Ryobi P410 Quick setup guide

1
RYOBI
18 VOLT SANDER
MODEL NO. P410
REPAIR SHEET

2
RYOBI 18 VOLT SANDER – MODEL NUMBER P410
1
2
3
4
4
1
6
6
7
8
9
10
11
12
13
14 17
16
18
15
5

3
* Standard Hardware Item – May Be Purchased Locally
PARTS LIST
RYOBI 18 VOLT SANDER – MODEL NUMBER P410
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 019284001011 Housing Assembly ..........................................................................................1
2 019284001013 Logo Label ......................................................................................................1
3 019284001014 Switch Assembly .............................................................................................1
4 019284001010 Screw (M4 X 16 mm) .......................................................................................6
5 019284001012 Data Label .......................................................................................................1
6 019284001036 Brush Assembly ..............................................................................................2
7 019284001009 Motor Assembly ..............................................................................................1
8 019284001008 Brake ...............................................................................................................1
9 019284001007 Counterbalance ...............................................................................................1
10 019284001035 Bearing Cap with Bearing ...............................................................................1
11 019284001004 Washer ............................................................................................................1
12 019284001034 * Lock Washer ...................................................................................................1
13 019284001003 * Screw (M5 X 8 mm) .........................................................................................1
14 019284001002 Pad ..................................................................................................................1
15 019284001001 * Screw (M5 X 6 mm) .........................................................................................4
16 019284001017 Sanding Disc #240 ..........................................................................................1
17 019284001016 Sanding Disc #120 ..........................................................................................1
18 019284001015 Sanding Disc #60 ............................................................................................1
987000005 Operator’s Manual (019284001022)
7-31-06 (REV:01)
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your SANDER or when ordering repair parts.

4
RYOBI 18 VOLT SANDER – MODEL NUMBER P410
ON (I) / OFF (O) SWITCH
CONTACT PLATE
RED
CONTACT LEAD
RED
MOTOR LEAD
BLACK
MOTOR LEAD
MOTOR
WIRING DIAGRAM
