Saeco 10002683 Operating instructions

TABLE OF CONTENTS
Operation and maintenance manual
Before using the machine, please read the attached operating instructions.
Carefully read the safety rules
FOR HOUSEHOLD USE ONLY

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. To protect against fire, electric shock and injury to person do not immerse
cord, plugs, or machine in water or other liquid.
4. Close supervision is necessary when the appliance is used by or near
children.
5. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
adjustment.
7. The use accessory attachments not recommended by the appliance
manufacturer may result in fire, electric shock or injury to persons.
8. Do not use outdoors.
9. Do not let cords hang over edge of table or counter, or touch hot surfaces.
10.Do not place on or near a hot gas or electric burner, or in a heated oven.
11.Always attach plug to appliance first, then plug cord into wall outlet. To
disconnect, turn any control to “off”, then remove plug from wall outlet.
12.Do not use appliance for than intended use.
13.Save this instructions.
SAVE THESE INSTRUCTIONS

CAUTION
This appliance is for household use only. Any servicing, other than cleaning and
user maintenance, should be performed by an authorized service centre. Do
not immerse machine in water. To reduce the risk of fire or electric shock, do not
disassemble the machine. There are no parts inside the machine serviceable
by the user. Repair should be done by authorized service personnel only.
1Check voltage to be sure that the voltage indicated on the nameplate
corresponds with your voltage.
2Never use warm or hot water to fill the water tank. Use cold water only.
3Keep your hands and the cord away from hot parts of the appliance during
operation.
4Never clean with scrubbing powders or harsh cleaners. Simply use a soft
cloth dampened with water.
5For optimal taste of your coffee, use purified or bottled water. Periodic
descaling is still recommended every 2-3 months.
6 Do not use caramelized coffee
INSTRUCTIONS FOR THE POWER
SUPPLY CORD
A. A short power-supply cord (or detachable power-supply cord) is to be
provided to reduce risks resulting from becoming entangled in or tripping
over a longer cord.
B. Longer detachable power-supply cords or extension cords are available and
may used if care is exercised in their use.
C. If a long detachable power-supply cord or extension cord is used,
1. The marker electrical rating of the detachable power-supply cord or extension
cord should be at least as great as the electrical rating of the appliance
2. If the appliance is of the grounded type, the extension cord should be a
grounding-type 3-wire cord, and
3. The longer cord should be arranged so that it will not drape over the counter top
or table top where it can be pulled on by children or tripped over.

2
GENERAL INFORMATION.................................................................................................................................3
MACHINE ........................................................................................................................................................4
ACCESSORIES ....................................................................................................................................................................4
INSTALLATION................................................................................................................................................5
STARTING THE MACHINE ........................................................................................................................................................5
MANUAL PRIMING OF THE WATER CIRCUIT....................................................................................................................................6
SETTING THE LANGUAGE AND THE CLOCK ....................................................................................................................................6
INTENZA WATER FILTER .........................................................................................................................................................7
DISPLAY .........................................................................................................................................................8
CHOOSE COFFEE AROMA........................................................................................................................................................8
ADJUSTMENTS...............................................................................................................................................9
COFFEE INTENSITIY..............................................................................................................................................................9
ADJUSTING THE HEIGHT OF THE DRIP TRAY. .................................................................................................................................9
FILLING THE MILK CONTAINER..................................................................................................................................................9
COFFEE MIXING ............................................................................................................................................10
DOUBLE COFFEE BEAN HOPPER .............................................................................................................................................. 10
SELECTION OF ASINGLE BLEND OR BLEND MIX ........................................................................................................................... 11
BEVERAGE DISPENSING................................................................................................................................12
ESPRESSO / COFFEE / LONG COFFEE ....................................................................................................................................... 12
HOT WATER DISPENSING ...................................................................................................................................................... 12
DISPENSING BEVERAGES WITH GROUND COFFEE........................................................................................................................... 13
LATTE MACCHIATO............................................................................................................................................................. 14
ESPRESSO MACCHIATO........................................................................................................................................................ 16
CAPPUCCINO ...................................................................................................................................................................16
DISPENSING HOT MILK ........................................................................................................................................................ 17
BEVERAGE PROGRAMMING ..........................................................................................................................17
BEVERAGE PROGRAMMING MENU ............................................................................................................................................ 17
ESPRESSO / COFFEE / LONG COFFEE PROGRAM........................................................................................................................... 17
PROGRAMMING MILK BEVERAGES............................................................................................................................................ 18
PROGRAMMING THE MACHINE .....................................................................................................................20
MACHINE SETTINGS ...........................................................................................................................................................20
LANGUAGE MENU ............................................................................................................................................................. 21
CUP ILLUMINATION MENU.................................................................................................................................................... 21
WATER FILTER MENU ......................................................................................................................................................... 21
WATER HARDNESS MENU - INTENZA AROMA SYSTEM ................................................................................................................... 22
RINSE MENU................................................................................................................................................................... 22
CUP WARMING PLATE MENU................................................................................................................................................. 23
ACCOUSTIC TONES AND ALARMS MENU.................................................................................................................................... 23
DISPLAY MENU ................................................................................................................................................................ 23
BEVERAGE SETTINGS..........................................................................................................................................................24
ADJUSTMENT OF THE COFFEE BREW TEMPERATURE ..................................................................................................................... 24
AROMA ADJUSTMENT FOR COFFEE BREWING.............................................................................................................................. 25
PREBREWING ADJUSTMENT (ONLY COFFEE BEVERAGES) ................................................................................................................ 25
«MIXING» ADJUSTMENT (ONLY COFFEE BEVERAGES) .................................................................................................................... 25
ADDITIONAL FUNCTIONS ......................................................................................................................................................26
COFFEE OF THE WORLD FUNCTION ......................................................................................................................................... 26
DEMO MODE................................................................................................................................................................... 28
BEVERAGE COUNTER FUNCTION............................................................................................................................................. 28
MAINTENANCE..................................................................................................................................................................29
MILK CIRCUIT RINSE CYCLE.................................................................................................................................................. 29
MILK CIRCUIT WASH CYCLE.................................................................................................................................................. 30
COFFEE CIRCUIT CLEANING CYCLE (BREW GROUP WASH CYCLE) ....................................................................................................... 33
BLOCK DISPLAY .............................................................................................................................................................. 33
DESCALING .................................................................................................................................................................... 34
CLOCK SETTINGS ..............................................................................................................................................................36
TIME SETTING ................................................................................................................................................................. 36
AUTOMATIC TIMER SETTINGS................................................................................................................................................ 37
ENERGY SAVING SETTINGS................................................................................................................................................... 39
SPECIAL.........................................................................................................................................................................40
FACTORY SETTINGS........................................................................................................................................................... 40
CLEANING AND MAINTENANCE.....................................................................................................................41
MAINTENANCE DURING OPERATION..........................................................................................................................................41
GENERAL MACHINE CLEANING................................................................................................................................................41
MILK CONTAINER MAINTENANCE AND CLEANING...........................................................................................................................42
CLEANING THE BREW GROUP.................................................................................................................................................44
GRINDER MAINTENANCE ......................................................................................................................................................45
ERROR CODES ..............................................................................................................................................46
TECHNICAL DATA..........................................................................................................................................47
SAFETY RULES .............................................................................................................................................48
TABLE OF CONTENTS

3
The coffee machine is intended for preparing espresso by using either coffee beans or ground coffee. It
includes an automatic device for preparing milk beverage and a hot water dispenser.
The machine is elegantly designed for domestic use and is not suitable for continuous heavy duty or
professional use.
Warning: no liability is assumed for any damage caused by:
• Incorrect use not in accordance with the intended uses;
• Repairs not carried out by authorized customer service centers;
• Tampering with the power cord;
• Tampering with any part of the machine;
• The use of non-original spare parts and accessories;
• Failure to descale the machine or use at temperatures below 0°C.
IN THESE CASES, THE WARRANTY IS NOT VALID.
Keep these operating instructions in a safe place and make them available to anyone else who may use the coffee
machine. For further information or if you experience problems not completely or sufficiently addressed in these
instructions, please contact an Authorized Customer Service Center.
KEEP THESE INSTRUCTIONS
A WARNING TRIANGLE DRAWS ATTENTION TO ALL THE INSTRUCTIONS THAT
ARE IMPORTANT FOR USER SAFETY. PLEASE FOLLOW THESE INSTRUCTIONS
CAREFULLY TO AVOID SERIOUS INJURY!
HOW TO USE THESE OPERATING INSTRUCTIONS
GENERAL INFORMATION

4
Compartment for pre-
ground coffee
Brew group
Coffee grounds drawer
Socket for
power cord
Open button of double
coffee bean hopper
Double coffee bean hopper
Cup warming plate
Main switch
Service door
ACCESSORIES
Coffee bean hopper cover
Drip tray
Button for raising/lowering
the drip tray
TOUCH SCREEN Display
SBS
Dispensing head
Drip tray + grill and float
Compartment for milk
container
Hot water spout
Water tank
MACHINE
Ground coffee
measuring scoop
Cleaning detergent
(Brew group)
Water hardness tester
Grinder
adjustment key
Lubricant for the
brew group
Cappuccinatore
maintenance kit
Detergent for cleaning
milk container
Cappuccinatore
Intenza water filter
tf l
Milk compartment open
button

5
1 3
45
87
6
2
Press the button to open the
cover. Fill hopper “A” with coffee
beans (see page 10).
The machine automatically primes
the water circuit.
The machine is now ready for use.
Water may not be dispensed into
the glass.
This should not be considered a
malfunction.
TO ADJUST THE WATER HARDNESS LEVEL AND SET THE INTENZA AROMA SYSTEM
SEE THE «WATER HARDNESS MENU» ON PAGE 22.
Fill hopper “B” with coffee beans.
INSTALLATION
Attach the female end of the
power cord to the machine. Insert
the male end into the power
outlet.
Place a container beneath the hot
water spout.
Close the cover pushing it down
completely.
Remove the water tank.
We recommend installing the water
filter (see page 7).
Press the main switch once to turn on
the machine. The appliance
automatically performs a diagnosis of
its functions. This test is performed
each time the machine is turned on.
Make sure that the main power button is not switched to the “ON” position.
Fill the tank with fresh drinking
water. Do not exceed the “max”
level indicated on the water tank.
Once filled place the tank back
into the machine.
STARTING THE MACHINE

6
Press to select the desired
language.
The machine starts and displays
the menu in the selected
language.
See manual on page 36 to
adjust the clock.
5
Select the desired language. Press “ok”.
demo
self-test
4
If desired, the “demo” function (see page 28)
may be activated by pressing the key, each time
the machine carries out a self-diagnosis.
demo
self-test
4
italiano (ch)
language
français
deutsch
english
ok
1
italiano (ch)
language
français
deutsch
english
ok
2
italiano (ch)
language
français
deutsch
english
ok
3
1 3
Position a container under the hot
water spout (it is possible that
water will not come out of the
spout).
When the prime circuit cycle is
finished, remove the container.
The machine is now ready for
use.
INSTALLATION
SETTING THE LANGUAGE AND THE CLOCK
When the machine is switched-on for the first time, it requires the selection of the desired language.
This allows you to adjust the parameters of the beverages to the typical parameters of the country
where the machine is used. This is why some languages are differentiated also by country.
MANUAL PRIMING OF THE WATER CIRCUIT
Press the display once and the
machine will begin priming the
water circuit.
2
start
priming the machine
position the SBS system as shown
Manually prime the water circuit only when display (2) appears.
Note: first make sure that the water tank is full.
Important: before performing the circuit priming, position the SBS system (see page 9) as shown on the
display. Then adjust as desired.

7
6
9
5
Press "machine settings". Press "water filter". Press "water filter activation".
water
filter
inserted
not
inserted
water filter
activation
Place a container beneath the
hot water spout.
Press "programming menu".
show icon
explanation my custom
coffee program-
ming
menu
main-
tenance
main
menu
specials
machine
settings
clock
settings
extras
beverage
settings
energy
saving back to
coffee
menu
alerts &
acoustic
settings
machine
settings
display
language
rinsing
water
hardness
water
filter
cup
illumination
cup
warmer
go back restore default
settings
back to
menu go back restore
default
settings
back to
menu
save
settings
The machine performs the water filter initialization. Wait until the cycle stops automatically.
At the end of the initialization cycle, the machine returns to the product selection menu. Do not use the water
dispensed during this phase.
NOTE: if the Intenza water filter is not available, insert the small white filter previously removed (see
point 1) into the tank.
4
13 2
Remove the small white filter
from the tank and store it in a dry
place sheltered from dust.
Fill the tank with fresh drinking
water and reinsert it into the
machine.
Set the Intenza Aroma System:
A = Light water
B = Medium water (standard)
C = Hard water
For further details see page 22.
INTENZA WATER FILTER
To improve the quality of the water you use, and extend the life of your machine at the same time, it is
recommended that you install the water filter. After installation, go to the water filter initialization program
(see programming). In this way, the machine informs the user when the water filter must be replaced.
Remove the water filter from its packaging, immerse it vertically (with the opening facing upwards)
in cold water and gently press its sides so as to let the air bubbles out.
Insert the filter in its place within
the empty tank (see figure).
Press down until it clicks into
place.
8
7

8
• To get the desired beverage, press the corresponding symbol on the display.
The machine automatically performs all the necessary operations (see page 11).
weak medium strong
The intensity of the color on the cup icon (only valid for coffee beverages) indicates the aroma, or
quantity of coffee to be ground, for preparing the beverage. The greater the quantity of coffee
ground the stronger the coffee will taste.
DISPLAY
Go to the "text
format" menu
Beverage
programming
Accessing the
programming menu
It is possible to change the type of display and choose between " icon format" and "text format"
ICON FORMAT
long
coffee
hot
water coffee espresso
hot
milk latte macchiato espresso
macchiato
cappuccino
medium strongmedium
medium strongmedium
Go to the "icon
format" menu
TEXT FORMAT
CHOOSE COFFEE AROMA
When the machine is programmed to use pre-ground coffee or when a beverage is customized, the
icon is displayed in a different way and/or accompanied by an asterisk (see section on
“programming beverages”.)
pre-ground customization
show icon
explanation my custom
coffee program-
ming
menu show
icon my custom
coffee program-
ming
menu

9
21 3
Open the milk compartment by
pressing the button and remove
the milk container.
Remove the cover and pour in the
milk. DO NOT EXCEED THE
MAXIMUM LEVEL shown in the
fi g u r e .
Close the container and put it back
in its appropriate seat. Make sure
to carefully close the compartment.
MEDIUM
COFFEE
STRONG
COFFEE
MILD
COFFEE
SBS adjusts the intensity of the brewed coffee,
and can even be adjusted while brewing. Any
adjustment has an immediate effect on the
brewing coffee.
COFFEE INTENSITIY
SBS – SAECO BREWING SYSTEM
Height adjustable drip tray.
To raise the drip tray, press lightly on the lower part of the button. To lower the tray,
press lightly on the upper part of the button; when the desired height is reached,
release the button.
Note: There is a red floater in the drip tray. When it rises, the tray must be emptied
and washed.
ADJUSTING THE HEIGHT OF THE DRIP TRAY.
FILLING THE MILK CONTAINER
ADJUSTMENTS
The SBS system has been carefully designed to give your coffee the intense taste you desire. Simply
turn the dial and you will notice that the coffee goes from mild intensity to strong intensity.
Only the container with the cappuccinatore must be filled before preparing beverages with milk. Do not
use milk after the best-before date. (Important! Refer to the instructions for maintenance and cleaning
of the cappuccinatore on page 42).
Adjust the drip tray before dispensing any beverages.
S
C

10
THE TWO COFFEE BEAN HOPPERS CANNOT BE FILLED WITH GROUND, INSTANT OR
CARAMELISED COFFEE.
COFFEE MIXING
DOUBLE COFFEE BEAN HOPPER
The Primea Cappuccino Duo has two coffee bean hoppers which will enable you to use one single type
of coffee or mix two different types together.
Thanks to the two ceramic coffee grinders - one for each hopper - you’ll be able to use the two blends
separately.
HOPPER «A» HOPPER «B»
The machine thus enables you to prepare the perfect coffee to suit your taste!
Of course, the display will guide you in choosing the coffee bean hopper to be activated, making the
use of the machine easy and enjoyable.
HOPPER LABELS
Some pre-printed or customizable labels are supplied for the identification of each type of blend.
The label support can be easily removed to allow an easy cleaning of the containers.

11
show icon
explanation my custom
coffee
program-
ming
menu
1
A:75% B:25%
A:50% B:50%
A:25% B:75%
A:100%
B:100%
2
go
back
SELECTION OF A SINGLE BLEND OR BLEND MIX
All coffee products may be dispensed by using one single coffee blend, or by mixing the two blends
together, according to your taste.
After a coffee beverage has been selected, the machine goes to screen 2, thus enabling the user to
decide which blend to use (the blend in hopper A or B), or if the two different coffee types are to be
mixed, and in which proportion.
By way of example, we will explain - for preparing an espresso coffee - how to activate the hopper
from which the coffee has to be taken or how to create a customized mix.
In this menu you can:
my
espresso
start!
decide to only use hopper “A”
coffee (A: 100%)
decide to use 25% of hopper “A”
coffee and 75% of hopper “B”
coffee.
decide to only use hopper “B”
coffee (B: 100%)
decide to use 50% of hopper “A”
coffee and 50% of hopper “B”
coffee.
decide to use 75% of hopper “A”
coffee and 25% of hopper “B”
coffee.
To start the brewing process:
- wait 5 seconds (the machine automatically starts the brewing process) or
- press the
start! button
For how to prepare each single product, please refer to the relevant sections.
Mixing the single coffee types is also possible while programming each single beverage; for this option, please see
section “Beverage programming”
• To make 2 cups, press the beverage symbol twice.
press twice
it shows the selection of a single
or double coffee.
If nothing is changed, coffee brewing will start 5 seconds later. This process will be carried out
according to the settings shown at point 2. To make the process faster, press the
start! button.

12
13
2
1
A:75% B:25%
A:50% B:50%
A:25% B:75%
A:100%
B:100%
2
my
espresso
start!
go
back
DISPENSING COFFEE, HOT WATER AND MILK CAN BE INTERRUPTED AT ANY TIME BY
SELECTING THE "STOP ... DISPENSING" BUTTON.
Check that all the containers are clean. To do this operation, follow the instructions in the "Cleaning and
Maintenance" (see page 41).
To brew 2 cups, the machine dispenses half of the entered quantity and briefly interrupts dispensing in
order to grind the second serving of coffee. Coffee dispensing is then restarted and completed.If a milk
beverage has been chosen, the machine automatically dispenses the milk. If the first coffee is interrupted,
the second will not be dispensed.
ESPRESSO / COFFEE / LONG COFFEE
Choose the beverage and press
the corresponding icon on the
display: once for 1 cup and twice
for 2 cups.
stop
coffee
dispensing
espresso
BEVERAGE DISPENSING
This procedure shows how to dispense an espresso. To dispense another type of coffee, press the
appropriate icon. Use appropriate espresso or coffee cups so that the coffee will not overflow.
The machine ends dispensing automatically according to the quantity determined by the manufacturer. It is
possible to customize this quantity. See page 17. If you wish to interrupt the dispensing cycle, press the " stop
coffee dispensing" button.
show icon
explanation my custom
coffee program-
ming
menu
Press the hot water icon once.
HOT WATER DISPENSING
WHEN THE HOT WATER BEGINS TO DISPENSE, SHORT SPURTS OF HOT WATER MAY BE
DISPENSED WHICH POSE A RISK OF SCALDING. THE HOT WATER SPOUT CAN REACH
HIGH TEMPERATURES: AVOID TOUCHING IT WITH BARE HANDS.
Begin hot water dispensing.
To dispense another cup of
hot water, repeat this
operation.
stop
water
dispensing
hot
water
show icon
explanation my custom
coffee program-
ming
menu
The machine starts grinding the
coffee; then, it starts brewing the
selected beverage.
Wait for the machine to start the
grinding process or modify your
selection.

13
1 2 3
4 5
DISPENSING BEVERAGES WITH GROUND COFFEE
Pre-ground coffee must be poured into the appropriate compartment positioned next to the coffee bean
hopper. Pour in only coffee ground for espresso machines and never coffee beans or instant coffee. (see the
"Beverage programming" chapter on page 17).
WARNING: PUT PRE-GROUND COFFEE IN THE COMPARTMENT ONLY WHEN YOU WISH TO
DISPENSE THIS TYPE OF BEVERAGE.
INSERT ONLY ONE SCOOP OF GROUND COFFEE AT A TIME. TWO CUPS OF COFFEE CANNOT BE
DISPENSED AT THE SAME TIME.
Press the appropriate button and
the display will show:
A message appears, reminding
the user ground coffee in the
appropriate compartment.
add preground
coffee
start!
go
back
Press the "start! "button to start
dispensing.
Pour ground coffee into the pre-
ground coffee compartment using
the measuring scoop provided
with the accessories.
add preground
coffee
start!
go
back
Begins dispensing the selected
beverage.
long
coffee
stop
coffee
dispensing
Note:
• After 1 minute from when the message appears (2), if brewing has not started the machine will return to
the main menu and dump any inserted coffee into the coffee grounds drawer.
• If no pre-ground coffee is poured into the compartment, only water will be dispensed.
• If 2 or more scoops of coffee are added, the machine will not dispense the beverage and the coffee in the
compartment will be dumped into the coffee grounds drawer.
In the example given below, we chose to dispense a long coffee using pre-ground coffee.
The customized choice of using pre-ground coffee is shown on the display with an asterisk next to the
chosen beverage.
show icon
explanation my custom
coffee program-
ming
menu

14
3
7 8
1
9
4
refill the milk container or
stop milk dispensing
If there is no milk left, the
following message will appear;
choose the option 5 or 6.
stop
milk
dispensing
5 6
refill the milk container or
stop milk dispensing
.... press the button; in both cases,
the brewing process will
automatically be completed.
stop
milk
dispensing
To continue, fill the milk
container or .....
A:75% B:25%
A:50% B:50%
A:25% B:75%
A:100%
B:100%
2
Wait for the machine to start the
grinding process or modify your
selection.
my latte
macchiato
start!
go
back
BEVERAGE DISPENSING
latte
macchiato
latte
macchiato latte macchiato
Select the beverage and press the
corresponding icon on the display:
once for 1 cup and twice for 2
cups.
When the coffee finishes grinding,
the machine will automatically
dispense the programmed quantity
of hot milk.
Once milk has been dispensed, the
machine automatically prepares the
coffee.
After this, the machine allows you to
dispense more milk if you wish.
This option remains active for
approximately 2 seconds. To activate,
press the “add milk” button.
The “milk rinsing” icon will flash
once the machine is done
dispensing in order to clean the
milk circuit. Press the “milk
rinsing” icon to clean the internal
milk circuit.
stop
milk
dispensing
add
milk
milk
rinsing
Fill the milk container
LATTE MACCHIATO
show icon
explanation my custom
coffee
program-
ming
menu
show icon
explanation my custom
coffee
program-
ming
menu
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
SEE INSTRUCTIONS ON PAGE 42 FOR OPTIMAL MILK DISPENSING
THE DISPENSED MILK CAN REACH HIGH TEMPERATURES: THERE IS A DANGER OF
SCALDING. DO NOT TOUCH IT WITH BARE HANDS.
THE MILK USED MUST HAVE BEEN PROPERLY PRESERVED.
DO NOT USE IT AFTER THE EXPIRATION DATE ON THE PACKAGE.
WHEN YOU HAVE FINISHED PREPARING BEVERAGES CONTAINING MILK, PROCEED WITH
CLEANING THE CONTAINER AND THE MACHINE'S CIRCUIT.

15
12
start
rinsing
milk rinsing cycle
To perform a rinse cycle, press
“start rinse cycle”.
11
rinsing...
rinsing milk circuit-
please wait
Wait for the cycle to be completed.
After this, the machine returns to
the main menu.
Remove the container and put it
in the refrigerator if it contains
remaining milk.
If the user wishes to continue preparing other drinks the
machine will keep the “milk rinsing” signal active.
After 20 minutes of inactivity, the machine requires the user
to perform a rinsing cycle as described in Step 9. If the
machine is turned off immediately after dispensing a milk
beverage, the next time the machine is turned on it will
require the user to perform a rinsing cycle.
Note: Before performing the “milk rinsing” function make
sure that:
1. an adequate sized container is placed under the
dispensing head
2. the water tank is full of fresh water.
10
THIS PROCEDURE MUST BE PERFORMED FOR ALL MILK PRODUCTS!
AFTER USE, ALWAYS REMOVE THE MILK CONTAINER AND PUT IT IN THE REFRIGERATOR IF IT
CONTAINS REMAINING MILK.
THE CONTAINER MAY BE LEFT IN THE MACHINE ONLY IF IT HAS BEEN WASHED WITH
DRINKING WATER AND IT DOES NOT CONTAIN MILK (SEE PAGE 42).
After performing the rinse cycle, the machine reminds the user to
remove the container with the remaining milk through the message
“remove milk”.
REMOVE THE MILK CONTAINER ONLY WHEN THE MACHINE IS ON.
milk
cleaning
show icon
explanation my custom
coffee
program-
ming
menu
After 14 days from the first dispensing of a
milk-based beverage, the message “milk
cleaning” is displayed; it is advisable to
clean the milk circuits as shown on page 30.
After another 7 days the machine stops
dispensing milk-based beverages and the
milk circuits must be washed; during this
phase, coffee and hot water may be brewed.
remove
milk
show icon
explanation my custom
coffee
program-
ming
menu

16
31
45
3
4 5
1
A:75% B:25%
A:50% B:50%
A:25% B:75%
A:100%
B:100%
2
my
cappuccino
start!
go
back
Wait for the machine to start the
grinding process or modify your
selection.
BEVERAGE DISPENSING
espresso
macchiato
espresso
macchiato
cappuccino
cappuccino
cappuccino
ESPRESSO MACCHIATO
Press the icon once for 1 cup and
twice for 2 cups.
Once the coffee has been brewed,
the machine automatically prepares
the hot milk.
CAPPUCCINO
Press the icon once for 1 cup and
twice for 2 cups.
After this, the machine allows you to dispense more milk if you wish.
Press the “add milk” button within 2 seconds.
Fill the milk container
Fill the milk container
When the "milk rinsing"
symbol flashes, clean the
milk circuits as described for
latte macchiato (see page 14,
Step 9).
When the "milk rinsing"
symbol flashes, clean the
milk circuits as described for
latte macchiato (see page 14,
Step 9).
When the coffee finishes grinding,
the machine will dispense the
programmed quantity of hot milk.
Once milk has been dispensed, the
machine automatically prepares the
coffee.
add
milk
To dispense more milk, press the
“add milk” icon.
espresso
macchiato
show icon
explanation my custom
coffee
program-
ming
menu
show icon
explanation my custom
coffee
program-
ming
menu
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing
stop
milk
dispensing
stop
coffee
dispensing add
milk
A:75% B:25%
A:50% B:50%
A:25% B:75%
A:100%
B:100%
2
Wait for the machine to start the
grinding process or modify your
selection.
When the coffee grinder has
finished grinding, the machine
starts brewing the espresso
macchiato.
my espresso
macchiato
start!
go
back

17
1
2
1
BEVERAGE PROGRAMMING
BEVERAGE PROGRAMMING MENU
Hold down the beverage button for
two seconds Press the button "my coffee" and
within two seconds, press the
beverage button
Each beverage can be programmed according to your individual taste. Customization is shown on the
display with the addition of an asterisk.
To program the desired beverage:
or
ESPRESSO / COFFEE / LONG COFFEE PROGRAM
Enter the menu of the beverage to
be customized by pressing and
holding the button for 2 seconds.
Once a beverage has been
customized it will only
dispense that type of
beverage. To change or
modify the beverage a new
customization must be
done.
show icon
explanation my custom
coffee
program-
ming
menu show icon
explanation my custom
coffee
program-
ming
menu
show icon
explanation my custom
coffee
program-
ming
menu
A:75%
B:25%
In this menu you can:
select the use of
pre-ground coffee
save settingsrestore factory settings
return to the
previous
window
select the
quantity of coffee
to be ground
(opti-dose)
select the blend to
be used or mix the
two blends in the
hoppers.
hot
milk
DISPENSING HOT MILK
Press the hot milk icon once. The hot milk is dispensed.
Fill the milk container
To dispense another cup of milk,
repeat this operation. When the
"milk rinsing" symbol flashes,
clean the milk circuits as
described for latte macchiato
(see page 14, Step 9).
show icon
explanation my custom
coffee
program-
ming
menu
stop
milk
dispensing
strong preground
my
espresso
medium
light
start!
go
back save
settings
restore
settings
2

18
A:75%
B:25%
1
5
6 7
A:75%
B:25%
select the blend
to be used (see
page 17)
BEVERAGE PROGRAMMING
To brew an amount of coffee greater
than that preset by the
manufacturer, press “custom
coffee amount” before the end of
the brew cycle in progress. When
the quantity is reached,
press “stop coffee dispensing”.
Pressing start! allows the
machine to brew coffee.
The machine automatically starts and
finishes brewing the coffee, according to
the standard settings.
The brew cycle may be
interrupted only by pressing
“stop coffee dispensing”.
If the button is not pressed,
the coffee can overflow in
the cup.
Once the brew cycle finishes,
press "save settings" within five
seconds.
If the "save settings" button
is not pressed the machine
returns to the main menu
and the customized settings
will not be saved.
saved!
The display shows the confirmation of
the memorized settings, and the
machine automatically returns to the
main menu.
PROGRAMMING MILK BEVERAGES
Enter the menu of the beverage
to be customized; press and hold
the button for 2 seconds.
In this menu you can:
select the
quantity of
coffee to be
ground. select the use
of pre-ground
coffee.
save settings.restore factory settings.
return to the
previous
window.
my
espresso
custom
coffee
amount
my
espresso
my
espresso
my latte
macchiato
Fill the milk tank
After pressing the start!
button, the brew cycle will
start.
my
espresso
my
espresso
show icon
explanation my custom
coffee
program-
ming
menu go
back save
settings
restore
settings
strong preground
medium
light
start!
go
back save
settings
restore
settings
strong preground
medium
light
start!
stop
coffee
dispensing
custom
coffee
amount
stop
coffee
dispensing
save
settings
go
back
3 4
2
