Overview
GE-1150 is a Fiber Gigabit Ethernet to 32
bits PCI bus adapter that fully complies
with all IEEE 802.3z and 1000Base-SX/LX
standards. It provides up to 2000Mbps full-
duplex bandwidth capacity to support high-
end servers. In addition, with advanced
functions like VLAN filtering packet
processing, the adapter provides added
performance, flexible configuration and
secure networking for users in a standards-
based environment. Two LED indicators
(LINK/ACT and FDX) on the bracket will
help to oversee the board link, activities
and full-duplex status
GE-1150:
PCI 32-Bit Gigabit 1000Base-X Fiber NIC
Key Features
High bandwidth 1000Mbps Network
Speed
Supports Full-Duplex Mode
Supports IEEE 802.3x Full-Duplex Flow
Supports 32 bits PCI bus
Compliant with PCI 2.2 Interface
Supports Jumbo Frame up to 9014
Bytes
Supports High Level VLAN Filtering
Function
Supports 802.3ad Link Aggregation
(LACP)
Supports on-board verification of IP
headers and TCP / UDP checksums for
received data
Supports on-board screening of VLAN
tagged Ethernet frames
GE-1150
RUB
TECHTECH
Gigabit Ethernet Fiber NIC with PCI 32bits
Fiber NIC
Fiber NIC
Technical SpecificationsTechnical Specifications
Standards: IEEE 802.3z Gigabit Ethernet 1000Base-SX/LX
IEEE 802.3x Full-DuplexFlow Control
IEEE 802.3ad LinkAggregation
IEEE 802.1Q VLANs
IEEE 802.1p Qualityof Service
Connector: 850nm SC multi-mode (Default)
*850nm LC multi-mode
*1310nm SC, LCsingle-mode
*1550nm SC, LCsingle-mode
*: Option isavailable upon request
Fiber Optic Cable: 62.5/125, 50/125m multi-mode
9/125m single-mode
Data Transfer Mode/Speed:
---Full duplex withNWay flow control
---1000Mbps speed
Diagnostics LED on Bracket:
---LINK/ACT
---FDX
Bus Slot: 32 bits PCI 2.2 Compliant
Power Requirement: Max. 10W, +5VDC@2A
Ambient Temperature: 0 to 50 C
Humidity: 5% to 90%
PCB Dimensions: 128.5(L)x57.5(H)mm
Weight: 0.07Kg
Emission: Complies with EMI Standard, FCC Class A & CE Mark
Software Support:
Windows 2000
Windows 2003
Windows XP
Windows NT4.0
Novell Netware 4.x,5.x, 6.x
Linux
UnixWare 7.0
PXE & RPLBoot ROM
SCO Open Server
Solaris
Packing InformationPacking Information
Carton Dimensions (mm) pcs/Carton N.W (KG) G.W (KG)
530x512x345 60 10.8 11.8
Fiber NIC
Fiber NIC
RUB
TECHTECH
Networking & Communications
R
Ordering InformationOrdering Information
Ruby Tech Corp.
2F, No.7, Lane 50, Nan Kang Road, Sec.3, Taipei, Taiwan http://www.rubytech.com.tw
2007-02.14-Version A
Gigabit Ethernet Fiber NIC with PCI 32bits
GE-1150SC PCI 32-Bit Gigabit1000Base-X Fiber Card,SC Multi-Mode
GE-1150LC PCI 32-Bit Gigabit1000Base-X Fiber Card,LC Multi-Mode (By Call)
GE-1150SC.S10 PCI 32-Bit Gigabit1000Base-X Fiber Card,SC Single Mode 10Km
GE-1150SC.S30 PCI 32-Bit Gigabit1000Base-X Fiber Card,SC Single Mode 30Km (By Call)
GE-1150SC.S50 PCI 32-Bit Gigabit1000Base-X Fiber Card,SC Single Mode 50Km (By Call)
