RUTHMAN RAE Pumps GMVCP Series User manual

Installation,
Operation, and
Maintenance Manual
GMVCP Series
Multistage Vertical
Immersion Pumps
RAE Pumps
1212 Streng Street
Cincinnati, OH 45223
513.779.3034
www.RAEPumps.com
60 Hz
MODELS
GMVCP 2
GMVCP 4
GMVCP 8
GMVCP 16

Table of Contents
INTRODUCTION ............................................................................................................................ 03
SPECIFICATIONS–SECTION A .................................................................................................... 03
MODEL CODE EXPLANATION.......................................................................................... 03
OPERATING PARAMETERS ............................................................................................. 04
MOTOR DATA .................................................................................................................... 04
INSTALLATION–SECTION B ........................................................................................................ 04
REQUIREMENTS ............................................................................................................... 04
ELECTRICAL CONNECTION–SECTION C .................................................................................. 04
SPECIFICATIONS .............................................................................................................. 04
CONNECTION .................................................................................................................... 04
ROTATION DIRECTION..................................................................................................... 04
POSITIONING CONNECTION BOX................................................................................... 05
WIRING DIAGRAM ............................................................................................................. 05
OPERATION AND MAINTENANCE–SECTION D......................................................................... 05
FINAL CHECKS.................................................................................................................. 05
START UP .......................................................................................................................... 05
SHUTDOWN ....................................................................................................................... 05
MOTOR LUBRICATION...................................................................................................... 06
SUCTION FILTER............................................................................................................... 06
PERIODIC INSPECTION.................................................................................................... 06
TROUBLESHOOTING–SECTION E .............................................................................................. 06
DIMENSIONS–SECTION F ............................................................................................................ 07
GMVCP 2 DIMENSIONS AND WEIGHTS.......................................................................... 07
GMVCP 2 OUTLINE DRAWING ......................................................................................... 07
GMVCP 4 DIMENSIONS AND WEIGHTS.......................................................................... 07
GMVCP 4 OUTLINE DRAWING ......................................................................................... 07
GMVCP 8 DIMENSIONS AND WEIGHTS.......................................................................... 08
GMVCP 8 OUTLINE DRAWING ......................................................................................... 08
GMVCP 16 DIMENSIONS AND WEIGHTS........................................................................ 08
GMVCP 16 OUTLINE DRAWING ....................................................................................... 08
WARRANTY–SECTION G ............................................................................................................. 09
Please read this manual carefully before
beginning installation and operation.

3

INTRODUCTION
This Installation, Operation, and Maintenance Manual is designed to help you get the best performance
and longest life from your RAE pump.
This pump is a GMVCP Series vertical multistage centrifugal pump. This pump should be immersed
during operation.
GMVCP Series pumps are intended for industrial use to carry fluids such as water, coolant, light oil and
other clean, non-aggressive liquids.
Standard pump construction is stainless steel immersed parts.
If there are any questions regarding the pump or its applications which are not covered in this manual,
or in other literature accompanying this unit, please contact your RAE Pumps distributor, or write:
RAE Pumps
1212 Streng Street
Cincinnati, OH 45223
513.779.3034
[email protected]
www.RAEPumps.com
For information or technical assistance on the power source, contact the power source manufacturer’s
local dealer or representative.
! DANGER !
This pump is not intended to transfer explosive liquids, such as gasoline, diesel oil and other
similar liquids. It is only suitable for water, and diluted, low viscosity, non-corrosive cooling or
lubricant liquids.
SPECIFICATIONS–SECTION A
MODEL CODE EXPLANATION
The pump models are coded based on the
number of pump stages. Standard stages
consist of both diffusers and impellers. Some
models contain null stages for special
installation considerations. Null stages consist
of only the diffuser chamber.
The number of stages is followed by a zero in
the model code. This zero is not part of the
stage count number. The pump model is shown
on the pump nameplate.

4

OPERATING PARAMETERS
Ambient temperature: Max 104°F
Liquid temperature range: 5°F to 221°F
GMVCP 2 GMVCP 4
Flow (gpm): 4 to 20 11 to 35
Head (feet): 60 to 775 85 to 768
Max psi: 335 333
Submerged depth: Min 3.36” Min 3.36”
GMVCP 8 GMVCP 16
Flow (gpm): 31 to 62 44 to 114
Head (feet): 85 to 722 131 to 650
Max psi: 315 290
Submerged depth: Min 3.94” Min 3.94”
MOTOR DATA
Nominal speed: 3500 rpm at 60 Hz
Standard voltage: 3 phase; 230V/460V
Protection class: IP54
Insulation class: F
INSTALLATION–SECTION B
! WARNING !
When running, the motor surface
temperature is extremely high. Mount pump
in a safe place to avoid accidental touch.
REQUIREMENTS
1. The pump should be located in a well-
ventilated but frost-free area.
2. Immersion depth should be as deep as
possible, but not less than the minimum
Submerged Depth listed in SECTION A of
this manual to prevent dry running and
damage to the pump.
3. When installing the drainage pipe, support
pipe weight to avoid strain on the pump and
twisting of the pipe.
4. Motor should be correctly grounded. Pump
can be damaged by phase loss, unstable
power or power surge.
5. Install a pressure meter on pump outlet to
monitor pump operation.
ELECTRICAL CONNECTION– SECTION C
! WARNING !
Electrical installation should be carried
out in accordance with the local
electrical code. Make sure that the
electricity supply has been switched off
before electrical connection.
Use care when accessing pump
electrical components.
SPECIFICATIONS
Electrical specifications (voltage, hertz) are
shown on the pump nameplate. Verify that the
power supply voltage and hertz match pump
requirements. An external ON/OFF switch must
be installed.
CONNECTION
Electrical connection should be in accordance
with diagram shown on the connecting box, and
motor current should be within rated amps as
shown on nameplate. Three phase pump
requires extra magnetic starter with protection.
ROTATION DIRECTION
On this three phase motor, rotating direction is
critical. The rotating direction is indicated on the
fan cover (counterclockwise viewing from fan
cover end). Interchanging any two leads with
power off can reverse the pump rotation.

5

POSITIONING CONNECTION BOX
The position of the motor connecting box is
adjustable. Referring to Figure 3, the position
can be changed by removing the motor fan
cover, unscrewing the frame bolts, and turning
the motor casing and connecting box
subassembly together to proper position.
Finally, screw the frame bolts tight, and put the
fan cover back.
Figure 3
WIRING DIAGRAM
OPERATION AND MAINTENANCE–SECTION D
! WARNING !
The pump cannot be operated with
discharge outlet fully closed. Doing so
will raise the liquid temperature
abnormally, and quickly damage pump.
! WARNING !
The pump cannot be used to transfer
explosive liquids.
Extra protective gear is required if the
working liquid temperature exceeds
140°F to avoid scald hazard.
The pump should not be used to transfer
toxic or contaminated liquid. Warranty
will be void if the pump application is not
in compliance with the installation and
operation procedures.
FINAL CHECKS
Before starting the pump, verify:
1. Pump rotation–the rotating direction
should be counterclockwise viewing
from fan cover end.
2. Piping and joints are fitted carefully to
prevent leaks.
3. Check that foot and air vent bolts are
secure and tighten if loose.
4. The pump has been filled with liquid and
air vented as described in the START
UP instructions below. Failure to do so
will damage the bearing and mechanical
seal.
5. The suction filter is clear of obstruction.
START UP
1. Start motor, verify motor is turning and
is turning in the right direction.
2. Open outlet valve, adjust it to the
required working condition. Suggested
flow is 0.5 to 1.3 times of the pump’s
rated flow.
3. Check pressure meter on pump’s
discharge for fluctuations in pressure
and observe pump for vibration. If
pressure drops/vibration indicate air in
the liquid, loosen air vent bolts to vent
air, retighten bolts once pressure
stabilizes and vibrations stops.
4. Observe for changes in the sound of
pump operation. If there are any
abnormal noises, pump should be
stopped and checked immediately.
SHUT DOWN
1. Close outlet valve slowly.
2. Switch off the power.

6

! WARNING !
Avoid frequent pump shut down and
start up.
Pumps with a motor power equal to or
less than 5HP should not be restarted
more than 100 times per hour. Pumps
with a motor power greater than 5HP
should not be restarted more than 20
times per hour.
MOTOR LUBRICATION
For motor powers less than 7.5HP,
lubrication is not needed. For motor power
equal to or greater than 7.5HP, fill grease
every 5000 running hours.
SUCTION FILTER
For maximum performance, the suction filter
should be always kept clean and free from
obstructions.
PERIODIC INSPECTION
The following checks should be carried out
periodically to ensure normal operation:
1. Measure the discharge and output
pressure.
2. Inspect piping and joints for leaks.
3. Measure motor temperature for
changes.
4. Examine the motor starter/container.
TROUBLE SHOOTING–SECTION E
! WARNING !
Verify electrical supply has been switched off before trouble shooting.
Fault Possible Causes Possible Solutions
Motor does not
start
1. No electrical supply
2. Fuses blown or breaker tripped
3. Overheating relay tripped
4. Defective magnetic contact
5. Control circuit malfunction
Check power supply and circuit.
Pump runs but no
liquid discharges
1. Incorrect rotating direction
2. Not immersed to correct minimum
depth
3. Insufficient liquid level
4.
A
ir in suction head or pump
1. Adjust motor connection
2. Lower installation position
3. Add liquid
4. Vent air
Insufficient flow 1. Pipe clogged
2. Neck ring worn
3. Incorrect model for application
1. Clean pump and pipes
2. Replace neck ring
3. Replace with correct model
Pump consumes
too much powe
r
1. Flow is too large
2. Motor bearing worn
1. Reduce flow
2. Replace moto
r
Abnormal noise/no
liquid discharges
1. Insufficient liquid level
2. Temperature of pumped liquid is
too high
1. Check pump suction and
liquid level
2. Lower pump suction height or
decrease liquid temperature
Very loud operation 1. Motor bearing or pump parts
broken
1. Inspect and replace motor
bearing or pump parts as
needed

7

DIMENSIONS AND WEIGHT–SECTION F
GMVCP 2
Model A B C D E Weight
(inches) (inches) (inches) (inches) (inches) (pounds)
GMVCP2-20-2 17.83 4.84 12.99 5.83 4.60 33
GMVCP2-30-3 19.65 5.55 14.09 6.69 5.59 40
GMVCP2-40-4 20.35 6.26 14.09 6.69 5.59 44
GMVCP2-50-5 21.06 6.97 14.09 6.69 5.59 44
GMVCP2-60-6 21.77 7.68 14.09 6.69 5.59 49
GMVCP2-70-7 24.65 8.39 16.26 7.48 6.10 60
GMVCP2-90-9 26.06 9.80 16.26 7.48 6.10 68
GMVCP2-110-11 27.48 11.22 16.26 7.48 6.10 68
GMVCP2-130-13 31.46 12.64 18.82 7.76 6.50 82
GMVCP2-150-15 32.87 14.06 18.82 7.76 6.50 83
GMVCP2-180-18 35.39 16.81 19.21 9.06 7.28 93
GMVCP 4
Model A B C D E Weight
(inches) (inches) (inches) (inches) (inches) (pounds)
GMVCP4-20-2 19.92 5.83 14.09 6.69 5.59 33
GMVCP4-30-3 20.98 6.89 14.09 6.69 5.59 40
GMVCP4-40-4 24.21 7.95 16.26 7.48 6.10 51
GMVCP4-50-5 25.28 9.02 16.26 7.48 6.10 60
GMVCP4-60-6 26.34 10.08 16.26 7.48 6.10 60
GMVCP4-70-7 29.97 11.14 18.82 7.76 6.50 73
GMVCP4-80-8 31.02 12.20 18.82 7.76 6.50 73
GMVCP4-100-10 33.54 14.33 19.21 9.06 7.28 84
GMVCP4-120-12 35.67 16.46 19.21 9.06 7.28 84
GMVCP4-140-14 39.96 18.58 21.38 10.24 8.27 139
GMVCP4-160-16 42.09 20.71 21.38 10.24 8.27 143

8

GMVCP 8
Model A B C D E Weight
(inches) (inches) (inches) (inches) (inches) (pounds)
GMVCP8-20-2 22.40 5.91 16.50 7.48 6.10 71
GMVCP8-30-3 23.58 7.09 16.50 7.48 6.10 82
GMVCP8-40-4 27.32 8.27 19.06 7.76 6.50 99
GMVCP8-50-5 28.50 9.45 19.06 7.76 6.50 104
GMVCP8-60-6 30.01 10.63 19.45 9.06 7.28 115
GMVCP8-80-8 34.60 12.99 21.61 10.24 8.27 159
GMVCP8-100-10 36.97 15.35 21.61 10.24 8.27 172
GMVCP8-120-12 39.33 17.72 21.61 10.24 8.27 176
GMVCP8-140-14 47.64 20.08 27.56 12.99 10.04 298
GMVCP 16
Model A B C D E Weight
(inches) (inches) (inches) (inches) (inches) (pounds)
GMVCP16-20-2 26.54 7.09 19.45 9.06 7.28 110
GMVCP16-30-3 30.47 8.86 21.61 10.24 8.27 143
GMVCP16-40-4 32.24 10.63 21.61 10.24 8.27 165
GMVCP16-50-5 39.96 12.40 27.56 12.99 10.04 287
GMVCP16-60-6 41.73 14.17 27.56 12.99 10.04 291
GMVCP16-70-7 43.50 15.94 27.56 12.99 10.04 309
GMVCP16-80-8 45.28 17.72 27.56 12.99 10.04 309
GMVCP16-100-10 50.79 21.26 29.53 12.99 10.04 331

9
M-RC20-005/10-20
www.RAEPumps.com | 513.779.3034
WARRANTY–SECTION G
RAE Pumps will replace, within one year of shipment from our plant, any pump that, in our judgment,
has failed due to defects in materials or workmanship, provided the pump has been properly installed
and maintained and has not been subject to abuse.
Modifications, including removal of pump tags or misapplication, void this warranty.
Pump must return to RAE Pumps with complete history of service for inspection and warranty
consideration.
RAE Pumps does not accept the responsibility for transportation to and from our plant. Furthermore, we
do not assume any responsibility for consequential damage or loss of production.
