RYOBI
1/2 in. TWO SPEED
18 VOLT HAMMER DRILL
MODEL NO. P211
REPAIR SHEET

RYOBI 1/2 in. (13 mm) HAMMER DRILL– MODEL NUMBER P211
2
10
6
3
1
4
7
11 12
5
2
17 18
13
16
19
23
15
14
20
21
22
24
18
29
30
8
9
25
26
27
28
19
31
32
33
34
35
36
37
38
39 40
41

RYOBI 1/2 in. (13 mm) HAMMER DRILL– MODEL NUMBER P211
3
KEY PART
NO. NUMBER DESCRIPTION QTY.
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your Hammer Drill or when ordering repair parts.
1 6613402 * SCREW (SPECIAL)................................................................. 1
2 690032024 1/2 in. CHUCK........................................................................ 1
3 660204007 * SCREW (M3 X 18 mm) ........................................................... 4
4 631494001 MOUNTING PLATE (OD42.8 X ID18.0 X 3.0 mm) .................. 1
5 6392201 SPRING PLATE ..................................................................... 2
6 540346014 SPRING HOLDER .................................................................. 1
7 301319001 CLUTCH CAP ASSEMBLY..................................................... 1
8 680338028 PIN.......................................................................................... 6
9 631817001 BYPASS SPRING PLATE (0.2 mm)......................................... 2
10 550014009 SLEEVE .................................................................................. 1
11 681015001 TORQUE CONTROL SPRING ................................................ 1
12 672044001 BYPASS WASHER (0.1 mm) .................................................. 1
672044002 BYPASS WASHER (0.2 mm) .................................................. 1
672044003 BYPASS WASHER (0.3 mm) .................................................. 1
672141001 WASHER (OD53.5 X ID44.0 X 0.2 mm) .................................. 1
13 672077001 CLUTCH WASHER................................................................. 1
14 343547001 FOWARD/REVERSE SELECTOR ........................................... 1
15 670283003 BIT HOLDER .......................................................................... 1
16 5621901 CONTACT PLATE STOPPER.................................................. 2
17 300823002 MAGNET ................................................................................ 1
18 560444002 FOAM RUBBER ..................................................................... 2
19 200105024 HOUSING ASSEMBLY ........................................................... 1
20 940057069 DATA LABEL........................................................................... 1
21 940054115 LOGO LABEL ......................................................................... 1
22 670800032 SINGLE BIT (PH#2 25 mm) .................................................... 1
23 270023160 SWITCH ASSEMBLY.............................................................. 1
24 200293044 MOTOR & GEAR TRAIN ASSEMBLY (INC. KEY NOS. 34-37).. 1
25 343637001 BYPASS RING........................................................................ 1
26 6620614 * SCREW (M3.5 X 14 mm PAN HD.) ......................................... 7
27 660004007 * SCREW (M3 X 12 mm PAN HD.) ............................................ 2
28 670804025 SINGLE BIT ............................................................................ 1
29 343552004 2-SPEED CHANGE KNOB ..................................................... 1
30 6721901 BALL (Ø5.0 mm)..................................................................... 6
31 200292003 PLUG IN LANYARD................................................................ 1
32 200073014 HANDLE ASSEMBLY (INC. KEY NOS. 38-41) ....................... 1
33 681013001 HEX NUT (M12) ...................................................................... 1
34 230033071 MOTOR ASSEMBLY............................................................... 1
35 6703001 SPRING WASHER (OD7.2 X ID4.1 X 1 mm)........................... 2
36 6621205 * SCREW (M4 X 8 mm PAN HD.) .............................................. 2
37 220018020 GEAR BOX ASSEMBLY.......................................................... 1
38 6341203 HEXAGON GUIDE ROD ......................................................... 1
39 513665001 GUIDE ROD SUPPORT.......................................................... 1
40 641028001 PRESS PLATE ........................................................................ 1
41 300067447 HANDLE ASSEMBLY ............................................................. 1
983000749 OPERATOR’S MANUAL (960223672)
03-17-08
(REV:02)

RYOBI 1/2 in. (13 mm) HAMMER DRILL– MODEL NUMBER P211
4
SWITCH
MOTOR
BLACK LEAD
RED LEAD
YELLOW
LEAD
BLUE LEAD
BLACK LEAD
WIRING DIAGRAM
RED LEAD
BLACK
LEAD
CONTACT
PLATE HOLDER
