Safavieh Lighting SUTTON LIT4218A User manual

PIECE DESCRIPTION PICTURE
QUANTITY
PIECE DESCRIPTION PICTURE QUANTITY
A
mounting
bracket
1X G chain 1X
B machine screw 2X H fixture loop 1X
Cmounting
screw 1X I ring nut 1X
D wire nut 3X J screwed ball 2X
E collar loop 1X K bulb 6X
F canopy 1X
Part List and Hardware List
CARE AND MAINTENANCE
To clean the outside of the fixture, use a dry or slightly dampened clean cloth (use clean water, never a
solvent) to wipe the surface of the fixture.
To clean the inside of the fixture, first disconnect power to the fixture by turning off the circuit breaker or by
removing the fuse at the fuse box. Next, use a dry or slightly dampened clean cloth (use clean water, never a
solvent) to wipe the interior surface of the fixture.
Do not use any cleaners with chemical, solvents or harsh abrasives. Use only a dry soft cloth to dust or wipe
carefully.
NOTICE& IMPORTANT SAFETY INSTRUCTIONS
Model#: LIT4218A
Product Dimensions: 17"D X 98.5"H
* Please make sure that you have all parts indicated before you begin assembly of this item
* This item should be assembled on a soft surface to prevent scratching the finish during assembly
* To reduce the risk of fire, electrical shock or injury to persons or property, please follow the guideline below
for safe use and installation
*The external flexible cable or cord of this luminaire cannot be replaced
If the cord is damaged, the luminaire shall be destroyed

1. Fix the mounting bracket (A) to the outlet box with machine screw (B).
2. Make wire connections, with wire connectors (D), following the reference chart listed below.
*Note: When parallel wire (SPT I & SPT II) is used. The neutral wire is square shaped
and ridged and the hot wire willbe round in shape and smooth. (See Illustration on left.)
Grounding Instructions:
a) For installation in the United States: Wrap ground wire from outlet box around green
ground screw on mounting bracket, no less than 2" from wire end. Tighten ground screw. If
fixture is supplied with a ground wire, connect to outlet ground wire with a wire connector.
b) For installation in Canada: If fixture is supplied with ground wire, wrap ground wire
around green grounding screw on mounting bracket. Tighten ground screw.
3. Raise the canopy (F) to the ceiling and then secure it by fixing the collar loop (E) to the mounting screw (C ).
4. Check to insure the wires go through the chains (G). Fix the fixture loop (H) to the ring nut (I).
5. Use the screwed balls (J) to fix the glass shade to the arms.
6. Install bulbs (K). Be sure to use light bulb (K) with wattage no greater than specified on this
fixture. Always make sure that electrical current is turned off before changing bulbs.
ENJOY YOUR LAMP
Connect, Hot, Black or Red Outlet SupplyWire to:
Connect, Neutral, White Outlet Supply Wire to:
Black
White
* Parallel Cord (round & smooth)
Insulated Wire (not green) with copper metal conductor
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
Estimated Assembly Time: 20 minutes.
Clear, Brown, Gold or Black without Tracer (colored stripes)
Clear, Brown, Gold or Black with Tracer (colored stripes)
Insulated Wire (not green) with Silver metal conductor.
* Parallel Cord (square & ridged)
