Saeco 10001865 Operating instructions

TABLE OF CONTENTS
Operation and maintenance manual
Before using the machine, please read the attached operating instructions.
Carefully read the safety rules
Mode d'emploi
Veuillez lire attentivement le mode d'emploi
(notamment les consignes de sécurité) avant d'utiliser l'appareil.
FOR HOUSEHOLD USE ONLY

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and/or injury to persons,
including the following:
1Read all instructions and information in this instruction book and any other
literature included in this carton referring to this product before operating or
using this appliance.
2Do not touch hot surfaces. Use handles or knobs.
3To protect against fire, electric shock and personal injury do not immerse
cord, plugs or appliance in water or other liquid.
4Close supervision is necessary when any appliance is used by or near
children.
5Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions or has been damaged in any way. Return appliance to
the nearest authorized service centre for examination, repair or adjustment.
7The use of accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or personal injury.
8Do not use outdoors.
9Do not let cord hang over edge of table or counter, or touch hot surfaces.
10 Do not place on or near a hot gas or electric burner, or in a heated oven.
11 Always turn appliance “OFF”, then plug cord into the wall outlet. To disconnect,
turn switch to “OFF”, then remove plug from wall outlet.
12 Do not use appliance for other than intended household use.
13 Use extreme caution when using hot steam.
SAVE THESE INSTRUCTIONS

CAUTION
This appliance is for household use. Any servicing, other than cleaning and
user maintenance, should be performed by an authorized service centre. Do
not immerse base in water. To reduce the risk of fire or electric shock, do
not disassemble the base. There are no user serviceable parts inside. Repair
should be done by authorized service personnel only.
1Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2Never use warm or hot water to fill the water tank. Use cold water only.
3Keep your hands and the cord away from hot parts of the appliance during
operation.
4Never clean with scouring powders or hard implements. Simply use a soft
cloth dampened with water.
5For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
AA short power-supply cord is provided to reduce risks of getting tangled up
or tripping over a longer cord.
BLonger extension cords are available and may be used if care is exercised in
their use.
CIf a long extension cord is used:
1 the marked electrical rating of the extension cord should be at least as great as
the electrical rating of the appliance.
2 if the appliance is of the grounded type, the extension cord should be a grounding
type
3 the cord does not hang from the table to avoid the risk of getting caught up in
it.

2
GENERAL INFORMATION.................................................................................................................................3
MACHINE........................................................................................................................................................4
ACCESSORIES ....................................................................................................................................................................4
INSTALLATION................................................................................................................................................5
STARTING THE MACHINE ........................................................................................................................................................5
MANUAL PRIMING OF THE WATER CIRCUIT....................................................................................................................................6
SETTING THE LANGUAGE AND THE CLOCK....................................................................................................................................6
"AQUA PRIMA" FILTER ..........................................................................................................................................................7
DISPLAY .........................................................................................................................................................8
CHOOSE COFFEE AROMA........................................................................................................................................................8
ADJUSTMENTS...............................................................................................................................................9
COFFEE INTENSITIY..............................................................................................................................................................9
ADJUSTING THE HEIGHT OF THE DRIP TRAY. .................................................................................................................................9
FILLING THE MILK CONTAINER..................................................................................................................................................9
PRODUCT DISPENSING .................................................................................................................................10
ESPRESSO / COFFEE / LONG COFFEE .......................................................................................................................................10
DISPENSING BEVERAGES WITH GROUND COFFEE...........................................................................................................................11
HOT WATER DISPENSING ...................................................................................................................................................... 12
LATTE MACCHIATO.............................................................................................................................................................12
DISPENSING HOT MILK ........................................................................................................................................................13
ESPRESSO MACCHIATO........................................................................................................................................................14
CAPPUCCINO ...................................................................................................................................................................14
BEVERAGE PROGRAMMING ..........................................................................................................................15
BEVERAGE PROGRAMMING MENU ............................................................................................................................................15
ESPRESSO / COFFEE / LONG COFFEE PROGRAM........................................................................................................................... 15
PROGRAMMING MILK BEVERAGES............................................................................................................................................16
MACHINE SETTINGS .....................................................................................................................................18
PROGRAMMING THE MACHINE................................................................................................................................................18
"LANGUAGE" MENU.......................................................................................................................................................... 19
"CUP ILLUMINATION" MENU................................................................................................................................................. 19
"AQUA PRIMA FILTER" MENU ............................................................................................................................................... 19
"WATER HARDNESS" MENU................................................................................................................................................. 20
"RINSE" MENU................................................................................................................................................................ 20
"CUP WARMING PLATE" MENU.............................................................................................................................................. 21
"ACCOUSTIC TONES AND ALARMS" MENU ................................................................................................................................ 21
"DISPLAY" MENU............................................................................................................................................................. 21
BEVERAGE SETTINGS..........................................................................................................................................................22
ADJUSTMENT OF THE COFFEE BREW TEMPERATURE ..................................................................................................................... 22
"AROMA" ADJUSTMENT FOR COFFEE BREWING .......................................................................................................................... 23
"PREBREWING" ADJUSTMENT (ONLY COFFEE BEVERAGES) ............................................................................................................. 23
ADDITIONAL FUNCTIONS ......................................................................................................................................................24
"COFFEE IN THE WORLD" FUNCTION....................................................................................................................................... 24
"DEMO" MODE................................................................................................................................................................ 26
PRODUCT COUNTER FUNCTION.............................................................................................................................................. 26
MAINTENANCE..................................................................................................................................................................27
MILK CIRCUIT RINSE CYCLE.................................................................................................................................................. 27
MILK CIRCUIT WASH CYCLE.................................................................................................................................................. 28
COFFEE CIRCUIT CLEANING CYCLE (BREW GROUP WASH CYCLE) ....................................................................................................... 30
BLOCK DISPLAY .............................................................................................................................................................. 30
DESCALING .................................................................................................................................................................... 31
CLOCK SETTINGS ..............................................................................................................................................................33
TIME SETTING................................................................................................................................................................. 33
CLOCK SETTINGS ............................................................................................................................................................. 34
ENERGY SAVING SETTINGS................................................................................................................................................... 36
SPECIAL.........................................................................................................................................................................37
FACTORY SETTINGS........................................................................................................................................................... 37
CLEANING AND MAINTENANCE ....................................................................................................................38
GENERAL MACHINE CLEANING................................................................................................................................................38
CLEANING THE BREW GROUP.................................................................................................................................................39
GRINDER MAINTENANCE ......................................................................................................................................................40
MILK CONTAINER CLEANING..................................................................................................................................................40
ERROR CODES ..............................................................................................................................................41
TECHNICAL DATA..........................................................................................................................................42
SAFETY RULES .............................................................................................................................................43
TABLE OF CONTENTS

3
The coffee machine is intended for preparing espresso by using either coffee beans or ground coffee. It
includes an automatic device for preparing milk products and a hot water dispenser.
The machine is elegantly designed for domestic use and is not suitable for continuous heavy duty use of a
professional kind.
Warning: no liability is assumed for any damage caused by:
• Incorrect use not in accordance with the intended uses;
• Repairs not carried out by authorized customer service centers;
• Tampering with the power cord;
• Tampering with any part of the machine;
• The use of non-original spare parts and accessories;
• Failure to descale the machine or use at temperatures below 0°C.
IN THESE CASES, THE WARRANTY IS NOT VALID.
Keep these operating instructions in a safe place and make them available to anyone else who may use the coffee
machine. For further information or if you experience problems not completely or sufficiently addressed in these
instructions, please contact an Authorized Customer Service Center.
KEEP THESE INSTRUCTIONS
A WARNING TRIANGLE DRAWS ATTENTION TO ALL THE INSTRUCTIONS THAT
ARE IMPORTANT FOR USER SAFETY. PLEASE FOLLOW THESE INSTRUCTIONS
CAREFULLY TO AVOID SERIOUS INJURY!
HOW TO USE THESE OPERATING INSTRUCTIONS
GENERAL INFORMATION

4
Compartment for pre-
ground coffee
Brew group
Dregsdrawer
Socket for power cord
Open coffee bean hopper
button
Coffee bean hopper
Cup warming plate
Main switch
Service door
ACCESSORIES
Coffee bean hopper cover
Liquid tray
Button for raising/lowering the drip
tray
TOUCH SCREEN Display
SBS
Brew unit
Drip tray + grill and float
Compartment for milk
container
Hot water spout
Water tank
"Aqua Prima" Filter
Ground coffee
measuring scoop
Cleaning brush
Applicator
Cleaning detergent
Water hardness
tester
Adjustment key
MACHINE
Lubricant for the
brew group
Cappuccinatore
cleaning pin
Additional milk container
(without cappuccinatore)

5
1 2 3
4
7
65
INSTALLATION
Attach the female end of the
power cord to the machine. Insert
the male end into the power
outlet.
Place a container beneath the hot
water spout.
Press the button on the coffee
hopper to open the cover. Fill the
hopper with coffee beans.
Close the cover pushing it down
completely.
Remove the water tank.
We recommend installing the "Aqua
Prima" filter (see page 7).
Press the main switch once to
turn on the machine. The
appliance automatically performs
a diagnosis of its functions. This
test is performed each time the
machine is turned on.
The machine automatically
primes the water circuit.
The machine is now ready
for use.
Make sure that the main power button is not switched to the “ON” position.
Fill the tank with fresh drinking
water. Do not exceed the “max”
level indicated on the water tank.
Once filled place the tank back
into the machine.
Water may not be dispensed
into the glass.
This should not be considered
a malfunction.
STARTING THE MACHINE
TO ASSESS WATER HARDNESS, SEE "WATER
HARDNESS MENU" ON PAGE 23.

6
1
1
2 3
MANUAL PRIMING OF THE WATER CIRCUIT
Position a container under the hot
water spout (it is possible that
water will not come out of the
spout).
Press the display once and the
machine will begin priming the
water circuit.
When the prime circuit cycle is
finished, remove the container.
The machine is now ready for
use.
start
priming the machine
av v io
priming the machine
INSTALLATION
Manually prime the water circuit only when the following
display appears.
Note: first make sure that the water tank is full.
SETTING THE LANGUAGE AND THE CLOCK
These settings allow you to regulate the machine parameters to dispense coffee according to the
typical parameters of the country where it is used. For this reason, the languages are also
differentiated by location.
show icon
explanation
my custom
coffee
program-
ming
menu
Press "programming menu".
alerts &
tones
machine
settings
display
language
rinsing
water
hardness
water
filter
cup
illumination
cup
warmer
Press "language".
go back
restore
standars
values
back to
menu
main-
tenance
main
menu
specials
machine
settings
timer
extras
beverage
settings
go in
standby
go back to
make coffee
Press "machine settings".
2
Select the desired language.
italiano (ch)
language
1/2
français
deutsch
nederlands
english
Italiano (i)
go
back
back to
menu
4
Return to the main menu.
Press "timer"
See page 33 to adjust the clock.
timer
time
settings
timer
settings
standby
settings
go
back back to
menu
main-
tenance
main
menu
specials
machine
settings
timer
extras
beverage
settings
go in
standby
go back to
make coffee
3
6
5

7
4 5 6
1 2 3
9
Remove the "Aqua Prima" filter
from its packaging. Enter the date
of the current month.
Insert the applicator on the filter.
«AQUA PRIMA» FILTER
To improve the quality of the water used, install the "Aqua Prima" filter. After installation, go to the
filter activation program (see programming). In this mode the machine advises the user when the
filter must be replaced.
Insert the filter in its place within the
empty tank (see figure).
Press down until it clicks into place.
Remove the filter applicator.
Press "machine settings". Press "water filter". Press "activate filter".
water
filter
inserted
not
inserted
activate
filter
The machine then activates the "Aqua Prima" filter. Wait for the cycle to finish automatically.
When the activation cycle ends, the machine proceeds to the choose product menu.
Fill the tank with fresh water. Let
the filter soak for 30 minutes. After
30 minutes discard the water in the
tank and refill with fresh water.
Place a container beneath the
hot water spout.
Press "programming menu".
show icon
explanation
my custom
coffee
program-
ming
menu
main-
tenance
main
menu
specials
machine
settings
timer
extras
beverage
settings
go in
standby
go back to
make coffee
alerts &
tones
machine
settings
display
language
rinsing
water
hardness
water
filter
cup
illumination
cup
warmer
go back
restore
standars
values
back to
menu go back
restore
standars
values
back to
menu
save
settings
1.
2.
8
7

8
• To get the desired beverage, press the corresponding symbol on the display.
The machine automatically performs all the necessary operations.
• To make 2 cups, press the beverage symbol twice.
press twice
weak medium strong
The intensity of the color on the cup icon (only valid for coffee beverages) indicates the aroma, or
quantity of coffee to be ground, for preparing the drink. The greater the quantity of coffee ground
the stronger the coffee will taste.
DISPLAY
Go to the "text
format" menu
Product
programming
Accessing the
programming menu
It is possible to change the type of display and choose between " icon format" and "text format"
ICON FORMAT
long
coffee
hot
water coffee espresso
hot
milk
latte
macchiato
espresso
macchiato
cappuccino
medium strongmedium
medium strongmedium
Go to the "icon
format" menu
TEXT FORMAT
CHOOSE COFFEE AROMA
When the machine is programmed to use pre-ground coffee or when a product is customized, the
icon is displayed in a different way and/or accompanied by an asterisk (see section on
“programming beverages”.)
pre-ground customization
show icon
explanation
my custom
coffee
program-
ming
menu
show
icon
my custom
coffee
program-
ming
menu

9
21
MEDIUM
COFFEE
STRONG
COFFEE
MILD
COFFEE
SBS adjusts the intensity of the brewed coffee,
and can even be adjusted while brewing. Any
adjustment has an immediate effect on the
brewing coffee.
COFFEE INTENSITIY
SBS – SAECO BREWING SYSTEM
Height adjustable drip tray.
To raise the drip tray, press lightly on the lower part of the button. To lower the tray,
press lightly on the upper part of the button; when the desired height is reached,
release the button.
Note: There is a red floater in the drip tray. When it rises, the tray must be emptied
and washed.
ADJUSTING THE HEIGHT OF THE DRIP TRAY.
FILLING THE MILK CONTAINER
Open the milk compartment and
remove the container located
within.
Remove the container cover and pour in the milk.
Close the container and put it back in its
appropriate place. Make sure to carefully close the
compartment.
ADJUSTMENTS
The SBS system has been carefully designed to give your coffee the intense taste you desire. Simply
turn the dial and you will notice that the coffee goes from mild intensity to strong intensity.
Only the container with the cappuccinatore must be filled before preparing beverages with milk. Do not
use milk after the best-before date. (Important! Refer to the instructions for maintenance and cleaning
of the cappuccinatore on page 40).
We recommend using the other
supplied container to store any
remaining milk in the refrigerator.
Clean the circuits using only the
container with the cappuccinatore.
Adjust the drip tray before dispensing any products.

10
1 2 3
DISPENSING COFFEE, HOT WATER AND MILK CAN BE INTERRUPTED AT ANY TIME BY
SELECTING THE "STOP ... DISPENSING" BUTTON.
THE DISPENSED MILK CAN REACH HIGH TEMPERATURES: THERE IS A DANGER OF
SCALDING. DO NOT TOUCH IT WITH BARE HANDS.
Check that all the containers are clean. To do this operation, follow the instructions in the "Cleaning and
Maintenance" chapter (see page 38).
WHEN YOU HAVE FINISHED PREPARING BEVERAGES CONTAINING MILK, PROCEED WITH
CLEANING THE CONTAINER AND THE MACHINE'S CIRCUIT.
To brew 2 cups, the machine dispenses half of the entered quantity and briefly interrupts dispensing in
order to grind the second serving of coffee. Coffee dispensing is then restarted and completed.If a milk
beverage has been chosen, the machine automatically dispenses the milk. If the first coffee is interrupted,
the second will not be dispensed.
THE MILK USED MUST HAVE BEEN PROPERLY PRESERVED.
DO NOT USE IT AFTER THE EXPIRATION DATE ON THE PACKAGE.
ESPRESSO / COFFEE / LONG COFFEE
Choose the product and press the
corresponding icon on the
display: once for 1 cup and twice
for 2 cups.
The machine begins grinding the
quantity of coffee entered.
Begin dispensing the selected
beverage.
stop
coffee
dispensing
espresso
PRODUCT DISPENSING
This procedure shows how to dispense an espresso. To dispense another type of coffee, press the
appropriate icon. Use appropriate espresso or coffee cups so that the coffee will not overflow.
The machine ends dispensing automatically according to the quantity determined by the manufacturer. It is
possible to customize this quantity. See page 15.
If you wish to interrupt the dispensing cycle, press the " stop coffee dispensing" button.
show icon
explanation
my custom
coffee
program-
ming
menu

11
1 2 3
4 5
DISPENSING BEVERAGES WITH GROUND COFFEE
Pre-ground coffee must be poured into the appropriate compartment positioned next to the coffee bean
hopper. Pour in only coffee ground for espresso machines and never coffee beans or instant coffee. (see the
"Beverage programming" chapter on page 15).
WARNING: PUT PRE-GROUND COFFEE IN THE COMPARTMENT ONLY WHEN YOU WISH TO
DISPENSE THIS TYPE OF PRODUCT.
INSERT ONLY ONE SCOOP OF GROUND COFFEE AT A TIME. TWO CUPS OF COFFEE CANNOT BE
DISPENSED AT THE SAME TIME.
Press the appropriate button and
the display will show:
A message reminding the user to
pour ground coffee in the
appropriate compartment.
add preground
coffee
go!
go
back
Press the "go! "button to start
dispensing.
Pour ground coffee into the pre-
ground coffee compartment using
the measuring scoop provided
with the accessories.
add preground
coffee
go!
go
back
Begins dispensing the selected
beverage.
long
coffee
stop
coffee
dispensing
Note:
• After 1 minute from when the message appears (2), if brewing has not started the machine will return to
the main menu and dump any inserted coffee into the coffee dregs drawer.
• If no pre-ground coffee is poured into the compartment, only water will be dispensed.
• If 2 or more scoops of coffee are added, the machine will not dispense the product and the coffee in the
compartment will be dumped into the coffee dregs drawer.
In the example given below, we chose to dispense a long coffee using pre-ground coffee.
The customized choice of using pre-ground coffee is shown on the display with an asterisk next to the
chosen beverage.
show icon
explanation
my custom
coffee
program-
ming
menu

12
2
23
4 5
1
1
6
Press the hot water icon once.
HOT WATER DISPENSING
WHEN THE HOT WATER BEGINS TO DISPENSE, SHORT SPURTS OF HOT WATER MAY BE
DISPENSED WHICH POSE A RISK OF SCALDING. THE HOT WATER SPOUT CAN REACH
HIGH TEMPERATURES: AVOID TOUCHING IT WITH BARE HANDS.
Begin hot water dispensing.
To dispense another cup of
hot water, repeat this
operation.
PRODUCT DISPENSING
latte
macchiato
latte
macchiato
latte
macchiato
The machine begins grinding the
quantity of coffee entered.
Select the product and press the
corresponding icon on the
display: once for 1 cup and twice
for 2 cups.
When the coffee finishes grinding,
the machine will automatically
dispense the programmed quantity
of hot milk.
Once milk has been dispensed, the
machine automatically prepares the
coffee.
After this, the machine allows you to
dispense more milk if you wish. This
option remains active for
approximately 2 seconds. To activate,
press the “more milk” button.
The “milk rinsing” icon will flash
once the machine is done
dispensing in order to clean the
milk circuit. Press the “milk
rinsing” icon to clean the internal
milk circuit.
stop
milk
dispensing
more
milk
stop
water
dispensing
hot
water
milk
rinsing
Fill the milk container
LATTE MACCHIATO
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing

13
2
1
9
hot
milk
DISPENSING HOT MILK
Press the hot milk icon once. The hot milk is dispensed.
start
rinsing
milk rinsing cycle
rinse the milk tank
Remove the milk container from the
machine; if it sill contains milk, put it
back in the refridgerator
for later use and substitute the
additional container.
Rinse the container and fill with fresh
water, place it in the machine and
press the “start rinsing”
button.
8
rinsing...
rinsing milk department-
please wait
While the machine is rinsing the
user cannot interrupt the cycle,
but must wait until the cycle is
completed. Once completed the
machine returns to the main menu.
THIS PROCEDURE MUST BE PERFORMED FOR ALL
MILK PRODUCTS!
Remove the container, rinse
and dry.
If the user wishes to continue preparing other drinks the machine
will keep the “milk rinsing” signal active.
After 20 minutes of inactivity, the machine requires the user to
perform a rinsing cycle as described in Step 7. If the machine is
turned off immediately after dispensing a milk product, the next
time the machine is turned on it will require the user to perform a
rinsing cycle.
Note: Before performing the “milk rinsing” function, make sure of
the following:
1. and adequate zised container is placed under the brew unit.
2. the milk container with the cappuccinatore is filled with fresh
drinking water and inserted in the machine.
3. the water tank is full of fresh water.
Fill the milk container
7
To dispense another cup of milk,
repeat this operation.
When the "milk rinsing" symbol
flashes, clean the milk circuits as
described for latte macchiato (see
page 12, Step 6).
show icon
explanation
my custom
coffee
program-
ming
menu
stop
milk
dispensing
milk
cleaning
show icon
explanation
my custom
coffee
program-
ming
menu
After 14 days from the first dispensing
of a milk-based beverage, the
message “milk cleaning” is displayed;
it is advisable to clean the milk
circuits as shown on page 28.
After another 7 days, the machine
comes to a halt and the milk circuits
must be cleaned.

14
231
45
23
4 5
1
PRODUCT DISPENSING
espresso
macchiato
espresso
macchiato
cappuccino
cappuccino
cappuccino
ESPRESSO MACCHIATO
The machine begins grinding the
quantity of coffee entered.
Press the icon once for 1 cup and
twice for 2 cups.
Espresso macchiato begins
brewing.
Once the coffee has been brewed,
the machine automatically prepares
the hot milk.
CAPPUCCINO
The machine begins grinding the
quantity of coffee entered.
Press the icon once for 1 cup and
twice for 2 cups.
After this, the machine allows you to dispense more milk if you wish.
This option remains active for approximately 2 seconds. To activate it,
press the "more milk" button.
Fill the milk container
Fill the milk container
When the "milk rinsing"
symbol flashes, clean the
milk circuits as described for
latte macchiato (see page 12,
Step 6).
When the "milk rinsing"
symbol flashes, clean the
milk circuits as described for
latte macchiato (see page 12,
Step 6).
When the coffee finishes grinding,
the machine will dispense the
programmed quantity of hot milk.
Once milk has been dispensed, the
machine automatically prepares the
coffee.
more
milk
To dispense more milk, press the
“more milk” icon.
espresso
macchiato
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
more
milk

15
2
1
BEVERAGE PROGRAMMING
BEVERAGE PROGRAMMING MENU
Hold down the beverage button for
two seconds
Press the button "my coffee" and
within two seconds, press the
beverage button
Each beverage can be programmed according to your individual taste. Customization is shown on the
display with the addition of an asterisk.
To program the desired beverage:
or
ESPRESSO / COFFEE / LONG COFFEE PROGRAM
Go to the menu of the beverage to be
customized (see "beverage
programming menu" chapter)
In this menu you can:
save settings.restore factory settings.
return to the
previous
window.
select the quantity
of coffee to be
ground (aroma).
go
back
save
settings
original
settings
strong preground
my
espresso
medium
light
go!
Once a beverage has been customized it will only dispense that type of
beverage. To change or modify the beverage a new customization must be
done.
Selecting a different quantity of coffee
changes the aroma of the beverage.
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
show icon
explanation
my custom
coffee
program-
ming
menu
select the use
of pre-ground
coffee.

16
1
5
6 7
BEVERAGE PROGRAMMING
To brew an amount of coffee greater
than that preset by the
manufacturer, press “custom
coffee amount” before the end of
the brew cycle in progress. When
the quantity is reached,
press “stop coffee dispensing”.
Pressing go! allows the machine
to brew coffee.
The machine automatically starts and
finishes brewing the coffee, according to
the standard settings.
The brew cycle may be
interrupted only by pressing
“stop coffee dispensing”.
If the button is not pressed,
the coffee can overflow in
the cup.
Once the brew cycle finishes,
press "save settings" within five
seconds.
If the "save settings" button
is not pressed the machine
returns to the main menu
and the customized settings
will not be saved.
saved!
The display shows the confirmation of
the memorized settings, and the
machine automatically returns to the
main menu.
PROGRAMMING MILK BEVERAGES
Go to the menu of the beverage to be
customized (see “beverage programming
menu” chapter on page 15).
In this menu you can:
select the
quantity of
coffee to be
ground. select the use
of pre-ground
coffee.
save settings.restore factory settings.
return to the
previous
window.
my
espresso
custom
coffee
amount
my
espresso
my
espresso
my latte
macchiato
Fill the milk tank
After pressing the go!
button, you must finish the
brew cycle.
my
espresso
my
espresso
show icon
explanation
my custom
coffee
program-
ming
menu go
back
save
settings
original
settings
strong preground
medium
light
go!
go
back
save
settings
original
settings
strong preground
medium
light
go!
stop
coffee
dispensing
custom
coffee
amount
stop
coffee
dispensing
save
settings
go
back
3 4
2

17
8
9
Pressing go! makes the machine
prepare to dispense the beverage.
The machine automatically starts and
finishes dispensing the milk,
according to the standard settings.
my latte
macchiato
To dispense an amount of milk greater than that preset by the
manufacturer, press “custom milk amount” before the end of the
dispensing cycle in progress. When the quantity is reached, press
“stop milk dispensing”.
The dispensing cycle may
be interrupted only by
pressing “stop milk
dispensing”.
If the button is not pressed,
the milk may overflow.
my latte
macchiato
The machine automatically starts
and finishes brewing the coffee,
according to the standard
settings.
my latte
macchiato
To brew an amount of coffee greater than that preset by the
manufacturer, press “custom coffee amount” before the end of the
brew cycle in progress. When the desired quantity is
reached, press “stop coffee dispensing”.
The brew cycle may be
interrupted only by pressing
“stop coffee dispensing”.
If the button is not
pressed, the coffee may
overflow.
save
settings
Once the brew cycle finishes,
press "save settings" within five
seconds.
If the "save settings" button
is not pressed the machine
returns to the main menu
and the customized settings
will not be saved.
saved!
my latte
macchiato
The display shows the confirmation of the
saved settings, and the machine
automatically returns to the main menu.
my latte
macchiato
my latte
macchiato
After pressing the go!
button, you must finish the
dispense cycle.
my latte
macchiato
go
back
save
settings
original
settings
strong preground
medium
light
go!
custom
coffee
amount
stop
coffee
dispensing
stop
milk
dispensing
custom
milk
amount
stop
milk
dispensing
custom
milk
amount
custom
coffee
amount
stop
coffee
dispensing
stop
milk
dispensing
custom
milk
amount
custom
coffee
amount
stop
coffee
dispensing
stop
milk
dispensing
custom
milk
amount
custom
coffee
amount
stop
coffee
dispensing
go
back
3
5
7
6
4

18 PROGRAMMING THE MACHINE
MACHINE SETTINGS
When the machine settings are selected the following screen appears. Here you can:
set the language of the menus.
set the illuminate cups function.
set the machine’s operation
through the “Aqua Prima” filter.
set/activate the tones.
set the water hardness.
set the circuit rinse cycle.
set the operation of the cup
warming plate.
set the brightness of the
display colors.
After having set each of the following menus, press
- "go back" to return to the previous screen
- "restore standard values" to restore the initial values
- "save settings" to save the settings
- "back to menu" to return to the main menu
Some of the machine’s functions can
be programmed to customize
operations according to your own
requirements.
Press the "programming menu" button.
The programming menu will access:
Programming the machine
operations (see page 18)
Special functions
(see page 37)
Maintenance (cleaning the
machine) (see page 27)
In depth product programming
(see page 22)
- Current date and time
- Standby timer
- Times to turn on/turn off over
the span of a day (see page
33)
Extra functions (see page 24)
Activate standby
Exit
show icon
explanation
my custom
coffee
program-
ming
menu
main-
tenance
main
menu
specials
machine
settings
timer
extras
beverage
settings
go in
standby
go back to
make coffee
alerts &
tones
machine
settings
display
language
rinsing
water
hardness
water
filter
cup
illumination
cup
warmer
go back
restore
standars
values
back to
menu
