Rosewill RSV-L4000 User manual

SERVER
User Manual
RSV-L4000

SERVER RSV-L4000 User Manual
1
Contents
Product Overview ..........................................................................................2
Introduction.............................................................................................3
Feature.....................................................................................................3
Specification ...........................................................................................3
Installation Guide......................................................................................................5
Top Cover Disassembly.........................................................................5
3.5” Device Installation ..........................................................................6
Server Rail Installation...........................................................................8
5.25” ODD Installation............................................................................9

SERVER RSV-L4000 User Manual
2
Product Overview

SERVER RSV-L4000 User Manual
3
Introduction
RSV-L4000 is a 4U rackmount industrial chassis for various kinds of server computer which supports any
E-ATX (12” x 13”) and below form factor motherboard design and PS2 power supply. In addition, RSV-L4000
has a large-scale fan filter and easy-to-use knob key for great serviceability of the system.
Feature
Carries 8 x internal 3.5" HDD and 3 x 5.25" devices (which can switch to a 3.5” HDD x 4 module) totally.
Best cooling design carry up to front 120 mm front cooling fan x5 and 80 mm back cooling fan x2 max (all 7
are included in RSV-L4000).
Front door with key lock for better security.
Special design of fixing PCI card in the system (7 pieces max).
Dual USB 2.0 connector in front panel.
Specification
Chassis Type Rackmount
Color Black
Case Material Metal/ Steel, 1.0 mm thickness
Motherboard Compatibility 12" x 13" E-ATX and below
Form Factor 4U Cooling System
80mm Fans 2 max (All 2 80mm Fans included)
120mm Fans 5 max (All 5 120 mm Fans included)
Expansion
Internal 5.25" Drive Bays 3
Internal 3.5" Drive Bays 8
Expansion Slots 7 Physical Spec
Control & Indicator 1 xPower switch +1x Reset switch
1 x LED (power) +1 x LED (HDD), 2 x LED (LAN)
2 x2.0 USB
Dimensions(L x W x H) 24" x 16.8" x 7.0"
Weight Net Weight : 28.1 lbs.
Gross Weight : 39.8 lbs
Package Contents RSV-L4000 Server Case
Keys
Screws
Other Accessories

SERVER RSV-L4000 User Manual
4
PIC ITEM PURPOSE PIC ITEM PURPOSE
MOTHERBOARD
STANDOFF x 12 MOTHERBOARD
RAIL x 6 HDD MODULE
ODD RAIL
SCREWS x 6 POWER
SUPPLY
SCREWS x 20 MOTHERBOARD Buzzer x 1
(PC Speaker) MOTHERBOARD

SERVER RSV-L4000 User Manual
5
Installation Guide
Top Cover Disassembly
1. Remove the screws from each side of
the Chassis. (two on each side)
2. Once the screws removed, push the
top cover to remove from the chassis.

SERVER RSV-L4000 User Manual
6
3.5” Device Installation
1. First press the two round shape button
using your thumbs, then use your index
finger to push the 3.5” module to
remove it.
2. Pull the module out from the front.
3. Pull the HDD tray out from the module
to begin installation.

SERVER RSV-L4000 User Manual
7
4. The HDD tray can be easily clipped
onto 3.5” HDD.
5. To complete the 3.5”HDD installation,
push the HDD tray back into the
module, then push the module back to
the chassis.

SERVER RSV-L4000 User Manual
8
Server Rail Installation
1. In order to install the rail, you must first
remove the cover on the side. Three
screws locate on each side.
2. Unscrew all three screws on each side.
3. Upon removing the side bar, you will find
several screw holes for you to install the
server rail.

SERVER RSV-L4000 User Manual
9
5.25” ODD Installation
1. First press the two round shape button
using your thumbs, then use your index
finger to push the middle 3.5” module
to remove it.
2. Pull the middle module out from the
front panel
3. Using a flathead screw driver to press
the Yellow circle to move the front
panel out.

SERVER RSV-L4000 User Manual
10
4. Press the ODD rail onto both side of
the ODD.
5. You can slide the ODD back in to
complete the installation.
Make sure the round shape button has
locked with the ODD rail.
You can also remove the ODD by
pressing the button, then pull out.

SERVER RSV-L4000 User Manual
Thank you for purchasing a quality Rosewill Product.
Please register your product at: www.rosewill.com for complete warranty information and future support for
your product.
