RYOBI 3/8 in. DRILL
DOUBLE INSULATED
MODEL NO. D41
REPAIR SHEET

RYOBI 3/8 in. DRILL – MODEL NUMBER D41
2
1
1
2
3
4
5
5
67
89
10
11
12 1314 25
15
16
17
18
17
19
20
21
22
23
24
26
27

* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
RYOBI 3/8 in. DRILL – MODEL NUMBER D41
3
1 200136005 HOUSING ASSEMBLY
1 200136005 HOUSING ASSEMBLY
........................................
1
2 3000907 LEVEL
2 3000907 LEVEL
.................................................................
1
3 380787003 FORWARD/REVERSE SELECTOR
3 380787003 FORWARD/REVERSE SELECTOR
.....................
1
4 760197012 SWITCH
4 760197012 SWITCH
..............................................................
1
5 290069092 BRUSH ASSEMBLY
5 290069092 BRUSH ASSEMBLY
............................................
1
6 681057001 * BALL BEARING (608LLU)
6 681057001 * BALL BEARING (608LLU)
...................................
1
7 691182001 REAR BEARING BLOCK
7 691182001 REAR BEARING BLOCK
.....................................
1
8
8
6861601 THRUST WASHER
..............................................
1
9 6861701 * BALL (Ø1/8 in.)
9 6861701 * BALL (Ø1/8 in.)
....................................................
1
10
300003091 OUTPUT SHAFT ASSEMBLY
.............................
1
11
6967201 FRONT BEARING BLOCK
..................................
1
12
6861402 SLEEVE BEARING
..............................................
1
13
9030306 FELT SEAL
..........................................................
1
14
6844703 * WASHER (OD16.0 X ID9.6 X 1.2 mm)
.................
1
15
300723002 CLUSTER GEAR ASSEMBLY
.............................
1
16
6953701 PIN
......................................................................
1
17
6620606 * SCREW (M3.5 X 16 mm PAN HD.)
.....................
13
18
3048001 REAR LEVEL ASSEMBLY
...................................
1
19
200216019 ARMATURE ASSEMBLY
(INC. KEY NOS. 6 AND 24)
.................................
1
20
7320108 POWER CORD
....................................................
1
21
5629001
BEND RELIEF
.......................................................
1
22
6933701 CORD CLAMP
....................................................
1
23
740889001 FIELD
..................................................................
1
24
681056001 * BALL BEARING (608ZZ)
.....................................
1
25
690032011 CHUCK
...............................................................
1
26
950051044 LOGO LABEL
......................................................
1
27
940055113 DATA LABEL
.......................................................
1
28
300636124 CARRYING CASE (NOT SHOWN)
......................
1
983000809 OPERATOR’S MANUAL (960223655)
09-13-06
(REV:02)
KEY PART
KEY PART
NO. NUMBER DESCRIPTION QTY
NO. NUMBER DESCRIPTION QTY
PARTS LIST
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
DRILL
or when ordering repair parts.
(INC. KEY NOS. 6 AND 24)
KEY PART
KEY PART
NO. NUMBER DESCRIPTION QTY
NO. NUMBER DESCRIPTION QTY

RYOBI 3/8 in. DRILL – MODEL NUMBER D41
4
WIRING DIAGRAM
RED LEAD
BLACK LEAD
MOTOR
SWITCH
BRUSH ASSEMBLY
BRUSH
ASSEMBLY
YELLOW LEAD
WHITE LEAD
WHITE LEAD
BLACK LEAD
POWER CORD
