SafeTrust 8845-000 User manual

8845-000 Quickstart Guide
Last Updated: January 18, 2024

Contents
Safetrust Inc. | safetrust.com
[e-mail]
In the box
What you'll need
Installation
Configuration
Testing
Regulatory
Support
01
02
03
04
05
06
07

01
Safetrust Inc. | safetrust.com
[e-mail]
In the box

Safetrust Inc. | safetrust.com
[e-mail]
#6 x 1.5” Phillips
sheetmetal screws
For mounting wall bracket
#6-32 x .375” Phillips
flat head screw
Secures the IoT Sensor and
the backplate together
Nylon wall plugs
Used to brace the screws
inside the wall

Safetrust Inc. | safetrust.com
[e-mail]
Mounting Plate

02
Safetrust Inc. | safetrust.com
[e-mail]
What you'll need

Safetrust Inc. | safetrust.com
[e-mail]
Power requirements: 12 Volts DC +/- 5% and 250mA at the endpoint (IoT Sensor)
is required.
We advise not only selection of the right gauge and power quality, but integrators
should confirm the power delivery is sufficient by checking power at the endpoints.
If existing cable is of higher gauge / lower capacity and cannot be replaced,
Safetrust sensors are designed to operate at up to 24VDC.*
As a result, higher voltage at the power source is safe to use with IoT Sensors if
the source and wiring implementation can safely support it and if it is compliant
with local code.
Cable Installation Note
* Safetrust recommends against using the same 24V power supply for both locks and IoT Sensors.

Safetrust Inc. | safetrust.com
[e-mail]
Power cable:
18/2 for distances < 500 ft.
16/2 for distances < 700 ft.
For distances up to 1000’, see Cable Installation Note above.
Data cable - Wiegand:
Cable, 5-12 conductor, 4 conductor Twisted Pair Over-All Shield and UL
approved (<500ft)
Data cable - OSDP:
Belden 6381MD - 1Pr 24AWG Shielded Data + 18/2 Power OSDP CMP or
equivalent (<500Ft)
Belden 6281MD - 1Pr 22AWG Shielded Data + 16/2 Power OSDP CMP or
equivalent (<700Ft)
Tools and Supplies:
Drill with various bits for mounting hardware
Additional tools and supplies as needed to connect sensor wires to associated
system cable

03
Safetrust Inc. | safetrust.com
[e-mail]
Installation

For a wall mounted installation, begin by pre-drilling your holes and insert the nylon
wall plugs provided to support the weight of the reader. Once secured, you can fix
the backplate to the wall using the Phillips sheetmetal screws (#6 x 1.5”) provided.
Safetrust Inc. | safetrust.com
[e-mail]

Safetrust Inc. | safetrust.com
[e-mail]
The next step is to connect the wires as per the wiring table above.
Ground
Relay In*
Relay Out*
Red LED
Tamper
Green LED
Wiegand D0/Data
Wiegand D1/Clock/F2F
12VDC
OSDP TX+ / RS-485(A) / D0
OSDP TX+ / RS-485(B) / D1
Beeper
Black
Grey
Blue
Brown
Purple
Orange
Green
White
Red
Aqua
Pink
Yellow
Wire Colors
*Low voltage

Safetrust Inc. | safetrust.com
[e-mail]
Once the backplate has been fitted and the wiring is complete, the IoT Sensor can
be mounted to the wall as shown above.

Safetrust Inc. | safetrust.com
[e-mail]
Complete the hardware installation by fixing the screw (#6-32 x .375” Phillips
flat head screw) through the base of the reader.

04
Safetrust Inc. | safetrust.com
[e-mail]
Configuration

Safetrust Inc. | safetrust.com
[e-mail]
Open the Safetrust Wallet App and select the Manage Sensor tab from the
navigation. Make sure your system administrator has set you up with a role that
has rights to configure a sensor.

Safetrust Inc. | safetrust.com
[e-mail]
With the Manage Sensor tab open, bring the phone in range of the IoT Sensor and
once visible from the App, highlight and select the “Configure” button.
SABRE–A1F5

Safetrust Inc. | safetrust.com
[e-mail]
Choose an Identity System*.1.
Specify the Type of access from the dropdown (eg. Door, Gate etc.) 2.
Assign a short Name and Description using alphanumeric characters.3.
Choose a Media Output for the sensor (the default is set to Wiegand).4.
*Note: Identity System must be previously created in the Safetrust Credential Manager
portal by a system administrator.

Safetrust Inc. | safetrust.com
[e-mail]
When the IoT Sensor information is saved successfully to Credential Manager and
assigned to the Identity System, the new name will appear in the Manage Sensor
tab with a unique serial number assigned.

05
Safetrust Inc. | safetrust.com
[e-mail]
Testing

Safetrust Inc. | safetrust.com
[e-mail]
LED Ring
Status LED
Solid red
Indicates idle mode
Flashing red, blue, green
Power up mode
Flashing green
Card credential is read
and transmitted
through designated
wires
Access with cards
