RYOBI
12 in. DRILL PRESS W/LASER
MODEL NO. DP121L
REPAIR SHEET

RYOBI 12 in. DRILL PRESS – MODEL NUMBER DP121L
2
32
20
21 22 19
19
114
133
132
118
119
12
2
3
35
33 34 36 37
56 139
140
116
117
123
113 53 42
103
104
102
130
101
100
135
126
97 96
95
81
82
83
14
14
80
79
78
138
131
134
127
3
3
84
85
86
87
75
76
136
77
137
94
93
92
91
141
90
89
88
125
99
98
6
124129
105
112
106
107
108
111
110
115
38
39
40
41
43
42
44
45 464748 49 50 5152
54
55
56
58
65
66
66
67
68
69
71
70
72
73
74
35
134
59
128
60
61
62
63
64
53
18 17 16
15
14
13
12 11
57
109
121
4
1
5
6
7
89
10
122
120
31
30
29
28
27
26
25
24
23

RYOBI 12 in. DRILL PRESS – MODEL NUMBER DP121L
3
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL PRESS or when ordering repair parts.
PARTS LIST FOR FIGURE A
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 089140300080 BEVEL STOP.......................1
2 089140300906 RPM LABEL ........................1
3 TDP07001 * SCREW
(M5 X 6 mm PAN HD.).........9
4 089140300001 BASE...................................1
5 13401002A COLUMN HOLDER.............1
6 TDP03001 * SET SCREW
(M8 X 10 mm HEX SOC.) ....3
7 089140300003 * BOLT (M10 X 30 mm HEX)..4
8 13401003A TUBE COLUMN ..................1
9 13201010A RACK ..................................1
10 089140300090 COLUMN COLLAR .............1
11 089140200022 KNOB..................................1
12 TDP06001 * HEX NUT (M8).....................2
13 089140200024 CRANK................................1
14 089140300007 * SCREW
(M6 X 8 mm HEX SOC.) ......3
15 13201007 GEAR SHAFT......................1
16 13401004B TABLE SUPPORT .................1
17 13201006 WORM GEAR .....................1
18 13201008 GEAR .................................1
19 16101013A TABLE LOCK HANDLE .......2
20 089140300010 TABLE ...............................1
21 TDP12B03009 * SCREW
(M12 X 25 mm HEX HD.).....1
22 13401005 ARM-TABLE ........................1
23 13103006M1 CHUCK KEY .......................1
24 13103006M CHUCK .............................1
25 13403007 ARBOR................................1
26 16103008 CHUCK TOOL (DRIFT)........1
27 13303001A SPINDLE .............................1
28 089140300015 BEARING (80204) ...............1
29 13303002A QUILL TUBE .......................1
30 13303006 QUILL GASKET...................1
31 TDP02001 BALL BEARING (60201)......1
32 TDP10001 RETAINING RING (11) ........1
33 089140200036 * SCREW
(M3.5 X 9.5 mm PAN HD.)...4
34 089140200037 SWITCH ..............................1
35 089140200035 * SCREW
(M5 X 25 mm PAN HD.).......2
36 089140200044 LIGHT SWITCH...................2
37 089140300019 SWITCH BOX......................1
38 16104007A SPRING RETAINER.............1
39 16104009 TORSION SPRING..............1
40 16104008 CAP SPRING ......................1
41 TDP12B06005 HEX NUT (M12)...................2
42 089140200083 KNOB..................................4
43 089140300024 HANDLE CLAMP ...............1
44 089140300025 FEED HANDLE....................1
45 089140300026 V BELT ................................1
46 TDP06002 * HEX NUT (M10 mm)............1
47 089140300027 LOCK WASHER (20-1)........1
48 089140300028 SPEED ADJUST-HUB .........1
49 089140300029 * SCREW
(M5 X 12 mm PAN HD.).......3
50 089140300030 COLLAR SHAFT .................1
51 089140300031 KEY (M3 X 6 mm)................1
52 089140300032 PINION SHAFT....................1
53 089140200071 * SCREW
(M6 X 5 mm HEX SOC.) ......2
54 089140300033 * SCREW
(M4 X 16 mm PAN HD.).......2
55 089140300034 SENSOR .............................1
56 089140300035 * SCREW (M2.2 X 6.5 mm)....4
57 089140300036 * SCREW
(M5 X 8 mm HEX SOC.) ......2
58 089140300037 SPINDLE PULLEY-LOWER .1
59 089140300038 SPINDLE PULLEY-UPPER..1
60 089140300039 C-CLIP (SPINDLE PULLEY) 1
61 089140300040 BEARING (61907) ...............1
62 089140300041 RETAINING RING (35).........1
63 089140300042 DRIVE PLATE ......................1
64 089140300043 RETAINING RING (24).........1
65 TDP10002 RETAINING RING (17).........1
66 089140200039 BALL BEARING (60203)......2
67 13302023A SPACER ..............................1
68 089140300045 INSERT PULLEY .................1
69 089140300046 KEY (M4 X 60 mm)..............1
70 089140300047 POWER CORD....................1
71 089140200082 HEX KEY (5 mm) .................1
KEY PART
NO. NUMBER DESCRIPTION QTY.

RYOBI 12 in. DRILL PRESS – MODEL NUMBER DP121L
4
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your DRILL PRESS or when ordering repair parts.
PARTS LIST FOR FIGURE A
72 TDP04001 HEX KEY (4 mm) .................1
73 089140200080 HEX KEY (3 mm) .................1
74 089140300048 PULLEY COVER .................1
75 089140300049 * SCREW (SET W/DOG POINT
M8 X 16 mm HEX SOC.) .....1
76 089140300050 RACK ..................................1
77 089140200067 * SCREW
(M4 X 8 mm PAN HD.).........4
78 089140300052 SENSOR SEAT....................1
79 089140200031 RUBBER GROMMET..........2
80 13202014A CORD CLAMP W/SLEEVE..2
81 089140300053 GEMEL SEAT ......................2
82 089140300054 MOTOR PULLEY-LOWER ..1
83 089140300055 MOTOR PULLEY-UPPER ...1
84 089140300056 RETAINING RING (14).........1
85 089140300057 * SCREW
(M4.2 X 9.5 mm PAN HD.)...4
86 089140300058 GEMEL CLAMP ..................2
87 089140300059 GEMEL................................1
88 089140300060 * SCREW
(M8 X 25 mm HEX SOC.) ....4
89 TDP11001 LOCK WASHER (M8) ..........4
90 089140300062 WASHER (M8).....................4
91 089140300063 MOTOR PULLEY SPRING ..1
92 089140300064 HOOD SPRING ...................1
93 089140300065 PALLET SPRING .................1
94 089140300066 KEY (M4 X 75 mm)..............1
95 089140300088 MOTOR...............................1
96 089140300068 ROLL PIN (D6 X 16 mm) .....1
97 089140300069 HEAD STOCK .....................1
98 089140200087 * SCREW (M4.2 X 13 mm
COUNTERSUNK HD.).........2
99 089140300070 GEAR SHAFT......................1
100 089140200074 SHAFT SEAT .......................1
101 089140200075 RETAINING RING (16).........1
102 089140200076 DEPTH STOP RING ............1
103 089140200084 ROD ....................................3
104 089140200086 KNOB DEPTH SCREW .......1
105 089140200085 HUB ....................................1
106 089140300071 * ROLL PIN (D2.5 X 12 mm) ..1
107 089140200088 BULB SOCKET W/NUT ......1
108 089140200089 BULB SOCKET-BRACKET..1
109 089140300083 * SCREW
(M4 X 12 mm PAN HD.).......2
110 089140300072 * SCREW
(M8 X 16 mm HEX SOC.) ....1
111 089140300073 WASHER (M8).....................1
112 089140300074 SPRING...............................1
113 089140200032 LASER LIGHT .....................2
114 089140200030 * ROLL PIN (D2.5 X 16 mm) ..1
115 TDP08001 EXT. TOOTH LOCK WASHER
(M5) .....................................2
116 089140300076 LED ASSEMBLY..................1
117 089140300077 BAFFLE...............................1
118 13202021 SPECIAL SET SCREW........1
119 TDP03002 * HEX SCREW (M8 X 8 mm)..1
120 089140300901 SCALE LABEL
(FOR BRACKET) .................1
121 089140300078 * SCREW
(M5 X 8 mm PAN HD.).........2
122 13406002A TABLE INDICATOR ..............1
123 089140200903 DEPTH (STROKE) INDICATOR .1
124 089140200905 LASER WARNING LABEL-1.. 1
125 089140300903 WARNING LABEL ...............1
126 089140300904 DATA LABEL .......................1
127 089140300905 SPEED ADJUST LABEL......1
128 089140200908 LOGO LABEL......................1
129 089140200909 LAMP WATT LABEL ...........1
130 089140300907 DEPTH SCALE LABEL........1
131 089140200911 LASER WARING LABEL-2..1
132 984406003 SWITCH KEY ......................1
133 089140200092 VISE (2.5 in.)........................1
134 089140200102 WASHER.............................3
135 089140200912 LASER LABEL.....................1
136 089140300081 * HEX NUT (M10 mm)............1
137 089140300082 CAPACITOR
(MOTOR) DP121L ...............1
138 089140300084 CABLE CLAMP ...................1
139 089140300085 INSULATING TAPE..............1
140 089140300086 WASHER.............................1
141 089140300087 MOTOR CUSHION..............1
983000642 OPERATOR’S MANUAL
06-06-08
(REV:06)
KEY PART
NO. NUMBER DESCRIPTION QTY.
KEY PART
NO. NUMBER DESCRIPTION QTY.

RYOBI 12 in. DRILL PRESS – MODEL NUMBER DP121L
5
M
~
WHITE WHITE
RED
RED
LASER
LASER
WHITE
WHITE
LED
PCB
3V
BLACK
BLACK
BLACK (SMOOTH)
TO CENTER
BLACK (RIDGE)TO EDGE
GREEN
GREEN
WIRING DIAGRAM
