Rosslare AY-B9250BT User manual

AY-B9250BT
Professional Fingerprint Reader
User Manual

Copyright © 2019 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’ (hereafter:
"ROSSLARE"). Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of
ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or other
intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS
DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER
LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD
PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL
PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third party any
license to these patents, trademarks, copyrights or other intellectual property rights,
except as expressly provided in any written agreement of ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.

AY-B9250BT User Guide 3
Table of Contents
Table of Contents.................................................................................................... 3
1. Before Getting Started ................................................................................. 5
1.1. Safety Notes........................................................................................................5
1.2. Product Details ...................................................................................................5
1.2.1. FRONT ......................................................................................................6
1.2.2. REAR.........................................................................................................7
1.2.3. Input / Output .............................................................................................8
1.3. Screen information during operation ................................................................9
1.3.1. Initial Screen ............................................................................................10
1.3.2. Icons ........................................................................................................10
1.3.3. Function KEY...........................................................................................10
1.3.4. Main Screen............................................................................................. 11
1.4. LED information during operation...................................................................12
1.5. Voice information during operation.................................................................12
1.6. Buzzer guide announced during operation ....................................................13
1.7. How to register and enter the correct fingerprint...........................................13
2. Product Description ................................................................................... 14
2.1. Product Features ..............................................................................................14
2.2. Diagram .............................................................................................................15
2.2.1. Single Type (Door Lock)...........................................................................15
2.2.2. Single Type (Lock Controller) ...................................................................15
2.2.3. Dummy Type............................................................................................15
2.2.4. Network Type (Door Lock)........................................................................16
2.2.5. Network Type (Lock Controller) ................................................................16
2.3. Product Specification.......................................................................................17
3. Environment Setting .................................................................................. 18
3.1. Checkpoints before Environment Setting.......................................................18
3.1.1. Menu........................................................................................................18
3.1.2. Administration authentication ...................................................................18
3.1.3. How to access the menu without administrator authentication .................19
3.1.4. Save Settings...........................................................................................19
3.1.5. Default Setting .........................................................................................20
3.1.6. Setting guide for Network Configuration ...................................................21
3.2. Access and Registration between Rosslare Bio9000 and terminal...............23
3.2.1. Install Rosslare Bio9000 ...........................................................................23
3.2.2. Execute Rosslare Bio9000.........................................................................23
3.2.3. Set in terminal..........................................................................................24
3.2.4. LAN connection in terminal.......................................................................25
3.2.5. Register the terminal in Rosslare Bio9000 ................................................25
3.3. Menu Configuration..........................................................................................27
3.4. USER Menu .......................................................................................................32
3.4.1. ADD..........................................................................................................32
3.4.2. AUTO ADD................................................................................................34
3.4.3. MODIFY....................................................................................................35
3.4.4. DELETE ....................................................................................................35
3.4.5. DELETE ALL..............................................................................................35
3.5. NETWORK Menu...............................................................................................36
3.5.1. AUTH Mode ..............................................................................................36
3.5.2. Terminal ID ..............................................................................................37
3.5.3. Terminal ...................................................................................................37
3.5.4. Server.......................................................................................................38
3.6. OPTION Menu ...................................................................................................38

AY-B9250BT User Guide 4
3.6.1. ATTEND ....................................................................................................39
3.6.2. Screen ......................................................................................................40
3.6.3. SAVE ........................................................................................................43
3.6.4. TIMEOUT..................................................................................................44
3.6.5. LOCKING ..................................................................................................45
3.7. INT DEVICE Menu .............................................................................................46
3.7.1. FP SENSOR...............................................................................................46
3.7.2. BEEP.........................................................................................................48
3.7.3. VOICE ......................................................................................................48
3.7.4. BLE...........................................................................................................48
3.7.5. TAMPER....................................................................................................48
3.8. EXT DEVICE Menu ............................................................................................49
3.8.1. DOORLOCK...............................................................................................49
3.8.2. RS485.......................................................................................................52
3.8.3. WIEGAND.................................................................................................52
3.9. STATUS Menu ...................................................................................................54
3.9.1. DB INFO...................................................................................................55
3.9.2. NETWORK ................................................................................................55
3.9.3. OPTION....................................................................................................55
3.9.4. INT DEVICE..............................................................................................55
3.9.5. EXT DEVICE .............................................................................................56
3.9.6. I/O PORT..................................................................................................56
3.9.7. VERSION ..................................................................................................56
3.10. RECOVERY Menu .............................................................................................57
3.10.1. INITIALIZE ........................................................................................57
3.10.2. SELF TEST.........................................................................................58
3.10.3. BACKUP .............................................................................................61
3.10.4. REBOOT ............................................................................................62
Appendix 1. Glossary............................................................................................. 63
Appendix 2. Declaration of Conformity ................................................................ 64
Appendix 3. Radio Equipment Directive (RED).................................................... 65
Appendix 4. RoHS Directive .................................................................................. 66

AY-B9250BT User Guide 5
1. Before Getting Started
1.1. Safety Notes
Warning
Do not operate the terminal
with wet hands, and pay
attention not to let any
liquid such as water enter
inside the terminal.
- > Otherwise, malfunction
or electric shock
may be
caused.
Keep the terminal away
from inflammables.
- >
Otherwise, it may
cause a fire.
Do not disassemble, repair
or remodel the terminal at
your disposal.
- > Otherwise, it may cause
malfunction, electric shock,
or a fire.
Do not allow children to
touch the terminal
carelessly.
- >
Otherwise, it may
cause safety accidents of
children or malfunction.
- Non-compliance of safety notes may cause death or serious injury for users.
Cautions
Do not install the terminal
in a place exposed to direct
sunlight.
→ Otherwise, it may cause
malfunction, deformation
and discoloration.
Do not install the terminal
in humid or dusty places.
→
Otherwise, it may
cause malfunction.
Do not clean this terminal
by sprinkling water, nor
wipe it with benzene,
thinner, and alcohol.
→ Otherwise, it may cause
electric shock or a fire.
Keep the terminal away
from magnets.
→
Otherwise, it may
cause failure and
malfunction.
Keep the fingerprint input
section clean.
→
Otherwise, the
fingerprint cannot be
recognized correctly.
Do not spray insecticides
or inflammables on the
terminal.
→
Otherwise, it may
cause deformation and
discoloration.
Keep the terminal away
from shock or sharp
objects.
→
Otherwise, it may
damage the terminal and
result in malfunction.
Do not install the terminal
in a place where there is
a severe change in
temperature.
→
Otherwise, it may
cause malfunction.
- Non-compliance of safety notes may cause personal injury or property damage for
users.
*We are not responsible for any accidents and damage that may arise from non-
compliance of the information in this manual.
1.2. Product Details

AY-B9250BT User Guide 6
1.2.1. FRONT
Camera
LCD
Function KEY (F1~F4)
Speaker
Card Sensor (EM/SC/HID)
Fingerprint
Sensor
State LED
BLE embedded
USB assist device
(UDL10) connection

AY-B9250BT User Guide 7
1.2.2. REAR
Fixed bracket
Cable harness

AY-B9250BT User Guide 8
1.2.3. Input / Output
Cable & Connector1.2.3.1.
Pin Details1.2.3.2.
Pin
number
Line color Label
(Line name)
Explanation IN/OUT Note
1 ORANGE EXT Inside open IN Connect to Exit button
2 YELLOW DM0 DoorMonitor0 IN Sense door state(DM0)
3 GREEN DM1 DoorMonitor1 IN Sense door state(DM1)
4 BLUE DM2 DoorMonitor2 IN Sense door state(DM2)
5
BLACK
GND
GND
-
Ground connection(for
door monitor)
6 RED 5V DC5V OUT DC 5V output
7
BLACK
PGND
Power GND
-
Power supply ground
connection
8
GREEN
R4A
RS485A
BI
RS-485 interface
9 BLUE R4B RS485B BI RS-485 interface
10
ORANGE
WO0
WIE_OUT0
OUT
Output WIGAND (WO0)
11 YELLOW WO1 WIE_OUT1 OUT Output WIGAND (WO1)
12
BROWN
WI0
WIE_IN0
IN
Input WIGAND (WI0)
13 PURPLE WI1 WIE_IN1 IN Input WIGAND (WI1)
14 BLACK GND GND - Ground connection
(WIGAND signal)
15
RED
-
N_TXN
OUT
LAN I/F (LAN cable)
16 BLACK - N_TXP OUT LAN I/F (LAN cable)
17
GREEN
-
N_RXN
IN
LAN I/F (LAN cable)
18 WHITE - N_RXP IN LAN I/F (LAN cable)
19 RED 12V DC12V IN DC 12V power supply
input
20 BLACK GND Power GND - Power supply ground
connection (Adapter)
21 RED 12V DC12V OUT DC 12V put out power

AY-B9250BT User Guide 9
22 GRAY L1C LOCK1_COM OUT Lock1 COM terminal
23
BROWN
L1NC
LOCK1_NC
OUT
Lock1 NC terminal
24 WHITE L1NO LOCK1_NO OUT Lock1 NO terminal
25 PURPLE L2 LOCK2 OUT Lock2 terminal
26 BLACK GND GND - Ground connection
(Lock connecter)
27 BLACK PGND Power GND - Power supply ground
connection (Lock
power)
28
BLACK
PGND
Panel GND
-
Panel ground
connection (Earth)
Terminal <- > MCP040 wiring1.2.3.3.
Category T2 terminal (Line name) MCP040
RS485A
R4A (green)
RDRA+
RS485B R4B (blue) RDRA-
ground connection GND (black) G
Terminal <- > LC015B wiring1.2.3.4.
Category T2 terminal (Line name) LC015B
RS485A R4A (green) 485A
RS485B
R4B (blue)
485B
ground connection GND (black) GND
DOOR MONITOR
IN1 (If this pin is not used,
connect to GND pin.)
INSIDE OPEN IN0
DC12V (LC015B separate power
supply)
DC12V IN
ground connection (Power only
for LC015B)
GND
But, door open time can be set with DIP SWITCH of LC015B (Maximum open time is 5 sec.)
Terminal <- > EM Type Door Lock wiring1.2.3.5.
Category T2 terminal (Line name) EM Door Lock
Lock
L1NC (Green)
+
GND GND (Black) -
Door Monitor DM0 (Black) NC(Normal Close)
Terminal <- > WIEGAND Device wiring1.2.3.6.
Category T2 terminal (Line name) WIEGAND Device
WIEGAND INPUT0 WI0 Wiegand output0
WIEGAND INPUT1 WI1 Wiegand output1
WIEGAND OUTPUT0 WO0 Wiegand input0
WIEGAND OUTPUT1 WO1 Wiegand input1
GND GND GND
1.3. Screen information during operation

AY-B9250BT User Guide 10
1.3.1. Initial Screen
When powering on at first, the screen is displayed as follow.
1.3.2. Icons
Server connection
State
NONE : No use network
: LAN line is disconnected.
: LAN line is connected (only link is connected)
: Connected with server
Gate
State
: Gate is closed.
: Gate is opened
: Gate is opened forcedly (unusual door open state)
: Gate communication problem
Warning signal
State
NONE : Normal
: Terminal Disassembly State
Fire detection
State
NONE
: Normal
: Sensed by fire detector (valid on DM2 fire set)
BLE connection
State
NONE : Disconnected with Admin App
: Connected with Admin App
MCP040 connection
State
NONE : MCP040 is not used (Normal state)
: MCP040 Mode and bad communication state
: MCP040 Mode and normal communication state
UDL connection
State
NONE : UDL is not used (Normal state)
: UDL is connected
1.3.3. Function KEY
Icon Meaning Function Key Explanation
UP F1 Move cursor up
DOWN F3 Move cursor down
LEFT F2 Move cursor to left
ESC F2 long Move to upper menu
RIGHT
F4
Move cursor to right
ENTER
F4 long or
Move to submenu
State icon
Operation Mode
TNA Mode
Date and Time
