Russound D Series User manual

DSERIES MULTICHANNEL
POWER AMPLIFIERS
D890, D1290, D1675
Designed for multi-room, home theater, and advanced audio systems
INSTALLATION GUIDE
D890
STATUS 1 2 3 4
D1290
STATUS 1 2 3 4 5 6
D1675
STATUS 1 2 3 4 5 6 7 8

2Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 3
OVERVIEW OVERVIEW
The latest generation of multi-channel Class D digital amplifiers from
Russound expand on Russound’s 55+ year history of audio design, adding
high performance to even the most demanding audio systems, with the
flexibility, power, and quality needed to be the backbone of your favorite audio
system for years to come.
WHAT’S IN THE BOX
• 1 Russound Multi-Channel Amplifier
• 1 6-foot Power Cord
• 1 Set of Removable, Screw-Down 4-pin Speaker Connectors
(accepts up to 14AWG wire) (4, 6, or 8 depending on model)
• 1 Set of Rack Mount Ears with Attachment Screws
(Rack Mount Screws Not Included)
• 1 Owner’s Manual
WHAT YOU NEED FOR THE INSTALLATION
Flat 1/8” (3mm) mini-screwdriver for the speaker connectors
#2 Phillips screwdriver for attaching the included rack mount ears
Wire Strippers
MAKING THE CONNECTIONS
Note: All wiring connections must be made with the system powered o and
the power cord disconnected from the electrical mains (unplugged from the
wall outlet).
The D-Series Power Amplifier is very easy to install and only requires three
connection types: audio source, power and loudspeakers.
Power is provided from the included 3-prong grounded electrical cord. The
amplifier accepts AC power from 115-230V, 50/60Hz.
The amplifier may be placed on a shelf or installed into an equipment rack
using the rack ears included within the box.
RACK MOUNTING
When installed in a rack, the four mounting feet on the bottom of the chassis
may be removed if needed. Save the feet in case the amplifier is ever moved
back to a shelf-mounted type of installation so that they may be re-attached.
Do not use the amplifier on a shelf or other surface without the mounting
feet being installed. They help provide ventilation space at the bottom of
the amplifier. Leave at least 2” (5cm) of clearance around the amplifier for
ventilation.
CONNECTING LOUDSPEAKERS
Loudspeakers will always connect directly to the D-Series amplifiers unless
a separate impedance matching volume control, speaker selector or similar
device is required (all sold separately). CL2 rated wire must be used when
running wire within a home’s walls. The loudspeaker connectors are
designed to use up to 14ga wire.
Model Number of
Channels
Minimum
Impedance
Bridgeable (8
ohms only)
Max Number
of 8-ohm
Speakers
Supported
Per Channel
Max Number
of 6-ohm
Speakers
Supported
Per Channel
Max Number
of 4-ohm
Speakers
Supported
Per Channel
D890
8
(Organized
into 4 zones)
2.66 Ohms Yes 3 2 1
D1290
12
(Organized
into 6 zones)
2.66 Ohms Yes 3 2 1
D1290
16
(Organized
into 6 zones)
2.66 Ohms Yes 3 2 1
BUS IN
B
A
L R
ZONE 1
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
ZONE 2
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
ZONE 3
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
ZONE 4
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
Designed In New Hampshire
Made In China
D890 Amplifier
ON
AUTO
12V
DC 12V
TRIGGER
IN
ON
AC 115/230V 60/50Hz Max 600 W
FUSE: T6.3AL/250V
UL62368
IEC62368
ON
AUTO
12V
DC 12V
TRIGGER
IN
ON
AC 115/230V 60/50Hz Max 60 0W
FUSE: T6.3AL/250V

4Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 5
OVERVIEW
When connecting the loudspeaker wires, be sure to observe proper polarity.
The positive and negative terminals on the Russound D-Series amplifier must
correspond with the positive and negative terminals at both the left and right
loudspeakers. This is also true of the power connections at the loudspeaker
side of the connection.
Strip 1/8” (about 3mm) from each of the conductors for both the left and
right loudspeaker connections and insert them into the removable screw-
down terminal, making sure to match the proper polarity of each connection.
Tighten the screw-down connections securely and make sure that there are
no exposed strands that might cause a short-circuit.
BRIDGING LOUDSPEAKER CONNECTION
Please note that all wiring changes and changes to the settings switches on
the rear of the Russound D-Series amplifier should be done with the amplifier
powered o by removing the power cord from the rear of the amplifier.
The Russound D-Series amplifier includes a powerful feature called
“Bridging”. Bridging combines 2 adjacent output channels to form a single,
higher power mono output. It is perfect for larger spaces, and especially for
any outdoor audio zones where higher power is required.
OVERVIEW
The wiring method for bridged connections is dierent from that of normal
stereo pairs of loudspeakers. When bridging, only 8-ohm speakers may
be used. At the bottom of each speaker connector on the rear of your
Russound amplifier, you’ll see the alternate wiring configuration for a bridged
connection. One conductor of your loudspeaker wire will connect to the
left-most position on the speaker connector, and the second conductor
will connect to the right-most position as indicated. Please make sure to
verify the polarity of the wiring, matching the amplifier connection to the
loudspeaker connection.
Once the loudspeaker wiring has been configured, set the “Stereo/Bridged”
slide switch to the right for “Bridged” operation.
CONNECTING AUDIO SOURCES
There are two input types on your Russound D-Series amplifier:
Bus Inputs: Two analog stereo inputs: A and B
Zone Inputs: One analog stereo input for each zone
BUS INPUTS
The bus inputs can be shared by any zone of the amplifier. Use one of the bus
inputs if you want to share an audio source across more than one zone of the
amplifier. For example, if you have an audio streamer such as the Russound
MBX-PRE, connect its audio outputs to Bus Input A and you can then have
the audio streamer’s music played in any of the zones of the amplifier. With 2
Bus Inputs, your Russound amplifier can have 2 dierent audio sources that
are shared among configured zones of the system.
ZONE INPUTS
The Zone Inputs are NOT shared to other zones of your Russound amplifier.
Use these inputs for a zone-specific input. For example, if creating a whole-
home audio system with an audio streamer for every room in the home,
connect each audio streamer such as the Russound MBX-PRE to each
Zone Input. By doing this, app or voice control of any audio system is easily
implemented.
Use quality RCA cables and make sure all cables are fully attached and
secured to the Russound D-Series amplifier.
ZONE 1
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
ZONE 1
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
STEREO SPEAKER
WIRING EXAMPLE BRIDGED SPEAKER WIRING EXAMPLE

6Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 7
OVERVIEW
INPUT SETTINGS
An easy-to-use slide switch is located on the
rear of your D-Series amplifier for each zone.
The switch has 3 positions:
A– Setting the switch to this position will select Bus Input A as the audio
source for this zone
B– Setting the switch to this position will select Bus Input B as the audio
source for this zone
Line In – Setting the switch to this position will select the Zone Input as the
audio source for this zone.
Make sure that the switch is set properly for your audio system. Setting
this switch incorrectly will result in improper audio settings including lack
of audio in any zone where the improper source is selected.
INPUT CONNECTIONS
Connect your input source(s) according to your installation needs. To share
a source to multiple zone loudspeaker outputs, connect the source to one
of the Bus Inputs, either A or B. Make sure to set the Input Setting for each
loudspeaker output to the corresponding input, A or B. The Bus Input setting
allows your D-Series amplifier to work in many flexible configurations such
as sharing a single source in every zone, sharing up to 2 sources in any
combination of zones, or even using unique sources for every zone of the
amplifier.
OUTPUT FILTER SETTINGS
The Russound D-Series amplifiers have a
powerful feature allowing their output signal to be
attenuated specifically for the application of the
loudspeakers.
The switch applies advanced audio filters that
allow the output signal to be:
OVERVIEW
Full Range “Full” – The entire audio signal is sent unfiltered to the connected
loudspeakers, from 20Hz to 20,000Hz.
Low Pass “LP” – An advanced low-pass custom-designed filter is applied
to the audio path for the zone. Use this setting when connecting a passive
subwoofer to the zone. By combining this setting with a bridged zone, a
powerful subwoofer can be added to any zone or to multiple zones of the
amplifier. When configured for Low Pass, the frequency output is limited to
20Hz to 160Hz.
High Pass “HP” – An advanced high-pass custom-designed filter is applied
to the audio path for the zone. Use this setting to avoid sending excessive
low-frequency sounds to a loudspeaker that is not designed to handle them.
By customizing these audio filters, you can custom tailor the audio of the
installation to maximize the performance of the amplifier, the eiciency of
your loudspeakers, and maximize the audio components of the system to best
work together for their specific needs. When configured for High Pass, the
frequency output is limited to 80Hz to 20kHz.
POWER CONNECTION
Once the source and loudspeaker connections have been made and the input
setting, stereo/bridged mode setting, and output filter settings switches have
been set, you can connect the power cable to the rear of amplifier.
FRONT PANEL POWER BUTTON
The Front Panel Power Button will toggle between “On” and “Standby”
modes whenever the rear panel turn-on switch is set to Auto. If the rear
panel switch is set to “ON” or “12V”, the front panel switch will have no eect
because it is being overridden by the rear switch setting.
TRIGGER IN/OUT
The Trigger Input is used to turn on the D-Series amplifier, toggling between
standby mode when no 12V signal is present and On mode when a 12V signal
is present. This is very helpful for audio sources that have a low output signal
or where discrete, dedicated control of the amplifier status is required.
The Trigger Output is activated when ANY of the D-Series amplifier’s zones is
activated and powered on.
LINE IN
A
B
LINE IN
B
A
D890/1290 D1675
FULL
HP
LP
FULL
HP
LP
D890/1290 D1675

8Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 9
OVERVIEW
REAR PANEL SWITCH SETTINGS:
• ON- The Trigger Output will be active
• Auto – The Trigger Output will be active whenever any input signal is
detected
• 12V – The Trigger Output will be active whenever there is a 12V input
signal detected
TURN ON MODE
Your D-Series amplifiers has three turn-on modes:
ON – The D-Series amplifier is always on and ready to be used. The amplifier
consumes more electricity in this mode.
12V – The D-Series amplifier will turn on whenever a 12V signal (~100mA) is
detected at the DC 12V trigger “In” connection. When no 12V signal is present,
the amplifier will enter standby mode after a brief delay and will consume less
than 0.5W of electricity.
AUTO – The D-Series amplifier will automatically detect an input signal for
each zone and will turn on when needed. When no signal is detected, the
amplifier will enter standby mode after a delay of approximately 10 minutes.
When in standby mode, it will consume less than 0.5W of electricity.
SPECIFICATIONS
D890 D1290 D1675
Number of Channels 812 16
Bridgeable Yes Yes Yes
Filter Options High Pass, Low Pass, Full
Range
High Pass, Low Pass, Full
Range
High Pass, Low Pass, Full
Range
Power Output
4 ohm 90W /Channel, 1kHz One
Zone Driven
90W /Channel, 1kHz One
Zone Driven
75W /Channel, 1kHz One
Zone Driven
8 ohm 45W /Channel, 1kHz One
Zone Driven
45W /Channel, 1kHz One
Zone Driven
37W /Channel, 1kHz One
Zone Driven
8 ohm - Bridged 180W, 1kHz, One Zone
Driven
180W, 1kHz, One Zone
Driven
150W, 1kHz, One Zone
Driven
Minimum Impedance 2.66 ohms 2.66 ohms 2.66 ohms
OVERVIEW
D890 D1290 D1675
Freq Response
Full Range Mode 20Hz to 20kHz +/-3dB at 1W
output into 4 or 8 Ohms
20Hz to 20kHz +/-3dB at 1W
output into 4 or 8 Ohms
20Hz to 20kHz +/-3dB at 1W
output into 4 or 8 Ohms
Low Pass (LP) Mode 20Hz to 160Hz +/-3dB at 1W
output into 4 or 8 Ohms
20Hz to 160Hz +/-3dB at 1W
output into 4 or 8 Ohms
20Hz to 160Hz +/-3dB at 1W
output into 4 or 8 Ohms
High Pass (HP) Mode 80Hz to 20kHz +/-3dB at 1W
output into 4 or 8 Ohms
80Hz to 20KHz +/-3dB at
1W output into 4 or 8 Ohms
80Hz to 20KHz +/-3dB at
1W output into 4 or 8 Ohms
Input Sensitivity
4 ohm, One Zone 620 mV for 90W @ 1kHz 620 mV for 90W @ 1kHz 620 mV for 75W @ 1kHz
8 ohm, One Zone 690 mV for 45W @ 1kHz 690 mV for 45W @ 1kHz 690 mV for 37W @ 1kHz
Input Impedance >22k ohms Line Input >22k ohms Line Input >22k ohms Line Input
Signal to Noise Ratio >90dB A-weighted >90dB A-Weighted >90dB A-Weighted
Trigger Input 12V, Global 12V, Global 12V, Global
Trigger Output 12V, Global 12V, Global 12V, Global
Volume Gain Adjustment By Zone By Zone By Zone
Line Inputs Selectable: Bus A, Bus B,
Zone
Selectable: Bus A, Bus B,
Zone
Selectable: Bus A, Bus B,
Zone
Speaker Connectors Detachable Screw-down, up
to 14AWG
Detachable Screw-down, up
to 14AWG
Detachable Screw-down, up
to 14AWG
Operating Temperature 32°F to 104°F (0°C to 40°C) 32°F to 104°F (0°C to 40°C) 32°F to 104°F (0°C to 40°C)
Altitude 0 to 9,843’ (3,000m) 0 to 9,843’ (3,000m) 0 to 9,843’ (3,000m)
Power Requirements
North American Model 115-120VAC, 60Hz (600W
Max)
115-120VAC, 60Hz (600W
Max)
115-120VAC, 60Hz (600W
Max)
International Model (-i) 220-240VAC, 50Hz (600W
Max)
220-240VAC, 50Hz (600W
Max)
220-240VAC, 50Hz (600W
Max)
Fuse Rating
North American Model 6.3A, 250V FA 10A, 250V FA 10A, 250V FA
International Model (-i) 3.15A, 250V FA 5A, 250V FA 5A, 250V FA
Power Connector IEC C14 IEC C14 IEC C14
Standby Power Consump-
tion
0.3W 0.3W 0.3W
Product Dimensions 17.125"(W) x 1.75"(H) x 9.75"(D)
(43.5 x 4.4 x 24.8 cm)
17.125"(W) x 1.75"(H) x 9.75"(D)
(43.5 x 4.4 x 24.8 cm)
17.125"(W) x 3.5"(H) x 9.75"(D)
(43.5 x 8.8 x 24.8 cm)
Product Weight 8 lbs (3.6 kg) 9 lbs (4.1 kg) 12.8 lbs (5.8 kg)
Shipping Dimensions 20.2"(W) x 4.9" (H) x 14.3"
(D) (51.33 x 12.5 x 36.3 cm)
20.2"(W) x 4.9" (H) x 14.3"
(D) (51.33 x 12.5 x 36.3 cm)
20.2"(W) x 6.7" (H) x 14.3"
(D) (51.33 x 17 x 36.3 cm)
Shipping Weight 9.5 lbs (4.3 kg) 10.6 lbs (4.8 kg) 14.8 lbs (6.7 kg)
Limited Warranty 2 Years 2 Years 2 Years

10 Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 11
APPLICATION DIAGRAMS APPLICATION DIAGRAMS
SUB 2SUB 1
ZONE 1
LEFT SPKR
LEFT INPUT
ZONE 6
LEFT SPKR
LEFT INPUT
ZONE 1
RIGHT SPKR
RIGHT INPUT
ZONE 6
RIGHT SPKR
RIGHT INPUT
ZONE 5
LEFT SPKR
LEFT INPUT
ZONE 2
RIGHT SPKR
RIGHT INPUT
ZONE 2
LEFT SPKR
LEFT INPUT
ZONE 3
RIGHT SPKR
RIGHT INPUT
ZONE 3
LEFT SPKR
LEFT INPUT
ZONE 4
LEFT SPKR
LEFT INPUT
ZONE 4
RIGHT SPKR
RIGHT INPUT
Using the output from a home theater pre-amplifier, feed each of the 11 channels of
audio output to your D1290. Here is one possible configuration:
Zones 1-5 should be set for Full Range “Full”
Zone 6 should be set to Low Pass “LP”
ZONE 1-5
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
ZONE 6
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
R L
LINE IN
R L
Right
Speaker
Input
Left
Speaker
Input
Right
Speaker
Output
Left
Speaker
Output
Right
Speaker
Input
Left
Speaker
Input
Right
Speaker
Output
Left
Speaker
Output
LARGE OUTDOOR SYSTEM WITH THE D1675
D1675
STATUS 12345678
ROCK SUBROCK
SPEAKER
ROCK
SPEAKER
ROCK
SPEAKER
ROCK
SPEAKER
HARDSCAPE
SUB
5B65
SPEAKER
5B65
SPEAKER

12 Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 13
OVERVIEW
1. Read Instructions - All the safety and operating instructions should be read before
the appliance is operated.
2. Retain Instructions - The safety and operating instructions should be retained for
future reference.
3. Heed Warnings - All warnings on the appliance in the operating instructions should
be adhered to.
4. Follow Instructions - All operating and user instructions should be followed.
5. Water and Moisture - The appliance should not be used near water; for example,
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a
swimming pool. The apparatus shall not be exposed to dripping or splashing liquids
and no objects filled with liquids, such as vases, shall be placed on the apparatus.
Do not touch the appliance with wet hands. Do not handle the appliance or power
cord with wet or damp hands. If water or any other liquid enters the appliance
cabinet, take it to qualified service personnel for inspection.
6. Cleaning - The appliance should be cleaned only as recommended by the
manufacturer. From time to time you should wipe o the front and side panels and
the cabinet with a soft cloth. Do not use rough material, thinners, alcohol or other
chemical solvents or cloths since this may damage the finish or remove the panel
lettering.
APPLICATION DIAGRAMS
Use to Add Extra Speakers to Any System
ZONE 1
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
L R
ZONE 2
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
L R
ZONE 3
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
L R
LINE IN
RL
ZONE 4
LEVEL
FULL
LINE IN BRIDGED
SPEAKER
BRIDGED 8Ω
STEREO
B
A
HP
LP
L R
LINE IN
RL
DesignedIn New Hampshire | Made In China
D890 Amplifier ON
AUTO
12V
DC 12V
TRIGGER
IN
OUT
AC 115/230V 60/50Hz M ax 600W
FUSE: T6.3AL/250V
LINE IN
RL
LINE IN
RL
RISQUE DE CHOC ELECTRIQUE
NE PASOUVRIR
BUS IN
L
B
A
RSN:
OUTDOOR
BEDROOM
OFFICE

14 Russound D-Series Amplier Installation Guide Russound D-Series Amplier Installation Guide 15
NOTES
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
OVERVIEW
7. Ventilation - The appliance should be situated so that its location or position does
not interfere with its proper ventilation. For example, the appliance should not
be situated on a bed, sofa, rug, or similar surface that may block the ventilation
openings, or placed in a built-in installation, such as a bookcase or cabinet that
may impede the flow of air through the ventilation openings. Place the unit in a
well-ventilated location, leaving at least 2 inches (5 cm) of clearance on all sides,
top and rear of unit for air flow. If ventilation is blocked, the unit may overheat and
malfunction.
8. Heat - The appliance should be situated away from heat sources such as radiators,
heat registers, stoves, or other appliances (including amplifiers) that produce heat.
9. Grounding or Polarization - Precaution should be taken so that the grounding or
polarization means of an appliance is not defeated.
10. Power Cord Protection - Power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying
particular attention to cords at plugs, receptacles, and the point where they exit
from the appliance.
11. Power Sources - The appliance should be connected to a power supply only of the
type described in the operating instructions or as marked on the appliance.
12. Main Power Disconnect - The main power plug is used as the disconnect device
and shall remain readily operable. When installing the product, ensure that the
plug is easily accessible.
13. Non-Use Periods - The power cord of the appliance should be unplugged from the
outlet when left unused for a long period of time.
14. Attachments - Only use attachments/accessories specified by the manufacturer.
15. Location of the Amplifier - Do not mount this unit under a kitchen cabinet. Do not
expose the amplifier to direct sunlight or heating units as the amplifier internal
components’ temperature may rise and shorten the life of the components.
16. Avoid damp and dusty places.
17. Object and Liquid Entry - Care should be taken so that objects do not fall and
liquids are not spilled into the enclosure through the openings.
18. Servicing - The user should not attempt to service the appliance beyond that
described in the operating instructions. All other servicing should be referred to
qualified service personnel.
19. Damage Requiring Service - The appliance should be serviced by qualified service
personnel when: A. The power supply cord or the plug has been damaged; B.
Objects have fallen, liquid has been spilled into the appliance; C. The appliance
has been exposed to rain; or D. The appliance does not appear to operate
normally; or E. The appliance has been dropped or the enclosure is damaged.

©2023 Russound/FMP, Inc. All rights reserved.
All trademarks are the property of their respective owners.
Specifications are subject to change without notice REV6
