Technical
Manual
RMB-1076
Table of Contents
Specification.....................................1
Parts List..........................................2~6
PCB Assembly.................................8
Schematic Diagram..........................9
10-10 SHINSEN-CHO , SHIBUYA-KU,
TOKYO 150-0045, JAPAN
Serial. NO.
®
Quality Uncompromised
Y-403A-0707/pdf
SIX CHANNEL POWER AMPLIFIER
Wiring Diagram ...............................7
Specifications
Power Configurations 6 x 100 watts
Watts/Channel 100 watts
All channels driven, with 20KHz filter unbridged, 8ohm, 20 to 20kHz, <0.02%THD
Total Harmonic Distortion < 0.02%
At rated power, 20-20,000Hz
Intermodulation Distortion < 0.03%
At rated power, 60 Hz : 7 kHz, 4:1
Power Output 4 ohms, 1.0% THD 180 watts
Frequency Response ±3 dB 10Hz–40kHz
Damping Factor 8 ohms 200
Signal to Noise Ratio IHF A network 105 dB
Amp Gain 27.2dB
Input Sensitivity / Impedance 1.25V/8.2 kohms
Auto Turn On Threshold Level (if activated) 10 mV input signal
Power Requirements
USA: 120 Volts, 60 Hz
Europe: 230 Volts, 50 Hz
Power Consumption 300 Watts
Output Peak Current 11A
Idling Power Consumption 70 watts
Standby Power Consumption 6 watts
Dimensions (W x H x D) 432 x 72 x 382 mm
17 1/8x 9 3/8x 15 1/8in
Front Panel Height (for rack mount) 60mm
Weight (net) 5.7 kg, 12.5 lb.

SIX CHANNEL POWER AMPLIFIER RMB-1076
POWER LEVELPROTECTION
CBA
Appearance RMB-1076
Please request:
When the fault are in the 200ASC or 200AC module,
replace the module and send back the modules later.
2

Parts List 1/2 RMB-1076
SYMBOL PARTS NO. DESCRIPTION
501 X-1493 PCB ASSY
L901 021 2698200001 LINE FILTER COIL RING-593
T001 022 T-1101N01 SUB TRANSFORMER
IC401,402 031 NJM5532DD IC (OPE DUAL)
IC701 031 PC817X2 IC (PHOTO COUPLER) PC817X2J000F
Q701,702 032 TA608-FG TRANSISTOR 2SA608KAA-FG
Q703-706 032 TC536-FG TRANSISTOR 2SC536KAA-FG
Q902 033 TA1016-FG TRANSISTOR 2SA1016KAA-FG
Q901 033 TC2362-FG TRANSISTOR 2SC2362KAA-FG
D701 034 T1N4148-86 DIODE 1N4148TAP-50
D903,904 034 TRD18JST1 ZENER DIODE 18V (AB2)
D901,902 034 W02M POWER DIODE 200V1.5A
C401-404 041 TUTES1E101-7TF ELECTROLYTIC CAPACITOR 25V100uF
C910-913 041 TUTES1E221-7TF ELECTROLYTIC CAPACITOR 25V220uF
C909 041 TUTES1E471-7TS ELECTROLYTIC CAPACITOR 25V470uF
C701 041 TUTES1H2R2-7TF ELECTROLYTIC CAPACITOR 50V2.2uF
C903-908 043 TC500V103 CERAMIC CAPACITOR 500V0.01uF
C902 044 DE2E3KH472MA3B SPARK KILLER 4700pF
C901 044 ECQU2A105KL SPARK KILLER 275V1uF
VR401-403 051 C-4170A36 VARIABLE RESISTOR 50KBX2
R715,716 053 CR16-224J-A CARBON RESISTOR 1/6W 220K
R717,906 053 CR16-472J-A CARBON RESISTOR 1/6W 4.7K
R902-905 054 ERQ1CJP2R2S FUSIBLE RESISTOR 1W 2.2
R901 054 MOF12-3M3 MOF RESISTOR 1/2W 3.3M
R907,908 054 TMF4700 METAL FILM RESISTOR 1/4W 470
R409,410 054 TMF1000 METAL FILM RESISTOR 1/4W 100
R401-406 054 TMF1001 METAL FILM RESISTOR 1/4W 1K
R407,408 054 TMF1002 METAL FILM RESISTOR 1/4W 10K
R701,702,707 054 TMF16-1001 METAL FILM RESISTOR 1/6W 1K
R703,704 054 TMF16-1002 METAL FILM RESISTOR 1/6W 10K
R708,711,712 054 TMF16-1003 METAL FILM RESISTOR 1/6W 100K
R709,710 054 TMF2202 METAL FILM RESISTOR 1/4W 22K
R411-417 054 TMF16-1004 METAL FILM RESISTOR 1/6W 1M
R705,706 054 TMF16-4702 METAL FILM RESISTOR 1/6W 47K
R713,714 054 TMF16-4703 METAL FILM RESISTOR 1/6W 470K
S901 061 C-4176A07 POWER SWITCH PS3-22-P3AV TV-8
S401,402 064 4TR-2341 SLIDE SWITCH SS010-P022BAb-PA9
S701 064 C-4660A00 SLIDE SWITCH SS010-P823
HJ1,2 065 YKB21-5103A 3.5ΦJACK (ST)
PJ1-4 066 4TR-2709#3 2P PIN JACK (WHT.RED)
SP1-3 067 C-4493B00 4P SPEAKER TERMINAL
D702,D905,AC115V,AC230V 068 B2B-EH CONNECTOR WAFER 2P
K33A 068 B2P3-VH CONNECTOR WAFER 2P
K34 068 B2P-VH CONNECTOR WAFER 2P
K1A,K2A,K3A,K32A 068 B4B-PH-KS CONNECTOR WAFER 4P
K4D,K10D 068 B5B-PH-KS CONNECTOR WAFER 5P
E3,E4 068 C-3681#1 2P PCB TERMINAL
AC115V,AC230V 068 C-4967A01 2P CONECTOR WIRE
011 FP-624-B BLACK PANEL ASSY
011 FP-624-S SILVER PANEL ASSY
O T H E R S
016 X-1493A01-05 PCB ASSY
3

Parts List 2/2 RMB-1076
SYMBOL PARTS NO. DESCRIPTION
011 VA3-01A00 H/S PANEL
012 RV4-09A00 PUSH BUTTON 14Φ(BLACK)
012 RV4-09A01 PUSH BUTTON 14Φ(SILVER)
012 VF4-22B00 KNOB 10Φ(BLACK)
012 VF4-22B01 KNOB 10Φ(SILVER)
014 WY3-05A00 UPPER COVER
019 4TSH-19#2 PLASTIC FOOT 50Φ(BLACK)
019 C-4714A00 POWER KNOB RING 14Φ(BLACK)
019 C-4714A01 POWER KNOB RING 14Φ(SILVER)
034 SEL1124R LED (RED) 1X5
034 SEL1E24W LED (BLU) 1X5
069 C-4629A01 AC 2P INLET 6102.3100
072 4TR-2489 3.5mm PLUG SHIELD CORD
072 C-4621A03 AC CORD SET SJT AWG16 for U.S.A.
072 C-4622A02 AC CORD SET for AUSTRALIA
072 C-4623A03 AC CORD SET for U.K.
072 C-4624A03 AC CORD SET for EUROPE
081 WY3-06A00 INSIDE CARTON
081 WY3-07A00 SHIPPING CARTON
081 ZE-219 ETHAFOAM MUOLDING
082 OMRMB-1076-81 OWNER'S MANUAL
092 ICEPOWER200AC DIGITAL AMP PCB ASSY
092 ICEPOWER200ASC DIGITAL AMP PCB ASSY
4

Panel Assy is included:
Side Cap
Knob Ring
LED
Addendum List for Black and Silver
LED (BLU) 1X5034 SEL1E24W LED (RED) 1X5034 SEL1124R PUSH BUTTON 14F (SLV)012 RV4-09A01 PUSH BUTTON 14F (BLK)012 RV4-09A00 H/S PANEL H60011 VA3-01A00 SILVER PANELASSY011 FP-624-S BLACK PANELASSY011 FP-624-B
DESCRIPTIONPARTSSYMBOL RMB-1076
5

<Memo>
6

J2
P1
J5J3
J4 J2
P1
J5J3
J4
J1J1
J2
J3
J6
J1
J5
092 ICEPOWER200AC
092 ICEPOWER200ASC 092 ICEPOWER200ASC
J2
J3
J6
J1
J5
092 ICEPOWER200AC
J2
J3
J6
J1
J5
092 ICEPOWER200AC
J2
J3
J6
J1
J5
092 ICEPOWER200AC
A-R B-L C-L C-R
B-R
A-L
501 X-1493-04(S1.S2)
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
P4P3
E1
P2P1
E5 E6 E7 E8
K19B
E2
K22B K24B
K26B K29B
K31B
K33A
19
501 X-1493-02
501 X-1493-03
K18B
D905 D702
K17B
K16B
K34
K33B
K25B
501 X-1493-05
K32B
E3
K4D
K7B K9B
K10D
K13B
K15B
K32A
K1A K2A K3A
E4
K5B K11B
3
39
2
1
456
789
10 11 12
12
14
15 16
17 18
7
11 10 98
12 13 7
3
3
3
3
3
4
4
4
4
4
4
4
3
3
3
S1
S2
K4B K6B K1B K8B
K10B
K2B
K12B K14B
K3B
POWER
LED
PROTECTION
LED
a
b
WIRING RMB-1076
N L
501 X-1493-01
CNT ASSY FROM
POWER LED
068 C-4586A09
(2P 160MM) X-1493-05 (D905)
X-1493-05 (D702)
X-1493-05 (K34)
X-1493-01 (K1A)
X-1493-01 (K2A)
X-1493-01 (K3A)
X-1493-01
X-1493-01
PROTECTION LED
068 C-4586A12
(2P 160MM)
X-1493-04 (S1.S2)
068 C-4877A05
(2P 120MM)
X-1493-03 (K1B)
068 C-4773A17
(4P 450MM)
X-1493-03 (K2B)
(K10D)
(E4-b)
068 C-4773A24
(4P 420MM)
X-1493-03 (K3B)
068 C-4773A25
(4P 400MM)
ICEPOWER
X-1493-03 (K10B)
068 C-4956A02
(8P-5P 160MM/2P 470MM)
200AC(C-R)
ICEPOWER
200AC(C-L)
ICEPOWER
(E4-b)
(J5)
(E4-b)
(J5)
X-1493-03 (K14B)
068 C-4957A01
(6P-2P 140MM)
X-1493-03 (K12B)
068 C-4957A02
(6P-2P 200MM)
X-1493-01
X-1493-01
X-1493-01
X-1493-01
(K4D)
(E4-a)
(J3)
X-1493-03 (K4B)
068 C-4956A01
(8P-5P 120MM/2P 450MM)
200AC(B-L)
ICEPOWER
200AC(A-R)
ICEPOWER
200ASC(A-L)
ICEPOWER
(E4-a)
(J5)
X-1493-03 (K8B)
068 C-4957A03
(6P-2P 250MM)
(E4-a)
(J5)
X-1493-03 (K6B)
068 C-4957A04
(6P-2P 400MM)
X-1493-05 (K16B) (P1)
068 C-4695A06
(2P 350MM)
X-1493-05 (K18B) (J5)
068 C-4958A01
(3P-2P 280MM)
X-1493-05 (K25B) (J5)
068 C-4958A02
(3P-2P 480MM)
X-1493-05 (K17B) (P1)
068 C-4695A13
(2P 540MM)
(J1)
068 C-4961A01
(2P 70MM)
200ASC(A-L)
ICEPOWER
200ASC(A-L)
ICEPOWER
200ASC(B-R)
ICEPOWER
200ASC(B-R)
ICEPOWER
200A(B-L)
ICEPOWER
200A(C-R)
ICEPOWER
200A(A-R) (J6)
ICEPOWER
(J1)
068 C-4961A01
(2P 70MM) 200A(C-L) (J6)
ICEPOWER
X-1493-05 (K33B)
068 C-4695A12
(3P 260MM) X-1493-02 (K33A)
200ASC(B-R)
ICEPOWER
200ASC(A-L)
ICEPOWER
200A(C-R)
ICEPOWER
200A(C-L)
ICEPOWER
200A(B-L)
ICEPOWER
200A(A-R)
ICEPOWER
X-1493-02 (K26B) (J2)
068 C-4959A01
(2P 120MM)
X-1493-02 (K31B) (J2)
068 C-4959A04
(2P 400MM)
X-1493-02 (K29B) (J2)
068 C-4959A03
(2P 300MM)
X-1493-02 (K24B) (J2)
068 C-4959A05
(2P 240MM)
X-1493-02 (K22B) (J2)
068 C-4959A02
(2P 240MM)
X-1493-02 (K19B) (J2)
068 C-4959A01
(2P 120MM)
200ASC(B-R)
ICEPOWER
200ASC(A-L)
ICEPOWER
200A(C-R)
ICEPOWER
200A(C-L)
ICEPOWER
200A(B-L)
ICEPOWER
200A(A-R)
ICEPOWER
X-1493-01 (K11B) (J4)
068 C-4661A09
(2P 140MM)
X-1493-01 (K15B) (J3)
068 C-4661A08
(3P 300MM)
X-1493-01 (K13B) (J3)
068 C-4661A07
(3P 240MM)
X-1493-01 (K9B) (J3)
068 C-4661A06
(3P 200MM)
X-1493-01 (K7B) (J3)
068 C-4661A07
(3P 240MM)
X-1493-01 (K5B) (J4)
068 C-4661A09
(2P 140MM)
200ASC(B-R)
ICEPOWER
200A(C-L)
ICEPOWER
200A(B-L)
ICEPOWER
200ASC(A-L)
ICEPOWER
X-1493-01 (K32A)
X-1493-05 (E3)
X-1493-02 (P3/E7) (J1)
068 C-4960A01
(2P 150MM)
X-1493-02 (P4/E8) (J1)
068 C-4960A04
(2P 300MM)
X-1493-02 (P2/E6) (J6)
068 C-4960A03
(2P 300MM)
X-1493-02 (P1/E5) (J1)
068 C-4960A02
(2P 300MM)
X-1493-05 (K32B)
068 C-4692A90
(4P 340MM)
X-1493-02 (E1) (E4-b)
073 RMB-1076-P
(#3 100MM)
073 RMB-1076-P
(#2 270MM) X-1493-02 (E2)
19
20
21
22
23
24
25
28
29
30
31
32
33
35
36
37
38
X-1493-02
39
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
27
26
34
AC INLET
WIRING
(N) (ACN)
(ACL)
(L)
200ASC(B-R) (J3) X-1493-01
TO 1 TO 2
7

PCB Assembly RMB-1076
Main PCB 016 X-1493A01~05
8

C30A
Schematic Diagram RMB-1076
9
