RunCam HD User manual

Drone's Eye View.
Manual for RunCam HD
V1.2

1. Function Buttons
●
●
Press the Power Button to turn the camera ON
or OFF.
In Playback Mode, pressing the power button
can allow the user to choose the different video
file.
Shutter Button：
●
●
Press the Shutter Button to start or stop
recording video, or take a snapshot.
In Playback Mode, press the Shutter Button to
play or stop the playback.
1
Mode Button：
●
●
Press the Mode Button to switch the working
mode of the camera.
Press the Mode Button to format the TF card
Reset Button：
●Press Reset Button to reset the camera.
Power Button:
Power Button ...................................................... 1
ShutterButton.......................................................1
Mode Button ........................................................ 1
Reset Button ........................................................ 1
Indicator A ........................................................... 2
Indicator B ........................................................... 2
Mini USB Port....................................................... 2
Battery Charging .................................................. 3
To turn the camera on ........................................... 4
Video Mode and Switching Operations ...................4
Video Recording and Snapshot Operation
and Indictor A Status Instruction
AV Output ............................................................ 6
Playback .............................................................. 6
Power-Saving Mode ..............................................7
Format the Memory Card ...................................... 7
Reset ................................................................... 8
Shutdown ............................................................ 8
Connect the Camera to PC ..................................... 8
Contens
Sketch of buttons and features
..........................5-6

23
●Indicates the mode and working status of the
camera.
Indicator A:
Indicator B:
●Auxiliary indicates the working status of the
camera.
●
●
●
For Power Charging
For Data Transmission
For Video Output
Mini USB Port:
2. Instructions
Battery Charging:
●
●
●
There is standard Mini 5-Pin USB cable
included in the product packaging. Please
connect one end to the camera and the other
end to 5 V DC power supply (For instance, a
charger, USB port of a PC, or another portable
power source).
The camera will turn on automatically once it
is powered on. When the camera detects that it
is being charged, it will turn off automatically
for more efficient charging.
When charging, Indicator A will display green.
When fully charged, the Indicator A will be off.
The average charge takes up to Three hours to
complete.
Note: If you want it to record video during the
charging, please make sure the current
output of the power supply is above 1000mA.

To turn the camera on:
●Press the Power Button and release after 1
second to turn on the camera. The Indicator A
light will change from Blue to Yellow. The
camera will then switch to Standby status of
Video Mode 1.
Video Mode and Switching Operations:
●
●
●
●
Video Mode 1 (Indicator A showing with
Yellow light constantly): Default 1080p@30fps
Full HD recording.
Video Mode 2 (Indicator A showing with Blue
light constantly): Default 720P@60fps HD
recording.
Photo Mode (Indicator A showing with Red
light constantly): Default 2304 x 1536 Photo
Mode.
Playback Mode: Plug in the TV output cable
included in the product packaging to camera to
activate this mode.
In Standby status, press the Mode Button to
switch to the next mode. Constantly press the
Mode Button to switch between the above four
modes.
Note: If the camera is in recording, you will need to pause the
recording before switching working modes.
45
Video Recording and Snapshot Operation
and Indictor A Status Instruction:
●
●
●
●
●
●
Indicator A illuminating a constant Yellow
light: the camera is in Standby status of Video
Mode 1. Press the Shutter Button to start
recording in Video Mode 1. Indicator A should
now flicker slowly in Yellow.
Indicator A slowly flickers in Yellow: (one
second on, one second off): the camera is
recording in Video Mode 1.
Indicator A illuminating a constant Blue light:
the camera is in Standby status of Video Mode 2.
Press the Shutter Button to start recording in
Video Mode 2. Indicator A should slowly flicker
in Blue.
Indicator A slowly flickers in Blue: (one second
on, one second off): the camera is recording in
Video Mode 2.
Indicator A illuminating a constant Red light:
the camera is in Standby status of Photo Mode.
Press the Shutter Button to take one photo and
save the photo to the TF card. Indicator A should
flash once in red.
Indicator A flickers in Red: every time the red
light flickers once, the camera takes one photo.

67
●
●
●
Indicator A illuminating a constant Green light:
the battery is charging.
When the camera is turned on, and the
Indicator A quickly flickers a Yellow light: there is
no memory card detected or the memory card is
invalid. Please format the memory card or change
a new card. (About formatting, please refer to
following “Format the Memory Card” chapters).
Indicator A quickly flickers a Red light during
video recording: the battery is low and the
camera will turn off automatically in several
seconds.
Playback:
●In Standby status (without connected the AV
output cable), the camera will automatically
shut down if there are not any operations
selected within 30 seconds.
Note: This mode will be effective only when the
TV output cable is connected to the camera.
Power-Saving Mode:
●In Standby status, the camera will automatically
shut down if there are not any operations selected
within 30 seconds.
Format the Memory Card:
●In any mode, long-press the Mode Button for
about 10 seconds to format the memory card.
The Indicator A light will turn Red and quickly
flicker Three times when the camera starts to
format the memory card. The camera will
automatically shut down after the formatting is
finished.
AV Output:
Turn the camera on, and connect the TV-out
cable to the camera, then the camera is in the AV
output status. In this status, the camera will
continuously outputs the AV signal. It won't shut
down even without video recording or snapshot.
Note:
●Make sure there are no important files saved
on the c ard b e for e form a ttin g i t. Afte r
formatting, all files will be deleted.
●This camera cannot support any memory card
formatted by a computer running Win XP.
Please use the formatting function of this
camera to format the memory card.

89
●In any mode, press the Power Button for at
least 1 second and release. Indictor A will turn
Red and blink Three times. The camera will then
completely shut down.
Shutdown:
Connect the Camera to PC:
●Using a standard USB cable, the camera can
be used as a removable storage device.
Connect the camera to PC with the USB cable
when it is turned off or in Standby status, you
can directly read or write the files in the TF
card.
Angle of Field F.O.V 120°
Photo Resolution 3MP
Video Resolution 1080P 30FPS FULL HD, 720P
60FPS, 720P 30FPS HD
Video/Photo Files Format * . MOV / *.JPG
Live TV Video Output NTSC / PAL
Interface Mini USB
Max Micro SD Supported 64G(Suggest using Class 6 or above)
Image Flip 180 Deg Roation
Weight 41 g
Dimension 60mm(L) * 35mm(W) * 18mm(H)
Rechargeable LIPO Battery 850mAH
Continuous Recording Time About 120 Minute
Working Voltage DC 5V
Working Current <500mAH
Reset:
●Turn the camera on, press the Reset Button to
restore it to factory settings.
