Rosewill RNX-N2X User manual

Quick Installation Guide
Wireless Adapter RNX-N2X
1
The high-speed wireless USB 2.0 client adapter is the most convenient way to let you put a
desktop/notebook computer almost anywhere without the hassle of running network cables.
Now you don’t need to suffer from drilling holes and exposed cables. Once you are connected,
you can do anything, just like the wired network. This USB client adapter operates seamlessly in
2.4GHz frequency spectrum supporting the 802.11b, 802.11g, and 802.11nwireless standards.
It’s the best way to add wireless capability to your existing wired network or simply surf the web.
For advanced configuration, refer to the User’s Manual in the CD-ROM provided.
USB Adapter Description
The USB adapter is a standard USB adapter that fits into any USB interface. The USB adapter has two
LED indicators and a built-in antenna.
LINK LED Indicator
USB Connector
USB Adapter for Windows 2000/XP/Vista – Installation
During the installation, Vista may need to copy systems files from its installation CD. Therefore,
you may need a copy of the Windows installation CD at hand before installing the drivers.
Follow the steps below in order to install the USB adapter drivers:
1. Insert the CD-ROM that was provided to you in this package. The setup should run
automatically. If the setup does not run automatically, then you must manually select the
setup.exe file from the CD-ROM drive.
2. Once the setup begins you will see the InstallShield Wizard. Select Rosewill Configuration
Tool and then click on the Next> button.

Quick Installation Guide
Wireless Adapter RNX-N2X
2
3. Click on the Install button to begin the installation.
4. The installation is complete. Click on the Finish button.

Quick Installation Guide
Wireless Adapter RNX-N2X
3
5. Carefully insert the USB adapter into the USB port. Windows will then detect and
install the new hardware.
6. An Ricon will then appear in the system tray. Right click on the Ricon and then click on
Launch Config Utilities.
Note: Click on Use Zero Configuration as Configuration Utility if you would like to use
Windows Zero Config.
USB Adapter Adding a Profile – Windows 2000/XP/Vista
The Profile tab is used to store the settings of multiple Access Points such as home,
office, café, etc. When adding a profile you are required to enter a profile name and
SSID as well as configure the power-saving mode, network type, RTS/fragmentation
threshold and encryption/authentication settings.

Quick Installation Guide
Wireless Adapter RNX-N2X
4
1. Profile: Enter a name for the profile; this does not need to be the same as the SSID.
2. SSID: Enter the SSID of the network or select one from the drop-down list.
3. Network Type: Select Infrastructure from the drop-down list.
4. TX Power: Select a transmit power from the drop-down list..
5. Click on the Apply button to save the changes.
Laptop clip Hardware Installation/ Uninstallation
1. Connect laptop clip to RN
X
-N2
X
wireless adapter.
2. Connect laptop clip to Your Laptop
LCD monitor.
Warning:
Please be careful not to damage the
LCD monitor and laptop clip.

Quick Installation Guide
Wireless Adapter RNX-N2X
5
3. Uninstallation: Take off the laptop clip
from RNX-N2X as picture.
RNX-N2X Application Direction
A type ( For Laptop )
Connect to laptop by flexible
stainless steel extended
connector.
B type ( For Laptop )
C type ( For Desktop )
Connect to laptop by laptop clip
and USB Cable.
Connect to desktop by USB Cable
in your home or office.
