RYOBI
TABLE SAW
MODEL NO. BTS12S
REPAIR SHEET

RYOBI TABLE SAW – MODEL NO. BTS12S
2
FIguRE A
35
36 40
18
34
14
1
2
3
4
5
10
11
23
12
13
12
19
21
21 29
22
41
6
30
33
21
11
11
17
17
15
16
32
24
42
31
20
27
25
26
37
38
28
39
7
8
9
10
7

RYOBI TABLE SAW – MODEL NO. BTS12S
3
The model number will be found on the data plate attached to the back panel of the cabinet. Always men-
tion the model number in all correspondence regarding your TABLE SAW or when ordering repair parts.
RYOBI TABLE SAW – MODEL NO. BTS12S
PARTS LIST FOR FIGURE A
Key Part
No. No. Description Qty.
1 410282702 SCREW
(3/16-24 x 3/8 in. HEX HD. ....... 1
2 412042001 EXTERNAL TOOTH LOCK
WASHER................................... 1
3 0101140303 POINTER ................................. 1
4 410012703 SCREW
(5/16-18 x 5/8 in. HEX HD.)....... 1
5 0101140304 POINTER SEAT ......................... 1
6 089015001003 CORD CLAMP BASE................ 2
7 412042702 EXTERNAL LOCK
WASHER (1/4 in.)...................... 3
8 412032701 INTERNAL LOCK
WASHER (1/4 in.)...................... 1
9 410151709 SCREW
(1/4-20 x 57 mm SOC. HD.)...... 1
10 410012702 SCREW
(1/4-20 x 3-1/4 in. HEX HD.) ..... 2
11 412012701 WASHER (D1/4 x D16 x t1)....... 3
12 411012701 HEX NUT (1/4-20) ..................... 3
13 0101010903 SPACER (M9 x 14.5 x 10.5 mm) 1
14 412042701 EXTERNAL TOOTH LOCK
WASHER (5/16 in.).................... 1
15 411012702 HEX NUT (5/16-18) ................... 1
16 410032720 CARRIAGE BOLT
(1/4-20 x 2 in.)........................... 1
17 0101010905 SPACER (9.5 x 68 mm) ............. 2
18 9181015330202 LABEL (NO HANDS) ................. 1
19 0101210902 DRIVING BLOCK ...................... 1
20 9121015333301 INSERT WARNING LABEL........ 1
21 411062701 NUT (1/4-20 CHEESE HD.) ....... 9
22 410162003 SCREW
(M6 x 18 mm CHEESE HD.)...... 3
23 A101014304 BRACKET ASSEMBLY.............. 1
24 089015001002 SAW TABLE .............................. 1
25 0101010301 THROAT PLATE INSERT ........... 1
26 410192001 SCREW
(M4 x 10 mm TRUSS HD.) ........ 2
27 0101141303 RUBBER WASHER ................... 2
28 412012030 WASHER................................... 2
29 414011002 SPRING PIN.............................. 1
30 410102702 SCREW
(1/4-20 x 7/8 in. FLAT HD.) ....... 4
31 089015001001 SCREW
(M8 x 30 mm SOC. HD.) ........... 1
32 089015001900 SCALE LABEL........................... 1
33 0101010303 STRAP (LONG).......................... 4
34 089015001701 MITER GAUGE ASSEMBLY...... 1
35 089015001700 RIP FENCE ASSEMBLY............ 1
36 A101141001 BLADE GUARD ASSEMBLY ..... 1
37 412012714 WASHER (1/4 in.)...................... 2
38 410152716 SCREW
(1/4-20 x 1/2 in. SOC. HD.)............ 2
39 0101010111 SPREADER SEAT...................... 1
40 9181015330203 BLADE GUARD LABEL............. 1
41 0101010308 MOTOR BRACKET ................... 1
42 089015001013 SCREW
(M8 x 35 mm SOC. HD) ............ 1
Key Part
No. No. Description Qty.

4
RYOBI TaBle Saw – MODel NUMBeR BTS12S
FIgURe B
36
35
34
40
44
17
16
32
33
39
37
38
15
14
13
12
11
9
8
7
6
5
4
43
31
7
31
30
27
28
18
1
29
226
25
24
23
10
21
20
20
22
41
42
19
45

5
RYOBI TaBle Saw – MODel NUMBeR BTS12S
PaRTS lIST FOR FIgURe B
KeY PaRT
NO. NUMBeR DeSCRIPTION QTY.
The model number will be found on a plate attached to the back panel of the cabinet. Always mention the model number in all correspondence
regarding your TaBle Saw or when ordering repair parts.
1 410182001 SCREW (M4 x 7 mm FLAT HD.) ......................... 6
2 089015001007 E-RING ............................................................... 1
3 0101040305 REINFORCEMENT PLATE.................................. 1
4 412042002 EXTERNAL TOOTH LOCK WASHER ................. 1
5 410132005 SCREW (M4 x 5 mm PAN HD.) .......................... 1
6 0101040203 CORD CLAMP.................................................... 1
7 410192002 SCREW (M4 x 16 mm PAN HD.) ........................ 6
8 0152011814 GROMMET ......................................................... 1
9 0101140701 POWER CORD ................................................... 1
10 411072702 LOCK NUT (1/4-20) ............................................ 1
11 0101090302 CORD CLAMP.................................................... 1
12 0101090201 SWITCH BOX ..................................................... 1
13 410162004 SCREW (M6 x 25 mm CHEESE HD.) ................. 5
14 0111140208 RUBBER FOOT .................................................. 4
15 9101145330203 WARNING LABEL............................................... 1
16 089015001901 DATA LABEL ....................................................... 1
17 089015001004 CABINET ............................................................ 1
18 9101145330101 FRONT PANEL LABEL ....................................... 1
19 412080001 NYLON WASHER ............................................... 1
20 412012701 FLAT WASHER (D1/4 x D16 x t1) ....................... 2
21 411012701 HEX NUT (1/4-20)................................................1
22 0101140221 LOCK NUT...........................................................1.
23 0101140205 HAND WHEEL .................................................... 1
24 412011712 WASHER ............................................................ 1
KeY PaRT
NO. NUMBeR DeSCRIPTION QTY.
25 0152010204 BLADE ADJUSTING HANDLE............................ 1
26 0101140203 SHOULDER BOLT .............................................. 1
27 0101140206 HAND WHEEL INSERT....................................... 1
28 414011003 SPRING PIN ....................................................... 1
29 089015001006 ELEVATING SHAFT ............................................ 1
30 0101140213 SWITCH KEY...................................................... 1
31 452020007 SWITCH ............................................................ 1
32 A101140109 MOTOR ASSEMBLY W/GUARD ........................ 1
33 0101015002 BRUSH ASSEMBLY ........................................... 2
34 *** 10 in. BLADE (422010025) ................................. 1
35 0101010302 OUTER BLADE WASHER................................... 1
36 0101010920 ARBOR NUT (5/8-18) ......................................... 1
37 0101010312 ARBOR WRENCH (15/16 in., SMALL)................ 1
38 0101010313 WRENCH (LARGE) ............................................. 1
39 0201010904 HEX KEY (M5)..................................................... 1
40 0101210208 GUARD (BAFFLE PLATE) ................................... 1
41 089015001005 BEVEL LOCK LEVER.......................................... 1
42 0101140904 SPRING............................................................... 1
43 411062004 NUT (M4, CHEESE HD.) ..................................... 2
44 410542005 SCREW (m4 X 15 mm) ....................................... 2
45 089015001702 BEVEL LOCK LEVER ASSEMBLY
(INC. PAGE 2 KEY NOS. 13 AND 16;
PAGE 4 KEY NOS. 19-22 AND 41-42) ............... 1

6
RYOBI TaBle Saw – MODel NUMBeR BTS12S
9
8
3
2
6
4
17
20
19
22
21
23
6
1
5
11
16
14
13
18
15
2
710
11
12
FIgURe C

7
RYOBI TaBle Saw – MODel NUMBeR BTS12S
PaRTS lIST FOR FIgURe C
The model number will be found on a plate attached to the back panel of the cabinet. Always mention the model number in all correspondence
regarding your TaBle Saw or when ordering repair parts.
KeY PaRT
NO. NUMBeR DeSCRIPTION QTY.
1 0101210210 LOWER BLADE GUARD..................................... 1
2 451020004 WIRE CONNECTOR ........................................... 2
3 0101140703 MOTOR CORD ................................................... 1
4 451010001 STRAIN RELIEF.................................................. 1
5 412042001 EXTERNAL TOOTH LOCK WASHER ................. 2
6 410252001 SCREW w/WASHER (M4 x 12 mm).................... 6
7 0101015002 BRUSH ASSEMBLY ........................................... 2
8 0101010208 END CAP (MOTOR)............................................ 1
9 0101010209 RUBBER PLUG .................................................. 2
10 0101010502 BRUSH HOLDER................................................ 2
11 411012001 HEX NUT (M5) .................................................... 2
12 410272004 SCREW (M5 x 75 mm)........................................ 2
KeY PaRT
NO. NUMBeR DeSCRIPTION QTY.
13 0101010207 MOTOR HOUSING ASSEMBLY ......................... 1
14 0101010807 SCREW w/WASHER (M5 x 30 mm).................... 1
15 412061001 WAVY WASHER ................................................. 1
16 A101010403 FIELD.................................................................. 1
17 410292001 HEX SCREW w/WASHER (M5 x 60 mm)............ 2
18 420010102 BALL BEARING (6001ZZ)................................... 1
19 420010101 BALL BEARING (6201ZZ)................................... 1
20 A101010301 ARMATURE (INC. KEY NOS. 18-19) .................. 1
21 0101010102 GEAR HOUSING ................................................ 1
22 420110004 NEEDLE BEARING ............................................. 3
23 A101010501 JACKSHAFT ASSEMBLY (ARBOR) .................... 1
987000372 OPERATOR'S MANUAL ..................................... 1
9-30-08
(REV:00)

RYOBI TABLE SAW – MODEL NO. BTS12S
6
6
7
7
3
3
3
3
4
4
9
9
9
9
8
8
8
10
11
2
2
2
2
5
5
Key Part
No. No. Description Qty.
1 A101141301 COMPLETE STAND ASSEMBLY
(INC. KEY NOS. 2-11)................ 1
2 0152010211 FOOT PAD ................................. 4
3 0101140318 LEG ............................................ 4
4 0101140317 LOWER SIDE BRACE ................ 2
5 0101140316 LOWER BRACE ......................... 2
6 0101140315 UPPER SIDE BRACE................. 2
Key Part
No. No. Description Qty.
PARTS LIST FOR FIguRE D
7 0101140314 UPPER BRACE .......................... 2
8 410032709 CARRIAGE BOLT
(5/16 x 5/8 in.) .......................... 16
9 411062702 HEX LOCK NUT (5/16-18) ....... 16
10 410032705 CARRIAGE BOLT
(1/4-20 x 1-5/8 in.) ..................... 4
11 411062701 HEX NUT (1/4-20) ...................... 4
8
FIguRE D

RYOBI TaBle Saw – MODel NUMBeR BTS12S
wIRINg DIagRaM
BLACKBLACK
WHITEWHITE
POWER CORD
SWITCH
MOTOR CORD MOTOR
9
