Rx Clear Niagara Rapid User manual

Owners Manual
Niagara Rapid™
Submersible Cover Pump
Multi-connection Adapter
Garden Hose Adapter
Carrying Handle
Easy Maintenance
1 Year Limited Warranty
Your Rx Clear® Niagara Rapids™ submersible pool cover pump is warranted against
defects in workmanship for a period of 1 year from date of purchase. Examine the
pump before usage or installation.
If the pump should fail for reason above and still within the warranty period it will be
repaired or replaced at the option of the manufacture discretion. All defective
product returned under this limited Warranty will be fully inspected to determine the
cause of failure before Warranty is approved. To file a claim contact the Authorized
Retailer the product was purchased from, you will be asked to provide a copy of your
sales order. Any / all freight charges incurred in returning the pump to the retailer will
be the sole responsibility of the purchaser
This limited Warranty is in lieu of all other warranties to the maximum extent
permitted by applicable law. The company disclaims all other warranties and
conditions, express or implied, including but not limited to the implied warranties of
merchantability and fitness for a particular purpose. Replacement of defective
products as provided under this Warranty is your exclusive remedy. The company will
not be liable in contract or tort for any direct, consequential, special or incidental loss
or damage arising out of the use, misuse or inability to use this product. This
Warranty is not transferable by the original owner to a subsequent owner of the pool
cover pump.
Some states do not allow the exclusion or limitation of incidental or consequential
damages so the above limitation or exclusion may not apply to you.
This Warranty gives you specific legal rights. You may have additional rights, which
vary from state to state.

INFORMATION
Read these instructions carefully and adhere to all warnings
before attempting to install, operate or perform
maintenance on this product. Failure to comply with these
instructions could result in personal injury and / or
property damage.
SPECIFICATIONS
DESCRIPTION
The Rx Clear® Niagara Rapids™Submersible Cover Pump is
designed for residential swimming pools and sumps. Unit is
equipped with a 3-prong grounding-type power cord.
Motor is sealed for cooler running. Bearings on motor
shaft never need lubrication. Automatic reset thermal
protection.
SPECIFICATIONS
Power Supply Required………………………………110V, 60HZ
Liquid Temp. Range………………..32°F to 95°F (0°C - 35°C)
Discharge…………………………………………………….1-½" FNTP
NOTICE: This unit is not designed as a waterfall or fountain
pump, or for applications involving salt water or brine! Use
with waterfalls, fountains, salt water will void warranty.
This pump is designed for use in a residential pool only,
pump only water with this pump.
NOTICE: Pump can pump down to about ¼" (6mm) but
should not be allowed to run for a period of time unless it is
in at least 5-½" of water.
Do not use where water recirculates
GENERAL SAFETY INFORMATION
Electrically powered cover pumps normally gives many
years of trouble-free service when correctly installed,
maintained, and used. However, unusual circumstances
(interruption of power to the pump, dirt/debris in the
pump, flooding that exceeds the pump's capacity, electrical
or mechanical failure in the pump, etc.) may prevent your
pump from functioning normally. See the 'Troubleshooting
Chart' in this manual for information about common cover
pumps problems and remedies.
Know the pump application, limitations, and potential
hazards
1. Do not use in water with fish present. If any oil leaks
out of the motor it can kill fish.
2. Disconnect power before servicing.
3. Release all pressure within system before servicing any
component.
4. Drain all water from system before servicing.
5. Secure discharge line before starting pump. An
unsecured discharge line will whip, possibly causing
personal injury and/or property damage.
6. Check hoses for weak or worn condition before each
use, making certain that all connections are secure.
7. Periodically inspect product and system components.
Keep free of debris and foreign objects. Perform
routine maintenance as required.
8. Personal Safety:
a. Wear Safety glasses at all times when working
with pumps.
b. Keep work area clean, uncluttered and properly
lighted –replace all unused tools and equipment.
c. Keep visitors at a safe distance from work area.
d. Make workshop child-proof –with padlocks,
master switches, and by removing started keys.
9. When wiring an electrically driven pump, follow all
electrical and safety codes that apply in your
state/county.
10. This equipment is only for use on 110 volt (single
phase) and is equipped with an approved 3-conductor
cord and 3-prong, grounding-type plug.
250W
400W
500W
Max. delivery
capacity
6000 l/h
7000 l/h
10,000 l/h
Max. pressure
0.6 bar
0.8 bar
0.85 bar
Max. delivery
height
6m
8m
8.5m
Max.
submersion
depth
5m
7m
7m
SAFETY GUIDELINES
WARNING To reduce risk of electric shock, pull plug
before servicing, Pump is supplied with a grounding
conductor and grounding-type attachment plug. Be sure it
is connected only to a properly grounded grounding-type
receptacle.
WARNING Where a 2-prong wall receptacle is
encountered, it must be replaced with properly grounded
3-prong receptacle installed in accordance with state / local
codes and ordinances.
WARNING Protect electrical cord from sharp objects,
hot surfaces, oil and chemicals. Avoid kinking cord.
Replace or repair damaged or worn cords immediately
WARNING Do not touch an operating motor. Modern
motors can operate at high temperatures.
WARNING Do not handle pump or pump motor with
wet hands or when standing on wet or damp surface, or in
water
WARNING Do not lift pump by power cord.
WARNING Do not bury cord. Locate cord to minimize
damage from lawn mowers, hedge trimmers, and other
equipment.
WARNING Never pump corrosive liquids with this
pump, this could damage the integrity of the enclosure and
cause an electrical short. This pump has been evaluated
for use with water only.
WARNING Do not run this pump dry. Running this
pump without water may damage the integrity of the
enclosures and cause electrical short.
WARNING Icy conditions can cause unnecessary wear
on pump. When these conditions exist cease operation of
pump and remove the pump from the pool cover.
OPERATION INSTRUCTIONS
OPERATION WARNINGS.
WARNING Risk of electrical shock. Do not handle a
pump or pump motor with wet hands or when standing on
wed or damp surface, or in water
To reduce the risk of electric shock, replace damaged cord
immediately. Contact the manufacture for replacement of
the power cord. .
WARNING If service is required, proceed carefully. The
pump and surrounding areas may be covered with water.
Never plug or unplug the device while standing in wet or
damp surfaces. If necessary, remove power at the breaker
panel or have certified electrician remove power before
attempting to service. Serious or fatal shocks could result if
proper procedures are not followed. Disconnect the power
at the main electrical service box by switching the
appropriate circuit breaker or removing the fuse. In
applications where screw type fuses are used, remove only
the one hand while other hand or torso is free from contact
with anything. Do not stand in water or do not touch any
other conductive surfaces. .
WARNING Verify that the electrical outlet to be used
meets the requirements of the National Electrical Code
(NEC) as well as local electrical codes including grounding
and GFCI protection. Also verify that the outlet is properly
sized and located for this pump. Your installation may
require a certified electrician or plumber. .
WARNING If necessary, check your plumbing codes to
verify that the final installation will be in compliance with
their requirements.
TROUBLESHOOTING CHART.
OPERATION Information
1. Shaft seal depends on water for lubrication. Do not
operate pump unless it is submerged in water as seal
may be damaged if allowed to run dry.
2. Motor is equipped with automatic reset thermal
protector. If temperature in motor should rise unduly,
switch will cut off all power before damage can be done
to motor. When motor has cooled sufficiently, switch
will reset automatically and restart motor. If protector
trips repeatedly, pump should be removed and checked
as to cause of difficulty. Low voltage, long extension
cords, clogged impeller, very low head or lift, or a
plugged or frozen discharge pipe, etc., could cause
cycling.
Follow these instructions to begin using your submersible
pump:
1. Locate an area for the end of the garden or backwash
hose that unwanted water should be discharged to.
Note: Check state / local codes for discharge of water
2. Locate a desirable flat area for your pump. Always use
carrying handle to transport pump.
3. Attach garden or discharge hose to multi-connection
adapter
4. Plug cord into an approved electrical outlet and begin
operation.
SYMPTOM
CAUSE(S)
CORRECTIVE ACTION
Pump won't start
or run
Pump is not plugged in
Blown fuse
Low line voltage
Defective motor
Defective float switch
Impeller
Frozen water in hose
Water inflow matches or exceeds pump
capacity
Stuck intake
Check and see if pump is plugged into a proper outlet
If blown, replace with fuse of proper size
If voltage under recommended minimum, check size of wiring
from main switch on property. If OK, contact power company
or hydro authority.
Replace Pump
Replace Pump
If impeller won't turn, remove lower pump body and locate
source of binding
Thaw or replace hose
Larger pump required or multiple pumps needed
Clean out area around base
Pump starts and
stops too often
Backflow or water from hose
Faulty float switch
Install or replace hose
Replace Pump
Pump won't shut
off
Restricted discharge (obstacle or ice in
piping)
Float obstructed
Pump is air locked
Restricted intake screen
Remove pump and clean pump and hose
Remove obstruction
Shut power off for approximately 1 min then restart the
pump. Repeat
Remove the pump and clean the intake screen and the
impeller
Pump operates but
delivers little or no
water
Something caught in impeller
Worn or defective parts or plugged
impeller
Restricted intake screen
Remove the pump and clean out the impeller
Clean impeller if plugged; otherwise replace pump
Remove the pump and clean out the intake screen
WARNING Hazardous voltage and risk of shock can shock, burn or kill. Unplug pump before performing maintenance.
