Rosslare AY-E20 User manual

AY-E20
Ultra-slim Vandal Resistant
Multi-format Proximity Reader
Instruction Manual
March 2008

Table of Contents
AY-E20 Instruction Manual Page ii
Table of Contents
1. General Information...........................................................3
1.1 Introduction.............................................................................. 3
1.2 Box Content............................................................................. 3
1.3 Ancillary Equipment................................................................ 3
2. Technical Specifications ...................................................4
2.1 Key Features............................................................................. 5
3. Installation...........................................................................6
3.1 Mounting the AY-E20 .............................................................. 6
4. Wiring Instructions ..............................................................8
4.1 Wiring the AY-E20..................................................................... 8
5. Operational Instructions ....................................................9
5.1 Testing the AY-E20 and Card Reading................................. 9
5.2 Card Transmission Format Selection ..................................... 9
5.3 Tri-Color LED Color Control................................................... 10
5.4 Buzzer Control ........................................................................ 10
5.5 Card Read/Hold Control...................................................... 10
5.6 Tamper Output...................................................................... 10
Appendix A. Limited Warranty ...........................................11
Appendix B. Technical Support .........................................13

General Information
AY-E20 Instruction ManualPage 3
1. General Information
1.1 Introduction
The AY-E20 is an ultra-slim, multi-format RFID proximity card reader
that is installed for use with access control systems. The unit is
vandal resistant and water resistant, suitable for indoor or outdoor
mounting.
This instruction manual contains information regarding the
features, mounting, wiring, operating instructions and warranty
details for the AY-E20 reader.
1.2 Box Content
Before beginning verify that all of the following is in the box. If
anything is missing, please report the discrepancy to your nearest
Rosslare office.
•One AY-E20 unit
•Installation kit and mounting template
•Installation and operating instruction
1.3 Ancillary Equipment
The following equipment is required to complete your installation:
•Compatible host controller (not supplied)- UL listed access
control unit, i.e., model AC-215U or AC-225U
Rosslare accessories can be found on www.rosslaresecurity.com.

Technical Specifications
AY-E20 Instruction Manual Page 4
2. Technical Specifications
Specifications AY-E20
Electrical Characteristics
Power supply type Linear type – recommended
Operating voltage
range 5 - 16VDC
Input current standby 40mA@12VDC
Max Input current 100mA@16VDC
Tamper output Open collector, active low, 16mA max
sink current
Cable distance to host
controller Up to 500ft (150 meters) using an 18AWG cable
Proximity card read
range* 1.37inch (3.5cm )
Proximity card
modulation ASK at 125 KHz
Proximity card
compatibility EM cards
Card Transmit format 26-bit Wiegand, Clock & Data or Serial
RS232
LED indicators One tri-colored LED
Environmental Characteristics
Operating temp. range -25 to 145° F (-31 to 63° C)
Operating humidity 0 – 95% (non-condensing)
Outdoor usage Weather-resistant, meets IP-68, epoxy

Technical Specifications
AY-E20 Instruction ManualPage 5
Specifications AY-E20
potted, suitable for outdoor use
Mechanical
Size
(Height x Width x Depth) 155 x 45 x 8 mm 6.1x1.77x0.314 inch
Weight 135gr(0.297lb)
*Measured using Rosslare proximity card (AT-14) or equivalent. Range also
depends on electrical environment and proximity to metal.
2.1 Key Features
The key features for the AY-E20 are:
•Ultra-Slim Flush-mount design on flat surface
•Fully potted, waterproof construction for outdoor use
•Built-In 125 KHz ASK EM proximity card reader
•Selectable Card Transmission Formats: 26-Bit Wiegand,
Clock & Data, or Serial RS-232 output
•Optical back tamper sensor
•Bi-Color LED control
•Buzzer control
•Card read/hold control
•Mounting template for easier installation
•Installation kit
•Limited lifetime warranty

Installation
AY-E20 Instruction Manual Page 6
3. Installation
3.1 Mounting the AY-E20
Before starting, select the location to mount the AY-E20. This
location should be at shoulder height. To mount the AY-E20,
perform the following:
1) For wall mounting, use the included mounting template as a
guide for drilling holes and mounting screws (See figure 1).
2) Drill a hole for the cable. If mounting on metal, place a
grommet or electrical tape around the edge of the hole.
3) Route the interface cable from the AY-E20 to the Controller.
Figure 1 Drilling & Mounting Template

Installation
AY-E20 Instruction ManualPage 7
For US Gang Box mounting, no drilling is necessary. Simply screw
the AY-E20 to its mounting location or US gang box.
Note:
•A linear type power supply is recommended
•Card readers are to be used with control panels whose power
supply is UL Listed Class 2 or equivalent

Wiring Instructions
AY-E20 Instruction Manual Page 8
4. Wiring Instructions
4.1 Wiring the AY-E20
The unit is supplied with a 39.4 inch pigtail, having a 10-conductor
cable. To connect the unit to the controller, perform the following:
1) Prepare the unit's cable by cutting the cable jacket back 1¼
inches and strip the wire ½ inch.
2) Prepare the controller cable by cutting the cable jacket
back 1¼ inches and strip the wire ½ inch.
3) Splice the unit’s pigtail wires to the corresponding controller
wires and cover each connection. Refer to the wire color
table below.
Wire
Color Weigand Output Mode Clock & Data Output Mode
Serial (RS232)
Output Mode
Red +DC +DC +DC
Black Ground Ground Ground
Green Data 0 Data Tx (RS-232)
White Data 1 Clock -
Orange Green LED Green LED Green LED
Brown Red LED Red LED Red LED
Yellow Buzzer Buzzer Buzzer
Blue Hold Hold Hold
Purple Tamper Tamper Tamper
Grey Open Input Connect to GND
Connect to +DC
4) If the tamper output is used, connect the purple wire to the
correct input on the controller.
5) Trim and cover all unused conductors.

Operational Instructions
AY-E20 Instruction ManualPage 9
5. Operational Instructions
The AY-E20, once connected to standard access controller,
functions as a reader. This is indicated by one beep immediately
after power-on reset.
The following pages explain the operational instructions of the AY-
E20.
5.1 Testing the AY-E20 and Card Reading
The AY-E20 should be tested after wiring it to the Controller. To test
the AY-E20, perform the following:
1) Power-up the AY-E20. The LED and Beeper will activate one
time. This indicates that the AY-E20 is working properly.
2) Present the appropriate type of proximity card to the AY-E20.
The LED will momentarily flash green and a short beep will be
emitted. This indicates that the card was read properly by
the AY-E20.
3) Once the card’s data has been processed by the Controller,
the Controller can then switch the LED on the AY-E20 to
green. Refer to the relevant Controller instruction manual for
more information on controlling LED behavior via the
Controller.
5.2 Card Transmission Format Selection
To select the appropriate Card Transmission Format, perform one
of the following:
•26-Bit Wiegand - the grey wire should be an open circuit
•Clock & Data - the grey wire should be held to ground
•Serial RS-232 - the grey wire should be held to +DC (VIN).

Operational Instructions
AY-E20 Instruction Manual Page 10
5.3 Tri-Color LED Color Control
The Tri-Color LED color can be controlled using the orange and
brown wires. To control the Tri-Color LED color, perform one of the
following:
•If the orange wire is held to ground the LED will light green
•If the brown wire is held to ground the LED will light red
•If both the brown and orange wires are held to ground the
LED will light amber
•If the orange and brown wires are not used (open) the LED
will remain red continuously and when successfully reading
a card the LED will flash green momentarily
5.4 Buzzer Control
The Buzzer can be controlled using the yellow wire. To control the
Buzzer, perform one of the following:
•If the yellow wire is held to ground the buzzer will sound
•If the yellow wire is not used (open) the buzzer will beep
only when a card is read successfully
5.5 Card Read/Hold Control
The reading of cards can be disabled using the blue wire. To
control the reading of cards, perform one of the following:
•If the blue wire is held to ground the reader will ignore all
cards placed in its field
•If the blue wire is not used (open) the reader will read all
compatible cards normally
5.6 Tamper Output
The AY-E20 has an optical tamper sensor; when the sensor detects
light the tamper output is held open collector; when the sensor
does not detect light the tamper output is held to ground.

Limited Warranty
AY-E20 Instruction ManualPage 11
Appendix A. Limited Warranty
ROSSLARE ENTERPRISES LIMITED S (Rosslare) FIVE YEARS LIMITED WARRANTY
is applicable worldwide. This warranty supersedes any other warranty. Rosslare's FIVE
YEARS LIMITED WARRANTY is subject to the following conditions:
Warranty
Warranty of Rosslare's products extends to the original purchaser (Customer) of the
Rosslare product and is not transferable.
Products Covered By This Warranty and Duration
ROSSLARE ENTERPRISES LTD. AND / ORSUBSIDIARIES (ROSSLARE) warrants that
the AY-E20, Ultra Slim Metal Reader as listed above, to be free from defects in materials
and assembly in the course of normal use and service. The warranty period commences
with the date of shipment to the original purchaser and extends for a period of 5 years (60
Months).
Warranty Remedy Coverage
In the event of a breach of warranty, ROSSLARE will credit Customer with the price of the
Product paid by Customer, provided that the warranty claim is delivered to ROSSLARE by
the Customer during the warranty period in accordance with the terms of this warranty.
Unless otherwise requested by ROSSLARE ENTERPRISES LTD. AND / OR
SUBSIDIARIES representative, return of the failed product(s) is not immediately required.
If ROSSLARE has not contacted the Customer within a sixty (60) day holding period
following the delivery of the warranty claim, Customer will not be required to return the
failed product(s). All returned Product(s), as may be requested at ROSSLARE
ENTERPRISES LTD. AND /OR SUBSIDIARY’S sole discretion, shall become the property
of ROSSLARE ENTERPRISES LTD. AND /OR SUBSIDIARIES.
To exercise the warranty, the user must contact Rosslare Enterprises Ltd. to obtain an
RMA number after which, the product must be returned to the Manufacturer freight prepaid
and insured
In the event ROSSLARE chooses to perform a product evaluation within the sixty (60) day
holding period and no defect is found, a minimum US$ 50.00 or equivalent charge will be
applied to each Product for labor required in the evaluation.
Rosslare will repair or replace, at its discretion, any product that under normal conditions
of use and service proves to be defective in material or workmanship. No charge will be
applied for labor or parts with respect to defects covered by this warranty, provided that
the work is done by Rosslare or a Rosslare authorized service center.

Limited Warranty
AY-E20 Instruction Manual Page 12
Exclusions and Limitations
ROSSLARE shall not be responsible or liable for any damage or loss resulting from the
operation or performance of any Product or any systems in which a Product is
incorporated. This warranty shall not extend to any ancillary equipment not furnished by
ROSSLARE, which is attached to or used in conjunction with a Product, nor to any Product
that is used with any ancillary equipment, which is not furnished by ROSSLARE.
This warranty does not cover expenses incurred in the transportation, freight cost to the
repair center, removal or reinstallation of the product, whether or not proven defective.
Specifically excluded from this warranty are any failures resulting from Customer's
improper testing, operation, installation, or damage resulting from use of the Product in
other than its normal and customary manner, or any maintenance, modification, alteration,
or adjustment or any type of abuse, neglect, accident, misuse, improper operation, normal
wear, defects or damage due to lightning or other electrical discharge. This warranty does
not cover repair or replacement where normal use has exhausted the life of a part or
instrument, or any modification or abuse of, or tampering with, the Product if Product
disassembled or repaired in such a manner as to adversely affect performance or prevent
adequate inspection and testing to verify any warranty claim.
ROSSLARE does not warrant the installation, maintenance, or service of the Product.
Service life of the product is dependent upon the care it receives and the conditions under
which it has to operate.
In no event shall Rosslare be liable for incidental or consequential damages.
Limited Warranty Terms
THIS WARRANTY SETS FORTH THE FULL EXTENT OF ROSSLARE ENTERPRISES LTD.AND
IT’S SUBSIDIARY'S WARRANTY
THE TERMS OF THIS WARRANTY MAY NOT BE VARIED BY ANY PERSON,WHETHER OR
NOT PURPORTING TO REPRESENT OR ACT ON BEHALF OF ROSSLARE.
THIS LIMITED WARRANTY IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES.ALL OTHER
WARRANTIES EXPRESSED OR IMPLIED,INCLUDING WITHOUT LIMITATION,IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,ARE
SPECIFICALLY EXCLUDED.
IN NO EVENT SHALL ROSSLARE BE LIABLE FOR DAMAGES IN EXCESS OF THE
PURCHASE PRICE OF THE PRODUCT,OR FOR ANY OTHER INCIDENTAL,
CONSEQUENTIAL OR SPECIAL DAMAGES,INCLUDING BUT NOT LIMITED TO LOSS OF
USE,LOSS OF TIME,COMMERCIAL LOSS,INCONVENIENCE,AND LOSS OF PROFITS,
ARISING OUT OF THE INSTALLATION,USE,OR INABILITY TO USE SUCH PRODUCT,TO
THE FULLEST EXTENT THAT ANY SUCH LOSS OR DAMAGE MAY BE DISCLAIMED BY LAW.
THIS WARRANTY SHALL BECOME NULL AND VOID IN THE EVENT OF A VIOLATION OF THE
PROVISIONS OF THIS LIMITED WARRANTY.

Technical Support
AY-E20 Instruction ManualPage 13
Appendix B.Technical Support
Asia Pacific, Middle East, Africa
Rosslare Security Products Headquarters
905-912 Wing Fat Industrial Bldg,
12 Wang Tai Road,
Kowloon Bay Hong Kong
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
United States and Canada
1600 Hart Court, Suite 103
Southlake, TX, USA 76092
Toll Free:[phone]
Local:[phone]
Fax: [phone]
E-mail: [e-mail]
Europe
Global Technical Support & Training Center
HaMelecha 22
Rosh HaAyin, Israel 48091
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
South America
Pringles 868, 1640 Martinez
Buenos Aires
Argentina
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Web Site: www.rosslaresecurity.com

0706-0960225+01
www.rosslaresecurity.com
