Ryobi ERO750VK Operation manual

THANK YOU FOR BUYING A RYOBI RANDOM ORBITAL SANDER
Your new random orbital sander has been engineered and manufactured to Ryobi's high standard
for dependability, ease of operation and operator safety. Properly cared for, it will give you years
of rugged, trouble-free performance.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
OWNER’S OPERATING MANUAL
RANDOM ORBITAL SANDER
MODEL ERO750VK
CAUTION: Carefully read through this entire owner's manual before using your
random orbital sander.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions.
If you use your random orbital sander properly and only for what it is intended, you will enjoy years
of safe, reliable service.
Thank You again for buying Ryobi tools.
DOUBLEDOUBLE
DOUBLEDOUBLE
DOUBLE
INSULATEDINSULATED
INSULATEDINSULATED
INSULATED
SPECIFICATIONS:
Input .......................................... 750 watt
No Load Speed ......................... 4000 - 7000 min-1
Pad Size .................................... 150 mm
Orbital Diameter ........................ 3.5 mm
Weight ....................................... 3 kg

RULES FOR SAFE OPERATION
Page 1
The purpose of safety rules is to attract your attention to
possible dangers. The safety symbols and the explanations
with them, require your careful attention and understanding.
The safety warnings do not by themselves eliminate any
danger. The instruction or warnings they give are not
substitutes for proper accident prevention measures.
The operation of any tool can
result in foreign objects being
thrown into your eyes, which can
result in severe eye damage.
Before beginning power tool
operation, always wear safety
1. KNOW YOUR POWER TOOL. Read owners manual
carefully. Learn its applications and limitations as well as
the specific potential hazards related to this tool.
2. GUARD AGAINST ELECTRICAL SHOCK BY
PREVENTING BODY CONTACT WITH GROUNDED
SURFACES. For example, pipes, radiators, ranges,
refrigerator enclosures.
3. KEEP WORK AREA CLEAN. Cluttered areas and
benches invite accidents.
4. AVOID DANGEROUS ENVIRONMENT. Don't use power
tools in damp or wet locations or expose to rain. Keep
work area well lit.
5. KEEP CHILDREN AND VISITORS AWAY. Visitors should
wear safety glasses and be kept a safe distance from
work area. Do not let visitors contact tool or extension
cord.
6. STORE IDLE TOOLS. When not in use, tools should be
stored in a dry and high or locked-up place, out of reach
of children.
7. DON'T FORCE TOOL. It will do the job better and safer
at the rate at which it was designed.
8. USE RIGHT TOOL. Don't force small tool or attachment
to do the job of a heavy duty tool. Don't use tool for
purpose not intended.
SAFETY ALERT SYMBOL. Indicates caution or
warning. May be used in conjunction with other
symbols or pictures.
WARNING: Failure to obey a safety warning can
result in serious injury to yourself or to others.
Always follow the safety precautions to reduce
the risk of fire, electric shock and personal injury.
WARNING:
Do not attempt to operate this tool
until you have read thoroughly and understood
completely, safety rules, etc. contained in this
manual. Failure to comply can result in accidents
involving fire, electric shock or serious personal
injury. Save owners manual and review frequently
for continuing safe operation and instructing
others who may use this tool.
goggles or safety glasses with side shields and a full
face shield when needed. We recommend Wide Vision
Safety Mask for use over eyeglasses or standard safety
glasses with side shields.
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
Due to continued product
refinement policy, product features
and specifications can and will
change without notice. Check
current features and specifications
with your retailer.
9. DRESS PROPERLY. Do not wear loose clothing or
jewellery. They can be caught in moving parts. Rubber
gloves and non-skid footwear are recommended when
working outdoors. Also wear protective hair covering to
contain long hair.
10.ALWAYS WEAR SAFETY GLASSES. Everyday
eyeglasses have only impact resistant lenses, they are
not safety glasses.
11. PROTECT YOUR LUNGS. Wear a dust mask if operation
is dusty.
12.PROTECT YOUR HEARING. Wear hearing protection
during extended periods of operation.
13.DON'T OVERREACH. Keep proper footing and balance
at all times. Do not use tool on a ladder or unstable
support. Secure tools when working at elevated levels.
14.MAINTAIN TOOLS WITH CARE. Keep tools sharp and
clean for better and safer performance. Follow instructions
for lubricating and changing accessories.
15.REMOVE ADJUSTING KEYS AND WRENCHES. Form
a habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it on.
16.NEVER USE IN AN EXPLOSIVE ATMOSPHERE. Normal
sparking of the motor could ignite fumes.
17.KEEP HANDLES DRY, CLEAN AND FREE FROM OIL
AND GREASE. Always use a clean cloth when cleaning.
Never use brake fluids, gasoline, petroleum based
products, or any strong solvents to clean your tool.
18.STAY ALERT AND EXERCISE CONTROL. Watch what
you are doing and use common sense. Do not operate
tool when you are tired. Do not rush operation of tool.
19.CHECK DAMAGED PARTS. Before further use of the
tool, a guard or any other part that is damaged should be
carefully checked to determine that it will operate properly
and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its
operation. A guard or any other part that is damaged should
be properly repaired or replaced by an authorised service
centre.
20.DO NOT USE TOOL IF SWITCH DOES NOT TURN IT
ON AND OFF. Have defective switches replaced by
authorised service centre.
21.DO NOT OPERATE THIS TOOL WHILE UNDER THE
INFLUENCE OF DRUGS, ALCOHOL OR ANY
MEDICATION.
22.THE APPLIANCE IS NOT INTENDED FOR USE BY
YOUNG OR INFIRM PERSONS WITHOUT
SUPERVISION. YOUNG CHILDREN SHOULD BE
SUPERVISED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.

1. Loop Handle
2. Lock-On Button
3. Rear Handle
4. Variable Speed Dial
5. Dust Bag
6. Hook and Loop Pad
Page 2
FEATURES
5
6
1
2
3
4

Never become complacent while using your sander, as
carelessness can result in serious personal injury.
Page 3
OPERATION
Your sander should never be connected to power supply
when you are assembling parts, making adjustments,
assembling or replacing sandpaper, cleaning or when
not in use. Disconnecting sander will prevent accidental
starting that could cause serious personal injury.
FEATURES
Your sander is suitable for sanding with coarse, medium, and
fine grit sandpaper. It will produce a fine scratch free finish
when used to sand with the grain on wood surfaces.
Before attemptingtouseyoursander,familiarizeyourself
with all operating features and safety requirements.
SWITCH
To turn the tool on, squeeze the trigger switch. To turn the
tool off, release the trigger switch. The trigger is spring
loaded and will return to the off position automatically.
LOCK ON BUTTON
The sander is equipped with a lock on button which is
designed for continuous sanding for extended periods. This
button locks the trigger switch on so you can focus on your
work. To activate the lock on feature:
a. Squeeze the trigger switch first.
b. Depress the lock on button then.
c. Finally rel
ease the trigger switch.
To release the lock or to turn off the sander, simply squeeze
and release the trigger switch.
VARIABLE SPEED DIAL
A variable speed dial is incorporated into the trigger switch.
You can select different speed by adjusting this dial. To
have the lowest speed application, turn the dial to
A . To
have full speed application, turn the dial to F.
For ease of operation, your sander has both loop handle
and rear handle for two handed operation, which is
necessary to maintain proper control. During operation,
always use both hands.
Hold your sander in front and away from you, keeping it
clear of the work piece. Start your sander by squeezing
the trigger switch and letting the motor build to its maximum
speed. Gradually lower your sander on the work with a
slight forward movement. Move it slowly using forward and
backward strokes.
Holes in sandpaper must line up with holes in backing
pad in order for the dust collection feature of your sander
to function properly.
Note: DO NOT use sander without sandpaper. Doing so
will damage the cushion.
WARNING:
WARNING:
APPLICATIONS
You may use the random orbital sander for the purposes
listed below:
Sanding on wood surfaces.
Removing rust from and sanding steel surfaces.
Sanding plastics.
INSTALLING SANDPAPER
Inspect sandpaper before installing. DO NOT use broken
or defective sandpaper.
1. Unplug your sander.
PREPARING FOR OPERATION
Failure to unplug your sander could result in accidental
starting causing possible serious personal injury.
WARNING:
Be careful not to let your hand completely cover air vents.
CAUTION:
SANDING
(Fig. 1)
Unsecured work could be thrown towards the operator
causing injury.
WARNING:
Fig. 1

Unplug your sander.
Remove the dust bag assembly from the sander.
Insert the dust bag to the dust frame.
Replace the dust bag assembly on the sander.
OPERATION
DO NOT FORCE. The weight of the unit supplies adequate
pressure, so let the sandpaper and sander do the work.
Applying additional pressure only slows the motor, rapidly
wears sandpaper and greatly reduces sander speed.
Excessive pressure will overload the motor causing possible
damage from motor overheating and can result in inferior
work. Any finish or resin on wood may soften from the
frictional heat. Do not allow sanding on one spot too long
as the sander’s rapid action may remove too much material,
making the surface uneven.
ORBITAL MOTION (Fig. 2)
Orbital motion is ideal for fast cutting action when removing
old finishes, smoothing rough wood, cutting stock down
to required dimensions, or for finishing surfaces to be
painted. The sandpaper moves in tiny circles at a very high
speed, allowing the sander to move easily.
Page 4
TO EMPTY THE DUST BAG ASSEMBLY (Fig. 4 & 5)
For more efficient operation, empty the dust bag when
it is no more than half full. This will permit the air to
flow through the bag better. Always empty and clean the
dust bag thoroughly upon completion of a sanding
operation and before placing the sander in storage.
TO EMPTY THE DUST BAG
USING THE DUST BAG ASSEMBLY
Thedust bag assemblyprovides a dustcollection system
for the sander. Sanding dust is drawn up through the
holes of the sanding disc and collected in the dust bag
during sanding.
Disassemble the dust bag from the dust bag assembly.
Shake out the dust.
Do not wear loose clothing or jewelry when operating
sander. They could get caught in moving parts causing
serious injury. Keep head away from sander and sanding
area. Hair could be drawn into sander causing serious
injury.
WARNING:
Collected sanding dust from sanding surface coatings
such as polyurethanes, linseed oil etc. can self-ignite in
your sander dust bag or elsewhere and cause fire. To
reducetherisk of fire alwaysemptyyourdust bag frequently
while sanding and never store or leave a sander without
totally emptying its dust bag. Also follow the
recommendations of the coatings manufacturers.
WARNING:
Fig. 2
Failure to unplug the tool could result in accidental starting
causing possible serious injury.
WARNING:
Failure to unplug your sander could result in accidental
starting causing possible serious personal injury.
WARNING:
TO ATTACH THE DUST BAG ASSEMBLY (Fig. 3)
Follow these directions to attach the dust bag assembly.
Unplug the sander.
Insert the dust bag into the dust extraction port as
illustrated.
Fig. 3
Fig. 4
Fig. 5

RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.
RYOBI TECHNOLOGIES AUSTRALIA PTY. LTD.
A.B.N. 98 002 277 509
SYDNEY: 359-361 Horsley Road, Milperra, N.S.W. 2214.
Contact during normal business hours.
Tel: [phone] - Fax: [phone] - www.ryobi.com.au
RYOBI NEW ZEALAND PTY. LTD.
AUCKLAND: 503 Mt Wellington Highway, Mt Wellington, N.Z.
Tel: [phone] - Free Call: 0800 279 624 - Fax: [phone] - www.ryobi.co.nz
Contact during normal business hours.
Subject to the guarantee condition below, this Ryobi tool
(hereinafter called “the product”) is guaranteed by Ryobi
(hereinafter called “the Company”) to be free from defects
in material or workmanship for a period of 24 months from
the date of original purchase covering both parts and
labour. Under the terms of this guarantee, the repair or
replacement of any part shall be the opinion of the
Company or its authorised agent. Should service become
necessary during the warranty period, the owner should
contact the Authorised Ryobi Retailer from whom the
Product was purchased, or the nearest Company Branch
Office. In order to obtain guarantee service, the owner
must present the sales docket and Guarantee Certificate
to confirm date of purchase. This product is sold by the
dealer or agent as principal and the dealer has no
authority from the Company to give any additional
guarantee on the Company’s behalf except as herein
contained or herein referred to.
Guarantee Conditions
This guarantee only applies provided that the Product
has been used in accordance with the manufacturer’s
recommendations under normal use and reasonable care
(in the opinion of the Company) and such guarantee
does not cover damage, malfunction or failure resulting
from misuse, neglect, abuse, or used for a purpose for
which it was not designed or is not suited and no repairs,
alterations or modifications have been attempted by
other than an Authorised Service Agent.This guarantee
will not apply if the tool is damaged by accident or if
repairs arise from normal wear and tear.
The Company accepts no additional liability pursuant to
this guarantee for the costs of travelling or transportation
of the Product or parts to and from the service dealer
or agent - such costs are not included in this guarantee.
Certain legislation, including the Trade Practices Act,
1974 (as amended) and other state and territorial laws
give rights to the buyer and impose liability on the seller
in certain circumstances. Nothing herein shall have the
effect of excluding, restricting or modifying any condition,
guarantee, right or liability imposed, to the extent only
that such exclusion, restriction or modification would
render any term herein void.
MELBOURNE: 960 Stud Road, Rowville,Vic. 3178
Tel : [phone]
BRISBANE: All enquiries Tel : [phone]
TOWNSVILLE: All enquiries Tel : [phone]
PERTH:
33-35 Sorbonne Cres., Canning Vale,W.A. 6155.
Tel : [phone]
ADELAIDE: All enquiries Tel : [phone]
HOBART: All enquiries Tel : [phone]
Purchased From
Address Of Dealer
Date Model No Serial No
For your record and to assist in establishing date of purchase (necessary for in-guarantee service)
please keep your purchase docket and this form completed with the following particulars.
Present: This Form With Your Purchase Docket When Guarantee Service Is Required.
