RYOBI
ANGLE GRINDER
MODEL NO. AG453
REPAIR SHEET

2
RYOBI ANGLE GRINDER – MODEL NUMBER AG453
6
4
3
1
78
9
13
12
39
40
41
42
43
44
45
8
47
48
49
10
50
52
47
34
15
16
37 38
17
18 19
21
22
23
36
25
30
29
32 33
30
31
24
27
26
53
54
35
28
11
14
20
10
5
2
46
51

3
RYOBI ANGLE GRINDER – MODEL NUMBER AG453
1 039028001001 Clamp Nut (5/8-11).....................................1
2 039028001051 Grinding Wheel...........................................1
3 039029001042 Disc Flange (5/8-11) ...................................1
4 039028001003 Wheel Guard...............................................1
5 039028001004 Screw (M5 x 12 mm) ..................................1
6 039028001024 O-Ring........................................................1
7 039028001022 Vent Guide .................................................1
8 039028001013 Screw (M4 x 10 mm) ..................................5
9 039028001025 Pinion..........................................................1
10 039028001009 Key .............................................................2
11 039028001026 Ball Bearing (608zz)....................................1
12 039028001028 Ball Bearing (607zz)....................................1
13 039028001074 Armature Assembly ....................................1
14 039028001029 Bearing Sleeve ...........................................1
15 039028001030 Fan Baffle ...................................................1
16 039028001031 Screw (M4.2 x 65 mm) ...............................2
17 039028001075 Field Assembly ...........................................1
18 039028001034 Motor Housing............................................1
19 039028003002 Data Label ..................................................1
20 039028001056 Logo Label..................................................1
21 039028001035 Brush Holder ................................................2
22 039028001036 Brush Assembly .........................................2
23 039028001037 Brush Cap ..................................................2
24 039028001038 Lead Clamp ................................................1
25 039028001039 Angle Adjustment Button ...........................1
26 039028001042 Screw (M3 x 10 mm) ..................................2
27 039028001041 Wavy Washer..............................................2
28 039028001040 Spring .........................................................1
29 039028001044 Right Handle ..............................................1
30 039028001043 Screw (M4.2 x 16 mm) ...............................7
31 039028001045 Switch.........................................................1
32 039028001047 Terminal Block ............................................1
33 039028001048 Cord Clamp ................................................1
34 039028001005 Screw (M4 x 14 mm) ..................................4
35 039028001049 Bend Relief .................................................1
36 039028003001 Power Cord ................................................1
37 039028001054 Abrasive Wheel...........................................1
38 039028001053 Wire Brush..................................................1
39 039028001055 Auxillary Handle..........................................1
40 039028001052 Wrench .......................................................1
41 039028001073 Gear Case Assembly..................................1
42 039028001023 Screw (M4.2 x 25 mm) ...............................4
43 039028001016 Retaining Ring ............................................1
44 039028001015 Wavy Washer..............................................1
45 039028001014 Gear............................................................1
46 039028001072 Gear Case Cover Assembly .......................1
47 039028001006 Spring Washer ............................................7
48 039028001012 Bearing Plate ..............................................1
49 039028001011 Ball Bearing (62002rs) ................................1
50 039028001008 Output Shaft...............................................1
51 039028001010 Gear Case Cover........................................1
52 039028001007 Washer .......................................................4
53 039028001046 Left Handle .................................................1
54 039028002021 Cord Label..................................................1
990000435 Operator’s Manual (039028003005)
4-19-13
(Rev:01)
PARTS LIST
The model number will be found on a label attached to the motor housing. Always mention the model number in all correspondence regarding your
ANGLE GRINDER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION QTY
WARNING: Improper repair of a double insulated tool can result in damage to the double insulation system possibly causing electrical shock or
electrocution. Any repairs requiring disassembly of your tool requires safety testing and should only be performed by a Ryobi Authorized Service
Center. For the service center nearest you call 1-800-525-2579.
KEY PART
NO. NUMBER DESCRIPTION QTY

4
RYOBI ANGLE GRINDER – MODEL NUMBER AG453
WIRING DIAGRAM
CONNECTOR
