Safe S31IP User manual

Indoor phone Safe S31IP SIP
(mod.C313)

About This Manual
Thank you for choosing Safe S31IP mod.C313 indoor monitor. This manual is intended for end users, who need to use and
configure the indoor monitor. It provides an overview of the most essential functions and features of the product, whose firmware
version is 113.241.4.4.
Contact us
For more information about the product, please visit us at www.safeautomation.pl or feel free to contact us by
Sales email: [email protected]
Technical support email: [email protected]
We highly appreciate your feedback about our products.

Content
1. Product overview............................................................................................................................................................................................... 1
1.1. Product Description................................................................................................................................................................................... 1
1.2. Power connection...................................................................................................................................................................................... 2
2. Daily use............................................................................................................................................................................................................... 3
2.1. Making a call............................................................................................................................................................................................... 3
2.1.1. Calling from digital keypad............................................................................................................................................................. 3
2.1.2. Calling from phonebook..................................................................................................................................................................4
2.1.3. Calling resident................................................................................................................................................................................ 4
2.1.4. Calling from call log......................................................................................................................................................................... 5
2.1.5. Calling doorphone........................................................................................................................................................................... 6
2.2. Receiving a call.......................................................................................................................................................................................... 6
2.2.1. Receive a incoming call.................................................................................................................................................................. 6
2.2.2. during the session........................................................................................................................................................................... 6
2.3. Contact........................................................................................................................................................................................................ 7
2.3.1. Local Phonebook............................................................................................................................................................................. 7
2.3.1.1. Add a group............................................................................................................................................................................ 8
2.3.1.2. Manage Contact.................................................................................................................................................................... 8
2.3.1.3. Add a contact......................................................................................................................................................................... 9
2.4. Status.........................................................................................................................................................................................................10

2.4.1. Basic Status................................................................................................................................................................................... 10
2.4.2. Network Status............................................................................................................................................................................... 11
2.4.3. Account Status............................................................................................................................................................................... 11
2.5. Live view....................................................................................................................................................................................................12
2.5.1. Door Phone.................................................................................................................................................................................... 12
2.5.2. Web Camera.................................................................................................................................................................................. 13
2.5.3. Onvif................................................................................................................................................................................................ 13
2.6. Message(s)............................................................................................................................................................................................... 14
2.6.1. Text Message................................................................................................................................................................................. 14
2.6.2. Create message............................................................................................................................................................................ 15
2.6.3. Maintenance...................................................................................................................................................................................15
2.6.4. Capture Log....................................................................................................................................................................................16
2.7. Arming........................................................................................................................................................................................................17
2.7.1. Arming Mode.................................................................................................................................................................................. 17
2.7.2. Disarm Code.................................................................................................................................................................................. 18
2.7.3. Alarm Log........................................................................................................................................................................................19
2.7.4. Status.............................................................................................................................................................................................. 19
3. Settings...............................................................................................................................................................................................................20
3.1. Display settings........................................................................................................................................................................................ 20
3.2. Sound settings..........................................................................................................................................................................................21

3.3. Time settings............................................................................................................................................................................................ 22
3.4. DND(Do Not Disturb) Settings............................................................................................................................................................... 23
3.5. Language.................................................................................................................................................................................................. 24
3.6. Album......................................................................................................................................................................................................... 24
3.7. Reboot....................................................................................................................................................................................................... 25
3.8. Screen clean.............................................................................................................................................................................................25
4. Advance Settings............................................................................................................................................................................................. 26
4.1. Network Settings......................................................................................................................................................................................26
4.2. SOS Settings............................................................................................................................................................................................ 27
4.3. Account Settings...................................................................................................................................................................................... 27
4.4. Direct IP.....................................................................................................................................................................................................29
4.5. Zone settings............................................................................................................................................................................................ 29
4.6. 4.6 Password setting............................................................................................................................................................................... 31
4.7. Door station.............................................................................................................................................................................................. 31
4.8. Reset..........................................................................................................................................................................................................33
5. Website............................................................................................................................................................................................................... 34
5.1. Status-Basic..............................................................................................................................................................................................35
5.1.1. Product Information.......................................................................................................................................................................35
5.1.2. Network Information...................................................................................................................................................................... 35
5.1.3. Account Information...................................................................................................................................................................... 36

5.2. Account-Basic...........................................................................................................................................................................................36
5.2.1. SIP Account.................................................................................................................................................................................... 36
5.2.2. SIP Sever 1.................................................................................................................................................................................... 37
5.3. Account-Advanced...................................................................................................................................................................................37
5.3.1. 5.3.1 SIP Account.......................................................................................................................................................................... 37
5.3.2. Call...................................................................................................................................................................................................37
5.3.3. Audio Codecs................................................................................................................................................................................. 38
5.3.4. Video Codecs.................................................................................................................................................................................38
5.3.5. Encryption.......................................................................................................................................................................................38
5.3.6. NAT.................................................................................................................................................................................................. 38
5.4. Network-Basic.......................................................................................................................................................................................... 39
5.5. Phone-Time/Lang.................................................................................................................................................................................... 39
5.5.1. Web Language...............................................................................................................................................................................39
5.5.2. LCD Language...............................................................................................................................................................................40
5.5.3. Format Setting............................................................................................................................................................................... 40
5.5.4. Type................................................................................................................................................................................................. 40
5.5.5. NTP..................................................................................................................................................................................................41
5.5.6. Daylight Saving Time.................................................................................................................................................................... 41
5.6. Phone-Call Feature................................................................................................................................................................................. 42
5.6.1. Forward Transfer........................................................................................................................................................................... 42

5.6.2. DND(Do Not Disturb).................................................................................................................................................................... 43
5.6.3. Open Lobby.................................................................................................................................................................................... 43
5.6.4. Open Local Door........................................................................................................................................................................... 43
5.7. Phone-Key/Display.................................................................................................................................................................................. 44
5.7.1. Display.............................................................................................................................................................................................44
5.8. Phone-Ringtones..................................................................................................................................................................................... 44
5.8.1. All Ringtones.................................................................................................................................................................................. 44
5.9. Phone-Intercom........................................................................................................................................................................................45
5.9.1. SOS................................................................................................................................................................................................. 45
5.10. Phone-Monitor........................................................................................................................................................................................46
5.10.1. DoorPhone................................................................................................................................................................................... 46
5.10.2. Web Camera................................................................................................................................................................................ 47
5.11. Phone-Addressbook..............................................................................................................................................................................48
5.11.1. Contact.......................................................................................................................................................................................... 48
5.11.2. Search........................................................................................................................................................................................... 48
5.11.3. Contact Setting............................................................................................................................................................................ 48
5.11.4. Group.............................................................................................................................................................................................49
5.11.5. Group Setting............................................................................................................................................................................... 49
5.11.6. Import/Export................................................................................................................................................................................49
5.12. Upgrade-Basic....................................................................................................................................................................................... 50

5.12.1. Upgrade-Basic............................................................................................................................................................................. 50
5.13. Upgrade-Advanced............................................................................................................................................................................... 51
5.13.1. PNP Option.................................................................................................................................................................................. 51
5.13.2. Manual Autop............................................................................................................................................................................... 51
5.13.3. Automatic AutoP.......................................................................................................................................................................... 52
5.13.4. System Log.................................................................................................................................................................................. 52
5.13.5. PCAP.............................................................................................................................................................................................53
5.13.6. Capture Log................................................................................................................................................................................. 53
5.13.7. Screenshots................................................................................................................................................................................. 54
5.13.8. Others........................................................................................................................................................................................... 54
5.14. Arming-Zone Setting............................................................................................................................................................................. 54
5.14.1. Zone Setting.................................................................................................................................................................................54
5.15. Arming-Arming Mode............................................................................................................................................................................ 55
5.15.1. Arming Mode................................................................................................................................................................................ 55
5.15.2. Home/Sleeping/Away................................................................................................................................................................. 56
5.16. Arming-Disarm Code.............................................................................................................................................................................57
5.16.1. Disarm Code................................................................................................................................................................................ 57
5.17. Security-Basic........................................................................................................................................................................................ 57
5.17.1. Web Password Modify................................................................................................................................................................57
5.17.2. Session Time Out........................................................................................................................................................................ 58

1
1.Product overview
1 . 1 . Product D e s c r i p t i o n
S 3 1 I P i s aLinux-based IPindoor monitorw i t h atouchscreen. It
incorporates audio communications, accesscontrol sensor armingand
obtainvideo stream fromdoor phone orIPC.
Its finely-tunedLinux OSallowsforbettersuit thehabitofusageofl o c a l
people. Powered byi t , S31IP multipleports, such asI/O and Bellports,
can beusedtoeasilyi n t e g r a t e externalArmingsystems, such asbell
controller and firealarmdetector,helpingcreate a holisticcontrol of
homesafety andaccesscontrol and g i v i n g occupants ag r e a t sense
ofsecurity.
Iti s applicabletomulti-storeyr e s i d e n t i a l buildings or villas.

2
1 . 2 . Power c o n n e c t i o n
TheS 3 1 I P i s powered bysimply connecting thetwow i r e s ofthepower
adapter tothew i r i n g i n t e r f a c e onthebackoftheindoor monitor.
S31IP also support POE(Power OverEthernet).
1 1 P I N connector
Forpower supply,RS485,B e l l a n d Relayconnector.
1 0 P I N connector
For8securityconnector
E t h e r n e t 1
Network port with P O E ( P o w e r o v e r E t h e r n e t ) , c a n b e
connectedto ah u b , switcho r o t h e r n e t w o r k a c c e s s
d e v i c e s .
E t h e r n e t 2
S h a r e the n e t w o r k a c c e s s fromE t h e r n e t 1 port, a n d for
P C a n d o t h e r e q u i p m e n t connection.

3
2. Daily use
2.1. Making a call
There are two ways to make a call from the indoor monitor to other units,
which can be another indoor monitor or an intercom app.
2.1.1. Calling from digital keypad
①Tap the icon to enter the call interface.
②Enter the number to call on the digital keypad,
③Choose a account for this outgoing call.
④Tap the dial key, you can choose audio call or video call to dial out.

4
2.1.2.Calling f r o m p h o n e b o o k
⑤Tapthei c o n toenter thephonebook.
⑥Ortapthisi c o n toenter thephonebook.
⑦Afterchoosing g r o u p , t o search thel i s t by number or alphabet.
S 3 1 I P supports fuzzymatchingq u e r y .
⑧Scroll upordownthepre-imported contact l i s t .
⑨Tapthedialkey nexttothecontact found.
2.1.3.Calling resident
①Pressthei c o n toenter thecall r e s i d e n t i n t e r f a c e .
②Enter ther o o m number you w a n t tocall, forexample,i f you w a n t to
call the community1,Building 1,U n i t 1,Floor 1,Room1;enter
001001010101,and then③press dialkey. Y o u can choose theaudio
call orv i d e o call.

5
2.1.4. Calling from call log
④Press the icon to enter the call log interface.
⑤You can also choose the icon in intercom interface to check call
log.⑥Choose a log.
⑦Choose audio or video call to dial out.
⑧Press the icon to delete the selected call log.
⑨Press the icon to delete all of the call log.
⑩Press the icon to check exact information of the selected call log.

6
2.1.5. Calling doorphone
①Press to make a call out, if you want to call doorphone unit.
2.2. Receiving a call
2.2.1. Receive a incoming call
①There will be a video preview in this window, when you receive a
incoming call.
②Press this icon to pick up the incoming call as an audio call.
③Press this icon to pick up the incoming call as a video call.
④Press this icon to reject the incoming call.
⑤Press this icon to adjust the ring tone volume.
2.2.2. During the session
①The call video will be showed in this window.

7
Notes: For cloud contact, it needs S31IP to work with
Akuvox cloud server. Then cloud server will assign
contacts automatically. For more information, please
contact with your administrator.
②To adjust the volume here.
③Press this icon to dial out another number.
④Press this icon to hold the current call.
⑤Press this icon to capture the video.
⑥Press this icon to unlock the corresponding door
phone(if the call is from door phone)
⑦Press this icon to hang up the current call.
2.3. Contact
2.3.1.Local Phonebook
①Press the icon to create a new group.
②Press the icon to delete the groups you want to delete.
③Press the icon to modify the corresponding group.

8
2.3.1.1. Add a group
Enter the phone book interface, you can
①Press the icon to add a group.
②Type in the group name.
③Choose a ring tone for this group.
④Press this icon to save the group.
⑤Press the icon to cancel the operations.
2.3.1.2. Manage Contact
Enter the contacts interface, ⑥select a contact.
⑦Press the icon to check the exact information of selected contact, you
can also modify it in contact info interface.
⑧Press this icon to delete the selected contact.
⑨Press this icon to clear all contacts.
⑩Press this icon to create a new contact.

9
2.3.1.3. Add a contact
①Select a group, to check the contacts in this group.
②Press the icon to add a contact.
③Type in the contact name.
④Type in the number 1, it must be a room number.
⑤Type in the number 2, it can be a SIP number or IP number.
⑥Select a specific ring tone for this contact.
⑦Select a group for this contact
⑧Press this icon to save the contact.
⑨Press this icon to cancel the operations.

10
2 . 4 . Status
2.4.1.Basic Status
Tocheck S 3 1 I P status by①pressing thisi c o n .
Afterenteringthestatus i n t e r f a c e , i t shows thebasicstatus asdefault.
You can check theM o d e l , H a r d w a r e version, Firmware version, M a c
Address and IPAddress i n f o r m a t i o n and so on.

11
2.4.2. Network Status
②Press the icon to check the network status.You can check the LAN
type, LAN IP, subnet mask, gateway and DNS here.
2.4.3. Account Status
③Press the icon to check the account status.You can check the
account number and status here, registered means it works normally.

12
2.5. Live view
①Press the icon to receive the video from indoor IPC or community IPC
any time.
2.5.1. Door Phone
②By entering the monitor interface, it is door phone list by default.You
can receive video from predefined doorphone station which you set
under the path"Setting-Advance- Door Station".
