RunCam Split-H User manual

Runcam Split-H
User Manual

Power input (red)
Module connector
Power/Shutter button
Power light indicator
Video signal output (blue)
NC (white)
PWM (yellow)
Ground (black)
HDMI
MIC
MicroSD Card
Type-C
Power light indicator
Diagram

MicroSD Card
Power/
Shutter button
Power light
indicator
Power light indicator
Camera Module Connection
Basic Camera Operations
To power on, long press the Power/
Shutter button, the power light indicator
is on, camera gets turned on.
Video mode
After turning on the camera, sho press Power/Shutter button, the power
indicator blinks slowly, camera stas to record.
When the camera records, sho press the Power/Shutter button, the power
indicator stays solid, camera stops recording.
Card error (no card, card full or low-speed
card etc.): light blinks red quickly
To power o, long press the Power/
Shuter button, the power light indicator
goes o, camera gets turned o.
Power on/o
Abnormal booting: camera fails to detect the
module, red light blinks slowly for 2 seconds,
and camera shuts o after 5 seconds.
Abnormal Conditions

SD卡槽
MicroSD Card
HDMI Connection
Use carefully when handling memo cards. Avoid liquids, dust, and debris.
As a precaution, please power o the camera before inseing or removing
the card. Check manufacturer guidelines
regarding use in acceptable temperature
ranges.
If camera cannot record, please format
the used microSD card via computer.
HDMI Display
For camera’s best peormance, please use the latest rmware.
Camera rmware update status: red light blinks fast, and camera shuts o
automatically when the update is nished.
Firmware le name: split-hc.bin
Firmware Update

Here we take Flight Controller Speedy Bee-F7 for an example.
Connect RunCam Split-H to SpeedyBee F7V3 via the cables, with Power
wire (red) to 5V pad, GND wire (black) to GND pad, PWM wire (yellow) to
M6 pad.
Congure M6 at CLI mode
Connect to BetaFlight, and enter the CLI inteace
Type in resource to proceed, and type the command as below
Runcam Split-H SpeedyBeeF7V3
PWM Remote Control
Steps to congure
# resource motor 6 none
# resource pinio 2 B05
# set pinio_ cong = 129,129,1,1
# set pinio_ box = 0,41 ,255,255
# save

Specications
Navigate to the Modes tab at the BetaFlight, and nd Mode USER2. Here
takes AUX3 as an example to congure, and the range is 1900-2100.
USER2
添加链接
添加范围
AUX 3
最小：1700
最大：2100
>
900 1000 1200 1400 1500 1600 1800 2000 2100
Please choose your Model on
the controller, then access to
the MIXER inteace and
assign the channel to a switch.
Here we take Radiomaster TX12
as an example, assigning CH7
to SF position.
Product
Sensor
Field of view
Resolution
Video le format
HDMI output format
SD card max. capacity
Power range
Lens module size
Mounting hole spacing
PCB size
Working current
Weight
SPLIT-H
SONY（5MP）
FOV 94°
1080P@60FPS
MP4
1080P60HZ
128G(U3 recommended)
5-20V
19*19mm
26.5mm*30.5mm
32mm*37mm
540mA@5V/365mA@7.4V/225mA@12V
22g
