INSTRUCTION MANUAL AND PARTS GUIDE

CAUTION Read the instruction manual before using the machine

D’Lite

Rugged Industries Pty Ltd

ABN: 59 154 866 878

12 / 51 Owen Street

Glendenning NSW 2761 Australia

Postal: PO Box 1076 Dundas NSW 2117

Ph: +61 2 9680 0052

Email: contactus@ruggedindustries.com.au

www: ruggedindustries.com.au

Model No.:15721100

Back Pack Vacuum Cleaner with H10

HEPA Filter

D’Lite Manual #rev11112021 2

Safety Instructions

Read this manual before using the back pack and always follow the

Safety and Maintenance Instructions

CAUTION: This machine shall be stored indoors only

•This machine is intended for domestic and commercial use only

•Do not leave the appliance when plugged in. Unplug from the power point when not in use and

before servicing.

•Do not use outdoors or on wet surfaces.

•For domestic use:

oThe appliance is not intended for use by persons (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge, unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety

•For commercial use:

oThe appliance is not intended for use by persons (including children) with reduced physical, sensory

or mental capabilities, or lack of experience and knowledge

•Children should be supervised to ensure that they do not play with the appliance.

•Use only as described in this manual. If appliance is not working as it should, has been dropped,

damaged, left outdoors, or dropped into water, return it to a service centre.

•Extension Cord MUST be secured by the relief retainer in the side of the vacuum cleaner

•Do not pull or carry by cord or plug, use cord as a handle, close a door on cord, or pull cord around

sharp edges or corners. Do not run appliance over cord. Keep cord away from heated surfaces.

•If the cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly

qualified person in order to avoid a hazard.

•Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.

•Do not handle plug or appliance with wet hands.

•Do not put any object into openings. Do not use with any opening blocked.

•Keep hair, loose clothing, fingers and all parts of body away from openings and moving parts.

•Turn off all controls before unplugging.

•Use extra care when cleaning stairs.

•Do not use to pick up flammable or combustible liquids, such as petrol, or use in areas where they

may be present.

•A locally approved optional electric power brush shall only be connected to the power outlet.

(Max Load:200w)

WARNINGS

SAVE THESE INSTRUCTIONS

Do Not

Do not vacuum wet surfaces, damp areas or suck up water

· Do not use machine if water has been picked up by the

vacuum system without an electrical inspection by a

qualified person.

· Do not vacuum anything that is burning or smoking such

as cigarettes, matches or hot ashes.

· Do not use the machine in areas where flammable or

combustible liquids, vapours or gas are present.

· Do not operate near explosive materials such as

solvents, thinners, fuels or grain dust.

D’Lite Manual #rev11112021 3

Packaging

•Every Impress unit comes with:

•A basic set of cleaning accessories: crevice tool, dusting brush, 10 paper filter bags, and 1

spare cloth filter, vacuum hose with elbow hand grip, 2 piece wand, and EZ2GO floor tool.

•Cloth filter bag

First,

•Motor Filter H-10 HEPA (located under cloth filter bag)

Assembly

•Connect both wands together to create one length

•To Remove Lid

Lift Magnetic Latch opposite side of inlet, rotate lid away from

Canister body.

•To Fit Lid

Rotate onto canister body fitting inlet side first and align accurately

Magnetic latch will engage automatically.

NOTE: The Lid can be fitted for either left or right operation.

•To Remove Hose

Press Hose Release Button, and gently pull Inlet Elbow from Lid.

•To Fit Hose

Insert Inlet Elbow into lid opening

•To Remove Filter Bag

Lift from top of canister using bag rim.

•To Fit Filter Bag –

Place over canister rim and press firmly ensuring bag is level.

•To Fit Paper Bag Filter

Align paper bag cardboard, engage non-serrated portion of cardboard (A)

into Inlet Spout groove. Ease the remaining serrated portion of cardboard

(B) onto groove. Keep corners of paper folded down to avoid entrapment

under lid edge.

•Removal & Disposal of Paper Bag Filter

Ease cardboard retainer off the groove on the Inlet Spout. Fold card board

tab over bag inlet hole to prevent spillage. Dispose into garbage bin.

D’Lite Manual #rev11112021 4

•To Fit Cord

To reducing tripping hazards, and for

safety when unplugging, Fit the cord

onto extension cord restraints on both

sides of machine as shown.

•To Remove Motor Filter

Use the Filter flaps to lift from canister base.Remove with

care from the canister.

•To Fit Motor Filter

Insert into canister base filter recess. Press firmly around the

edge of the filter to fit into position.

NOTE: Do not press on filter media.

•To Regulate Suction

Slide the suction regulator on the Bent End Piece forward to

close, this provides more air at the nozzle. Slide the regulator

back for less air, this is suitable when vacuuming loose

materials such as mats.

•To Fit or Remove.

Twist and pull to disassemble. Attach at any point from

Bent End Piece to Wand end, to suit application

D’Lite Manual #rev11112021 5

•Adjustment and Wearing

Safety and Maintenance Checks

•Wearing the Vacuum Cleaner

Loosen Shoulder Pad Straps by pulling

straps in the direction shown, and lift the

vacuum onto the shoulder.

Position the waist-band into the 'small' of

your back just above your backside.

•Adjusting Waist, Shoulder and Sternum Straps

Tighten the elasticised waist belt, over- lapping

the hook and loop flaps until secure and

comfortable.

Pull down on the shoulder straps to tighten.

Adjust the length of the Sternum Strap to suit

and snap together.

•Correct Wear

•Motor Filter

•Cloth Filter Bag

D’Lite Manual #rev11112021 6

Operation

•Using

For comfortable operation, stand upright with a relaxed posture, arms

hanging loosely to the side

Maintain a straight wrist, hold the handle grip of the Bent End Piece

with one hand parallel to the floor.

When vacuuming under office desks, the reach of the wand is sufficient

to avoid bending at the waist

When vacuuming under lower profile objects orwhen picking up items

off the floor, bend the knees and maintain a straight back.

When turning, do not twist at the waist. Turn using your feet

•Working

Plan the work path based on location of the power point,

room/furniture layout, and entrance and exit points.

Commence vacuuming using a systematic approach

working one half of the area first, away from the power

point, and then the other half of the area, returning back

to the start.

Ensure that the power cord is clear of feet to reduce

likelihood of tripping.

•As Needed

Check Inlet Elbow, Hose, Bent End Piece and Floor Tool

for blockages.

Regularly

Check cord for cuts, exposed wire, abrasion and twisting.

Replace cord only with original manufacturer’s part.

Note:

Always unplug cord from power point when not in

use. Gather the cord by winding from the machine

end.

Drape cord over handle for storage.

D’Lite Manual #rev11112021 7

Product Specifications

General

Packaging

Vacuum

Type: Dry

Class: Type 2 Double Insulated

Approval: RCM

Air Flow Nozzle:

34l/s Suction: 22

kPa Noise: 72 dBA

at 1m

Weight: 4.4 kg - not including cord and rod

Filtration

Cloth Filter Bag

Size: 5 Litre, Antimicrobial polyester needle felt.

Paper Filter Bag

Size: 5 Litre, Rubber membrane sealed cardboard reinforced paper bag.

Motor Pre-Filter

Type: Polyester Pleated Filter

Class: H10 HEPA

Electrical

Power Supply

220 - 240V.a.c., 50 Hz

Power Outlet

2 Pin IEC

Total Power

1500W

Electrical Cord

18 m, 10 A, 3 core ordinary duty

Thermal Protection

110°C auto-reset thermostat

Motor

Vacuum Motor

Type: Rated 1300w, Eco Single Turbine Flow Through

Output Performance: Air flow 42.0 l/s, Suction 27.2kPa, Air Watts 450

Carbon Brush Life: 700h

Warranty

2 year Body, 2 year Motor

Sound level

72 dB(A) Noise level average

Accessories

32mm EZ2GO Floor Tool with rubber

tread

32mm Crevice Tool 10 Paper Bag

Filters

32mm Dusting Brush

32mm Crevice Tool

Spare 1 x 5 Litre Antimicrobial cloth Bag

32mm x 1.2m “Crush Proof” Antimicrobial Hose

2 x 495L Corrosion Resistant Stainless-Steel Rods

Please note specifications can change without notice.

Size:

36x 36x 54 cm

Weight:

9.0 kg

800mA

FUSE

0.22uF CAPACITOR

BROWN (ACTIVE)

POWER

OUTLET

BLUE (NEUTRAL)

110

C AUTOMATIC

RESET THERMOSTAT

DOUBLE POLE

SINGLE THROW

SWITCH

Item

Part Number & Description

Qty.

13717003 Lid BVC DGrey Assy

13610009 Button Release BVC Black

13710001 Lid View Lens

13710004 Lid Spout

13710021 Latch with Magnet Black

13750001 Pin Latch

13780010 Spring Release

13790005 Trim Lid DGrey

13657006 Filter Bag Paper 5L 5/Pkt. Std.

13657001 Filter Bag Assy 5L AB Std.

13657003 Filter VFD Assy

13677001 Housing Upper Canister Assy

13780004 Seal Canister Housing

13610003 Base Upper Canister

13780002 Screw WN1412 KB40 x 12 ZP

13780006 Seal Motor Harbin

13610004 Baffle Motor Housing

13727002 Motor Vacuum Harbin 240V

13620005 Clamp Motor

13827001 Wire Thermostat Assy 4L & 5L BVC

13780014 Switch Rocker 2HP

13820002 Wire N 240V Inlet-Switch 4L & 5L BVC

13820003 Wire N 240V Switch-PO 4L & 5L BVC

13657011 Fuse Link 4L & 5L BVC

13780005 Foam Seal (Upper Baffle)

13670004 Housing Canister Lower In Out and Sw

13780003 Screw WN1412 KB50 x 16 ZP

13680003 Insulation End Cap (Set)

13620022 Cap Motor Housing BVC LGrey

13680002 Insulation Motor Housing Side (Set)

13680001 Insulation Motor Housing End (Set)

16002004 Cord Extension 18m Orange

13620009 Cord Coupling IEC - 4L & 5L BVC

13780007 Socket Inlet C14

13780008 Scocket Outlet C18

13750003 Pad Back BVC

16018025 Strap Sternum with Adjuster and Buckle

13750006 Pad Shoulder BVC 4 Piece Set

13650002 Frame BVC DGrey

13750007 Pad Waist BVC

13677006 Hose AB BEP & Elbow 4L & 5L Assy

13640001 Elbow Inlet BVC

13640002 Elbow BEP 32mm Black

16022005 Rod Stainless 32mm x 495L

16019002 Tool Crevice

16019003 Tool Dusting Brush

16019004 Tool Floor EZ2GO

15721100 D

LITE ASSEMBLY

VACUUM MOTOR

DLITE MODEL

220-240V 50

Hz SUPPLY

ELECTRICAL CIRCUIT DIAGRAM

OPTIONAL ACCESSORIES

ITEM NO.

PART NUMBER

DESCRIPTION

QTY

1 16019005

Tool Turbo Brush 32mm

2 16019006

Tool Combination 32mm x 300mm Wide

3 16019014

Tool Mega Gulper Pro 32mm x 385mm Wide

4 16019007

Tool Upholstery 32mm

5 16019017

Tool Electric Brush 32mm x 355mm Wide

6 16019016

Tool Hard Floor 32mm x 360mm Wide

D'LITE

ACCESSORIES

D’Lite Manual #rev11112021

Trouble Shooting

Always switch off D’Lite and unplug from wall prior to correcting any problems. If you are unable to rectify the

problem, contact your local service agent.

Problem:

Machine not working

Cause

No power at power point.

Solution

Connect machine to a functional power point.

Cause

Power cord not plugged into power point or machine.

Solution

Check plug is firmly plugged into a power point and machine.

Cause

Machine or power supply not switched on.

Solution

Turn on/off switch to ON (I). Turn power supply outlet on.

Cause

Machine has switched off due to overheating.

Solution

Switch off and unplug machine. Check for any blockages in wand, floor tool and inlets. Ensure

filters and paper and cloth bags are clean. Wait for 30 minutes and switch machine back on. If

machine does not start up, contact service agent.

Problem:

Poor or No Suction

Cause

Blockage.

Solution

Turn off machine and unplug. Check wand, suction hose, floor tool, elbow inlets for

obstructions and remove.

Cause

Paper or Cloth Filter Bags are full.

Solution

Check paper bag and if full, remove and replace. Check Cloth Filter Bag, turn inside

out and brush with a soft banister brush before replacing.

Cause

Hose not installed properly or damaged.

Solution

Check hose connection and ensure it is locked in. Replace if damaged.

Cause

Motor Filter is blocked.

Solution

Remove Secondary Filter and tap gently to remove excess dust before replacing.

Cause

Air Regulator needs adjustment.

Solution

Adjust Air Regulator on hose to obtain suction required.

Problem: Uncomfortable to Wear

Cause

Backpack is not fitted correctly to your body.

Solution

Adjust waist and shoulder pad as described on page 5 to ensure correct fit.

Cause

Pads or straps are worn.

Solution

Replace padding/straps.

D’Lite Manual #rev11112021

General Warranty Policy

Rugged Industries Pty Ltd ACN 154 866 878 (“Rugged”) warrants to the original purchaser that the equipment

specified in this manual (“Equipment”) is free from defects in workmanship and materials under normal use for a

period of 12 months.

Under this warranty, after examination discloses it to have been defective, Rugged will repair or replace at its factory

or authorised dealer service outlet, parts of the Equipment that fail under normal use and service, when operated

and maintained in accordance with the applicable operation and instruction manuals.

All warranty claims must be submitted via the Rugged-authorised dealer or service agent the item was purchased.

The purchaser is responsible to return the defective goods at their expense, to the Rugged-authorised dealer or

service agent the item was purchased from.

This warranty does not apply to components replaced due to recommended service schedules, normal wear and tear

or to items whose life is dependent on their use and care.

Use of replacement parts not manufactured or supplied by Rugged will void all warranties expressed or implied and

may give rise to a potential health hazard. All parts replaced under this warranty become the sole property of

Rugged or its original manufacturer, whichever the case may be.

This warranty is applicable only to the original purchaser. Rugged is not responsible for costs or repairs performed by

persons other than those specifically authorised by Rugged. This warranty does not apply to damage from

transportation, alterations by unauthorised persons, misuse or abuse of the equipment, use of non-compatible

parts, or damage to property, or loss of income due to malfunction of the Equipment. If a difficulty develops with

this Equipment, you should contact the dealer from whom it was originally purchased.

The warranty coverage period on Equipment will commence 1 year after the date of shipment from Rugged to its

dealer or authorised agent unless the Equipment is sold before this time. This sale date would then be the beginning

date of the warranty coverage.

The following statements only apply to a consumer sale of goods or services as defined in the Australian Consumer

Law. In this statement, ‘Our’ means ‘Rugged’ and ‘you’ means ‘original purchaser’:

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a

replacement or refund for a major failure and for compensation for any other reasonably foreseeable loss or

damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and

the failure does not amount to a major failure.

To the extent permitted by law, all other warranties whether implied or otherwise, not set out in these warranty

terms and conditions are excluded and Rugged is not liable in contract, tort (including, without limitation, negligence

or breach of statutory duty) or otherwise to compensate you for:

•any increased costs or expenses;

•any loss of profit, revenue, business, contracts or anticipated savings;

•any loss or expense resulting from a claim by a third party; or

•any special, indirect or consequential loss or damage of any nature

whatsoever caused by Rugged’s failure in complying with its obligations

The benefits given to you in this warranty are in addition to other rights and remedies under a law in relation to the

Equipment or services to which this warranty applies.

D’Lite Manual #rev11112021

Warranty Registration Details

Purchaser:..........................................................................................Purchase date:....................................

Address:............................................................................................................................................................

State:............................Post Code:.........................Contact:................................................ph:

Model No.:....................................Serial Number:..........................................

Purchased from:...............................................................................................................................................

Address:..............................................................................................................................................................

Please attach copy of receipt.
