Ryobi AG402 Quick setup guide

RYOBI
ANGLE GRINDER
MODEL NO. AG402
REPAIR SHEET

2
RYOBI ANGLE GRINDER – MODEL NUMBER AG402
1
2
3
4
5
6
7
8
1 039029001031 NUT (M5) ....................................................1
2 039029001002 SCREW (M5 X 16 mm) ..............................1
3 039029001042 DISC FLANGE ............................................1
4 039028001001 CLAMP NUT (5/8-11) .................................1
5 039028001051 GRINDING WHEEL ....................................1
6 039029001001 WHEEL GUARD .........................................1
7 039028001052 WRENCH
...................................................1
8 039028001055 AUXILLARY HANDLE .................................1
983000997 OPERATOR’S MANUAL(039029001037)
7-28-06 (REV:00)
PARTS LIST
KEY PART
NO. NUMBER DESCRIPTION QTY
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
The model number will be found on a plate attached to the motor housing. Always mention the model number in all correspondence regarding your
ANGLE GRINDER or when ordering repair parts.
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
