Rowenta HU5120 User manual

INTENSE AQUA CONTROL
HU5120
1800132653/03 - 33/15
EN
FR
SP
READ AND SAVETHESE INSTRUCTIONS
LISEZ ET CONSERVEZ CES INSTRUCTIONS
LEERY CONSERVAR ESTAS INSTRUCCIONES

2
3 3
2
4
2
91 1
13
8
2
4
7
1
6
10
5

3
EN
PRODUCT DESCRIPTION
Please read this instruction manual carefully as well as the instructions on safety and cleaning be-
fore you start using the appliance. Please keep this instruction manual in a safe place.
1. Product base
2. Water tank
3. Adjustable nozzle
4. Carrying handle for tank
5. Ceramic disc
6. Water level sensor
7.Tank stopper (and removable demineralization cartridge)
8. Removable demineralization cartridge
9. Control panel
10. Air outlet for the blower
Air that is too dry can cause or aggravate sinus and respiratory problems, lead to dry skin, nose
and throat and dry out plants and furniture.
Your humidifier is an effective device for diffusing water vapor in the surrounding air.
Humidity, which is expressed as Relative Humidity (HR), is the quantity of vapor present in the
air expressed as a percentage of the maximum quantity of vapor that the air can hold at the
same temperature without causing condensation.
Relative Humidity is measured with a hygrometer:
• RH <50%: the air in the room is too dry.
• RH between 50 and 60%: the air is considered healthy.
• HR> 60%: the air is too humid.
OPERATING PRINCIPLE
Your humidifier uses two complementary humidifying systems:
• A cold vapor system: a ceramic disc that vibrates at an ultrasonic frequency to create tiny
water droplets.
• Pre-heated mist system (95°F) for anti-bacterial and turbo effects: a heating tube generates
water vapor (only on HU5120 model).
It can thus be used to automatically increase the level of humidity of the surrounding air and it also
has an electronic hygrometer for precise control of the Relative Humidity.
LOCATION
The use of a humidifier is particularly recommended in winter but the house should still be re-
gularly aired.
First, place the humidifier in the room requiring priority treatment. It is suitable for a room of
45m² [500sq ft].

4
EN
DESCRIPTION OFTHE CONTROL PANEL
Controls
A. On/Off Button
B.Timer button
C. Select button for targeted relative humidity
D. Pre-heated mist (95°F) for anti-bacterial and turbo effects button (only on HU5120 model)
E. Select button for ”Smart” (pre-set) modes
F. Vaporisation speed selection button
G. Lighting/Sound button
Display screen
h.Timer : 1 to 9 hours
i. “House” indicator - actual (ambient) relative humidity
j. SELECT mark - required (target) relative humidity
k. Relative Humidity (RH) in % HR
l. AUTOMATIC mode
m. BABY mode
n. NIGHT mode
o. Water level too low
p. Vaporisation speeds
q. Pre-heated mist (95°F) for anti-bacterial and turbo effects (only on HU5120 model)
B
h
Ak nmlji
q p
C
D
G
F
E
o

5
EN
WARNINGS
It is essential to read these instructions carefully and to observe the following recommendations.
•This appliance is not intended to be used by persons (including chil-
dren) with reduced physical, sensory or mental capacities, or without
the necessary experience and knowledge unless they are supervi-
sed or have been given instructions beforehand on the use of the
appliance by a person responsible for their safety.
• This appliance may be used by children aged 8 and over and by
persons with reduced physical, sensory or mental capacities, or wi-
thout the necessary experience or knowledge, if they are properly
supervised or have been given instructions beforehand on how to
use the appliance safely and made aware of the risks involved.
Make sure that children do not play around with the appliance.
Cleaning and maintenance must not be carried out by children un-
less supervised.
• For your safety this appliance is compliant with applicable standards and regulations (Low Voltage
and Electromagnetic Compatibility Directives…).
•This appliance has been designed for domestic use only. It can therefore not be used for any indus-
trial application.
•The guarantee is void in the event of any damage caused by improper use.
• Do not operate your appliance in a very dusty atmosphere or where there is a fire risk.
• Before each use, check that the appliance, power cord and plug are in good general condition.
• Never insert objects into the appliance (e.g. : needles…)
• If the power cord is damaged, it must be replaced by the manufacturer, an approved after-sales ser-
vice centre or a similarly qualified person in order to avoid any danger.
• Keep this appliance out of the reach of children.
• Never pull on the power cord or the appliance, even to disconnect the plug from the wall outlet.
• Unroll the power cord completely before use.
•The regulations concerning the removal of oil and refrigeration agent when the appliance is being dis-
posed of must be observed.
• Do not use the appliance outdoors.
VERY IMPORTANT
•The appliance must be installed in accordance with your country’s national regulations.
•The appliance must be fully assembled before connecting to the mains.
• Never use the appliance in any position other than an upright position.
• Place the appliance on a flat, horizontal and stable surface that is not sensitive to humidity. Do not
place the humidifier on any wooden furniture, Hi-fi system,TV, or any other electrical appliance.
• Fill the water tank with clean, cool tap water. Use preferably distilled water if you live in a hard water
area, or if white dust accumulates around the product despite the use of the anti-calc cartridge. It is re-
commended to change the water in the tank at least once a week.
• Never cover the appliance.
• Never obstruct the intake grills which are located under the appliance.
• Never use the appliance without its nozzle.
• Never touch the appliance with wet hands.
• Never move the appliance when it is in operation.
• Never put water in the evaporation duct, it could cause an overflow.
• Never use the appliance near to inflammable objects and materials (curtains, aerosols, solvents, etc.…).
• Only use special Rowenta demineralization cartridges.
•Turn off and disconnect the appliance before filling, cleaning or moving it.
• Never put essential oil or other additives in the evaporation duct and/or the water tank.
• Never leave water in the tank when the appliance is not being used.
•
Please be aware that high levels of humidity may encourage biological organisms to grow in the environment .

6
• Do not allow the area around the appliance to become humid or damp. Should this happen, you
should reduce the humidifying speed or turn the appliance off.
• Never allow absorbent materials such as carpet, curtains, or tablecloths to become humid or damp…
• If the appliance is to be left unattended for a prolonged period of time: it is important to turn it off, un-
plug it, empty the water tank and the vaporisation compartment, then clean and allow the appliance to dry.
• Clean the appliance before and after storage.
• Regular cleaning of the appliance is recommended; approximately every 1-2 weeks (depending on use).
•WARNING : Micro-organisms can grow in the water tank and be blown in the air when the water tank
is not cleaned regularly and properly (see MAINTENANCE paragraph).
This device complies with Part 18 of the FCC Rules. Operation is subject to the following two conditions :
(1) this device may not cause harmful interference, and (2) this device must accept any interference recei-
ved, including interference that may cause undesired operation.
STARTINGTHE APPLIANCE
Before using the appliance for the first time, check that your main supply voltage matches that indi-
cated on the appliance.
Before switching on your appliance make sure that:
• the appliance is positioned in accordance with these instructions,
• the appliance is on a flat and stable horizontal surface which is not sensitive to humidity and at
least 20cm from any other object,
• the intake grills located under the appliance are totally unobstructed.
How to use your appliance:
1. Lift the water tank, remove the adjustable nozzle (3) and unscrew the demineralization cartridge
holder stopper (7).
2. Clean the tank (see paragraph CLEANING) and fill it with clean, cool tap water (minimum 2 litres
[0,5 gallon] / maximum 5.5 litres [1.5 gallons]).
PLEASE NOTE:We advise you to use preferably distilled water if you live in a hard water area, or if
white dust accumulates around the product despite the use of the anti-calc cartridge.
3. Tighten the stopper and check that there are no water leaks.
4. Check that the base of the appliance is clean and that there are no foreign objects.
5. Check that the water level sensor is not obstructed.
6. Reposition the tank on the base.
7. Adjust the nozzle so that the vapor jet is not directed at an obstacle, which could adversely affect
the humidity regulation.
8. Wait for ten or so minutes for the water to pass through the demineralization cartridge and fill the
vaporisation compartment.
9. Plug the appliance in.
10.Turn the appliance on.
20cm20cm
5,5L
[1.5 gal]
max
EN

7
10min
HOWTHE APPLIANCE OPERATES
This appliance has 2 operating modes (MANUAL or AUTOMATIC) as well as various additional func-
tions.
• ”ON/STAND-BY”: Switch on / Standby (Stop); Button A.
Press button (A) to start the appliance or to put it on standby.
MANUAL FUNCTION MODE:
Adjusting the required (target) level of humidity and vaporisation speed
• Humidity level: Button C for adjusting the required (target) humidity level;
Select the required humidity level by pressing button C several times.
When SELECT appears, the humidity level displayed is the required level that you have set the ap-
pliance to: between 40% and 75% RH or “Co” for a continuous operation (there is a safety stop sys-
tem if the humidity level in the room exceeds 90% RH).
When the “HOUSE” logo is visible without SELECT, the humidity level displayed is that of the area in
the room around the appliance.
PLEASE NOTE:This setting cannot be used for “Smart” modes.
WARNING: In the continuous operating mode, the humidity in the room can reach very high levels
that are not beneficial to health and can damage certain objects.The recommended optimal humi-
dity level is between 50 and 60% HR.
• Vaporisation speed: Button F for setting the vaporisation speed;
Select the required vaporisation speed by pressing button F several times.There are three vaporisa-
tion speeds to choose from.
PLEASE NOTE:This setting cannot be used for “Smart” modes.
SMART OPERATION MODES:
How to use the 3 pre-set operating modes
• SMART MODES: Button E for selecting the pre-set operating modes;
You can select one of the three pre-set modes by pressing button E several times.
AUTO Mode: Automatic operation mode for a required humidity level pre-set at 55% RH; the ap-
pliance will automatically adapt its vaporisation speed depending on the humidity of the room.
BABY Mode: Automatic operation mode for a required humidity level pre-set at 50% RH; the ap-
pliance will automatically adapt its vaporisation speed depending on the humidity of the room. Once
it has been running for 7 hours the appliance will stop automatically.
PLEASE NOTE:The lights and beeps are deactivated in this mode.
NIGHT Mode: Automatic operation mode for a required humidity level pre-set at 50% RH; the ap-
pliance will gradually reduce its vaporisation speed. Once it has been running for 8 hours the ap-
pliance will stop automatically.
PLEASE NOTE:The lights and beeps are deactivated in this mode.
EN

8
ADDITIONAL FUNCTIONS:
•Timer: Button B for programming the automatic stop of the appliance.
Select the number of hours that you want the appliance to run for (from 1 to 9 hours) before the ap-
pliance automatically stops, by pressing button B several times.
PLEASE NOTE:This function cannot be used for “Smart” modes.
• Pre-heated mist (95°F) for anti-bacterial and turbo effects: Button D for using the Pre-heated mist
function (only on HU5120 model).
Press button (D) to start or stop the “Pre-heated Mist” function.
This function allows you to kill the bacteria which may develop in the water*. This function also comes as an
extra to the other operating modes and allows you to increase the humidity output by 20%.
• ”Light &Sound”: On/Off Light &Sound; Button G.
Press button (G) to turn the function on or off.
This function allows you to switch off the LCD screen backlighting as well as the beep sounds and to
light up the water tank.
MAINTENANCE
IMPORTANT:
•This type of appliance requires regular and thorough maintenance. Like for any humidifier with
stagnant water, we recommend to clean approximately every 1-2 weeks (depending on use) to
avoid bacteria proliferation.
• Regular cleaning of the ceramic disk will avoid scaling.
•You must always switch off and unplug your appliance before undertaking any maintenance on it.
It is important to clean the water tank, the vaporisation area (around the ceramic disk) and the intake
grills located under the appliance regularly.
• Cleaning the tank:
1- Remove the demineralization cartridge and rinse it in fresh tap water only.
2- Clean the tank and the tank stopper using soapy water and dry it with a soft dry rag.
3-To clean the inside of the tank, pour a little water into it and shake vigorously. Empty and dry with
a soft dry rag.
• Cleaning the vaporisation compartment:
1- Remove the tank.
2- Fill the vaporisation compartment half with water and half with white vinegar (4% acetic acid).
3- Leave the mixture for a minimum of 4 hours so that it can take effect.
4- Empty and remove the scale using a soft damp rag.
5- Rinse out the whole of the compartment with fresh tap water (Important, make sure that no water
gets into the blower opening (10).
CAUTION:
• Never use detergents, scouring products or abrasive cleaners for cleaning the appliance as these are
likely to spoil the appearance of your device. Instead, clean your appliance with a slightly moist rag.
• Never use hard or abrasive ustensils to clean the ceramic disk so as not to damage it.
• Never immerse the base of the appliance, the power cord or plug in water or any other liquid.
• Demineralization cartridge:
On average the demineralization cartridge should be replaced every 1 to 3 months.This interval can
be shorter or longer depending on the hardness of the water. White dust around the appliance is a
sure sign that the cartridge needs replacing.
*Kills 100% of Escherichia Coli and Staphylococcus Aureus bacteria representing most of the bacteria known to
exist after 30 minutes of use - under normal conditions of use – tests carried out by an independent laboratory.
EN

9
If you have any questions, please see the ROWENTA international guarantee card enclosed with this
product, where you will find the Consumer Service contact details.
STORAGE
When the appliance is not in use, it should be stored in a dry place.
Make sure to empty the tank, clean and dry the appliance before storing it.
INTHE EVENT OF A PROBLEM
Never dismantle your appliance yourself. An incorrectly repaired appliance can be a danger to the user.
Before contacting an approved Service Centre from our network, make sure that the appliance is in
the normal operating position and the air intake and outlet grills are totally unobstructed.
This user manual is downloadable online.
For any product problems or queries, please visit our website : www.rowenta.com
or contact our helpline on 1-800-ROWENTA (for US only)
Type of problem Points to check
The appliance does not work when switched on Is the low water level indicator blinking?
Positioning of the appliance (tilt). Positioning
of the tank. Connection of the appliance.
Required water level not yet reached in the
vaporisation compartment (wait a few moments).
The humidification capacity is too low Doors and windows are closed.
Vaporisation rate too low.
Obstruction of the intake grills and nozzle.
The ambient humidity is too high Relative humidity setting.
Condensation in the room The room temperature is too low.
The appliance is too noisy Place the appliance on a flat and stable surface
The appliance stops Programmed operating period has run out.
Is the water level indicator blinking?
Optimum humidity level set.
The pre-heated mist function doesn’t produce
any warm humidity
Even if the water is heated in the base, the mist
produced doesn’t feel warm due to the fact it is
so fine and is cooled rather quickly from the air
in your home.
There is white dust around the appliance This is a sure sign that the cartridge needs
replacing. If white dust still accumulate around
the product despite the change of the anti-calc
cartridge or if you live in a hard water area,
use preferably distilled water.
There is a difference between the humidity
level read by the humidifier and the one read
by an external hygrometer
Not all hygrometers are calibrated the same,
and most are off by +/- 5%. Moreover, the humi-
dity level is not the same in the whole room as
the air circulation is different in every corner of
the room. Besides,do not place the device near
a heater or a radiator as the heat will absorb
all of the moisture.”
EN
