RYOBI 6 in.
18 VOLT BUFFER/POLISHER
MODEL NO. P430
REPAIR SHEET

RYOBI 6 in. 18 VOLT BUFFER/POLISHER – MODEL NUMBER P430
2
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your BUFFER/POLISHER or when ordering repair parts.
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
KEY PART
NO. NUMBER DESCRIPTION QTY
1 019011001003 PAD ASSEMBLY .......................................................................1
2 019011001002 SPRING WASHER (M5) ............................................................1
3 019011001001 * SCREW (M5 X 12 MM)..............................................................1
4019011001012 POLISHING BONNET ...............................................................1
5019011001011 TERRY CLOTH BONNET..........................................................1
6130255004 BATTERY PACK (P100) (NOT SHOWN) ...................................1
130224028 BATTERY PACK (P100) (NOT SHOWN) ...................................1
71423701 CHARGER (P110) (NOT SHOWN) ............................................1
140237021 CHARGER (P110) (NOT SHOWN) ............................................1
140237023 CHARGER (P110) (NOT SHOWN) ............................................1
983000967 OPERATOR’S MANUAL (019011001017)
04-28-08
(REV:01)
