UNDERSTAND THESE SAFETY PRECAUTIONS BEFORE OPERATING
THE MACHINE. FAILURE TO PROPERLY FOLLOW THESE PRECAUTIONS MAY
LEAD TO A FIRE, EXPLOSION, OR ELECTRICAL SHOCK.
FOG FLUID HEALTH CAUTION: VAPOR FROM THIS FLUID, LIKE ANY OTHER
COMMON MATERIAL IN A VAPORIZED STATE, MAY BE IRRITATING TO OR
CAUSE ALLERGIC SYMPTOMS IN SOME PERSONS WITH ALLERGENIC
SENSITIVITY. DO NOT EXPOSE AT CLOSE RANGE TO KNOWN ASTHMATICS.
1. This machine uses electrical power at common commercially available voltages. When
directly contacted, such voltages are hazardous to human life. All precautions commonly
applicable to the use of electric power generally are applicable to the use of this machine.
This machine is designed to operate from three-wire power systems where one of the wires is
a safety ground. DO NOT disconnect the safety ground or use extension cords or "cheater"
plugs to connect this machine to a two-wire system. Operation without a safety ground may
result in a hazardous electrical shock.
2. Check the current and voltage rating of your machine. Extension cords must be properly
sized and rated for voltage, current and length. Check your local electrical code for the correct
gauge extension cord. If an extension cord shows signs of wear or gets warm to the touch,
discontinue its use and obtain a cord with a higher current rating. Improper extension cords
are not only hazardous, but may result in poor machine performance due to excessive voltage
drop.
3. Never use any machine that shows signs of improper use. Even slight damage may be an
indication of a major problem. If the machine looks questionable, use it only under strict
observation. If the machine shows any unusual behavior, disconnect machine immediately
from power and send machine to a Service Center for repair.
4. Do not operate the machine in a tightly confined space where the ambient temperature
might exceed 135° F (57° C). A continuous flow of air is required to maintain temperature
within the machine housing. Sensitive electronic components deteriorate rapidly under high
heat conditions. Operation of the machine in an enclosure of less than ten cubic feet (one
cubic meter) is dangerous, and automatically voids the warranty.
Enclosing any heating device so it is invisible to the operator creates a potential fire
hazard, no matter what the ambient temperature of the enclosure. To do so with any
high-amperage device is to assume substantial risk. Rosco strongly recommends against
it.
5. In any facility, the smoke concentration should be controlled. The smoke should never
mask emergency exits, safety signs, staircases or other safety constructions.
6. After long use, or if the machine is not properly set, some liquid droplets or wet area may
appear in front of the machine’s outlet. This liquid should be wiped up to prevent a condition
where someone might slip and fall.

ROSCO MODEL 1900 Page 3 03/07
www.rosco.com
7. Machines are designed for continuous use over an 8-hour day, but to protect components, it
is wise to turn off the machine when it is not in use. In permanent installations, it is advisable
to equip the circuit with a night cut-off device.
8. During the warm-up phase and during operations, people should not stand within one meter
of the front of the machine. Flammable material like paper, fabric, etc., should never be
placed directly on or around this equipment, or any other electrical device with a heating
element.
9. The smoke should be blown into an open space and should not be directed at people or
objects. Never blow smoke on hot surfaces, into glowing heating elements or into open
flames. The normally non-flammable and non-toxic smoke could react on very hot surfaces
and be burnt or decomposed.
10. Unauthorized repair or alteration of any safety devices can lead to improper operation and
accidents. Repairs should be performed only by an authorized Service Center.
WARNING: USE OF ANY FLUID OTHER THAN ROSCO FOG FLUIDS OR
MODIFICATION OR ATTEMPTED UNAUTHORIZED REPAIR OF THE ROSCO
MODEL 1900 WILL IMMEDIATELY INVALIDATE THE WARRANTY.
HOW THE MACHINE WORKS
When the heat exchanger has reached proper operating temperature, the operator switches
power to the siphoning pump, which draws the fluid from an external reservoir into the heat
exchanger. The fluid is rapidly heated and vaporized. The vaporized fluid is then discharged
through the nozzle into the atmosphere where, upon mixing with the cooler air, it turns into an
aerosol consisting of millions of fine particles.
NOTE: The terms “fog” and “smoke” are used interchangeable. However the ROSCO
MODEL 1900 does not produce smoke, but a mist or aerosol.

ROSCO MODEL 1900 Page 4 03/07
www.rosco.com
OPERATING INSTRUCTIONS
1. POWER HOOK-UP
Connect the power cord into a socket rated at the proper voltage and amperage. The machine
requires a dedicated power circuit. Turn on the main power switch (I/O) located at the rear of
the machine.
2. REMOTE CONTROL
The remote control fits into a cavity on the rear of the machine. The Model 1900 ships with
the remote control already screwed in place and can be removed. If it is not already plugged
in, plug the remote control into the socket in the cavity on the back of the machine. Push the
grey button marked POWER ON. This will enable the electronics and the unit will start to
heat up. The red LED on the Remote Control should light up indicating that the electronics
are enabled. The red LED on the top of the machine should light as well indicating that the
machine is heating up.
Note: The Rosco Model 1900 Fog Machine will operate either from the Remote Control,
from a lighting control console using the optional DMX Remote Control (see below) or as a
unit in a daisy chain (see below).
3. WARM UP
Let the machine warm up for about 9.5 minutes until the green LED on the top of the machine
turns on. The machine is now ready to use, as long as the green LED remains on and the fluid
reservoir contains fluid.
4. FLUID DELIVERY
Place either the 2.5-liter or the 4-liter size bottles of any Rosco fluid in the cavity located at
the rear of the machine. Place the end of the tube coming out of the top of the machine into
the bottle. A cap is provided that fits on the bottle.
NOTE: The machine only works with uncontaminated Rosco fog fluids. Other
manufacturers’ fluids may cause spitting and serious clogging problems and could result in
the production of an unhealthful aerosol. The use of other fluids voids the warranty of the
Rosco Model 1900 Fog Machine.
5. PRODUCING FOG
To produce fog, push the red FOG button located on the remote control. Push the switch
again to stop producing fog. The volume of the fog can be varied by turning the knob marked
FOG LEVEL. Note: At higher outputs the machine will give a large burst and then ramp back
the volume. This is to allow the machine to run continuously and is normal.
CAUTION: If the fluid bottle is empty, DO NOT run the pump. Running the machine
without fog fluid can seriously damage the pump.
6. TIMERS
The Rosco Model 1900 Remote Control is equipped with timers as standard epuipment. To
enable the timers, push the grey TIMER ON button on the remote. The green CYCLE LED
will be lit. To set the amount of time that the machine will make fog, adjust the FOG ON

ROSCO MODEL 1900 Page 5 03/07
www.rosco.com
knob. To set the delay between bursts, adjust the FOG OFF knob. The range of time for both
FOG ON time and FOG OFF time is 2-18 seconds.
NOTE: The numbers indicated by the FOG ON and FOG OFF knobs are relative and should
be used for reference only.
7. DAISY CHAIN (OPTIONAL)
The Rosco Model 1900 has the capability to control up to 4 machines from a single controller.
In this “Daisy Chain” process, the machine that controls the others is called the MASTER and
the others are called SLAVES. Make sure that a Remote Control is attached to the MASTER
machine as outlined in Step 2 and all Remote Controls are removed from all the SLAVE
machines. Connect a cable with a male 3-pin XLR connector at each end to the link socket on
the top of the MASTER machine and connect the other end to the remote connection on the
first SLAVE machine. Repeat the process from the first SLAVE machine to the next. As
many as 4 machines may be operated from a single remote. Operate the remote as outlined in
Steps 5 and 6 above.
8. DMX CONTROLLER (OPTIONAL)
The Rosco Model 1900 has the option to be operated from a lighting control console that uses
a DMX signal. After removing the Remote Control, attach the optional DMX Interface to the
remote control connection.
Attaching DMX cable: Plug a standard 5-pin DMX cable in the connection narked DMX IN
on the remote. Note that the DMX can pass through to another device by plugging another
cable into the DMX OUT plug.
Setting the address: To set the DMX address, use the dip switches located on the DMX
interface. The dip switches are based on the binary system, so the channel number must first
be converted to a binary number. (See illustration). When the dip switch is in the down
position, it is “on”. When there is a valid DMX signal, the LED next to the dip switches will
light. NOTE: The Rosco Model 1900 uses one DMX channel.
Operating the unit: Turn the power switch (I/O) on. If the DMX interface is plugged in the
machine will automatically start to heat up. This will be indicated by the red LED on the top
of the machine. When the machine reaches proper operating temperature, the green LED on
top of the machine will light. When the proper DMX channel is given a non-zero value, the
machine will make fog. The fog volume will be proportional to the value of the channel
setting.
Test Button: There is a red momentary test button located on the DMX Interface. This button
is operable if the machine is on and the DMX interface is plugged in. When the machine is at
proper operating tempearture (as designated by the green LED on top of the machine),
pressing the Test Button will momentarily make fog.

ROSCO MODEL 1900 Page 6 03/07
www.rosco.com
DMX INTERFACE ADDRESS
Address Switches
LED indicating
DMX si
g
nal
Binary columns
Address for Channel 217
1+8+16+64+128=217
Address for Channel 19
1+2+16=19
= OFF = ON

ROSCO MODEL 1900 Page 7 03/07
www.rosco.com
DO'S & DON'TS
DO Read the entire manual before operating the machine and pay particular
attention to all CAUTIONS AND WARNINGS.
DO Use ONLY Rosco manufactured fluids.
DO Use an extension cord which is properly rated for voltage, current and length
and which is free from nicks or other signs of wear.
DO Before each operating period, check to see that the machine is clean and free of
foreign objects.
DO Test first for dry smoke.Turn the FOG switch on. Place a piece of cardboard or
paper 18 inches in front of the machine. If the surface is at all wet return the
machine to your dealer for servicing.
DO Ensure that the machine is adequately ventilated.
DO Use proper caution when handling hot surfaces
DO Use the minimum amount of smoke required to achieve the desired effect.
DO NOT Use the machine near a person who has asthma or similar inhalation disorder.
DO NOT Use any foreign substances in the machine.
DO NOT Use a machine that is damaged or operating improperly in any way.
DO NOT Use a machine that leaks fluid from the housing.
DO NOT Leave the machine switched on for prolonged periods without producing fog.
DO NOT Enclose the machine.
DO NOT Install the machine in such a fashion that the operator cannot see the whole
machine including indicator lights.
DO NOT Touch the shielded nozzle of the machine. Allow sufficient cooling time after
operation before attempting to perform maintenance.
DO NOT Direct the smoke continuously against the same spot. This may eventually
cause fluid to recondense on walls, furniture, sets, etc.
READ THE COMPLETE MANUAL TO INSURE SAFE OPERATION.

ROSCO MODEL 1900 Page 8 03/07
www.rosco.com
MAINTENANCE
1. There are two fuses on the ROSCO MODEL 1900 smoke machine, one is located on the
circuit card inside the machine and the other is located on the rear, below the mains switch.
NOTE: Be sure to check the specifications when replacing any fuses.
WARNING: DISCONNECT THE ROSCO MODEL 1900 FROM POWER BEFORE
CHECKING OR REPLACING THE FUSE. FAILURE TO DO SO COULD BE
HAZARDOUS AND RESULT IN AN ELECTRICAL SHOCK.
2. After every operation, the siphon hose should be removed from the external reservoir. The
machine should be turned on and fog produced. When there is no more fog coming out of the
machine, the machine should be immediately turned off.
3. After every operation, only after the machine has cooled, it should be wiped with a clean
damp cloth or paper towel. This practice prevents the build up of dirt and dust which may
enter the machine and damage sensitive internal components. Do not use solvents for
cleaning. Soap and water are effective.
4. Before and after the machine is stored for an extended period, the machine should be
properly cleaned. The best method for cleaning is using distilled or de-ionized water. To flush
the machine, turn it on and, when ready to use, put the fluid pick-up tube into a container of
distilled or de-ionized water. Run the water through the machine and flush for three minutes.
The tube should be removed from the water and the machine run until nothing comes out of
the nozzle. The machine should be immediately turned off.
5. During use, operation of all switches and indicator lights should be monitored. Lights that
blink or flicker when they should be on or off, for example, are an indication of problems in
the machine's circuitry.
FOG DISTRIBUTION
The fog distribution in an enclosed area depends on air flow and temperature. Natural air
movement, air conditioning and other ventilation systems will affect movement of the fog.
Test under realistic conditions before using. If a space must be filled very quickly, move the
machine up and down and side to side. To conduct fog to particular areas, use a hose adaptor
and ducting hose (see OPTIONAL ACCESSORIES). Make sure that there is an air space of
2-3 inches between the nozzle and any ducting hose. Do not use ducting hose smaller than 4
inch diameter. The ROSCO MODEL 1900 works properly only in a horizontal position. Do
not tilt the machine during operation.

ROSCO MODEL 1900 Page 9 03/07
www.rosco.com
ROSCO OFFICES WORLDWIDE
If the machine fails and repairs are required, call or write the nearest Rosco office (listed
below) or your local Rosco dealer.
UNITED STATES
World Headquarters
Rosco Laboratories, Inc.
52 Harbor View Avenue
Stamford, CT 06902
[phone]
[phone]
E-mail: [email protected]
Rosco Laboratories, Inc.
1265 Los Angeles Street
Glendale, CA 91204
[phone]
[phone]
Rosco Service Center
1675 Brandywine Ave.
Suite B
San Diego, CA 91911
[phone]
[phone]
CANADA
Rosco Laboratories, Ltd.
1241 Denison Street, #44
Markham, Ontario
L3R 4B4
[phone]
(888) ROSCO TO
E-mail: [email protected]
UNITED KINGDOM
Roscolab, Ltd.
Blanchard Works
Kangley Bridge Road
Sydenham, London
SE26 5AQ England
[phone]
E-mail: [email protected]
SPAIN & PORTUGAL
Rosco Iberica, S.A.
C/Oro,76 Polígono Industrial Sur
28770 Colmenar Viejo, Madrid. España
(34) 918 473 900
E-mail: [email protected]
AUSTRALIA
Rosco Australia Pty Ltd.
42 Sawyer Lane
Artarmon 2064
N.S.W. Australia
[phone]
E-mail: [email protected]
BRAZIL
Rosco do Brasil Ltda.
R. Antônio de Barros, 82
03401-000 São Paulo-SP
[phone]
E-mail: [email protected]

ROSCO MODEL 1900 Page 10 03/07
www.rosco.com
LIMITED WARRANTY
ROSCO LABORATORIES, INC. warrants to the original purchaser that the ROSCO MODEL
1900 will be free from original defects in workmanship and material for a period of twelve
months from the date of purchase. During the warranty period, machines will be repaired or
replaced at the option of ROSCO.
The warranty does not extend to any parts of the ROSCO MODEL 1900 that have been subject
to misuse or accident. Neither does the warranty cover any machine that has been opened,
modified or repaired other than by ROSCO or its designated repair station.
The warranty will not apply if procedures described in the Operations Manual are not followed.
It is the user's obligation to clean and maintain the ROSCO MODEL 1900 according to these
instructions, and to follow acceptable practices for handling electrical devices.
NOTE: USE OF ANY FLUID OTHER THAN A ROSCO BRAND FLUID WILL VOID
THE WARRANTY.
STORAGE AND SHIPMENT
If you do not anticipate using your machine for an extended period, prepare your machine for
storage as follows:
1. Perform maintenance as outlined in "Maintenance" section.
2. Wipe the outside of the machine clean.
3. Store in a sealed cardboard box.
4. Whenever the unit is shipped, considerable care should be taken in packing to avoid damage
in transit.

ROSCO MODEL 1900 Page 11 03/07
www.rosco.com
ROSCO MODEL 1900
TECHNICAL SPECIFICATIONS
POWER REQUIREMENTS
115 volts, 60 Hz., 15 amps
230 volts, 50 Hz., 7 amps
PARTICLE SIZE
0.25-60 microns
DIMENSIONS
Height: 8.5 in. (21.6 cm)
Width: 9.75 in. (24.8 cm)
Length: 22.5 in. (57 cm)
WEIGHT
27 lb. (12.3 kg)
REMOTE CONTROL
Volume Control
Sequencers
On time: 2-18 seconds
Off time: 2-18 seconds
MAX. FLUID CONSUMPTION
6 liters/hour
FUSE
15/115v
10/230v
OPTIONAL ACCESSORIES
DMX INTERFACE
Allows the machine to be operated from a lighting control console.
HOSE ADAPTOR
Metal frame that connects ducting hose to machine
Dimensions: 4 in. (10.2 cm) x 6.75 in. (17.14 cm)
DUCTING HOSE
Flexible, plastic hose, connects to hose adaptor for ducting of fog
Dimensions: 4 in. (10.2 cm) x 25 ft. (7.62 m)

ROSCO MODEL 1900 Page 12 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Left View with Cover Removed
A. Mains Switch # 23711700E001
B Fuse Holder (240V)
Fuse Holder (110V)

ROSCO MODEL 1900 Page 13 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Right View: Main PCB and XLR
A. 3 Pin male XLR-Panel Mount #23711700E009
B. 3 Pin female XLR-Panel Mount #23711700E010
C. Main PCB (240v) # 23711900E240
Main PCB (110v) # 23711900E110

ROSCO MODEL 1900 Page 14 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Rear View with Remote
A. Mains Switch #23711700E001
B. Fuse Holder
C. Remote Control #23711700R001

ROSCO MODEL 1900 Page 15 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Left View: Pump and Fittings
A Pump 240V # 23711700F240
Pump 110V # 23711700F110
Pump 100V # 23711700F100
B Fluid tube to heat exchanger (part of HE assembly)
C Elbow 1/8 x 3/16 # 23711900F001
D Rubber connecting tube # 23711700A002
E Main power connection to pump. When reconnecting power to the
pump, please ensure that the positive goes to the diode side of the of the
two connectors (this is marked on the pump body)

ROSCO MODEL 1900 Page 16 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Top View: Heat Exchanger Assembly (closed)
A. Hole in heat exchanger housing to access Thermal Trip

ROSCO MODEL 1900 Page 17 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Top View: Heat Exchanger Assembly (open)
A. Thermocouple attached to the heat exchanger.
B. Heat Exchanger Assy. 240V # 23711900H240
Heat Exchanger Assy. 110V # 23711900H110
C. Thermal Trip (240V) # 23711700E005
Thermal Trip (110V) # 23711900E006
D. Insulation Kit # 23711900H001

ROSCO MODEL 1900 Page 18 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Remote Control
A FOG Switch
B POWER ON switch
C TIMER ON switch
D FOG LEVEL knob
E TIMER OFF knob
F TIMER ON knob
G Male XLR Connector # 23711700E002
All knobs # 23711700R002

ROSCO MODEL 1900 Page 19 03/07
www.rosco.com
ROSCO MODEL 1900 PARTS IDENTIFICATION GUIDE
Main PCB with Heatsink
A Main PCB (240v) # 23711900E240
Main PCB (110v) # 23711900E110
B Heatsink # 23711900E011
