RST Instruments DT2011B User manual

8-Inch Secondary Enclosure
Installation Guide

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 2
Table of Contents
1PRODUCT OVERVIEW ...........................................................................................3
1.1 Dimensions................................................................................................3
1.2 Intended Audience.....................................................................................3
2REQUIRED TOOLS................................................................................................3
3INSTALLATION GUIDES.........................................................................................3
3.1 Install an 8-Inch Secondary Enclosure.......................................................3
3.2 Install a DT2011B Data Logger..................................................................7
3.3 Install a DT2055B Data Logger..................................................................9
3.4 Install an Affinity Data Logger..................................................................10
4SERVICE,REPAIR AND CONTACT INFORMATION...................................................12
REVISION HISTORY
Rev.
Revision History
Date
Prepared By
Approved By
A
Initial release
April 19, 2023
Hadylee Wan
Tommy Wong

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 3
1 PRODUCT OVERVIEW
RST’s 8-Inch Secondary Enclosure is built for use in remote locations where
data loggers will require protection from natural elements and tampering from
vandals or wildlife. Designed for use with RST’s Affinity, DT2011B and DT2055B
data loggers, this enclosure fully meets most site protection and security
requirements.
1.1 DIMENSIONS
Enclosure only: Height 38.3" X Diameter 9.1"
Enclosure with ground stake: Height 68" x Width 9.8"
Enclosure with pole mounting bracket: Height 38.3" x Width 12.3"
1.2 INTENDED AUDIENCE
This guide is for the personnel installing an RST 8-inch secondary enclosure.
This guide provides steps for installing a secondary enclosure and an Affinity,
DT2011B or DT2055B data logger inside it.
2 REQUIRED TOOLS
The following tools you will need to install the secondary enclosure:
•Screw driver
•M6 hex driver
•M10 wrench, ratchet socket wrench or adjustable wrench
•Level (optional)
•Hammer or mallet (to drive the ground stake)
NOTE: Depending on the soil you are installing on, you may need an appropriate
tool to drive the stake to the ground.
3 INSTALLATION GUIDES
3.1 INSTALL AN 8-INCH SECONDARY ENCLOSURE
To install an 8-inch secondary enclosure, complete the following steps:
1. Loosen the M6 hex head locking screw on the front of the enclosure.
NOTE: Do not remove the M6 hex head locking screw from the lower enclosure.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 4
2. Twist the upper and lower sections of the enclosure and pull them apart.
3. Unscrew the 36-inch ground stake from the lower enclosure.
NOTE: Do not remove the mounting post. Do not discard the M10 hex head screws,
washers, and nuts. You will need them to reinstall the ground stake.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 5
4. Drive the pointed end of the ground stake no more than 30” (762 mm) into
the ground. Make sure to leave 6” of the stake above the ground.
NOTE: Depending on the soil you are installing on, you may need a hammer, a
mallet, or an appropriate tool to drive the ground stake to the ground.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 6
5. Re-install the lower section of the enclosure to the ground stake using the
M10 hex head screws, washers, and nuts.
NOTE: Make sure the lower section of the enclosure is as close to the ground as
possible without touch the ground surface.
6. Install the data logger. Refer to the procedure specific to the data logger.
•Install a DT2011B Data Logger
•Install a DT2055B Data Logger
•Install an Affinity Data Logger

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 7
3.2 INSTALL A DT2011B DATA LOGGER
To install a DT2011B data logger to a secondary enclosure, complete the
following steps:
1. Remove the front lid from the data logger.
2. Find the mounting plate and the appropriate screws (check the label on the
bag) for the data logger in the secondary enclosure package.
3. Insert the screws through the mounting holes on the data logger.
4. Screw the data logger onto the mounting plate with the antenna pointing up.
5. Screw the front lid back onto the data logger.
6. Slide the mounting plate downward on the mounting post to lock in place.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 8
7. Twist the upper enclosure onto the lower enclosure. Tighten the M6 hex
head locking screw.
NOTE: The see-through picture on the right is for illustration purposes only.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 9
3.3 INSTALL A DT2055B DATA LOGGER
To install a DT2055B data logger to a secondary enclosure, complete the
following steps:
1. Remove the front lid from the data logger.
2. Find the mounting plate and the appropriate screws (check the label on the
bag) for the data logger in the secondary enclosure package.
3. Insert the screws through the mounting holes on the data logger.
4. Screw the data logger onto the mounting plate with the antenna pointing up.
5. Screw the front lid back onto the data logger.
6. Slide the mounting plate downward on the mounting post to lock in place.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 10
7. Twist the upper enclosure onto the lower enclosure. Tighten the M6 hex
head locking screw.
NOTE: The see-through picture on the right is for illustration purposes only.
3.4 INSTALL AN AFFINITY DATA LOGGER
To install an Affinity data logger to a secondary enclosure, complete the
following steps:
1. Find the mounting plate and the appropriate screws (check the label on the
bag) for the data logger in the secondary enclosure package.
2. Insert the mounting screws through the back of the mounting plate.
3. Screw the mounting plate onto the data logger with the antenna pointing up.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 11
4. Slide the mounting plate downward on the mounting post to lock in place.
5. Twist the upper enclosure onto the lower enclosure. Tighten the M6 hex
head locking screw.

Secondary Enclosure
Installation Guide
ELI0095A
RST Instruments Ltd.
Page 12
NOTE: The see-through picture on the right is for illustration purposes only.
4 SERVICE,REPAIR AND CONTACT INFORMATION
Contact RST for product services or repairs.
•For sales information: [e-mail]
•For technical support: [e-mail]
•Website: www.rstinstruments.com
•Toll free: 1-800-665-5599
RST Canada Office (Head Quarters)
Address: 11545 Kingston Street, Maple Ridge, BC, Canada V2X 0Z5
Telephone: [phone]
Fax: [phone]
Business hours: 7:30 a.m. to 5:00 p.m. (PST) Monday to Friday, except holidays
RST UK Office
Address: Unit 4 Charles Industrial Estate Stowupland Road, Stowmarket
Suffolk, UK, IP14 5AH
Telephone: [phone]
Business hours: 9:00 a.m. to 6:30 p.m. (GMT) Monday to Friday except holidays
