SABINE NEXFX PEDALS User manual

PedalEffectshavebeenaroundforover30years,andyoucanhardlytellthey’vechanged
in all that time. Evolution is too slow – we think it’s time for a revolution. Sabine’s new
NexFX Pedals are massive, professional quality monsters packed with features you can’t
getanywhereelse.AndSabine,aworldleaderinprofessionalsignal processing, gives you
the sounds you’ve been waiting for. Test drive the NexFX Series at your Sabine dealer
today.
• Warm Analog Sound / Maximum Control: Recreate classic sounds or invent futuristic
new sounds with five adjustments!
• DualOutputs:effectoutputplus a sparedryout; stereopanningon Chorusand Phlanger
for those swirly sounds!
• Glowsinthedark! BrightGlowKnobsand backlitdisplaylight upforeasyviewingonstage.
• Power to the Pedals: 9v power input and OUTPUT! Who needs batteries? Power all
your Sabine pedals (and most others) with one power supply!
• Easy-Change Battery: Cover lifts off with a squeeze, drops back in a snap!
• MonsterSwitch: Heavy-duty foot switch activates hard-wire bypass–absolutely no col-
oration of your sound.
• Solid Case:All-metal case for rugged use on the road. Go ahead – stomp on it!
13301 Highway 441 • Alachua, FL 32615 USA
Phone: [phone] • Fax: [phone]
Check out the NexFX pedals online at:
www.Sabine.com
Dual Outputs: One effect
and one clean. Think of
the possibilities!
(except StereoChorus & Phlanger)
More Sounds: Five pots on
every pedal — dial up your
custom setting — no limits!
Power In and Out: Use any
NexFX pedal to power
almost any other 9V pedal
GlowKnobs & Backlit display: See the
whole picture on a dark stage — way cool!
Cord-Kicker — Your cord
can’t get stuck here
Stomp here for true
hard-wire bypass!
Easy-change
battery — just
squeeze the
buttons and the
lid lifts off
Large, bright, easy-
to-read note
indicator and
Sweeping LED
Display
Get the entire
line of NexFX
Pedals:
FuzzStortion
Overdrive
StereoChorus
Compressor
Phlanger
Pedal Tuner
Every pedal comes with
a power patch cord —
use a NexFX Power
Supply to power up to
six NexFX pedals, or
power other pedals.
NexFX Power Supply
and six-pack of patch
cords sold separately.
Nex-FX-2-page-BW.p65 01.07.02 - hto
Rugged
metal
case
NeNe
NeNe
NexFXxFX
xFXxFX
xFX PePe
PePe
Pedals from Sabinedals from Sabine
dals from Sabinedals from Sabine
dals from Sabine
TM
© Sabine 2001

NeNe
NeNe
NexFX PexFX Pe
xFX PexFX Pe
xFX Pedals: the whole stordals: the whole stor
dals: the whole stordals: the whole stor
dals: the whole storyy
yy
y..
..
.
NEX-5100 FuzzStortion
Fromwarm and fuzzy tohead-crushing,this one has allthe distortion you need! Blendthe
perfectmix, from 60-ish fuzztoneto end-of-the-millennium bombast. Carveouta heaping
scoop of midrange while leaving a sparkling top and a thunderous bottom — or leave the
mids intact and tweak the treble. You’ll love the buzz from this fuzz!
• Fuzz and Distortion in one pedal
• Two tone controls for optimal sonic contouring
• Broad range of sound, from light crunch to thick metal distortion
NEX-5200 Overdrive
Boost it! Crunch it! This NexFX is fat, lean, clean, mean, dirty, sweet, and in-
between. With squeaky clean Sustain or pumped up Overdrive, plus Mid, Treble,
and Level controls, you can change moods faster than a jilted lover on a bad hair
day. Make your leads sing!
• Rippin ’analog overdrive sound
• Sustain control for extra punch in your lead
• Threshold control for touch-sensitive effect
NEX-5300 StereoChorus
The greatest event in the history of swirl since chocolate met vanilla in a Kansas twister.
Lush swirling choruses with control for Depth, Speed, Wet/Dry Mix (no, not for your dog),
Tone, and Sabine’s unique Stereo Auto-Pan. Your head will spin as your guitar gently
whirls. It’s Tabernacle Choir awesome!
• True stereo effects; two outputs
• AutoPan function sweeps between outputs at adjustable rate
• Mix control let’s you balance effect and dry sound
NEX-5400 Compressor
Nowyou cut through the mix like a silk knifeora raging chain saw,without overpowering the
rest of the band. Ratio, Threshold, Level,Attack, and Tone Controls allow you to put 10 tons
of whammy into a 1 pound mix.Add punch without distortion — your sound will be clean, fat
and chillin’. Like your first kiss in the back of the movie theatre, it’s so smooooth and drawn out!
• Famous Sabine compressor
• Control Ratio, Threshold and Attack
• Clean sustain for punch without distortion
NEX-5500 Phlanger
It’s a phase shifter! It’s a flanger! It’s schizoid and funky! It’s two effects for the price of
one!Guaranteed to be more than just aphase you’re going through — with allthesounds
in this pedal, it’s more like a lifelong experiment. Sounds better than listening to the radio
on your ‘64 Cutlass in a magnetic storm! Go forth and multiply!
• Two effects in one: Flanger and Phaser
• Control Intensity, Speed and Regeneration
• Mix between both effects — create new sounds by combining effects
NEX-5000 Tuner
When we do a pedal tuner, you know it’s fast and accurate. Big, bright, multi-color LED
display for fearless tuning on stage! Four levels of flat tuning (down to low C), easy
recalibration, transparent signal path, two outputs, and a mute foot switch in a bombproof
metal case, all from the people who revolutionized guitar tuning. We’re doing it again!
• Sabine’s finest tuning algorithm — chromatic and automatic
• Large, bright, sweeping LED display for easy tuning — looks like a bar graph of your pitch!
• Flat Tuning: tune scale down 1,2,3,or 4 half steps
• Calibrate: fromA=438 to 445 Hz
Dimensions (all models): 6 3/8” x 3 3/8” x 2 3/16” (16.2 cm x 8.6 cm x 5.5 cm). Weight: 19 oz (0.510 kg)
GlowKnob
controls &
Backlit
display! (all
models)
Power In & Out:
power other 9V
pedals! (all
models)
