Safety Switches HLM User manual

Safety Limit Switches
4. Always ensure that when running electrical conductors that they are routed correctly and no damage can occur to the cable insulation.
5. Always use M5 mounting bolts and ensure 2Nm tightening torque for robust fitting.
Maintenance:
Every Wee : Chec switch actuator and body for signs of mechanical damage and wear. Replace any switch showing damage.
Every 6 Months: Isolate power and remove cover. Chec screw terminal tightness and chec for signs of moisture ingress. Never attempt to repair any switch.
Incorrect Incorrect Correct
APPLICATION:
IDEM Limit switches are designed to be mounted for position sensing of moving applications e.g. guard doors, conveyors, machine beds, elevators etc.
They are available with linear plungers, rotary levers or roller plungers and either slow or snap action contacts. All contact bloc s are positively operated to satisfy IEC 60947-5-1.
Operation:
Operation of the switches is achieved by a sliding actuation of the moving object to cause deflection of the switch plungers or levers.
For Safety applications it is important that the moving object does not pass completely over the switch actuators so as to cause the actuator to return to its original position.
Installation Guide: Correct Mountin of Limit Switches is critical to obtain optimum performance and ensure safety reliability.
Installation of all switches must be in accordance with a ris assessment for the individual application.
Installation must only be carried out by competent personnel and in accordance with these instructions.
1. Never use the switch as a mechanical stop. Ensure that the actuator is protected from mechanical shoc .
2. For switches with Linear actuators the actuating direction and force from the moving object should be applied in line with the axis of the plunger.
3. For switches with Rotary actuators or rollers the operating cam from the moving object should be designed such that the switch is never operated beyond its over travel position.
Always use a 30 degree tapered actuating cam.
Contact Block Options:
HLM
-
SS (Stainless Steel)
IP69K
HLM (Die
-
Cast) IP67
3NC 1NO 2NC 2NO
4NC
HLM HLM-SS Operatin Instructions
Correct
1NC 1NO
(Snap Action)

Safety Limit Switches
Safety Limit Switches HLM

Safety Limit Switches
Safety Limit Switches HLM-SS

Safety Limit Switches
Mechanical Reliability B10d 2.5 x
10
6
operations at 100mA load
EN 954-1
Up to Category 4 with Safety Relay
ISO 13849-1
Up to PLe depending upon system architecture
EN 60261 U
p to SIL3 depending upon system architecture
Safety Data – Annual Usage
8
cycles per hour / 24 hours per day / 365 days
PFHd
3.44 x 10
-8
Proof Test Interval (Life)
35 years
MTTFd
356 years
Conforming to standards
EN1088 IEC 947
-
5
-
1 UL508 EN50041
Positive Opening Operation
NC Contact
s
Utilization Category
AC15
A300
240V. 3A.
Min Current
5V, 5mA, DC
Thermal Current (Ith)
10A
Rated Impulse Withstand Volt
2500VAC
Case Material
HLM (Die Cast Painted Red) HLM
-
SS (Stainless Steel 316)
Enclosure Protection
HLM IP67
HLM
-
SS IP67 / IP69K
Operating Temperature
Min.
-
25°C Max 80°C
Mechanical Life Expectancy
5 x 10
6
Cycle min.
Vibration
IEC 68
-
2
-
6, 10
-
55Hz 0.35mm
Conductor size
1.5 sq.mm
Fixing
M5 Bolts
Quic Connect (QC)
M23 12 Way Male
(connector length 26mm)
(Pin View from Switch)
Switch Circuit
1 3
11 / 12
4 6
21 / 22
7 8
33 /34 or 31 / 32
9 10
41 / 42 or 43 / 44
12
Earth
Technical Specification:
IDEM SAFETY SWITCHES Ltd., 2 Ormside Close, Hindley Industrial Estate, Hindley Green, Wi an, WN2 4HR UK. Tel: [phone] Fax.: [phone]
IDEM (USA) 4416 Technolo y Drive, Fremont, CA 94538 Tel:[phone] Fax: [phone] email: [e-mail] Web: www.idemsafety.com
Doc: 102534
Dec. 2013
Safety Classification and Reliability Data:
Wirin circuits for Explosion Proof Versions:
1 NC 1 NO
2 NC 2 NO
2 NC
Pre
-
Wired Explosion Proof
:
Quick Connect Version:
