RYOBI
18 VOLT LAWN MOWER
ITEM NO. P1102
MANUFACTURING NO. 107179001
REPAIR SHEET

2
RYOBI P1102 18 VOLT LAWN MOWER
FIGURE A
50
47
40
25
41
25
53
22
25
54
38
15
39
4
4
34
28
64
36
36
35
37
26
27
27
66
66
33
33
1
7
2
10
112
58
57
75
56
107
107
19
1
42
8
30
1
1611
108
107
107
25
41
53
21 12
8
31
20
44
52
55
107
51
14
106
45
48
63 13
80
105
29
24
43
23
18
69
61
60
62
3
6
5
49
32
17
110
59
59 16
28
64
46
5
9
109
65
65
111
113

3
RYOBI P1102 18 VOLT LAWN MOWER
FIGURE A
73
73
82
82
104
78
78
94 93
91
90 89 88
87
86
84
92
77
81
82
78
70
70
70
70
78
71
81
81
81
67
68
25
78
78 76
76
78
74
103 85
82
79
79
25
72
28
41
28
83
107
107
107
65
64
84
66
83 65
64
84
84
84
66
79
95
96
97
98
99
100
102
101

4
RYOBI P1102 18 VOLT LAWN MOWER
FIGURE A PARTS LIST
The model number will be found on a label attached to the deck. Always mention the model number in all correspondence regarding your LAWN
MOWER or when ordering replacement parts.
Key Part
No. Number Description Qty
Key Part
No. Number Description Qty
1 200708001 Trigger Handle Assembly ................................................1
2 311404002 Upper Handle Assembly .................................................1
3 639193005 Height Adjustment Plate .................................................1
4 519801001 Cord Clamp.....................................................................2
5 678509001 Lock Nut (M5) .................................................................4
6 570839002 Dust Gasket ....................................................................1
7 661189002 Screw (M4 x 10 mm, T20 Torx Pan Hd.) ......................... 1
8 200686001 Trigger Housing Assembly .............................................. 1
9 790009004 Wire Connector (Closed End) .........................................2
10 311280002 Start Key .........................................................................1
11 694991001 Compression Spring .......................................................1
12 760557001 Switch .............................................................................1
13 621628001 Battery Door Axle............................................................ 1
14 291562001 Lead Wire w/Terminal Block ...........................................1
15 940705314 Bag Door Label...............................................................1
16 694136002 Button Return Spring ...................................................... 2
17 200688001 Start Button Assembly....................................................1
18 940851112 Lithium Label (Left) .........................................................1
19 660208104 Screw (M4 x 30 mm, T15 Torx Pan Hd.) ......................... 6
20 940851162 Fuel Gauge Label............................................................1
21 291564004 Starter Cable (Long)........................................................1
22 528681002 Slide Door .......................................................................1
23 940657190 Icon Warning Label ......................................................... 1
24 940657188 Warning Icon Label (Right).............................................. 1
25 660608002 Screw (M4 x 16 mm, T20 Torx Pan Hd.) ....................... 15
26 679987007 Lower Handle..................................................................1
27 526905001 Pressure Block................................................................ 2
28 350878001 Handle Lock Assembly ................................................... 4
29 940657188 Warning Icon Label (Left) ................................................ 1
30 940851109 Start Key Label (Eng) ......................................................1
31 940851110 Start Key Label (FR/SP) .................................................. 1
32 526906001 Knob ...............................................................................2
33 526907001 Block Washer.................................................................. 2
34 526857003 Rear Discharge Door.......................................................1
35 639200001 Rear Door Axle................................................................1
36 678880001 Retaining Ring (E)............................................................2
37 679076001 Torsion Spring (Rear Door) .............................................1
38 639183003 Bag Frame ......................................................................1
39 970699001 Bag..................................................................................1
40 526854009 Deck................................................................................1
41 513211001 Cord Clip.........................................................................3
42 679034001 Spring .............................................................................1
43 940851113 Lithium Label (Right) ....................................................... 1
44 662028001 Screw (M4 x 16 mm).......................................................4
45 940705314 Starting Instructions Label.............................................. 1
46 660203001 Screw (M3 x 8 mm, Pan Hd.)..........................................3
47 680196006 Lock Nut (M6) .................................................................3
48 526874001 Handle............................................................................. 1
49 563768001 Rubber Block ..................................................................4
50 742166003 Motor ..............................................................................1
51 280347002 Start Circuit Board ..........................................................1
52 660203068 Screw (M4 x 16 mm, T20 Torx Socket Pan Hd.)............. 4
53 200685001 Key Holder Assembly .....................................................1
54 636440001 Key Receptacle...............................................................8
55 526873002 Deck Cover .....................................................................1
56 526979001 Press Cover (Battery Connect) .......................................2
57 300001067 Plate (Battery Connect)...................................................2
58 526978001 Base (Battery Connect)...................................................2
59 200707001 AC Plug Housing Assembly............................................1
60 526872001 Battery Cover.................................................................. 1
61 694051001 Torsion Spring (Battery Door) .........................................1
62 660713001 Screw (M5 x 16 mm, Pan Hd.)........................................2

5
RYOBI P1102 18 VOLT LAWN MOWER
The model number will be found on a label attached to the deck. Always mention the model number in all correspondence regarding your LAWN
MOWER or when ordering replacement parts.
FIGURE A PARTS LIST
Key Part
No. Number Description Qty
63 679073001 Pressure Spring ..............................................................1
64 679988001 Spring Pin .......................................................................4
65 526904001 Latch ...............................................................................4
66 661865002 Quick Lock Press............................................................4
67 526977001 Grass Protector (Right) ................................................... 1
68 526976001 Grass Protector (Left)...................................................... 1
69 941851111 Height Adjust Label ........................................................1
70 639113003 Washer (OD20 x ID13 x 1t) ............................................. 4
71 526980001 Mulching Plug .................................................................1
72 525668001 Rear Cover......................................................................1
73 311253001 Front Wheel (6 in., Inc. Key No. 81)................................2
74 528595001 Rear Skirt ........................................................................1
75 940705269 Ryobi Logo Label (Front).................................................1
76 311255001 Rear Wheel w/Bearing & Cap (8 in., Inc. Key No. 81).... 2
77 636378001 Rear Wheel Axle.............................................................. 1
 78 678279004 CotterPinφ(2.5) ................................................................8
79 639013001 Washer (OD18 x ID8.4 x 1t) ............................................ 3
80 941641001 Cut Finger Label .............................................................1
81 526876001 Wheel Cover ................................................................... 4
82 639116001 Axle Pressure Plate.........................................................6
83 526922001 Base (Lock Handle).........................................................2
84 661189003 Screw (M4 x 18 mm, Torx Pan Hd.) .............................16
85 639186001 Rear Lift Rod................................................................... 1
86 526924001 Height Adjustment Handle..............................................1
87 664021001 Screw (M3 x 9 mm, Flat Hd.) .......................................... 2
88 639204001 Height Adjustment Lever ................................................ 1
89 679992001 Torsion Spring (Height Adjustment) ................................1
90 639203001 Height Adjustment Bracket.............................................1
91 639122001 Axle (Height Adjustment) ................................................ 1
92 639125001 Pressure Plate (Height Adjustment) ................................ 2
93 694052001 Retention Spring .............................................................1
94 639185001 Front Lift Rod..................................................................1
95 679075001 Blade Nut (M10) ..............................................................1
96 639118001 Blade Retainer ................................................................1
97 526920001 Spacer.............................................................................1
98 639180003 Blade...............................................................................1
99 526921001 Blade Holder ...................................................................1
100 639120002 Motor Shaft Bushing....................................................... 1
101 660722002 Bolt (M6 x 16 mm, Hex Hd.) ...........................................3
102 638557001 Washer (OD15 x ID6 x 1t) ...............................................3
103 526975001 Bumper ........................................................................... 1
104 636379001 Front Wheel Axle.............................................................1
105 941588111 Data Label.......................................................................1
106 940705179 Ryobi Logo Label (Handle).............................................. 1
107 660563002 Screw (M4 x 20 mm) ..................................................... 23
108 760034012 Micro Switch ...................................................................1
109 291441004 Plug Wire......................................................................... 1
110 661863001 Screw (M5 x 30 mm) ....................................................... 2
111 790021001 Wire Connector (Closed End) ......................................... 1
112 291420007 Lead Wire (Red) ..............................................................1
113 291420008 Lead Wire (Brown)...........................................................1
NOT SHOWN:
991000690 Operator’s Manual
1-5-16
(Rev:02)
Key Part
No. Number Description Qty

6
RYOBI P1102 18 VOLT LAWN MOWER
CONNECTOR
CONNECTOR
SWITCH
CONTACT PLATE
CONTACT PLATE
LED BOARD
TERMINAL BLOCK
TERMINAL BLOCK
PLUG
KEY HOLDER
CIRCUIT BOARD
ASSEMBLY
CIRCUIT BOARD
ASSEMBLY
MOTOR
WIRING DIAGRAM
