RunCam Eagle User manual

800TVL Global WDR
5-17 VDC FPV Camera
RunCam Eagle
12mm
19mm
26mm
28mm 30mm
29mm
26mm

Monitor
Video out
Power in
5D-OSD
Connection
For OSD setting
①
1

* Unplug the 5D-OSD menu cable after OSD setting.
Video Power
GND
Power in
Transmitter
Screw thread：3 mm maximum
Connection
For FPV
②
3 mm
2

MAINMENU
DAY
&NIGHT
VIDEO STANDARD
LANGUAGE
LOAD DEFAULT
SOFT VERSION
SAVE
&EXIT
EXIT
3D-NR
WDR
IMAGE ENHANCE
MIRROR
BRIGHTNESS
ZOOM IN
RETURN
AUTO
PAL-50HZ
ENGLISH
**********
ON
OFF
44
0
· DAY &NIGHT (Auto/External/B&W/Color)
· VIDEO STANDARD (PAL-50Hz/NTSC-60Hz)
· LANGUAGE (English/中文)
· WDR
(ON/OFF)
· MIRROR (OFF/ON)
· BRIGHTNESS (44 / 8-250)
· ZOOM IN (0 / 0-5)
OSD Menu
3

3D-NR
NR-MODE
RETURN
AUTO
IMAGE ENHANCE
SHARPNESS
SATURATION
RETURN
· NR-MODE (AUTO/MANUAL: 0-15) · SHARPNESS (AUTO/MANUAL: 0-15)
· SATURATION (AUTO/MANUAL: 0-15)
OSD Menu
4

Model
Image Sensor
Horizontal Resolution
Lens FOV
Signal System
Synchronization
OSD Set
S/N Ratio
Electronic Shutter Speed
Min. Illumination
WDR
Day/Night
Video Output
Power Input
Housing Material
Net Weight
Dimensions
RunCam Eagle
1/1.8" CMOS Sensor
800TVL
16:9 Version 130° / 4:3 Version 140°
NTSC/PAL Switchable on OSD menu
Internal
Yes
>50dB
Auto
0.01Lux/1.2F
Global WDR
Auto/External/Color/B&W
CVBS
5-17 VDC
Magnesium Alloy
16g
26mm * 26mm * 31mm
