RunCore S70 User manual

S70 Rework Guide
Indlinx rework
guide
手册
S70 Rework Guide
2011-11-22

S70 Rework Guide
Indlinx rework
guide
手册
Rework Step:
1. Copy “runcore_20312030_024(IM34n)”and “Cleaner of S70_B001”to work computer.
2. Install the MPTool of “runcore_20312030_024(IM34n)”to your computer.
3. Clean the flash blocks by “Cleaner of S70_B001”.
a). Connect the S70** and SATA interface of the platform by the following adapter.(MiniPCIe
to USB adapter don’t support the cleaner).
b). Set to factory mode. Short the position of J1 on S70** by jumper before power on, then
detect the drive in device manager. It is shown as ”YALONG Barefoot”in hd device.
c). Select the corresponding configuration in “Cleaner of S70_B001”to clean the flash
blocks.

S70 Rework Guide
Indlinx rework
guide
手册
d). Finish.
4. Open MPTool, click “option”If you use SATA to USB, please select “Use usb bridge”.
5. When detect the device, click “device”to setup information as follow.
6. Click “Flash”to select the right config.
Detect device
Clik this option
If you use SATA to USB ,please select this option.
√

S70 Rework Guide
Indlinx rework
guide
手册
7. When all set OK, please press “start”to download FW.
8. Pass.
Press this buttom
to download FW
