Scorpion II® Truck Mounted
Attenuator Assembly
Manual and Mounting
Instruction Guide
For Model:
Scorpion II® C-90 MASH TL-3 Vertical
TMA
PLEASE READ ALL INSTRUCTIONS CAREFULLY
BEFORE PROCEEDING WITH THE INSTALLATION
Version 2.3

P+64 9 259 2600
[e-mail]
Auckland
Wellington
Christchurch
Invercargill
RTL Auckland
31 Maurice Road, Penrose,
Auckland 1061, New Zealand
P O Box 1411, Panmure, Auckland
0800 785 744 rtl.co.nz
Scorpion II C-90 Height Verification – Please Complete
Attention Installer, please fill inthe check boxes &information in this document with the actual measurements of
the Scorpion II C-90after installation. Once completed, please email the form to [email protected]
Installer:
Customer:
Truck VIN Number:
Truck Registration Number:
TMA (Serial) Number:
M
Installer Signature:
Date:
Height to Underside (Left Side):
Height to Underside (Right Side):
Height:
Bottom of Mounting Plate to Ground:
TMA Serial Number is located
here.
TMA No. MXXXXX
Scorpion II C-90 Verification Form V.1.2
This completed form must be sent to RTL for the product to be covered under warranty.

The TMA Support
Structure Rotates to
Lifted Position Before
the TMA will Lift to the
Vertical Stored Position
The TMA is Designed to
Remain in the
Horizontal Position Until
the Support Structure in
the Lifted Position
Support Structure in
Final Lifted Position and
TMA is Shown in the
Final Vertical Position
Rotation of the TMA and Support Structure is Hydraulically
Sequenced and is Activated when the Up or Down Button is Pressed
The TMA Hydraulic System Sequences the Movement of the TMA,
Latch, and the Support Structure

The TMA Must be Fully
Deployed into the Horizontal
Position Before the Support
Structure Begins to Rotate to
the Horizontal Position
Rotation of the TMA and Support Structure are Hydraulically
Sequenced and is activated when the Up or Down Button is Pressed

The Gold Latch Secures the TMA in the Stored Position
Minimizing TMA Movement. The Latch Design is Based
on a Car Hood Latch. When the TMA is Rotated into the
Stored Position the Latch Engages the TMA Frame*.
When the TMA is Deployed the Latch Disengages the
Frame by means of a Sequenced Hydraulic Cylinder that
Disengages the Latch Thereby Allowing the TMA to
Rotate to the Horizontal Stored Position.
*

Assembly Instructions: Scorpion C-90 TMA
Recommended Tools and Equipment:
Forklift with 2,500 lb minimum lifting capacity •
Lifting rings, straps, chain, high strength rope, etc. •
Wheel chocks •
Air compressor •
Impact gun, 1/2" drive •
Impact sockets: 1-1/16", 1-1/8", 3/4" •
Wrenches: 7/16", 9/16", 3/4", 1-1/16", 1-1/8" •
Ratchet, 3/8" drive •
Sockets: 7/16", 9/16", 3/16" Allen •
Pry Bars •
Wire cutters •
Tin snips •
Recommended Safety Equipment:
Safety glasses •
Gloves •
Hearing protection •
Steel toe boots •
Hard hat •
REV ECO DESCRIPTION DATE ORIG. APPROVED
A Initial Release 10/13/16 RS GM
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 1 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 1. Removing the Strut From its Pallet
Attach a suitable set of lifting rings/straps to the upper steel diaphragm of the Strut assembly. All rigging should have a minimum lifting capacity of 4,000 lbs (1,800 kg) and be in good
condition. Each lifting strap assembly should be the same length. Attach one lifting strap to each angle of the diaphragm. Position a forklift (minimum capacity of 2,500 lbs, [1,150 kg]) with
the forks above the Strut and carefully slide the lifting straps over each fork. Slowly raise the forks until there is tension in the straps and check that the straps are fully taught.
REV ECO DESCRIPTION DATE ORIG. APPROVED
A Initial Release RS GM
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 2 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 2. Removing the Strut From its Pallet
Raise the Strut off of the pallet and then set it down with the mounting plate on the edge of the pallet.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 3 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Wheel Chock
Step 3. Removing the Strut From its Pallet
Continue lowering the Strut section until the jack wheels contact the ground. Insert a pair of wheel chocks (or similar object) to prevent the wheels from rolling. Lower the drop jacks until the
yellow stripe is no longer visible. Lastly, attach a rope or cable to the upper angle of the diaphragm and fasten it to the backstop of the forklift. The length of the tied off rope should be
about 8-12" (200-300 mm) longer than the fork length.
Carefully lower the forks while slowly reversing the forklift. This will bring the rear of the strut down to the ground. Continue lowering the Strut rear until the drop jacks come in contact with
the ground.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 4 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

12"±1"
304.8±25.4
Step 4. Leveling Strut
Once the Strut section is down on all 4 wheels, the lifting straps and rope can be removed. Move the forklift to the front end of the Strut and lift from the lower tube so the jacks can be
lowered. Level the Strut so that it is 12" +/- 1" (304.8 +/- 25.4 mm) above the ground.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 5 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

2
3
Locking Latch
G G
Locking Latch
1
Step 5. Unfolding C-90 Frame
Position forklift forks a few inches below the mounting plate.
1
Carefully pull the locking latch down to release it from the latch plate.
2
After the latch has been released, the frame
can be rotated down onto the forks.
3
Slowly lower the forks and reverse the forklift to lower the frame to the horizontal position.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 6 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

69
71
38
73
81
83
84 30
Step 6. Install Skid Plate and Bumpers
Install the bumpers and skid plate with the supplied hardware as shown below. Tighten the 1/2"-13 bolts for the bumpers until there is approximately 1/2" (13 mm) of thread exposed past the
end of the nut.
Recommended Tools:
Ratch, 3/8" drive •
Sockets: 7/16", 3/16" Allen •
Wrenches: 7/16" •
REV ECO DESCRIPTION DATE ORIG. APPROVED
A Initial Release 10/13/16 RS GM
Item No. Part No. Description Qty.
38 11610 Bumper 2
69 12004 Bolt, 1/2"-13 x 2-1/2", Zn Plated, Gr. 5 4
71 12075 Washer, 3/4" USS, Zn-Y Plated 4
73 12024 Locknut, Nylon Insert, 1/2"-13, Gr. 8 4
30 11570 Skid Plate 1
81 12029 Bolt, 1/4"-20 x 1", Zn Plated, Gr. 5 3
78 12032A
Bolt, SHCS, 1/4"-20 x 1-1/4", Zn Plated
Alloy Steel
1
83 12005 Fender Washer, 1/4", Zn Plated Steel 4
84 12014 Locknut, Nylond Insert, 1/4"-20 4
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 7 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 7. Remove Cartridge Modules
Cut the banding that restrains the modules inside the Cartridge and carefully remove the modules. Don't cut the banding that holds the Cartridge to the pallet. Be sure to lift the modules one
at a time and use 2 people to perform this task. Bring the forklift into position as shown below with the forks positioned 6-12" (150-300 mm) below the angle braces.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 8 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 8. Lower Cartridge to Horizontal Position
Rock Cartridge back until the angle braces contact the forks and the Cartridge will stay in place. Slowly lower the forks and reverse the forklift simultaneously to lower the front of the
Catrtridge to the ground.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 9 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 9. Joining the Strut and Cartridge
First, loosen the turnbuckles until there is no longer tension in the steel cables that cross the top of the strut. Next, remove the eight (8) 3/4" nuts and washers from the bolts that attach the
middle diaphragm to the strut tubes.
Recommended Tools:
Impact gun, 1/2" drive •
Impact Sockets: 1-1/16" •
Wrenches: 1-1/8" •
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 10 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 10. Joining the Strut and Cartridge
Lift the front end of the Cartridge and set thetube end plates on the bottom edge of the middle diaphragm. Align the bottom holes of the end plates with the corresponding 3/4" bolts.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 11 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 11. Joining the Strut and Cartridge
Use the forklift to lift the rear of the Cartridige so that the top holes of the tube end plate can be aligned with the upper 3/4" bolts. Once all the bolts have been aligned with the cartridge
tube endplate, the angle braces can be removed by loosening the 3/8" bolts that attach them.
Recommended Tools:
Ratchet, 3/8" drive •
Sockets: 9/16" •
Wrenches: 9/16" •
Pry Bars •
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 12 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

12
67
66
63
Step 12. Joining the Strut and Cartridge
Reinstall the 3/4" nuts and washers that were removed in step 9. Be sure to install the 10122 Vertical Support Angles in the outside positions. After all of the bolts/nuts have been tightened,
retighten the turnbuckles until each cable deflects no more than 1/4" (6.5 mm) when pushing the cable in the center with the palm of your hand. Cut the banding that attaches the pallet to
the cartridge diaphragm and remove the pallet.
Recommended Tools:
Impact gun, 1/2" drive •
Impact Sockets: 1-1/16" •
Wrenches: 1-1/16", 1-1/8" •
Item No. Part No. Description Qty.
12 10122 Vertical Support Angle, Powder Coated Black 2
63 12007 Bolt, 3/4"-10 x 2-1/2", Zn Plated, Gr. 5 8
66 12060 Washer, 3/4" USS, Zn-Y Plated 8
67 12008 Locknut, Nylon Insert, 3/4"-10, Gr. 8 8
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 13 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Module A Module B Module C
*Not Shown
78 82 83
Step 13. Installing the Modules
Position each of the modules in place as shown below. Fasten them to the TMA using the supplied hardware consisting of eight (8) 1/4"-20 socket head screws, eight (8) 1/4" USS washers, and
eight (8) 1/4" fender washers for each module. Be sure to apply a drop or two of the provided red thread locking adhesive to the threads of each screw.
Recommended Tools:
Ratchet, 3/8" drive •
Sockets: 3/16" Allen •
Item No. Part No. Description Qty.
78 12032A Screw, SHCS, 1/4"-20 x 1-1/4", Zn Plated Alloy Steel 24
82 12042 Washer, 1/4" USS, Zn-Y Plated, Gr. 8 24
83 12005 Fender Washer, 1/4", Zn Plated 24
* 14511 Threadlocker, Red Vibra-Tite, 2 mL 1
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 14 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16

Step 14. Connecting the Lighting Cables
Route the lighting cables as shown in the photos below and secure with cable ties. Utilize the loop clamps installed on module C to secure the cables. Be sure to test all light functions after the
connections have been made.
This concludes the assembly of the Scorpion C-90 TMA. Proceed to the installation portion of the manual for attachment to the host truck.
D
C
B
A
A
B
C
D
1
2 3
4
5
6
7
8
8
7
6
5
4
3
2
1
TITLE:
SIZE
B
DWG. NO.
REV
A
SHEET 15 OF 15
1000-165
Assembly Instructions
Scorpion C-90 TMA
DRAWN BY:
Ryan Selvius
DATE:
10/3/16
APPROVED BY:
GM
DATE:
10/13/16
