RYOBI
9.6 VOLT CORDLESS DRILL – MODEL NO. HP496
&
12 VOLT CORDLESS DRILL – MODEL NO. HP412
REPAIR SHEET

RYOBI 9.6 &12 VOLT CORDLESS DRILL – MODEL NO. HP496 AND HP412
14
18
17
12
13
26
24
14
19
21
22 23
20
4
3
2
1
11
10
9
8
7
6
6
5
16
15
25
2

RYOBI 9.6 &12 VOLT CORDLESS DRILL – MODEL NO. HP496 AND HP412
16 210014028 MOTOR W/GEAR TRAIN ASSEMBLY (HP412)
210014027 MOTOR W/GEAR TRAIN ASSEMBLY (HP496)...........1
17 6722001 BALL (4 mm) ................................................ 16
18 6620606 * SCREW (M3.5 X 16 mm)................................ 8
19 570271001 BIT HOLDER.................................................. 1
20 671479001 MAGNET TRAY .............................................. 1
21 130269012 BATTERY PACK (HP412)
130269002 BATTERY PACK (HP496) ............................... 1
22 140295003 CHARGER (HP412)
140295002 CHARGER (HP496)........................................ 1
23 6782045 BIT (HP412)
6782044 BIT (HP496).................................................... 1
24 342567001 FORWARD/REVERSE SELECTOR ................ 1
25 940203042 LOGO LABEL................................................. 1
26 940252088 DATA LABEL .................................................. 1
27 300912123 CARRYING CASE HP412 (NOT SHOWN)
300912124 CARRYING CASE HP496 (NOT SHOWN) .............1
983000501 OPERATOR'S MANUAL
12-05-07
(REV:03)
1 6612001 * SCREW (M5 X .8 X 26 mm) ........................... 1
2 690031201 CHUCK .......................................................... 1
3 6620311 * SCREW (M3 X 20 mm)................................... 2
4 6387101 MOUNTING PLATE ........................................ 1
5 5553201 SPRING HOLDER .......................................... 1
6 630922004 SPRING PLATE (HP412)
6399201 SPRING PLATE (HP496) ................................ 2
7 512569001 CLUTCH CAP ................................................ 1
8 5501402 SLEEVE.......................................................... 1
9 6894301 SPRING.......................................................... 1
10 6901103 WASHER........................................................ 1
11 6901102 WASHER........................................................ 1
12 6710501 CLUTCH WASHER ........................................ 1
13 3000907 TOP LEVEL ASSEMBLY .............................. 1
14 200202238 HOUSING ASSEMBLY (HP412)
200202237 HOUSING ASSEMBLY (HP496)..................... 1
15 270018068 SWITCH ASSEMBLY ..................................... 1
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
RYOBI CORDLESS DRILL or when ordering repair parts.
PARTS LIST
KEY PART
NO. NuMBER DESCRIPTION qTY.
KEY PART
NO. NuMBER DESCRIPTION qTY.
** STANDARD HARDWARE ITEM – MAY BE PuRCHASED LOCALLY
3

RYOBI 9.6 &12 VOLT CORDLESS DRILL – MODEL NO. HP496 AND HP412
WIRING DIAGRAM
SWITCH
RED LEAD
BLACK LEAD
4
