RS IDM 61 User manual

Instruction Manual
IDM 61/62T
Digital Multimeter
EN DE ES IT FR

IDM 62T

EN - 1
Safety Information
Read and understand this Instruction Manual completely before using this
instrument. Failure to observe the warnings and cautions in this Instruc-
tion Manual may result in injury or death, or damage to the
instrument and other equipment or property.
If this instrument is used in a manner not specified in these instructions,
the protection provided by the instrument may be impaired.
WARNING
-Examine the instrument and probes before use. Do not use the
instrument if it is wet or damaged.
-When using test leads or probes, keep your fingers behind the
finger guards.
-Remove the test lead from the instrument before opening the
battery cover or instrument case.
-Always use the correct terminals, switch position and range for
measurements.
-Never attempt a voltage measurement with the test leads inserted
into the A input terminals.
-Verify the instrument is operating correctly by measuring a known
voltage before use. If in doubt, have the instrument serviced.
-Do not apply more than the rated voltage, as marked on the
instrument, between terminals or between any terminal and earth
ground.
-Do not attempt a current measurement when the open-circuit
voltage is above the fuse protection rating.
-Only replace a blown fuse with the correct type and rating as specified
in this Instruction Manual.
-Use caution when measuring voltages above 30 Vac rms or 60 Vdc.
These voltages pose a shock hazard.
-To avoid incorrect readings that can lead to electric shock, replace the
battery as soon as low battery indicator <appears in the display.
-Disconnect the circuit power and discharge all high-voltage capacitors
before making resistance, current, continuity, diode or capacitance
measurements.
-Do not use the instrument in a Hazardous Area or around explosive
gasses or vapours.
-Wear suitable Personal Protective Equipment when working around or
near hazardous Live conductors which could be accessible.

EN - 2
The following symbols may appear on the instrument
and in this Instruction Manual :
Risk of electric shock
Refer to Instruction Manual
Direct Current (dc)
Equipment protected throughout by double or reinforced
insulation
Battery
Fuse
Earth
Alternating Current (ac)
Conforms to applicable EU directives
Caution
-Disconnect the test leads from the test points before changing the
position of the function rotary switch.
-Never connect the instrument to a source of voltage with the function
rotary switch in Ω/ ;/A//Hz position.
-If possible, do not work alone, so assistance can be given if required.
-Do not expose the instrument to extremes of temperature or high
humidity.
-Never set the instrument to the A function to measure the
voltage of a power supply circuit, as it may result in damage to the
instrument and the equipment under test.
Maintenance
Do not attempt to repair this Instrument. It contains no user-serviceable
parts. Repair or servicing should only be performed by qualified person-
nel. This instrument should be calibrated yearly, or more frequently if
used in harsh conditions or if it is suspected of being inaccurate.
For calibration and repair contact RS Components - the address is
given at the end of these instructions.
Cleaning
Periodically wipe the case with a damp cloth and detergent. Do not use
abrasives or solvents.

EN - 3
Measuring AC/DC Voltage and Frequency
Continuity and Diode Test
Black
Red
Black
Red
Black
Red
Black
Red
Bad Diode
Good Diode

EN - 4
Resistance and Capacitance Measurement
(Capacitance for 62T only)
Note –To improve the measurement accuracy of a small value capacitor,
record the reading with the test leads open circuit, then substrate the
residual capacitance of the Instrument and leads from the final
measurement.
CUNKNOWN =CMEASUREMENT - CRESIDUAL
MIN MAX Record (For 62T only)

EN - 5
Measuring DC / AC Current (For 62T only)
Disconnect
Temperature °C , °F
R
DCV

EN - 6
Manual Ranging and Auto Ranging
10 min
Auto Power-off (Battery Saver)
Display Hold

EN - 7
NCV
1. The VoltSense function will operate irrespective of the position of
the function rotary switch, including the OFF position.
2. Remove the test leads from the instrument as they are not used for
the VoltSense test.
3. Press and hold the VoltSense button. The LCD display will go blank,
a tone will sound and the red LED will illuminate momentarily to
confirm the instrument is operational.
4. Hold the Volt sense button down and move the instrument over the
area where detection is required. The buzzer will sound and the LED
will illuminate when a live conductor is detected. Release the
VoltSense button to return to normal operation.
Non-Contact Voltage Sensing (VoltSense)
Disable Auto Power-off

EN - 8
Fuse Replacement (For 62T only)
WARNING
Disconnect the test leads from the circuit and the instrument before
removing the rear cover. Caution
Use only a replacement fuse of the type and rating given in the
specifications.
Refer to the following figure to replace the fuse :
Battery Replacement
When the low battery indicator "<" appears on the LCD, replace the
batteries with the type given in the specifications.
WARNING
Disconnect the test leads from the circuit and the instrument before
removing the battery cover.
Refer to the following figure to replace the batteries :

EN - 9
Specifications
General Specifications
Display : 2000 counts.
Polarity Indication : Automatic, positive implied, negative indicated.
Overrange Indication : “OL” or “-OL”.
Batteries Life : 250 hours approx with Alkaline cells.
Low Batteries Indication :
drops below the minimum operating voltage.
Auto Power Off : Approx 10 minutes after last operaton.
Storage Temperature : -20 to 60C (-4F to 140F) @ 0 to 80%
R.H. with the battery removed from the instrument.
Operating Ambient : Non-condensating, ≦10C (50F) ; 11 to 30C
(51.8F to 86F) @ ≦80% R.H; 31 to 40C (87.8F to 104F) @ ≦75%
R.H; 41 to 50C (105.8F to 122F) @ ≦45% R.H.
Measurement Category (Installation Category) per IEC 61010-
1:2001: V/Ω: CAT.III. 600V, CAT.II. 1000V.
A: CAT.III. 600V (for 62T only)
Pollution Degree 2
Measurement Category l is for measurements performed on circuits
not directly connected to mains. Examples include: Measurements on
battery powered equipment and specially protected (internal)
mains-derived circuits.
Measurement Category ll is for measurements on circuits directly
connected to the low voltage installation. Examples include: Household
appliances, portable tools and similar equipment.
Measurement Category lll is for measurements performed in the
building installation. Examples include measurements on distribution
boards, junction boxes, socket-outlets and wiring and cables in the fixed
installation.
Measurement Category lV is for measurements performed at the
source of the low-voltage installation. Examples include measurements
on primary over current protection devices and electricity meters.

EN - 10
Temperature Coefficient : 0.27 x Spec. Accy / C <18C or >28C;
(0.15 x Spec.Accy / F,< 64.4F or > 82.4F).
Power Requirements : Qty. 2 x 1.5V Alkaline type AA batteries.
Fuse (For 62T only) : 10mmx38 mm 10Amp 600V ac/dc HBC,
Little fuse KLKD10 or equivalent.
Dimensions (W x H x D) : 74mm x 156mm x 44mm
Accessories : Battery (installed), Test leads and user manual.
Measurement rate : Sampling rate 2 times per second nominal.
Altitude : 6561.7 ft (2000m)
Safety : Complies with EN61010-1:2001, UL61010-1:2001 and
IEC 61010-1:2001.
Weight : (320g) including battery.
Electrical Specifications
Accuracy is ±(% reading + number of digits) at 23°C ±5°C < 80%RH.
DC / AC Volts
Range AC Accuracy
200.0mV * Unspecified
2.000V * ±(1.5%+5dgt) 50Hz ~ 300Hz
20.00V ~ 200.0V * ±(1.5%+5dgt) 50Hz ~ 500Hz *
750V AC / 1000V DC
DC Accuracy : ±(0.5% + 2dgt)
Over voltage protection : 1000V DC or 750 V ACrms.
Input Impedance : 10MΩ // less than 100pF.
* CMRR / NMRR : (Common Mode Rejection Ratio)
(Normal Mode Rejection Ratio)
VAC : CMRR > 60dB at DC, 50Hz / 60Hz
VDC : CMRR > 100dB at DC, 50Hz / 60Hz
NMRR > 50dB at DC, 50Hz / 60Hz
AC Conversion Type : Average sensing rms indication.
AC conversions are ac-coupled,true rms responding, calibrated to the
sine wave input.
* The minimum LCD reading is 1400 count in Auto Ranging Mode.
Crest Factor : C.F. = Peak / Rms
+ 1.5% addition error for C.F. from 1.4 to 3
+ 3% addition error for C.F. from 3 to 4

EN - 11
DC / AC Current (For 62T only)
Range DC Accuracy AC Accuracy Voltage Burden
±(1.0% + 3 dgt) ±(1.5% + 5 dgt)
50Hz ~ 500Hz * 2V max
2.000A
10.00A **
Overload Protection :
A input : 10A (600V) fast blow fuse
* AC Conversion Type : Conversion type and additional specification
are same as DC/AC Voltage.
Resistance
Range Accuracy Voltage Burden
200.0 ~ 200.0KΩ ** ±(0.7% + 3 dgt)
2V max
2.000MΩ** ±(1.0% + 3 dgt)
20.00MΩ*±(1.5% + 3 dgt)
Open circuit Voltage : -1.3V approx.
* <100 dgt rolling.
** Ampere Testing Duty Ratio Table
Ampere Testing Time Rest Time
10A 4min 10min
9A 5min 10min
8A 7min 10min
7A 10min 10min
6A Continually N/A

EN - 12
Diode Check and Continuity
Range Resolution Accuracy
10 mV ±(1.5% + 5 dgt)*
*For 0.4V ~ 0.8V
Max.Test Current : 1.5mA
Max. Open Circuit Voltage : 2V
Overload Protection : 600V rms.
Frequency (For 62T only)
Range Sensitivity Accuracy
2000Hz ~200.0KHz >1.5 Vac rms, <5 Vac rms Frequency :
0.01%±1digit
2.000MHz ~ 20.00MHz >2 Vac rms, <5 Vac rms
Overload Protection : 600V rms.
Minimum pulse width : >25 ns
Duty cycle limits : >30% and <70%
Capacitance (For 62T only)
Range Accuracy Overload Protection
2.000nF ~ 200.0µF
±(1.9% + 8 dgt) 600V rms
2.000mF *
* < 10 dgt of reading rolling.
Temperature (°C ) (For 62T only)
Temperature Accuracy Overload Protection
-20°C ~ 0°C ±(2% + 4°C )
600V rms
1°C ~ 100°C ±(1% + 3°C )
101°C ~ 500°C ±(2% + 3°C )
501°C ~ 800°C ±(3% + 2°C )

EN - 13
Temperature (°F ) (For 62T only)
Temperature Accuracy Overload Protection
-4°F ~ 32°F ±(2% + 8°F)
600V rms
33°F ~ 212°F ±(1% + 6°F)
213°F ~ 932°F ±(2% + 6°F)
933°F ~ 1472°F ±(3% + 4°F)
Limited Warranty
This instrument is warranted to the original purchaser against defects in
material and workmanship for 3 years from the date of purchase.
During this warranty period, RS Components will, at its option, replace
or repair the defective unit, subject to verification of the defect or
malfunction. This warranty does not cover disposable batteries, or
damage from abuse, neglect, accident, unauthorized repair, alteration,
contamination, or abnormal conditions of operation or handling.
Any implied warranties arising out of the sale of this product, including
but not limited to implied warranties of merchantability and fitness for a
particular purpose, are limited to the above. RS Components shall not
be liable for loss of use of the instrument or other incidental or
consequential damages, expenses, or economic loss, or for any claim
or claims for such damage, expense or economic loss. Some states or
countries laws vary, so the above limitations or exclusions may not
apply to you. For full terms and conditions, refer to the current RS
Catalogue.

Africa
RS Components SA
P.O. Box 12182, Vorna Valley, 1686
20 Indianapolis Street, Kyalami Business Park,
Kyalami, Midrand
South Africa
www.rs-components.com
Asia
RS Components Pte Ltd.
31 Tech Park Crescent
Singapore 638040
www.rs-components.com
China
RS Components Ltd.
Suite 23 A-C , East Sea Business Centre
Phase 2 , No. 618 Yan'an Eastern Road
Shanghai, 200001
China
www.rs-components.com
Europe
RS Components Ltd.
PO Box 99, Corby,
Northants. NN17 9RS
United Kingdom
www.rs-components.com
Japan
RS Components Ltd.
West Tower (12th Floor),
Yokohama Business Park, 134 Godocho, Hodogaya,
Yokohama, Kanagawa 240-0005
Japan
www.rs-components.com
U.S.A
Allied Electronics
7151 Jack Newell Blvd. S.
Fort Worth, Texas 76118
U.S.A.
www.alliedelec.com
South America
RS Componentes Limitada
Av. Pdte. Eduardo Frei M. 6001-71
Centro Empresas El Cortijo
Conchali, Santiago, Chile
www.rs-components.com
